TOYOTA TUNDRA
Signal
®
Mirror Installation Instructions
2007 Toyota Tundra (USA built model only)
PLEASE READ INSTRUCTIONS PRIOR TO INSTALLATION
PROBLEMS OR QUESTIONS?
Technical Assistance is available by calling
Muth Mirror Systems Technicians at:
1-800-844-6616
Monday through Friday
Between 8:00 am and 5:00 p.m. CST
Or through the Muth web site:
Or via E-mail:
techsupport@muthco.com
PROFESSIONAL INSTALLATION RECOMMENDED
Warranty does not cover damage to the vehicle or mirror housing due to improper installation.
Muth Mirror Systems, LLC (MMS) assumes no responsibility with regard to the accuracy of this information.
MMS assumes no liability or responsibility resulting from improper installation, even in reliance upon this information.  Proper installation is
the responsibility of the installer.  It is your responsibility to verify any circuit before interfacing with it using a digital multimeter.
THE safety accessory of the 21
P/N 210-0134-0
Issue: A
5/3/07
2007
www.muthco.com
:
Rev. A (5/2/07), BTV
Page 1 of 9 pages
®
Signal
Mirror Installation Instructions
Century.™
st
© 2007 Muth Mirror Systems, LLC
Supplier Ref. Number: 21001340

Advertisement

loading
Need help?

Need help?

Do you have a question about the Signal and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for muth Signal

Summary of Contents for muth Signal

  • Page 1 PLEASE READ INSTRUCTIONS PRIOR TO INSTALLATION PROBLEMS OR QUESTIONS? Technical Assistance is available by calling Muth Mirror Systems Technicians at: 1-800-844-6616 Monday through Friday Between 8:00 am and 5:00 p.m. CST Or through the Muth web site: www.muthco.com Or via E-mail: techsupport@muthco.com :  PROFESSIONAL INSTALLATION RECOMMENDED Warranty does not cover damage to the vehicle or mirror housing due to improper installation.  ...
  • Page 2 ® Signal TOYOTA TUNDRA 2007 Mirror Installation Instructions NOTE: Part number of this accessory may not be the same as the part number shown. Recommended Tools Continued Kit Contents Item # Qty Req’d. Description Item # Qty Req’d. Description Signal®...
  • Page 3 ® Signal TOYOTA TUNDRA 2007 Mirror Installation Instructions Care must be taken when installing this accessory to ensure damage does not occur to the vehicle. The installation of this accessory should follow approved guidelines to ensure a quality installation. These guidelines can be found in the "Accessory Installation Practices" document.
  • Page 4 ® Signal TOYOTA TUNDRA 2007 Mirror Installation Instructions Fig. 2-3 Remove trim piece from bottom of door handle to expose screw, remove screw. (Fig. 2-3) Fig. 2-4 Unsnap control panel from door, disconnect all connectors. (Fig. 2-4) Fig. 2-5 Starting at bottom of panel, gently pull on panel to release all push pin connections which are around the perimeter of panel.
  • Page 5 ® Signal TOYOTA TUNDRA 2007 Mirror Installation Instructions Fig. 2-6 Pull door panel out slightly, disconnect wiring behind door panel light [located on the lower left hand corner]. (Fig. 2-6) Fig. 2-7 Lift door panel and pull it out partially. Unsnap door lever cable behind door panel.

  • Page 6: Mirror Replacement

    Using a slotted screwdriver, carefully remove the plastic cover from beneath the mirror housing. (Fig. 3-2) Fig. 3-3 3. With a utility knife, cut a small access hole in grommet for Signal® mirror wire harness. WARNING: Take care not to damage OEM wires. (Fig. 3-3) Page 6 of 9 pages Supplier Ref.
  • Page 7 ® Signal TOYOTA TUNDRA 2007 Mirror Installation Instructions Fig. 3-4 Signal Start with the shorter of the two ® mirror wire harnesses, route the wire from inside housing, along side OEM wire, leaving about 4-6 inches of wire within the mirror housing. Connect the...
  • Page 8 ® Signal TOYOTA TUNDRA 2007 Mirror Installation Instructions WARNING: When routing wire into vehicle, it is extremely important to not let wire get pinched or crushed at any time. Avoid window track and sharp edges at all times. Not doing so may cause circuit shortage problems in the long run.
  • Page 9 G. Reconnect all original wiring. Turn the ignition power to on, check to verify all features are working properly. H. Replace the plastic door frame moldings, trim, door panels, and all accessories. Muth products are protected by these, and other pending, United States Patents 3,075,779 5,005,009 5,014,167...
