SAMSUNG LED TV User Manual

6 series.
Hide thumbs

Advertisement

Contact SAMSUNG WORLDWIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre.
Country
Customer Care Centre
AUSTRALIA
1300 362 603
CHINA
800-810-5858
400-810-5858
010-6475 1880
HONG KONG:3698 - 4698
INDIA
3030 8282
1-800-3000-8282
1800 110011
INDONESIA
0800-112-8888
JAPAN
0120-327-527
MALAYSIA
1800-88-9999
NEW ZEALAND
0800 SAMSUNG (0800 726 786)
PHILIPPINES
1-800-10-SAMSUNG(726-7864)
1-800-3-SAMSUNG(726-7864)
02-5805777
SINGAPORE
1800-SAMSUNG(726-7864)
1800-29-3232
THAILAND
02-689-3232
TAIWAN
0800-329-999
VIETNAM
1 800 588 889
SOUTH AFRICA
0860-SAMSUNG(726-7864 )
U.A.E
800-SAMSUNG (726-7864)
8000-4726
© 2010 Samsung Electronics Co., Ltd. All rights reserved.
Web Site
www.samsung.com/au
www.samsung.com/cn
www.samsung.com/hk
www.samsung.com/in
www.samsung.com/id
www.samsung.com/jp
www.samsung.com/my
www.samsung.com/nz
www.samsung.com/ph
www.samsung.com/sg
www.samsung.com/th
www.samsung.com/tw
www.samsung.com/vn
www.samsung.com/za
www.samsung.com/ae
BN68-02514E-00
LED TV

user manual

imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/register
Model _____________ Serial No. _____________

Advertisement

   Also See for SAMSUNG LED TV

   Related Manuals for SAMSUNG LED TV

   Summary of Contents for SAMSUNG LED TV

  • Page 1: User Manual

    Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Country Customer Care Centre Web Site AUSTRALIA 1300 362 603 www.samsung.com/au CHINA www.samsung.com/cn 800-810-5858 400-810-5858 010-6475 1880 HONG KONG:3698 - 4698 www.samsung.com/hk...
  • Page 2 Failing to do so may result in fire or a problem with the product due to an increase in the internal temperature of the product. ✎ When using a stand or wall-mount, use parts provided by Samsung Electronics only. If you use parts provided by another manufacturer, it may result in a problem with the product or an injury due to the product falling.
  • Page 3: Table Of Contents

    Contents Getting Started Accessories Viewing the Control Panel Viewing the Remote Control Connecting to an Antenna Plug & Play (Initial Setup) Connections Connecting to an AV Device Connecting to an Audio Device Changing the Input source Basic Features How to Navigate Menus Using the button (Now &...
  • Page 4: Getting Started

    Getting Started Accessories ✎ Please make sure the following items are included with your LED TV. If any items are missing, contact your dealer. ✎ The items’ colours and shapes may vary depending on the models. y Remote Control & Batteries (AAA x 2)
  • Page 5: Viewing The Control Panel

    Getting Started Viewing the Control Panel ✎ The product colour and shape may vary depending on the model. Speakers Power Indicator Remote control sensor Toggles between all the available input sources. In the on-screen menu, use this SOURCEE button as you would use the ENTERE button on the remote control. MENU Displays an on-screen menu, the OSD (on screen display), of your TV’s features.
  • Page 6: Viewing The Remote Control

    AD: Turns the audio description on and Use these buttons in Media Play off (not available in some locations). and Anynet+ (HDMI-CEC) modes P.SIZE: Selects the picture size. (�: Controls recording for Samsung SUBT.: Displays digital subtitles. recorders that have the Anynet+ feature) English...
  • Page 7 (not available in some locations). Use these buttons in Media Play P.SIZE: Selects the picture size. and Anynet+ (HDMI-CEC) modes. SUBT.: Displays digital subtitles. (�: Controls recording for Samsung recorders that have the Anynet+ feature) Installing batteries (Battery size: AAA) ✎ NOTE Use the remote control within 23 feet from the TV.
  • Page 8: Connecting To An Antenna

    Connecting to an Antenna When the TV is initially powered on, basic settings proceed automatically. ✎ Preset: Connecting the mains and antenna. VHF/UHF Antenna ANT 1 IN ANT 2 IN (CABLE) Cable (AIR) ANT OUT Power Input Plug & Play (Initial Setup) When the TV is initially powered on, a sequence of on-screen prompts will assist in configuring basic settings.
  • Page 9: Connections

    Connections Connections Connecting to an AV Device Using an HDMI / DVI Cable: HD connection (up to 1080p) Available devices: DVD, Blu-ray player, HD cable box, HD STB (Set-Top-Box), satellite receiver (STB) HDMI OUT DVI OUT AUDIO OUT R-AUDIO-L White ✎...
  • Page 10: Connecting To An Audio Device

    Connecting to an Audio Device Using an Optical (Digital) or Headphone Cable Connection Available devices: digital audio system, amplifier, DVD home theatre digital audio system OPTICAL ✎ DIGITAL AUDIO OUT (OPTICAL) When a digital audio system is connected to the jack, decrease the volume DIGITAL AUDIO OUT (OPTICAL) of both the TV and the system.
  • Page 11: Changing The Input Source

    Connections Changing the Input Source Edit Name ■ VCR / DVD / Cable STB / Satellite STB / PVR STB / Source List AV Receiver / Game / Camcorder / PC / DVI PC / DVI Devices / TV / IPTV / Blu-ray / HD DVD / DMA: Name Use to select TV or other external input SOURCE the device connected to the input jacks to make your...
  • Page 12: Basic Features

    Basic Features TTX/MIX PRE-CH MUTE How to Navigate Menus Using the INFO button (Now & Next guide) Before using the TV, follow the steps below to learn how to The display identifies the current INFO navigate the menu and select and adjust different functions. channel and the status of certain CH LIST audio-video settings.
  • Page 13: Channel Manager

    Basic Features Using Scheduled View Channels: Shows the channel list according to ■ channel type. Guide Tue,1 Jun 2:10 pm My Channels: Shows the group of the channel. ■ DTV Air 800 five Scheduled: Shows all the currently reserved Family Affairs ■...
  • Page 14: Channel Menu

    Using Favourite Channels Channel Menu ¦ Retuning channels ¦ My Channels (in Channel Manager) Antenna Shows all favourite channels. ■ Edit My Channels : You can set the selected Your TV can memorize both Air and Cable channels. channels to desired my channels group. ■...
  • Page 15: Editing Channels

    Basic Features ✎ Channel mode ■ Lock / Unlock: Lock a channel so that the channel cannot be selected and viewed. P (programme mode): When tuning is complete, ✎ the broadcasting stations in your area have been NOTE assigned to position numbers from P0 to P99. You This function is available only when the Child Lock can select a channel by entering the position number is set to On.
  • Page 16: Picture Menu

    Picture Menu ■ No Signal Stand by (Off / 15 min / 30 min / 60 min): Activates the Stand-by mode, in the case of “No Signal” or “Check Signal Cable” status for a certain period of Changing the Preset Picture Mode ¦...
  • Page 17: Picture Options

    Basic Features ■ 10p White Balance (Off / On): Controls the white ■ Size: Your cable box/satellite receiver may have its balance in 10 point interval by adjusting the red, green, own set of screen sizes as well. However, we highly and blue brightness.
  • Page 18: Sound Menu

    ■ 100Hz Motion Plus (Off / Clear / Standard / Smooth / same basic set-up information will almost always be applied. Custom / Demo) : Removes drag from fast scenes with (If not, contact your computer manufacturer or Samsung a lot of movement to provide a clearer picture. Dealer.) ✎...
  • Page 19: Adjusting Sound Settings

    Basic Features Adjusting sound settings Auto Volume (Off / Normal / Night) ¦ To equalize the volume level on each channel, set to Normal. ■ Night: This mode provides an improved sound Equalizer experience compared to Normal mode, making almost Adjusts the sound mode (standard sound mode only).
  • Page 20: Setup Menu

    Setup Menu ■ SPDIF Output: SPDIF (Sony Philips Digital InterFace) is used to provide digital sound, reducing interference going to speakers and various digital devices such as a Setting the Time ¦ DVD player. Audio Format: During the reception of a digital TV broadcast, you can select the Digital Audio output Time (SPDIF) format from the options PCM or Dolby Digital.
  • Page 21: Locking Programs

    Basic Features On Time / Off Time: Set the hour, minute, and activate ■ Change PIN: Change your personal ID number required / inactivate. (To activate timer with the setting you’ve to set up the TV. chosen, set to Activate.) ✎...
  • Page 22 Sub picture ■ BD Wise (Off / On): Provides the optimal picture quality Component, HDMI1/DVI, for Samsung DVD, Blu-ray and Home Theatre products HDMI2, HDMI3, HDMI4, which support BD Wise. When BD Wise is turned On, the picture mode is automatically changed to the optimal resolution.
  • Page 23: Support Menu

    If the function is selected during the software Software Upgrade can be performed via a broadcasting transmission period, software will be automatically signal or by downloading the latest firmware from samsung. searched and downloaded. com to a USB memory device.
  • Page 24: Advanced Features

    Advanced Features Connecting to a PC Using an HDMI/DVI Cable / a D-sub Cable PC OUT AUDIO OUT AUDIO OUT PC OUT Display Modes (D-Sub and HDMI/DVI Input) Optimal resolution is 1920 X 1080 @ 60 Hz. Horizontal Frequency Vertical Frequency Pixel Clock Frequency Sync Polarity Mode...
  • Page 25: Network Connection

    Advanced Features Network Connection You can set up your TV so that it can access the Internet through your local area network (LAN) using a wired or wireless connection. Connecting to a Wired Network ¦ You can attach your TV to your LAN using cable in three ways: y You can attach your TV to your LAN by connecting the LAN port on the back of your TV to an external modem using a Cat 5 cable.
  • Page 26 If your AP supports WPS (Wi-Fi Protected Setup), you can connect to the network via PBC (Push Button Configuration) or PIN (Personal Identification Number). WPS will automatically configure the SSID and WPA key in either mode. If the device isn’t certified, it may not connect to the TV via the “Samsung Wireless LAN Adapter”. English...
  • Page 27: Setting Up The Network

    Advanced Features Setting up the Network ■ Wireless Network Setup ✎ The menu is activated only if the “Samsung Wireless LAN Adapter” is connected. Network Type (Wired / Wireless) Select a network Select Wired or Wireless to connect to the network.
  • Page 28: Network Test

    Ad-hoc: You can connect to a mobile device without Network Test an access point through the “Samsung Wireless LAN Test or confirm the network connection status after setting Adapter” by using a peer to peer network. up the network. How to connect to new Ad-hoc ✎...
  • Page 29: Media Play

    PC IP addresses should be the same and only the last part (the host address) should be changed. (e.g. IP Address: 123.123.123.**) 2. Using a LAN cable, connect between the external modem and the PC onto which the Samsung PC Share Manager program will be installed.
  • Page 30 The Divx DRM, Multi-audio, embedded caption does not supported. ✎ Samsung PC Share manager should be permitted by the firewall program on your PC. ✎ When you use Media Play mode through a network connection, According to functions of the provided server: The sorting method may vary.
  • Page 31: Screen Display

    Advanced Features Screen Display ¦ Move to the file you desired using the up/down/right/left buttons and then press the ENTERE button. The file is played. Information : Videos You can ascertain the selected file name and the number of files and page.
  • Page 32 • WMA sampling rate 22050Hz mono is not supported. – Below 1280 x 720: 60 frame max – Above 1280 x 720: 30 frame max • GMC 2 over is not support. • Only Samsung Techwin MJEPG is supported. English...
  • Page 33 Advanced Features Playing movie continuously (Resume Play) 00:04:03 / 00:07:38 If you exit the playing movie function, the movie can be played later from Movie 01.avi the point where it was stopped. 1. Select the movie file you want to play continuously by pressing the ◄ or ►...
  • Page 34: Playing The Multiple Files

    Playing the multiple files ¦ Playing the selected video/music/photo files Videos 1. Press the Yellow button in the file list to select the desired file. 2. Repeat the above operation to select multiple files. ✎ NOTE The (c) mark appears to the left of the selected files. To cancel a selection, press the Yellow button again.
  • Page 35: Anynet

    Anynet+ is a function that enables you to control all connected Samsung devices that support Anynet+ with your Samsung TV’s remote. The Anynet+ system can be used only with Samsung devices that have the Anynet+ feature. To be sure your Samsung device has this feature, check if there is an Anynet+ logo on it.
  • Page 36: Setting Up Anynet

    Make sure to switch to an Anynet+ device by using the Device List. Recording ¦ You can make a recording of a TV programme using a Samsung recorder. 1. Select Recording. ✎ When there are more than two recording devices When multiple recording devices are connected, the recording devices are listed.
  • Page 37: Listening Through A Receiver

    Advanced Features Listening through a Receiver ¦ You can listen to sound through a receiver (i.e Home Theatre) instead of the TV speaker. 1. Select Receiver and set to On. 2. Press the button to exit. EXIT ✎ If your receiver supports audio only, it may not appear in the device list. ✎...
  • Page 38: Internet@tv

    Screen Display Recommended TV Screen: Recommended Applications: Displays the current channel. Displays the recommended service by Samsung. You are not able to add or delete a service in this list. Information: My Applications by Date 1/1 Displays notices, new applications, and...
  • Page 39: Samsung Apps

    ▪ Ticker Autorun : Off ▪ Internet@TV ID ▪ Channel Bound Service : Off Samsung Apps is a store for downloading applications to be ▪ Service Manager ▪ Change the Service Lock password used on Samsung TV/AV equipment. ▪ Properties ▪...
  • Page 40: Allshare

    ✎ For more information, visit “www.samsung.com” or contact the Samsung call centre. Mobile devices may Using the Message Function need additional software installation. For details, refer to Using this function, you view call arrivals, SMS messages each user’s guide.
  • Page 41 Return depending on the type of media content. Using the mobile device, you can control the media Using your Samsung phone to control your TV Simply playing. For details, refer to each mobile’s user’s guide. Before you can use this feature, you must connect to...
  • Page 42: Calendar

    Holiday of Day Tips If time information has been set, the focus date is samsung current date. If time information hasn’t be set, the focus date is default date (Jan 1, 2010). If notes have been added, the note for present day pops up when the TV is turned on.
  • Page 43: Other Information

    Other Information Assembling the Cables Stand Type Enclose the cables in the Holder-Wire Cable so that the cables are not visible through the transparent stand. Wall-Mount Type ✎ Do not pull the cables too hard when arranging them. This may cause damage to the product’s connection terminals. English...
  • Page 44: Installing The Wall Mount

    For detailed information on installing the wall mount, see the instructions provided with the wall mount. Contact a technician for assistance when installing the wall mount bracket. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the TV on your own.
  • Page 45 Samsung is not liable for these kinds of accidents. Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions.
  • Page 46: Anti-theft Kensington Lock

    Please find a “K” icon on the rear of the TV. A kensington slot is beside the “K” icon. 1. Insert the locking device into the Kensington slot 1 on the LED TV and <Optional> turn it as shown 2.
  • Page 47: Troubleshooting

    If you have any questions about the TV, first refer to this list. If none of these troubleshooting tips apply, please visit “www. samsung.com” then click on Support, or contact the call centre listed on the back-cover of this manual.
  • Page 48 Network Connection (Depending on Models) Wireless network connection failed. • Samsung Wireless USB dongle is required to use a wireless network. • Make sure the Network Connection is set to Wireless. • Make sure the TV is connected to a wireless IP sharer (router).
  • Page 49 Other Information Issues Solutions and Explanations You see small particles when you look • This is part of the product’s design and is not a defect. closely at the edge of the frame of the TV. The PIP menu is not available. • PIP functionality is only available when you are using a HDMI, PC or components source.
  • Page 50: Specifications

    Specifications Model Name UA32C6900 UA40C6900 UA46C6900 UA55C6900 Screen Size (Diagonal) 32 inch 40 inch 46 inch 55 inch PC Resolution (Optimum) 1920 X 1080 @ 1920 X 1080 @ 60 Hz 1920 X 1080 @ 60 Hz 1920 X 1080 @ 60 60 Hz Sound Output...
  • Page 51 This page is intentionally left blank.
