- Page 1 ® ® Signal Mirror Installation Instructions Honda Goldwing GL 1500, 1988-2000 THE safety accessory of the 21 Century.™ P/N 210-0049-0 Rev E (10/5/07), BTV © 2003 Muth Mirror Systems, LLC.
- Page 2 1-800-844-6616 REQUIRED TOOLS: Monday through Friday Medium Philips screwdriver Between 8:00 a.m. and 5:00 p.m. CST Needle nose pliers Electric drill Or through the Muth web site ¼” drill bit www.muthco.com Masking tape Multimeter Or via E-mail: sales@muthco.com Sturdy gloves Safety glasses or goggles Professional Installation Recommended...
- Page 3 Mirror Housing Removal Start on either the left or right side mirror. These There are three screws holding the mirror housing to the mirror mount. Remove the three screws. Set the mirror instructions start with the right side mirror. Pull housing aside.
- Page 4 Mirror Replacement ® ® Remove the three screws holding the hinge to the Match the base of the hinge up to the new Signal Position the rubber boot over the Signal mirror mirror housing. Remove the hinge and remove the mirror housing.
- Page 5 Wiring and Wire Identification ® ® Male pins are already installed on harness from Signal Install plug and play harness. Route wire from Signal mirror harness irror. ® ® ® Route wire from Signal mirror harness continued… Reinstall Signal mirror onto motorcycle Reinstall Signal mirror onto motorcycle continued…...
- Page 6 Wiring and Wire Identification Continue *WARNING: INCORRECT WIRING WILL CAUSE SIGNAL® MIRROR NOT TO FUNCTION * Plug mirror into motorcycle harness. Turn ignition on, test the Signal® mirror for functionality. Insert pins into female connector. NOTE: Insert pin from the black wire into hole #1. Put the pin from black with Tuck wiring into fairing.
