System Setup Procedures

Summary of Steps
1) Install receiver batteries and select the battery type in the setup screen
or connect power.
2) Select frequency step size in the receiver.
3) Select the compatibility mode in the receiver.
4) Find a clear operating frequency (two methods).
5) Set up transmitter to matching frequency and compatibility mode.
6) Adjust transmitter input gain.
7) Adjust receiver audio output level to match recorder, camera, mixer, etc.
1) Install Receiver Batteries
Install the batteries according to the polarity marked on the back of the hous-
ing and select the correct battery type in the menu. Check the BATT LED on
the control panel to verify adequate power is present - the LED should glow
green. Select the type of batteries being used in the RX Battery setup screen.
2) Select Frequency Step Size
Navigate to Step Size in the LCD menu and select 100 kHz or 25 kHz as
needed to match the associated transmitter.
3) Select Receiver Compatibility Mode
Navigate to Compat.Mode on the menu and press MENU/SEL to enter the
setup screen. The optional modes will appear one at a time. Use the UP and
DOWN arrow buttons to scroll through the list. When the desired mode ap-
pears in the screen, press MENU/SEL or BACK to select the mode and return
to the previous menu. Press BACK to return to the Main Window.
Transmitter Models
US Digital Hybrid
Wireless
®
Mode 3*
200 Series
100 Series
Euro Digital Hy-
brid Wireless®
300 Series:
Mode 7*
Mode 6*
IFB Series
NA Dig. Hybrid is the best mode to use when both transmitter and receiver
are Digital Hybrid Wireless models. This compandor-free, wide deviation
mode produces the best audio quality.
6
LCD menu item
NA Dig. Hybrid
Mode 3
200 Series
100 Series
EU Dig. Hybrid
300 Series
Mode 7
Mode 6
IFB
