Note: Professional Installation Recommended Warranty does not cover damage to the vehicle or mirror housing due to improper installation. The following installation instructions are to be considered as a guide only. Door removal procedures, indicator wire color and location may have changed since publication of these instructions.
DOOR PANEL REMOVAL Start with opening the driver’s side door and lowering the window. Using a 7mm socket wrench, remove all (8) hex screws along the perimeter of the door frame (A). Unsnap corner plastic triangular cover (B). Carefully remove door handle cover using a slotted screwdriver (C). Remove screw in door handle with a T-15 torx wrench (D).
Page 4
DOOR PANEL & MIRROR HOUSING REMOVAL CONTINUED Carefully pry out the control console with a small pry bar (G). Disconnect all wiring connections behind control console and remove it. Using a 7mm socket wrench, remove screw revealed by the removal of the control console (H). Pull on door panel to unsnap it from door frame (I). Lift up and pull door panel out a few inches away.
MIRROR REPLACEMENT WARNING: Safety glasses and sturdy gloves are required for mirror replacement. Push down on the lower outboard edge of glass until mirror pivots fully outward. Insert a large slotted screwdriver in between the mirror backing plate and motor actuator (A). Carefully pry and twist screwdriver until original mirror pops off.
WIRE ROUTING WARNING: When routing wire into vehicle, it is extremely important to not let wire get pinched or crushed at any time. Avoid window track and sharp edges at all times. Not doing so may cause circuit shortage problems in the long run. Guide all wire harnesses thru the hole in the door fram e and position the mirror housing assembly on the mirror mount.
Page 7
WIRE ROUTING CONTINUED ® Tape the open end of the Signal mirror wire harness to the fish rod. Push the fish rod thru the boot connector opening and out the 1/2” drilled hole (F). ® ® Pull the fish rod thru to get the Signal mirror wire harness inside the vehicle, and remove any slack in the Signal mirror wire harness.
WIRE IDENTIFICATION TURN & BRAKE The vehicle’s electrical wiring for the TURN & BRAKE is located within the wire bundle on each side of the kick panel. Locate the WHITE w/ RED STRIPE wire within the wire bundle on the driver side kick panel. Turn the ignition key so that electrical power is on and activate the driver side turn indicator. Probe the wire with the wire tester to verify that flashing turn directional power is present.
Page 9
E. Reconnect all original wiring. Turn the ignition power to on, check to verify all features are working properly. F. Replace the plastic door frame moldings, trim, door panels, and all accessori es. Muth products are protected by these, and other pending, United States Patents Muth products are protected by these, and other pending, United States Patents...
