4.4 Rotary switch setting: Operating Mode

Parameter
Standby In this operating mode all the internal functions are switched off. Frost protection
remains active and a blocking protection for the pump is guaranteed. Attention:
This operating mode does not mean that all outputs are always potential-free.
Reducing The internal heating circuit provides continuous (24 h per day) regulation to the
parametrised setback temperature.
heating The internal heating circuit provides continuous (24 h per day) regulation to the
parametrised day set room temperature (heating).
cooling The internal heating circuit provides continuous (24 h per day) regulation to the
parametrised day set room temperature (cooling).
Summer In this operating mode the internal heating circuit is switched off. Frost protection
remains active and a blocking protection for the pump is guaranteed. Hot water
generation works normally.
Automatic 1 The internal heating circuit regulates according to the first parametrised timer pro-
gramme with the individual set day room temperatures.
Automatic 2 The internal heating circuit regulates according to the second parametrised timer
programme with the individual set day room temperatures.
Tab. 4 -3 Parameter in rotary switch setting "Operating Mode"

4.5 Rotary switch setting: Set Temp Day

Parameter
T-Room des 1 The set value of the room temperature in °C with one decimal point that applies to
the 1st. switch timer programme block in the timer programmes Automatic 1 and
Automatic 2.
T-Room des 2 The set value of the room temperature in °C with one decimal point that applies to
the 2nd. switch timer programme block in the timer programmes Automatic 1 and
Automatic 2.
T-Room des 3 The set value of the room temperature in °C with one decimal point that applies to
the 3rd. switch timer programme block in the timer programmes Automatic 1 and
Automatic 2.
Tab. 4 -4 Parameter in rotary switch setting "Set Temp Day"

4.6 Rotary switch setting: Set Temp Night

Parameter
T-Reduced We adjust the set value of the setback room temperature in °C with one decimal
point which applies to the timer programmes Automatic 1 and Automatic 2.
T-Absence We adjust the set value of the setback room temperature in °C with one decimal
point which applies to the timer programmes Away and Vacation.
Tab. 4 -5 Parameter in rotary switch setting "Set Temp Night"

4.7 Rotary switch setting: DHW Set Temp

Parameter
T-DHW 1 des We adjust the set value of the hot water temperature in °C with one decimal point
that applies to the 1st. switch timer programme block in the timer programmes
Automatic 1 and Automatic 2.
T-DHW 2 des We adjust the set value of the hot water temperature in °C with one decimal point
that applies to the 2nd. switch timer programme block in the timer programmes
Automatic 1 and Automatic 2.
T-DHW 3 des We adjust the set value of the hot water temperature in °C with one decimal point
that applies to the 3rd. switch timer programme block in the timer programmes
Automatic 1 and Automatic 2.
Tab. 4 -6 Parameter in rotary switch setting "DHW Set Temp"
BA ROTEX HPSU compact 4 - 03/2013
Designation
Designation
Designation
Designation
4 x Parameter settings
Access Setting range Factory
Min / Max setting
BE HF
E E
E E
E E
E E
E E
E E
E E
Access Setting range Factory
Min / Max setting
BE HF
E E 5 - 40°C 20 °C
E E 5 - 40°C 20 °C
E E 5 - 40°C 20 °C
Access Setting range Factory
Min / Max setting
BE HF
E E 5 - 40°C 15 °C
E E 5 - 40°C 15 °C
Access Setting range Factory
Min / Max setting
BE HF
E E 10 - 70°C 48 °C
E E 10 - 70°C 48 °C
E E 10 - 70°C 48 °C
Increment
Increment
0.5 K
0.5 K
0.5 K
Increment
0.5 K
0.5 K
Increment
0.5 K
0.5 K
0.5 K
