Large slotted screwdriver Small screwdriver Monday through Friday Between 8:00 a.m. and 5:00 p.m. CST Vehicle sealant (optional) Small pry bar Or through the Muth web site Gopher wire Electrical tape www.muthco.com Wire crimper and stripper Needle nose pliers Or via E-mail: techsupport@muthco.com...
Door Panel Removal 1. Open the driver’s side door and lower the window. Use a Philips screwdriver to remove the (2) screws located on the bottom of the door panel (A & B). 2. Remove the screw located on the inside corner of the door.
Page 4
Door Panel Removal Continued 6. Lift the door panel off of the door and hold it a few inches away from the door. Disconnect the wires that run from the mirror to the door panel control. Remove door panel. Unscrew the (3) bolts holding the mirror housing to the door frame and remove mirror housing.
Mirror Replacement WARNING! Safety glasses and sturdy gloves are recommended for mirror glass replacement. 7. Lay the mirror housing on a cloth covered, flat surface. Push on the top edge of the mirror to manually pivot it fully outward. Insert a large flathead screwdriver into groove and push-up on locking tab.
Page 6
Mirror Replacement Continued Remove the double-sided adhesive disc liner. Align the motor mount posts to their corresponding holes on the motor actuator. Slowly seat the new Signal® mirror into place. ® 10. With the entire palm of your hand, firmly press down on the Signal® mirror until it snaps into place. Press down on all sides of the Signal mirror to ensure proper fit, form, and function.
Latch hole (AVOID) Signal® mirror wires Insert Signal® mirror wires here Wire Routing 11. Attach the mirror housing to the door frame. Peel back plastic cover, route the Signal® mirror wire harness around OEM wires as shown to avoid door panel latching hole. Insert the Signal® mirror wires into the third hole down.
Page 8
Signal® Mirror wires Grounding bolt (source) Wire Routing Continued 12. Disconnect rubber boot from both ends. Reach inside door frame and fish out the Signal® mirror wires. 13. Using a fish wire, guide the Signal® mirror wires through rubber boot. Note: Route the Signal® mirror wires in-between the two connectors as shown.
Page 9
Wire Routing Continued 15. Remove floor board trim. Lift carpet to reveal parking brake line grommet. Using an awl or other suitable tools, puncture two small holes through rubber grommet. Route the two red Signal® mirror wires alongside OE wires and down through grommet holes.
