muth Signal Installation Instruction
Mirror for hummer h2 2003-2006
Hide thumbs
Also See for Signal:
- Instructions manual (10 pages) ,
- Installation instructions manual (14 pages) ,
- Installation instructions manual (9 pages)
Subscribe to Our Youtube Channel
Related Manuals for muth Signal
Summary of Contents for muth Signal
- Page 1 ® ® Signal Mirror Installation Instructions Hummer H2 (2003 - 2006) THE safety accessory of the 21 Century.™ P/N 210-0083-0 Rev A4 (11-29-05), GG © 2003 Muth Mirror Systems, LLC...
- Page 2 Small slotted screwdriver Monday through Friday Medium Philips screwdriver Between 8:00 a.m. and 5:00 p.m. CST Needle nose pliers Small pry bar Or through the Muth web site Gopher wire www.muthco.com Electrical tape Wire crimper and stripper Or via E-mail: techsupport@muthco.com...
-
Page 3: Mirror Removal
8. Disconnect heating element wires from mirror glass and remove mirror. ® 9. For both driver and passenger side mirrors, remove the rubber boot around the motor actuator PRIOR to installing the Signal mirror into the mirror housing. NOTE: Permanent removal of rubber boot, by pulling it over the motor, is required for this application and will not... -
Page 4: Mirror Replacement
17. Pass Signal® mirror harness through the rubber boot between the door and vehicle. 18. Route the Signal® mirror wire harness to back side of the instrument panel fuse block located at the lower left corner of the instrument panel, behind the knee bolster trim panel. - Page 5 23. Using multi-meter, probe right turn indicator wire (A-11, dark blue) at junction block to verify that flashing turn indicator power is present. 24. Using supplied quick splice connectors, attach respective left and right Signal® mirror red wire to proper location. 25. Using supplied ring terminal, twist left and right Signal® mirror black wires together, crimp and secure to ground source. ®...
- Page 6 - 3 -...
