Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Country Web Site Customer Care Centre HONG KONG (852)3698-4698 www.samsung.com/hk www.samsung.com/hk_en/ LED TV user manual Thank you for purchasing this Samsung product.
Page 2
Warning! Important Safety Instructions (Please read the appropriate section that corresponds to the marking on your Samsung product before attempting to install the product.) CAUTION This symbol indicates that high voltage is present inside. It is dangerous to make any kind of contact with any internal part of this product.
• External impact or drop. • Use of supplies or separately sold product unspecified by Samsung. • Repair from a person who is not an engineer of outsourcing service company or partner of Samsung • Electronics Co., Ltd. • Remodeling or repairing the product by customer.
✎ When using a stand or wall-mount, use parts provided by Samsung Electronics only. • If you use parts provided by another manufacturer, it may result in a problem with the product or an injury due to the product falling.
List of Features Media Play • Allows you to play music files, pictures, and movies saved on a USB device. e-Manual • Allows you to read on screen full manual. (p. 10) Accessories ✎ Please make sure the following items are included with your TV. If any items are missing, contact your dealer. ✎...
Viewing the Remote Control ✎ This is a special remote control for the visually impaired persons and has Braille points on the Power, Channel, and Volume buttons. Displays and selects the available video sources. Turns the TV on and off. Press to directly access to channels.
Using the TV’s Controller (Panel Key) The TV's Controller, a small joy stick like button on the rear right side of the TV, lets you control the TV without the remote control. ✎ Some functions which require a PIN code may not be available. ✎...
Page 8
Connections HDMI connection AV connection Component connection Set top Box / BD Player / PC BD Player BD Player HDMI OUT DVI OUT AUDIO OUT COMPONENT OUT AUDIO OUT VIDEO OUT R-AUDIO-L R-AUDIO-L TV Side Panel ✎ It supports both Component and AV connection in one HDMI IN 2 port.
Changing the Input Source Source TV / HDMI1 / HDMI2/DVI / AV / Component Use to select TV or other external input sources such as DVD / Blu-ray players / cable box / STB satellite receiver connected to the TV. ✎...
How to use the e-Manual You can find instructions about your TV’s features in the e-Manual in your TV. To use, press the E-MANUAL button on E-MANUAL your remote. Move the cursor using the up/down/right/left buttons to highlight a category, then a topic, and then press the E button.
3D images on your 3D TV. The Samsung data. 3D glasses communicate with Samsung 3D TVs via ✎ Ensure your Samsung TV and 3D glasses are no farther than the 2.4GHz RF band. 19.5 in (50 cm) apart from each another while pairing is in ✎...
3D TV after a repair. glasses will power on and pairing will start. • If you want to play 3D content on another Samsung 3D TV The message “3D glasses are connected.” wil be displayed model that belongs to the D, E, or F series released in 2011 on the TV screen when the pairing is successfully completed.
Troubleshooting If the TV seems to have a problem, first try this list of possible problems and solutions. If none of these troubleshooting tips apply, visit “www.samsung.com”, then click on Support, or call Samsung customer service centre. Issues Solutions and Explanations First of all, please perform the Picture Test and confirm that your TV is properly displaying test image.
Page 14
• Programme the Cable/Set top box remote control to operate the TV. Refer to the Cable/Set top box user manual for doesn’t turn the TV on or off, or the SAMSUNG TV code. adjust the volume. A “Mode Not Supported” message • Check the supported resolution of the TV, and adjust the external device’s output resolution accordingly.
Page 15
✎ To keep your TV in optimum condition, upgrade to the latest firmware on the Samsung web site by USB (www.Samsung.com > Support > Downloads). ✎ This TFT LED panel uses a panel consisting of sub pixels which require sophisticated technology to produce. However, there may be a few bright or dark pixels on the screen.
We recommend you contact a technician for assistance when installing the wall mount bracket. We do not advise you to do it yourself. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the wall mount on your own.
Tip Prevention – Securing the TV to the Wall Caution: Pulling, pushing, or climbing on the TV may cause the TV to fall. In particular, ensure your children do not hang on or destabilize the TV. Doing so may cause the TV to tip over, causing serious injuries or death. Follow all safety precautions provided in the Safety Flyer included with your TV.
Anti-theft Kensington Lock The Kensington Lock is not supplied by Samsung. It is a device used to physically fix the system when using it in a public place. The appearance and locking method may differ from the illustration depending on the manufacturer. Refer to the manual provided with the Kensington Lock for additional information on proper use.
10% to 80%, non-condensing Storage Temperature -20°C to 45°C (-4°F to 113°F) Storage Humidity 5% to 95%, non-condensing Stand Swivel (Left / Right) 0° Model Name UA32F6100 UA40F6100 UA46F6100 Screen Size 32 inches 40 inches 46 inches Display Resolution 1920 x 1080...
Page 21
Full available resolution Optimal resolution is: 1920 x 1080@60Hz. See specification page for full available resolution. Horizontal Frequency Mode Resolution Vertical Frequency (Hz) Pixel Clock Frequency (MHz) Sync Polarity (H / V) 1366 x 768 1920 X 1080 (KHz) 640 x 350 31.469 70.086 25.175...
Page 28
連接 HDMI 連接 AV 連接 分量連接 BD 播放器 機頂盒 / BD 播放器 / PC BD 播放器 HDMI OUT DVI OUT AUDIO OUT COMPONENT OUT AUDIO OUT VIDEO OUT R-AUDIO-L R-AUDIO-L 電視側面板 ✎ 支援在一個連接埠中連接分 量端子和 AV。 HDMI IN 2 (DVI) (5V 0.5A) HDMI IN 1 (STB) COMPONENT...
Page 29
變更輸入信號來源 訊號源 電視 / HDMI1 / HDMI2/DVI / AV / 分量輸入 用於選擇電視或外部輸入信號來源,如連接電視的 DVD / Blu-ray 播放機 / 有線電視接收盒 / 機上盒衛星接收器。 ✎ 按 SOURCE 按鈕。 在顯示的訊號源清單中 ,會反白顯示已連接的輸入信號。 ✎ 不支援 PC (D-Sub) 輸入 。如果要將電腦連接到電視 , 可以使用電視上的 HDMI IN 2(DVI) 連接埠連接 HDMI 轉接 DVI 纜線。 ✎...
Page 31
3D 主動式眼鏡 功能 配對 3D 主動式眼鏡 ✎ Samsung 的 SSG-5100GB 3D 眼鏡可讓您在 3D 電視上觀看 3D 什麼是配對? 配對是連接 3D 眼鏡和 3D 電視的程序,讓兩 影像。Samsung 3D 眼鏡會透過 2.4GHz RF 頻段與 Samsung 3D 個裝置之間能夠交換資料。 電視進行通訊。 ✎ 請確保您的 Samsung 電視和 3D 眼鏡在進行配對期間彼此之 間的距離不超過 19.5 吋(50 公分)。...
Page 32
• 如果 3D 眼鏡在重新配對後,即使按下電視(尤其是 3D 電 視)上的電源按鈕仍然沒有作用。 快速按下 3D 眼鏡上的電源按鈕, 3D 眼鏡的電源會開啟並開 始進行配對。 • 如果您要在屬於 D、E 和 F 系列(從 2011 到2013 年間上市) 配對成功完成時,電視上會顯示「3D 眼鏡已連接至電視。 的其他 Samsung 3D 電視機型上播放 3D 內容。 」的訊息。 觀賞 3D 視訊 • 如果配對失敗,3D 眼鏡會關閉電源。 依影像來源的格式而定,某些 3D 模式可能無法使用。 • 如果第一次嘗試配對失敗,可將電視的電源關閉再開啟,然...
Page 36
購買我們的壁掛架組時,會提供詳細安裝手冊和組裝所需的所有零件。 − 請勿使用與 VESA 標準螺絲規格不相符的螺絲。 − 請勿使用比標準尺寸長,或與 VESA 標準螺絲規格不相符的螺絲。太長的螺絲可能導致電視機內部損壞。 − 對於不符 VESA 標準螺絲規格的壁掛架,螺絲長度可能根據壁掛架規格而有所不同。 − 請勿將螺絲鎖得太緊;這樣可能損壞產品或造成產品掉落,導致人身傷害。Samsung 對於這類意外不負任何責任。 − 若使用非 VESA 或非指定壁掛架,或因消費者未遵守安裝指示而造成的產品損毀或人身傷害,Samsung 不負任何責任。 − 電視安裝傾斜角度勿超過 15 度。 英吋 VESA 規格 (A * B) 標準螺絲 數量 200 x 200 4个 400 x 400 切勿在電視開啟時安裝壁掛架組。否則可能會因觸電而導致人身傷害。...
