Mirror Installation Instructions
2005 -2012 Toyota Tacoma
THE safety accessory of the 21
Century.™
st
P/N 210-0115-0
Rev. A3
© 2005 Muth Mirror Systems, LLC
Page 3 of 12PplPage 3 of 12

Advertisement

loading
Need help?

Need help?

Do you have a question about the Signal Mirror 2005 -2012 Toyota Tacoma and is the answer not in the manual?

Questions and answers

Summary of Contents for muth Signal Mirror 2005 -2012 Toyota Tacoma

  • Page 1 ® ® Signal Mirror Installation Instructions 2005 -2012 Toyota Tacoma THE safety accessory of the 21 Century.™ P/N 210-0115-0 Rev. A3 © 2005 Muth Mirror Systems, LLC Page 3 of 12PplPage 3 of 12...
  • Page 2 PROFESSIONAL INSTALLATION RECOMMENDED Warranty does not cover damage to the vehicle or mirror housing due to improper installation. Muth Mirror Systems, LLC (MMS) assumes no responsibility with regard to the accuracy of this information. MMS assumes no liability or responsibility resulting from improper installation, even in reliance upon this information.
  • Page 3: Door Panel Removal

    DOOR PANEL REMOVAL Start with opening the driver’s side door and lowering the window (A). Unsnap corner plastic triangular cover (B). Carefully remove door handle cover using a slotted screwdriver (C). Remove screw in door handle with a Phillips screwdriver (D). With the slotted screwdriver, remove plastic covering on the grab bar (E). Release the revealed screw using a Phillips screwdriver.
  • Page 4 DOOR PANEL & MIRROR HOUSING REMOVAL CONTINUED Using a small Phillips screwdriver, push in the center post on the plastic dowel pin and release the dowel pin from the door panel (G). Carefully pry on the lower outboard corner of the door panel using a small plastic pry bar (H). Continue prying around the door panel until it unsnaps from the door frame. Lift up and pull door panel out a few inches away (I).
  • Page 5: Mirror Replacement

    MIRROR REPLACEMENT WARNING: Safety glasses and sturdy gloves are required for mirror replacement. Push down on the upper outboard edge of glass until mirror pivots fully outward. Insert a large slotted screwdriver in between the mirror backing plate and motor actuator (A). Carefully pry and twist screwdriver until original mirror pops off.
  • Page 6 MIRROR REPLACEMENT CONTINUED Remove sail from mirror housing (G). Remove the revealed remaining screw on mirror housing with a T-25 Torx wrench (H). Remove sail mount from mirror housing. Using the shorter of the two harnesses from the supplied wiring kit, start from inside mirror housing, guide the end without the connector thru the narrow passage down and ®...
  • Page 7 MIRROR REPLACEMENT CONTINUED ® Continue routing the Signal mirror wire harness thru the sail and plastic insulation (M). CAUTION: When replacing the sail, make sure to position all wire harnesses as shown on . Not doing so could result in wiring harnesses being crushed by the sail, when re-assembling, causing shortage in the long run. Re-assemble the sail back onto the mirror housing.
  • Page 8: Wire Routing

    WIRE ROUTING WARNING: When routing wire into vehicle, it is extremely important to not let wire get pinched or crushed at any time. Avoid window track and sharp edges at all times. Not doing so may cause circuit shortage problems in the long run. Guide all wire harnesses thru the hole in the door frame and position the mirror housing assembly onto the mirror mount.
  • Page 9 WIRE ROUTING CONTINUED Before proceeding, please read remainder of instructions for information regarding wiring identification and options. The vehicle’s electrical wirings are located on the driver side, behind the fuse box. To gain access to the wiring location, ® remove the stash tray on the knee panel (F). Route the red wire on Signal mirror wire harness on the driver side to the wiring location behind fuse box.
  • Page 10: Wire Identification

    WIRE IDENTIFICATION NOTE: On models without daytime running lights, the BLUE w/ BLACK STRIPE and the BLUE w/ YELLOW STRIPE trigger both the front and rear turn indicators. The vehicle’s electrical wirings for the TURN directional are located behind the fuse box on the driver side knee panel. Locate the BLUE w/ BLACK STRIPE wire behind fuse box.
  • Page 11 USE THE INCLUDED WIRE TAPS AND FOLLOW THE FOUR STEPS ABOVE TO SPLICE INTO THE TURN INDICATOR WIRES A. Make sure the harnesses are routed securely and enough slack is left for splicing. B. Splice the RED wire from the driver side harness into the wire previously labeled ‘driver side indicator’. C.
  • Page 12 Muth’s discretion, replace the defective product. Any warranty or replacement part will be charged to the customer when shipped. Credit will be given when the defective part is returned to and received by Muth , and the replacement is warranted.
