- Page 1 Signal Mirror Installation Instructions ® 2007-2011 Silverado/Tahoe/Suburban/Avalanche/Sierra/Yukon THE safety accessory of the 21 Century.™ P/N 210-0133-0 Rev. A3 (7/19/11), BTV © 2006 Muth Company, LLC...
-
Page 2: Included Items
Warranty does not cover damage to the vehicle or mirror housing due to improper installation. Muth Mirror Systems, LLC (MMS) assumes no responsibility with regard to the accuracy of this information. MMS assumes no liability or responsibility resulting from improper installation, even in reliance upon this information. -
Page 3: Door Panel Removal
Door Panel Removal 1) Start with opening the driver’s side door and lowering the window. Remove lock lever (1A). 2) Using a plastic pry bar [slotted screwdriver], slowly pry plastic cover to reveal screw. CAU- TION: These plastic covers are fragile and break easily. - Page 4 Mirror Housing Removal 1) Carefully remove the (3) wire retention clips on door frame with a clip removal tool. 2) Secure the mirror housing with one hand, remove the (3) nuts hold- ing the mirror housing to the door frame using a 10mm socket. WARNING: Not securing mirror housing with one hand before loosening the nuts could cause the mirror housing to fall and be- come damaged.
-
Page 5: Mirror Replacement
Mirror Replacement WARNING: Safety glasses and sturdy gloves are required for mirror replacement. 1) Push down on the lower edge of the mirror until mirror piv- ots fully inward. Insert a clip removal tool into the gap be- tween mirror and mirror housing, slowly press to release mirror from motor actuator. - Page 6 Mirror Replacement Continued WARNING: Safety glasses and sturdy gloves are required for mirror replacement. 7) Guide all wire harnesses thru the access hole in the door frame and position the mirror housing assembly on the mirror mount. Attach the mirror housing to the mirror mount with three mir- ror mounting nuts.
-
Page 7: Wire Routing
Wire Routing 1) Locate the grounding bolt shown on the door frame. Cut and split the red w/ black stripe wire and the black wire on the Signal mirror wire harness. Route the black wire ® to the grounding bolt location. Cut the black wire to length, making sure enough slack is left for splicing. - Page 8 Page 8...
- Page 9 PROFESSIONAL INSTALLATION RECOMMENDED Warranty does not cover damage to vehicle or mirror housing due to improper installation. Muth Mirror Systems, LLC (MMS) assumes no responsibility with regard to the accuracy of this information. MMS assumes no liability or responsibility resulting from improper installa- tion, even in reliance upon this information.
