  • Page 1 POWERED MN 00505-QRG09-CAMH Printed in the USA 1/08...
  • Page 2 Interactive Owner’s Guide Trunk-Internal release Have a question about the main features of your new Toyota? Find the answers quickly and easily in this Quick Reference Guide, which Pull up includes highlights from the Owner’s Manual. For more detailed information, and helpful interactive demonstrations and tips, visit www.Toyotaiguide.com.

  • Page 3: Table Of Contents

    Seat belts Seat belts-Shoulder belt anchor Spare tire & tools Tire Pressure Warning System Trunk-Internal release Visit your Toyota dealer for information on customizing this feature. Programmable by customer. Refer to the Owner’s Manual for instructions and more information. ® HomeLink...
  • Page 4 OVERVIEW Instrument panel Steering wheel controls Steering wheel audio controls Steering wheel climate controls Multi-information display button Voice command button Telephone controls Headlight and turn signal controls Wiper and washer controls Emergency flasher button Audio system or navigation system with integrated audio system Air Conditioning controls Tire Pressure Warning System reset (in glove box) Rear window and outside rearview mirror defogger switch...
  • Page 5 AUX audio jack Seat heater controls “POWER” switch Cruise control Tilt and telescopic steering lock release Auxiliary boxes Air Conditioning/Heating economy (ECO) mode switch Fuel filler door opener Power outside rearview mirror controls If equipped For details, refer to the “Navigation System Owner’s Manual.”...

  • Page 6: Instrument Cluster

    OVERVIEW Instrument cluster Engine coolant temperature Service indicator and reminder Fuel economy meter Gear shift position indicator Speedometer Fuel gauge Trip meter reset knob/Instrument panel light control Multi-information display Driving ready light...

  • Page 7: Indicator Symbols

    Anti-lock Brake System warning If indicator does not turn off within a few seconds of starting engine, there may be a malfunction. Have vehicle inspected by your Toyota dealer. If this light flashes, refer to “Cruise control,” Section 2-4, 2009 Owner’s Manual.

  • Page 8: Keyless Entry 1

    OVERVIEW Keyless entry Locking operation Push Unlocking operation Push ONCE: Driver door TWICE: All doors NOTE: If a door is not opened within 60 seconds of unlocking, all doors will relock for safety. Trunk lid operation Push and hold Panic button Push and hold...
  • Page 9 Smart Key system* Start function Green indicator ON Depress Push Carrying brake pedal NOTE: Gear shift lever must be in “Park” and brake pedal depressed. Power (without starting Hybrid System) Without depressing the brake pedal, pressing the “POWER” switch will change the operation mode in succession from: Accessories such as the radio will operate.

  • Page 10: Fuel Tank Door Release And Cap

    OVERVIEW Fuel tank door release and cap Push* Turn * It may take up to 10 seconds after pushing button for the door to Store open if the internal tank pressure is high. NOTE: Tighten until one click is heard. If the cap is not tightened enough, Check Engine “...

  • Page 11: Engine Maintenance

    Hood release Pull Pull up latch and raise hood Engine maintenance Engine oil filler cap Engine oil level dipstick Windshield washer fluid tank Engine coolant reservoir Note: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance. Please refer to the “Owner’s Warranty Information Booklet,”...

  • Page 12: Hybrid Synergy Drive System

    FEATURES/OPERATIONS Hybrid Synergy Drive System The Hybrid Synergy Drive System utilizes a computer controlled gasoline engine and electric motor to provide the most efficient combination of power for the vehicle. To conserve energy, when the brakes are applied the braking force generates electricity which is then sent to the traction battery.

  • Page 13: Auto Lock Functions 2

    Auto lock functions Automatic door locks can be programmed to operate in four different modes, or turned OFF. -Doors lock when shifting from “Park.” -Doors lock when the vehicle speed goes above approximately 12 mph. -Doors unlock when shifting into “Park.” -Doors unlock when the “POWER”...

  • Page 14: Parking Brake

    FEATURES/OPERATIONS Tilt and telescopic steering wheel Angle Length Lock release lever Hold wheel, push lever down, set angle and length, and return lever. Note: Do not attempt to adjust while the vehicle is in motion. Parking brake Set: Depress Release: Depress again Windows-Power Window lock switch Driver side...

  • Page 15: Windshield Wipers & Washers

    Windshield wipers & washers Adjust interval Single wipe Interval wipe Slow Fast Pull to wash and wipe Lights & turn signals Headlights Headlights Parking lights Auto DRL OFF High beam Low beam High beam flasher -Daytime Running Light system (DRL) Automatically turns on the turn signal lights at a reduced intensity.

  • Page 16: Seat Adjustments-Front

    FEATURES/OPERATIONS Seat adjustments-Front Manual seat Power seat Seatback angle Position Lumbar support (driver side only) Position, cushion angle and height (driver side only) Seats-Head restraints Lock release button Seats-Folding rear seats Pull Fold down...

  • Page 17: Cruise Control

    Refer to “Garage door opener,” Section 3-6 in the Owner’s Manual for more details. For programming assistance, contact the Toyota Customer Experience Center at 1-800-331-4331, or visit http://www.homelink.com. * HomeLink ® is a registered trademark of Johnson Controls, Inc.

  • Page 18: Telephone Controls (Bluetooth ® )

    FEATURES/OPERATIONS Telephone controls (Bluetooth ® (if equipped) Audio unit Microphone Steering wheel telephone switches Volume Voice command End call button Start call ® Bluetooth technology allows you to place or receive calls without taking your hands from the steering wheel or using a cable to connect the compatible telephone and the system.

  • Page 19: Moonroof

    Multi-information display Push “DISP” to change information in the following: (1) Outside temperature (2) Miles left on remaining fuel (3) Current gas mileage (4) Running distance from engine start (5) Average vehicle speed from engine start (6) Multi-information display OFF (7) Zoom display of odometer and trip meter (8) Energy monitor (9) Average gas mileage...
  • Page 20 FEATURES/OPERATIONS Audio Type 1 Push to adjust Eject CD tone & balance Push to turn ON/OFF Push to skip up/down folder Mode Seek station/ CD track select View CD text Preset buttons - functions in other modes indicated above number Station/CD track scan Type 2 other functions...

  • Page 21: Steering Wheel Switches

    RADIO To preset stations Tune in the desired station and hold down a preset button (1-6) until you hear a beep. Push desired preset button (1-6) to select. To scan stations Push and hold “SCAN” to scan preset stations. Push again to hold selection.
  • Page 22 FEATURES/OPERATIONS Air Conditioning/Heating “DUAL” button Indicator ON: Separate temperature settings for driver and passengers. Indicator OFF: Synchronize temperature settings for driver and passengers. Temperature (driver side) Fan speed Airflow vent In “ ” or “ ” mode, use fresh air (“ ”...

  • Page 23: Clock

    “ECO HEAT/COOL” switch Economical mode ON/OFF NOTE: Slightly improves gas mileage. It may take longer to reach set cabin temperature. Plasmacluster Improves air quality by emitting positive and negative ions into the cabin. This system operates from the driver side vent and a low system noise is normal.

  • Page 24: Cup Holders

    FEATURES/OPERATIONS Door locks Unlock Lock Power outlets Instrument panel Center console “POWER” switch must be set at “ACC” or “ON” to be used. Cup holders Front Rear...

  • Page 25: Doors-Child Safety Locks

    SAFETY AND EMERGENCY FEATURES Doors-Child safety locks Rear door Moving the lever to “LOCK” will allow the door to be opened only from the outside. Seat belts Take up slack Too high Keep as low on hips as possible If belt is fully extended, then retracted even slightly, it cannot be re-extended beyond that point, unless fully retracted again.

  • Page 26: Child Comfort Guide

    SAFETY AND EMERGENCY FEATURE Seat belts-Shoulder belt anchor Push up, or squeeze lock release to lower Child comfort guide Rear seat outside position guides provide added comfort for children who have outgrown child restraints. Tire Pressure Warning System System reset initialization 1.
  • Page 27 Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Air Conditioning Anti-Lock Brake System Automatic Locking Retractor Calibration Child Restraint System DISP Display Economical/Ecology Electronic Control Unit Event data recorder Emergency Locking Retractor Electric Power Steering GAWR Gross Axle Weight Ratings GVWR Gross Vehicle Weight Rating Emission inspection and maintenance Intermittent Light Emitting Diode...
  • Page 28 TABLE OF CONTENTS Index 1-7. Theft deterrent system..83 Before driving Immobilizer system....83 Theft prevention labels (for U.S.A.) ......85 1-1. Hybrid system ....22 Hybrid system ...... 22 1-8. Safety information ....86 Correct driving posture ..86 1-2.
  • Page 29 2-4. Using other driving 3-3. Using the hands-free systems ......155 phone system (for cellular phone)..213 Cruise control...... 155 Hands-free phone system Driving assist systems ..158 (for cellular phone) features (CD player with 2-5. Driving information... 162 changer only) ....213 Cargo and luggage .....
  • Page 30 TABLE OF CONTENTS Index Trunk features ....263 When trouble arises Garage door opener... 264 Compass ......269 5-1. Essential information ..342 If your vehicle needs to Maintenance and care be towed ......342 If you think something is wrong........
  • Page 31 Vehicle specifications 6-1. Specifications....396 Maintenance data (fuel, oil level, etc.).... 396 Fuel information ....406 Tire information ....409 6-2. Customization ....421 Customizable features ..421 6-3. Initialization ....... 424 Items to initialize ....424 For owners Reporting safety defects for U.S.

  • Page 32: For Your Information

    A wide variety of non-genuine spare parts and accessories for Toyota vehicles are currently available on the market. You should know that these parts are not covered by Toyota warranty and that Toyota is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
  • Page 33 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
  • Page 34 CAUTION General precautions while driving Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that will hurt or kill you, your occupants or others.
  • Page 35 In the event that your vehicle must be disposed of, the hybrid battery must be disposed of by your Toyota dealer or a qualified service shop. If the hybrid battery is not disposed of properly, it...
  • Page 36 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.

  • Page 37: Before Driving

    TABLE OF CONTENTS Information on the hybrid system and adjusting and op- Before driving erating features such as door locks, mirrors, and steer- ing column. When driving Driving, stopping and safe-driving information. Interior fea- Air conditioning and audio systems, as well as other in- tures terior features for a comfortable driving experience.
  • Page 38 Pictorial index Exterior Headlights (low beam) Turn signal/parking lights P. 149 P. 137, 149 ∗ Moon roof P. 75 Headlights (high beam) P. 149 Outside rear view Hood P. 288 mirrors P. 71 Side marker light P. 149 Windshield wipers P.
  • Page 39 Rear window defogger P. 182 Rear turn signal lights P. 137 Fuel filler door P. 78 Trunk P. 54 Doors P. 50 Tail lights P. 149 Tires Rotation P. 304 Replacement P. 368 Inflation pressure P. 404 Tail and rear side marker lights P.
  • Page 40 Pictorial index Interior Head restraints P. 59 SRS driver airbag P. 88 Floor mat P. 262 Seat belts P. 60 Power window SRS front passenger switches P. 73 airbag P. 88 Glove box P. 248 Armrest P. 261 Front seats P.
  • Page 41 Vehicles with moon roof Vanity mirrors P. 254 Sun visors P. 253 Auxiliary box P. 251 Moon roof switches P. 75 Front personal lights P. 246 Interior light P. 245 SRS curtain shield airbags P. 88 Rear personal lights P. 246 ∗...
  • Page 42 Pictorial index Interior Vehicles without moon roof Vanity mirrors P. 254 Sun visors P. 253 Auxiliary box P. 251 Front personal lights P. 246 SRS curtain shield airbags P. 88 Interior light P. 245 ∗ Garage door opener switches P. 264 Anti-glare inside rear view mirror P.
  • Page 43 Power window switches P. 73 Door lock switch P. 50 Window lock switch P. 73 Inside door lock button P. 50 ∗ : If equipped...
  • Page 44 Pictorial index Instrument panel Gauges and meters P. 139 Windshield wiper and Multi-information display P. 145 washer switch P. 153 Audio system P. 183 Headlight switch P. 149 Navigation system * Turn signal lever P. 137 Emergency flashers Clock P. 255 Outside rear view Security indicator P.
  • Page 45 Air conditioning system P. 174 ∗ Rear window defogger switch Rear window defogger switch and ∗ outside rear view mirror defogger switch P. 182 ∗ : If equipped : Refer to “Navigation System Owner’s Manual”.
  • Page 46 Pictorial index Instrument panel Audio remote control Air conditioning remote switches P. 211 control switches P. 179 ∗ Telephone switches P. 217 “DISP” switch P. 146 ∗ Talk switch P. 217 Cruise control switch P. 155 Power (ignition) switch P. 131...
  • Page 47 AUX adapter P. 210 Power outlet P. 257 Cable pass-through P. 252 ∗ Seat heater switches P. 259 ∗ : If equipped : For vehicles with a navigation system, refer to “Navigation System Owner’s Manual”.

  • Page 48: Hybrid System

    1-1. Hybrid system Hybrid system Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the char- acteristics of your vehicle, and operate with care. The hybrid system combines a gasoline engine and an electric motor (traction motor) according to driving conditions, improving fuel efficiency and reducing exhaust emissions.
  • Page 49 30 minutes or 10 miles (16 km). If the hybrid battery becomes fully discharged, you are unable to jump-start the vehi- cle with the 12-volt battery, contact your Toyota dealer. If the shift lever is in N, the hybrid battery (traction battery) will not be charged.
  • Page 50 After the 12-volt battery has discharged or has been changed or removed The gasoline engine may not stop even if the vehicle is running on the hybrid battery (traction battery). If this continues for a few days, contact your Toyota dealer. Sounds and vibrations specific to a hybrid vehicle There may be no engine sounds or vibration even though the vehicle is able to move.
  • Page 51 1-1. Hybrid system High voltage components Air conditioning compressor Electric motor (traction motor) and transaxle Power control unit Caution label High voltage cables Hybrid battery (traction bat- tery) and DC/DC converter Take care when handling the hybrid system, as it contains a high volt- age system (about 650V at maximum) as well as parts that become extremely hot when the hybrid system is operating.
  • Page 52 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer. Energy monitor/consumption screen You can view the status of your hybrid system on the multi-infor- mation display (→P.
  • Page 53 1-1. Hybrid system Energy monitor l How to display on the navigation system screen (if equipped): Press “INFO”. STEP Touch “Trip information” on the STEP “Information” screen. If the “Consumption” screen is displayed, touch l How to display on the multi-information display: Press the “DISP”...
  • Page 54 1-1. Hybrid system Multi-information Navigation system screen display When the vehi- cle is powered by both the gas- oline engine and the electric motor (traction motor) When the vehi- cle is powered by the gasoline engine When the vehi- cle is charging the hybrid bat- tery (traction battery)
  • Page 55 1-1. Hybrid system Consumption (navigation system only) Press “INFO”. STEP Touch “Trip information” on the STEP “Information” screen. If the “Energy Monitor” screen is displayed, touch Fuel consumption in the past 30 minutes Regenerated energy in the past 30 minutes One symbol indicates 50 Wh.
  • Page 56 The hybrid system may not start. In that case, try to start the system again. If the “READY” indicator does not come on, contact your Toyota dealer. When refueling, the fuel filler door may take a few moments to open As part of emission system operation, it may take up to 10 seconds for the fuel filler door to automatically release after the opener switch is pressed.
  • Page 57 1-1. Hybrid system CAUTION High voltage precautions The vehicle has high voltage DC and AC systems as well as a 12-volt sys- tem. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury. Never touch, disassemble, remove or replace the high voltage parts, cables and their connectors.
  • Page 58 1-1. Hybrid system CAUTION Road accident cautions Observe the following precautions to reduce the risk of injury. Pull your vehicle off the road, put the shift lever in P, apply the parking brake, and turn the hybrid system off. Do not touch the high voltage parts, cables and connectors. If electric wires are exposed inside or outside your vehicle, an electric shock may occur.
  • Page 59 1-1. Hybrid system NOTICE Hybrid battery air vent Do not put foreign objects over the air vent. The hybrid battery (traction battery) may overheat and be damaged. Clean the air vent regularly to prevent the hybrid battery (traction battery) from overheating. Do not wet the air vent.

  • Page 60: Key Information

    Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (→P. 381)
  • Page 61 1-2. Key information NOTICE To prevent key damage Do not subject the keys to strong shocks, expose them to high tempera- tures by placing them in direct sunlight, or get them wet. Do not expose the keys to electromagnetic materials or attach any mate- rial that blocks electromagnetic waves to the key surface.

  • Page 62: Opening, Closing And Locking The Doors

    1-3. Opening, closing and locking the doors Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Locks and unlocks the doors (→P. 37) Unlocks the trunk (→P.
  • Page 63 1-3. Opening, closing and locking the doors Locking and unlocking the doors (front door handles only) Press the lock button to lock the door. Grip the handle to unlock the door. Make sure to touch the sensor on the back of the handle. The door cannot be unlocked for 3 seconds after the door is locked.
  • Page 64 1-3. Opening, closing and locking the doors Antenna location and effective range Antenna location Antennas outside the cabin Antenna outside the trunk Antenna inside the trunk Antennas inside the cabin...
  • Page 65 1-3. Opening, closing and locking the doors Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) of either of the outside front door handles.
  • Page 66 1-3. Opening, closing and locking the doors Operation signals A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system and wireless remote control from operating properly.
  • Page 67 1-3. Opening, closing and locking the doors The setting changes each time an operation is performed, as shown below. (When changing the setting continuously, release the buttons, wait for at least 5 seconds, and repeat step 2.) Multi-information Unlocking doors Beep display Hold the driver's door han-...
  • Page 68 1-3. Opening, closing and locking the doors Electronic key battery depletion The standard battery life is 1 to 2 years. (The battery becomes depleted even if the electronic key is not used.) If the smart key system or the wireless remote control function does not operate, or the detection area becomes smaller, the battery may be depleted.
  • Page 69 1-3. Opening, closing and locking the doors The doors may unlock if a large amount of water splashes on the door handle, such as in the rain or in a car wash. (The doors will automatically be locked after approximately 60 seconds if the doors are not opened and closed.) Gripping the door handle when wearing a glove may not unlock the door.
  • Page 70 1-3. Opening, closing and locking the doors The following table describes circumstances and correction procedures when only alarms are sounded. Alarm Situation Correction procedure Tried to lock the doors Retrieve the elec- using the entry function tronic key from the while the electronic key is passenger compart- still inside the passenger...
  • Page 71 Starting the hybrid system:→P. 383 When the electronic key battery is fully depleted →P. 322 Customization that can be configured at Toyota dealer It is possible to deactivate the smart key system, etc. (Customizable features →P. 421) Certification for the smart key system For vehicles sold in the U.S.A.
  • Page 72 (→P. 38) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves.

  • Page 73: Wireless Remote Control

    1-3. Opening, closing and locking the doors Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle from outside the vehicle. Locks all doors Unlocks all doors Unlocks the trunk (press and hold) Sounds an alarm (press and hold) 2-step unlocking function...
  • Page 74 When the electronic key battery is fully depleted →P. 322 Conditions affecting operation →P. 40 Customization that can be configured at Toyota dealer Settings (e.g. trunk unlocking function) can be changed. (Customizable fea- tures →P. 421) Certification for wireless remote control For vehicles sold in the U.S.A.
  • Page 75 1-3. Opening, closing and locking the doors NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 76: Doors

    1-3. Opening, closing and locking the doors Doors The vehicle can be locked and unlocked using the entry function, wireless remote control, key or door lock switch. Entry function →P. 37 Wireless remote control →P. 47 Door lock switch Locks all doors Unlocks all doors Inside lock button Unlocks the door...
  • Page 77 1-3. Opening, closing and locking the doors Locking the front doors from the outside without a key The door cannot be locked if the “POWER” switch is in ACCESSORY or ON mode, or the electronic key is left inside the vehicle. Depending on the position of the electronic key, the key may not be detected correctly and the door may be locked.
  • Page 78 1-3. Opening, closing and locking the doors Setting and canceling the functions To switch between set and canceled, follow the procedure below: STEP Close all the doors and switch the “POWER” switch to ON mode. (Perform step 2 within 10 seconds.) STEP Shift the shift lever to P or N, and press and hold the driver's door lock switch (...
  • Page 79 1-3. Opening, closing and locking the doors Customization that can be configured at Toyota dealer Settings (e.g. unlocking function using a key) can be changed. (Customiz- able features →P. 421) CAUTION To prevent an accident Observe the following precautions while driving the vehicle.

  • Page 80: Trunk

    1-3. Opening, closing and locking the doors Trunk The trunk can be opened using the key, trunk opener, entry function or wireless remote control. Trunk opener Release the trunk lid. Entry function →P. 37 Wireless remote control →P. 47 Luggage security system To protect luggage stored in the trunk against theft, do the following procedure.
  • Page 81 1-3. Opening, closing and locking the doors Internal trunk release lever The trunk lid can be opened by pulling down on the glow-in-the-dark lever located on the inside of trunk lid. The lever will continue to glow for some time after the trunk lid is closed. Trunk light The trunk light turns on when the trunk is opened.

  • Page 82: Adjustable Components (Seats, Mirrors, Steering Wheel)

    1-4. Adjustable components (seats, mirrors, steering wheel) Front seats Power seat Seat position switch Seatback angle switch Seat cushion (front) angle switch (driver’s side only) Vertical height adjustment switch (driver’s side only) Lumbar support switch (driver’s side only)
  • Page 83 1-4. Adjustable components (seats, mirrors, steering wheel) Manual seat Seatback angle adjustment lever Seat position adjustment lever CAUTION Seat adjustment Do not recline the seat more than necessary when the vehicle is in motion to reduce the risk of sliding under the lap belt. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of...

  • Page 84: Rear Seats

    1-4. Adjustable components (seats, mirrors, steering wheel) Rear seats Folding down rear seatbacks Pull the seatback lever in the trunk for the seatback you wish to fold down. CAUTION After returning the seatback to the upright position Observe the following precautions. Failure to do so may result in death or serious injury.

  • Page 85: Head Restraints

    1-4. Adjustable components (seats, mirrors, steering wheel) Head restraints Vertical adjustment Push and hold the lock release button when lowering the head Lock restraint. release Removal button Pull the head restraint up while pressing the lock release but- ton. Adjusting the height of the head restraints Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears.

  • Page 86: Seat Belts

    1-4. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. Correct use of the seat belts l Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
  • Page 87 1-4. Adjustable components (seats, mirrors, steering wheel) Adjusting the height of the belt (front seats) Down Move the height adjuster up and down as needed until you hear a click. Seat belt comfort guide (outside rear seat) If the shoulder belt fits close to a person's neck, use the seat belt comfort guide.
  • Page 88 1-4. Adjustable components (seats, mirrors, steering wheel) Buckle, position and release the STEP seat belt. Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal collision.
  • Page 89 1-4. Adjustable components (seats, mirrors, steering wheel) Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
  • Page 90 Toyota dealer free of charge. Rear seat belts Use the seat belt after passing it through the guide if the seat belt comes free from...
  • Page 91 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system.
  • Page 92 Ensure that the belt and tab are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
  • Page 93 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION Using a seat belt extender Do not wear the seat belt extender if you can fasten the seat belt without the extender. Do not use the seat belt extender when installing a child restraint system because the belt will not securely hold the child restraint system, increas- ing the risk of death or injury in the event of a collision.

  • Page 94: Steering Wheel

    1-4. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. STEP Hold steering wheel and press the lever down. STEP Adjust to the ideal position by moving the steering wheel hori- zontally and vertically.

  • Page 95: Anti-Glare Inside Rear View Mirror

    1-4. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions. Manual anti-glare inside rear view mirror Normal position Anti-glare position Auto anti-glare inside rear view mirror In automatic mode, sensors are used to detect the headlights of vehicles behind and the reflected light is automatically reduced.
  • Page 96 1-4. Adjustable components (seats, mirrors, steering wheel) To prevent sensor error To ensure that the sensors operate prop- erly, do not touch or cover them. CAUTION Caution while driving Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and an accident, resulting in death or serious injury.

  • Page 97: Outside Rear View Mirrors

    1-4. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch when the “POWER” switch is in ACCESSORY or ON mode. Select a mirror to adjust. STEP Left Right Adjust the mirror. STEP Right Down...
  • Page 98 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION When driving the vehicle Observe the following precautions while driving. Failing to do so may result in loss of control of the vehicle and cause an acci- dent, resulting in death or serious injury. Do not adjust the mirrors while driving.
  • Page 99 1-5. Opening and closing the windows Power windows The power windows can be opened and closed using the following switches. Close Open One-touch open (driver’s window only) Pressing the switch in the opposite direction will stop win- dow travel partway. Lock switch Press the switch down to lock passenger window switches.
  • Page 100 1-5. Opening and closing the windows The power windows can be operated when The “POWER” switch is in ON mode. Operating the power windows after turning the hybrid system off The power windows can be operated for approximately 45 seconds after the “POWER”...

  • Page 101: Opening And Closing The Windows

    1-5. Opening and closing the windows Moon roof (if equipped) Use the overhead switches to open, close, and tilt the moon roof up and down. Opening and closing Open The moon roof stops slightly before the fully open position. Push the switch again to fully open.
  • Page 102 1-5. Opening and closing the windows The moon roof can be operated when The “POWER” switch is in ON mode. Operating the moon roof after turning the hybrid system off The moon roof can be operated for approximately 45 seconds after the “POWER”...
  • Page 103 1-5. Opening and closing the windows CAUTION Opening the moon roof Observe the following precautions. Failing to do so may cause death or serious injury. Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving. Do not sit on top of the moon roof.

  • Page 104: Refueling

    1-6. Refueling Opening the fuel tank cap The fuel tank of your vehicle has a special structure, which requires a reduction in fuel tank pressure before refueling. After the opener switch has been pressed, it will take several seconds until the vehi- cle is ready for refueling.
  • Page 105 1-6. Refueling If the pressure in the fuel tank high, message “PLEASE WAIT OPENING” will appear on the multi-information display. may take up to 10 seconds. Turn the fuel tank cap slowly STEP to open. Hang the fuel tank cap on the STEP back of the fuel filler door.
  • Page 106 When the fuel filler door opener is inoperable If the fuel filler door opener switch cannot be operated, contact your Toyota dealer to service the vehicle. In cases where refueling is urgently necessary, the fuel filler door can be opened using the lever in the trunk.
  • Page 107 This may cause static electricity to build up, resulting in a possible ignition hazard. When replacing the fuel cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
  • Page 108 1-6. Refueling NOTICE Refueling Finish refueling within 30 minutes. If more than 30 minutes passes, the internal valve closes. In this condition, fuel may spill out if you continue to refuel the vehicle. About 5 minutes after the valve is closed, a message “CLOSE FUEL LID”...

  • Page 109: Theft Deterrent System

    1-7. Theft deterrent system Immobilizer system The vehicle's keys have built-in transponder chips that prevent the hybrid system from starting if the key has not been previously regis- tered in the vehicle's on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. The indicator light flashes after the “POWER”...
  • Page 110 1-7. Theft deterrent system Certifications for the immobilizer system For vehicles sold in Canada This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, includ- ing interference that may cause undesired operation of the device.

  • Page 111: Theft Prevention Labels (For U.s.a.)

    1-7. Theft deterrent system Theft prevention labels (for U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from sto- len vehicles. Do not remove under penalty of law.

  • Page 112: Safety Information

    1-8. Safety information Correct driving posture Drive in a good posture as follows: Sit upright and well back in the seat. (→P. 56) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
  • Page 113 1-8. Safety information CAUTION While driving Do not adjust the position of the driver's seat while driving. Doing so could cause the driver to lose control of the vehicle. Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.

  • Page 114: Srs Airbags

    1-8. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
  • Page 115 1-8. Safety information Airbag system components Front airbag sensors Front passenger’s seat belt buckle switch Front passenger occupant classification system (ECU Airbag sensor assembly and sensors) Curtain shield airbag sen- Side and curtain shield air- sors bag sensors Driver airbag Front passenger airbag Driver’s seat position sen- Side airbags...
  • Page 116 1-8. Safety information The main SRS airbag system components are shown above. The SRS airbag system is controlled by the airbag sensor assembly. The airbag sensor assembly consists of a safing sensor and an airbag sensor. In certain types of severe frontal or side impacts, the SRS airbag sys- tem triggers the airbag inflators.
  • Page 117 1-8. Safety information SRS warning light This warning light system monitors the airbag sensor assembly, front airbag sensors, side and curtain shield airbag sensors, curtain shield airbag sen- sors, driver's seat position sensor, driver's seat belt buckle switch, front pas- senger occupant classification system, “AIR BAG ON”...
  • Page 118 1-8. Safety information Operating conditions (side airbags and curtain shield airbags) The SRS side airbags and curtain shield airbags are designed to inflate when the passenger compartment is subjected to a severe impact from the side. The SRS side airbag on the passenger seat will not activate if there is no passenger sitting in the front passenger seat.
  • Page 119 1-8. Safety information Types of collisions that may not deploy the SRS airbag (side airbags and curtain shield airbags) The SRS side airbags and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a col- lision to the side of the vehicle body other than the passenger compartment.
  • Page 120 1-8. Safety information When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. Do not disconnect the 12-volt battery cables before contacting your Toyota dealer. Any of the SRS airbags have been inflated.
  • Page 121 1-8. Safety information CAUTION SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts. The SRS driver airbag deploys with considerable force, and can cause death or serious injury especially if the driver is very close to the airbag.
  • Page 122 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are the safest for infants and children.
  • Page 123 1-8. Safety information CAUTION SRS airbag precautions Do not allow a child to sit on the knees of a front passenger while the vehicle is moving. Do not drive the vehicle while the driver or passenger has items resting on their knees.
  • Page 124 1-8. Safety information CAUTION SRS airbag precautions Do not attach anything to areas such as the door, windshield glass, side door glass, front and rear pillars, roof side rail or assist grip. Do not hang coat hangers or other hard objects on the coat hooks.
  • Page 125 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillars garnishes, are damaged or cracked, have them replaced by your Toyota dealer. Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer.

  • Page 126: Front Passenger Occupant Classification System

    1-8. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for the front passenger.
  • Page 127 1-8. Safety information Conditions and operation of the front passenger occupant classification system Adult* “AIR BAG ON” and “AIR BAG OFF” indi- “AIR BAG cator lights ON” Indicator/ SRS warning light warning light Front passenger’s seat belt reminder light Flashing Front passenger airbag Side airbag on the front passenger seats...
  • Page 128 1-8. Safety information Unoccupied “AIR BAG ON” and “AIR BAG OFF” indi- Not illuminated cator lights Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seats Devices Curtain shield airbag in the front Activated passenger side...
  • Page 129 1-8. Safety information *4: Never install a rear-facing child restraint system on the front pas- senger seat. A forward-facing child restraint system should only be installed on the front passenger seat when it is unavoidable. (→P. 105) *5: In case the indicator is not illuminated, consult this manual as for installing the child restraint system properly.
  • Page 130 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. Child restraint systems installed on the rear seat should not contact the front seatbacks.

  • Page 131: Child Restraint Systems

    1-8. Safety information Child restraint systems A child restraint system for a small child or baby must be properly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of U.S.A. and Canada now require the use of child restraint systems.
  • Page 132 1-8. Safety information Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child. Infant seat Convertible seat Booster seat...
  • Page 133 In an accident, the child can be crushed against the windshield, or between you and the vehicle's interior. Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
  • Page 134 1-8. Safety information CAUTION Child restraint precautions Never install a rear-facing child restraint system on the front passenger seat even if the “AIR BAG OFF” indicator light is illuminated. In the event of an accident, the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child if the rear-facing child restraint system is installed on the front passenger seat.

  • Page 135: Installing Child Restraints

    1-8. Safety information Installing child restraints Follow the child restraint system manufacturer's instructions. Firmly secure child restraints to the rear seats using a seat belt or a child restraint lower anchorage. Attach the top strap when installing a child restraint. Seat belts equipped with a child restraint locking mecha- nism (ALR/ELR belts except...
  • Page 136 1-8. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear facing ⎯ Infant seat/convertible seat Place the child seat on the rear STEP seat facing the rear of the vehi- cle. Run the seat belt through the STEP child seat and insert the plate into the buckle.
  • Page 137 1-8. Safety information While pushing the child seat STEP down into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that in cannot be extended.
  • Page 138 1-8. Safety information While pushing the child seat into STEP the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
  • Page 139 1-8. Safety information Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Installation with child restraint lower anchorages Type A STEP Widen the gap between the seat cushion and seatback slightly.
  • Page 140 1-8. Safety information Type B STEP Widen the gap between the seat cushion and seatback slightly. STEP Latch the buckles onto the anchorages. If the child restraint has a top strap, the top strap should be latched onto the anchorages. For owners in Canada: A symbol on a restraint system indicates the presence of a lower...
  • Page 141 1-8. Safety information Child restraint systems with a top strap Secure the child restraint using STEP the seat belt lower anchors, and lock the head restraint in place at the lowest position. Open the anchor bracket cover, STEP latch the hook onto the anchor bracket and tighten the top strap.
  • Page 142 1-8. Safety information CAUTION When installing a booster seat Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode: (→P. 63) ALR mode causes the belt to tighten only which could cause injury or dis- comfort to the child.
  • Page 143 1-8. Safety information CAUTION When installing a child restraint system When a booster seat is installed, always ensure that the shoulder belt is positioned across the center of the child's shoulder. The belt should be kept away from the child's neck, but not so that it could fall off the child's shoulder.
  • Page 144 1-8. Safety information...

  • Page 145: Driving Procedures

    2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. Starting the hybrid system (→P. 131) Driving STEP With the brake pedal depressed, shift the shift lever to D. (→P. 135) STEP Release the parking brake. (→P.
  • Page 146 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or when- ever the parking brake shoes and/or drum are replaced. Have your Toyota dealer perform the bedding down.
  • Page 147 2-1. Driving procedures For efficient use Put the shift lever into D when driving In the N position, the gasoline engine operates but electricity cannot be generated. The hybrid battery (traction battery) will be discharged requir- ing unnecessary engine power to recharge. Drive your vehicle smoothly Avoid abrupt acceleration and deceleration.
  • Page 148 If they do not work well, depress the brake pedal firmly. If the brake system warning light comes on, immediately stop your vehicle and contact your Toyota dealer. In the following conditions, you may hear a sound in the engine compart- ment.
  • Page 149 2-1. Driving procedures CAUTION When starting the vehicle Always keep your foot on the brake pedal while stopped with the hybrid sys- tem operating. This prevents the vehicle from creeping. When driving the vehicle Do not drive if you are unfamiliar with the location of the brake and accel- erator pedals to avoid depressing the wrong pedal.
  • Page 150 Large amounts of exhaust in the vehicle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immedi- ately. Do not under any circumstances shift the shift lever to P or R while the vehicle is moving.
  • Page 151 2-1. Driving procedures CAUTION When driving on slippery road surfaces Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle, resulting in an accident. Sudden changes in braking force, such as engine braking and regenera- tive braking caused by shifting the shift lever to the B position, may cause the vehicle to skid, resulting in an accident.
  • Page 152 The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in...
  • Page 153 2-1. Driving procedures CAUTION When taking a nap in the vehicle Always turn the hybrid system off. Otherwise, you may accidentally move the shift lever or depress the accelerator pedal, which could cause an accident or fire due to hybrid system overheating. Additionally, if the vehicle is parked in a poorly ventilated area, exhaust gases may collect and enter the vehicle, leading to death or a serious health hazard.
  • Page 154 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage can result if the pads are not replaced when needed.
  • Page 155 Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following. Brake function Changes in quantity and quality of oil and fluid used for the engine, hybrid system transaxle, etc.

  • Page 156: Power (Ignition) Switch

    2-1. Driving procedures Power (ignition) switch Modes can be switched by pressing the “POWER” switch when car- rying the electronic key on your person. (The hybrid system can be started in any mode by operating the “POWER” switch at the same time as depressing the brake pedal.) Starting the hybrid system STEP...
  • Page 157 2-1. Driving procedures Changing “POWER” switch mode OFF* Emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can be used. The “POWER” switch indicator turns amber. ON mode All electrical components can be used. The “POWER”...
  • Page 158 If the “READY” indicator does not come on when you press the “POWER” switch with the shift lever in P and the brake pedal depressed, contact your Toyota dealer immediately. Auto power off function If the vehicle is left in ACCESSORY mode for more than an hour with the shift lever in P, the “POWER”...
  • Page 159 2-1. Driving procedures When the electronic key battery is discharged →P. 322 Conditions affecting operation →P. 40 Note for the smart key system →P. 42 CAUTION When starting the hybrid system Always start the hybrid system while sitting in the driver's seat. Do not depress the accelerator pedal while starting the hybrid system under any cir- cumstances.

  • Page 160: Transmission

    2-1. Driving procedures Transmission Select a shift position appropriate for the driving conditions. Shifting the shift lever While the “POWER” switch is in ON mode, depress brake pedal and move the shift lever.
  • Page 161 2-1. Driving procedures Shift position uses Shift position Function Parking the vehicle or starting the hybrid system Reversing Neutral Normal driving Position for engine braking When in heavy traffic If the shift lever is in N, the hybrid battery (traction battery) will not be charged.

  • Page 162: Turn Signal Lever

    2-1. Driving procedures Turn signal lever Left turn Right turn Move and hold the lever partway to signal a lane change. The left hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change.

  • Page 163: Parking Brake

    2-1. Driving procedures Parking brake Sets the parking brake* (Depressing the pedal again U.S.A. Canada releases the parking brake.) *: Fully depress the parking brake pedal with your left foot while depressing the brake pedal with your right foot. NOTICE Before driving Fully release the parking brake.

  • Page 164: Instrument Cluster

    2-2. Instrument cluster Gauges and meters The following gauges, meters and displays illuminate when the “POWER” switch is in ON mode. Engine coolant temperature gauge Displays the engine coolant temperature. Fuel economy meter Displays the current fuel consumption in analog form when the hybrid system is operating.
  • Page 165 2-2. Instrument cluster Instrument panel light control The brightness of the instrument panel lights can be adjusted. Brighter Darker When the headlight switch is turned on, the brightness will be reduced slightly unless the control dial is turned fully clockwise. Eco drive level The brightness of the arcs around the fuel economy...
  • Page 166 2-2. Instrument cluster NOTICE To prevent damage to the engine and its components The gasoline engine may be overheating if the engine coolant temperature gauge is in the red zone (H). In this case, immediately stop the vehicle in a safe place.

  • Page 167: Indicators And Warning Lights

    2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. Instrument cluster Center panel...
  • Page 168 2-2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Headlight indicator (→P. 137) (→P. 149) (U.S.A.) Headlight high beam Tail light indicator indicator (→P. 150) (→P. 149) (CANADA) Slip indicator SRS airbag on-off indi- (→P.
  • Page 169 Have the vehicle inspected by your Toyota dealer immediately if this occurs.

  • Page 170: Multi-Information Display

    2-2. Instrument cluster Multi-information display The multi-information display presents the driver with a variety of driving-related data, including the outside temperature. l Outside temperature dis- play (→P. 146) Indicates the outside tempera- ture. l Trip information (→P. 146) Displays driving range, fuel consumption and other cruis- ing-related information.
  • Page 171 2-2. Instrument cluster Switch the display Display items can be switched by pressing the “DISP” button. The display will return to the out- side temperature display when the “DISP” button is pressed and held. l Outside temperature Displays the outside air temperature. The temperature range that can be displayed is from -40°F (-40°C) to 122°F (50°C).
  • Page 172 2-2. Instrument cluster l Driving distance Displays the driving distance since the hybrid sys- tem was started. l Average vehicle speed Displays the average vehicle speed since the hybrid system was started. l Cruise information off Displays the odometer and trip meters only. l Zoom display of odometer and trip meter Displays the odometer and one of the trip meters simultaneously.
  • Page 173 2-2. Instrument cluster NOTICE The multi-information display at low temperatures Allow the interior of the vehicle to warm up before using the liquid crystal information display. At extremely low temperatures, the information display monitor may respond slowly, and display changes may be delayed.

  • Page 174: Operating The Lights And Wipers

    2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. For U.S.A. The headlights and parking lights turn on and off automatically. (When the “POWER” switch is in ON mode) The side marker, park- ing, tail, license plate and instrument panel lights turn on.
  • Page 175 2-3. Operating the lights and wipers For Canada The side marker, park- ing, tail, license plate and instrument panel lights turn on. The headlights and all lights listed above turn The headlights and parking lights turn on and off automatically. (When the “POWER”...
  • Page 176 To turn the lights on again, turn the “POWER” switch to ON mode, or turn the headlight switch off and then back to the position. Customization that can be configured at Toyota dealer Settings of light sensor sensitivity can be changed. (Customizable features →P. 421)
  • Page 177 2-3. Operating the lights and wipers NOTICE To prevent the 12-volt battery from being discharged Do not leave the lights on longer than necessary when the hybrid system is off.

  • Page 178: Windshield Wipers And Washer

    2-3. Operating the lights and wipers Windshield wipers and washer Wiper intervals can be adjusted for intermittent operation (when “INT” is selected). Decreases the intermittent windshield wiper frequency Increases the intermittent windshield wiper frequency Intermittent windshield wiper operation Low speed windshield wiper operation High speed...
  • Page 179 2-3. Operating the lights and wipers NOTICE When the windshield is dry Do not use the wipers, as they may damage the windshield. When there is no washer fluid spray from the nozzle Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually.

  • Page 180: Using Other Driving Systems

    2-4. Using other driving systems Cruise control Use cruise control to maintain a set speed without using the acceler- ator. Set the vehicle speed STEP Press the “ON-OFF” button to activate the cruise control. Press the button once more to deactivate the cruise control.
  • Page 181 2-4. Using other driving systems Canceling and resuming regular acceleration Cancel Pull the lever towards you to cancel cruise control. The speed setting is also can- celed when the brakes are applied. Resume To resume cruise control and return to the set speed, push the lever up.
  • Page 182 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Contact your Toyota dealer and have your Toyota inspected. CAUTION To avoid operating the cruise control by mistake Keep the “ON-OFF”...

  • Page 183: Driving Assist Systems

    2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ABS (Anti-lock Brake System) Helps to prevent wheel lock when the brakes are applied suddenly, or if the brakes are applied while driving on a slippery road surface...
  • Page 184 2-4. Using other driving systems When VSC and TRAC are operating If the vehicle is in danger of slip- ping or the front wheels spin, the indicator flashes to indicate that VSC/TRAC have been engaged. A buzzer (intermittent) sounds to indicate that VSC is operating.
  • Page 185 2-4. Using other driving systems CAUTION ABS does not operate effectively when Tires with inadequate gripping ability are used (such as excessively worn tires on a snow covered road). The vehicle hydroplanes while driving at high speed on the wet or slick road.
  • Page 186 The ABS and VSC system will not function correctly if different tires are fitted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. Handling of tires and suspension Using tires with any kind of problem or modifying the suspension will affect...

  • Page 187: Driving Information

    2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. l Stow cargo and luggage in the trunk whenever possible. l Be sure all items are secured in place. l Be careful to keep the vehicle level. Placing the weight as far for- ward as possible helps maintain vehicle balance.
  • Page 188 Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. Example on your vehicle...
  • Page 189 2-5. Driving information CAUTION Storage precautions To prevent cargo and luggage from sliding forward during braking, do not stack anything in the enlarged trunk. Keep cargo and luggage low, as close to the floor as possible. Never allow anyone to ride in the enlarged trunk. It is not designed for passengers.

  • Page 190: Vehicle Load Limits

    Seating capacity means the maximum number of occupants whose estimated average weight is 150 lb. (68 kg) per person. Towing capacity Toyota does not recommend towing a trailer with your vehicle. Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.

  • Page 191: Winter Driving Tips

    2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. Pre-winter preparations l Use fluids that are appropriate to the prevailing outside tem- peratures.
  • Page 192 2-5. Driving information When driving the vehicle Accelerate the vehicle slowly and drive at a reduced speed suit- able to road conditions. When parking the vehicle Park the vehicle and move the shift lever to P without setting the parking brake. The parking brake may freeze up, preventing it from being released.
  • Page 193 2-5. Driving information Tire chains Observe the following precautions when installing and removing chains. Install and remove tire chains in a safe location. Install tire chains on the front tires only. Do not install tire chains on rear tires. Install tire chains following the instructions provided in the accompanying manual.
  • Page 194 2-5. Driving information NOTICE Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota dealers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.

  • Page 195: Trailer Towing

    Your Toyota is not designed for trailer towing or for the use of tow hitch mounted carriers.

  • Page 196: Dinghy Towing

    2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground.

  • Page 197: Using The Air Conditioning System And Defogger

    3-1. Using the air conditioning system and defogger Automatic air conditioning system Air outlets are automatically selected and fan speed is automatically adjusted according to the temperature setting. Front passenger’s side temperature Air outlet display setting display Driver’s side temperature setting display Fan speed Change the air outlets used...
  • Page 198 3-1. Using the air conditioning system and defogger Using the automatic mode STEP Press The air conditioning system will begin to operate. Air outlets and fan speed are automatically adjusted according to the temperature setting. STEP Turning to the right increases the temperature and turning to the left decreases the temperature on the driver’s side.
  • Page 199 3-1. Using the air conditioning system and defogger Adjusting the fan speed Press “∧” (increase) or “∨” (decrease) on the fan speed selector. The fan speed is shown on the display. (7 levels) Press to turn the fan off. Changing the air outlets Press the air flow selector button.
  • Page 200 3-1. Using the air conditioning system and defogger Air flows to the feet and the windshield defogger operates. Recirculated air mode will auto- matically switch to outside air mode. Switching between outside air and recirculated air modes Press The mode switches between outside air mode (indicator off) and recirculated air mode (indicator on) modes each time the button is pressed.
  • Page 201 3-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets Center outlets Direct air flow to the left or right, up or down. Right and left side outlets Direct air flow to the left or right, up or down.
  • Page 202 3-1. Using the air conditioning system and defogger Steering wheel switches Some air conditioning features can be controlled using the switches on the steering wheel. Temperature selector “DUAL” button indicator on: Indi- vidual setting on the driver's side only. “DUAL” button indicator off:...
  • Page 203 There may be a problem in the air conditioning system if the indi- cator light continues to flash. Turn the air conditioning system off and have it inspected by your Toyota dealer. Windshield air flow button When the “POWER” switch is set at ON mode after the 12-volt battery is reconnected, the indicator light on the button may flash and a motor sound may be heard.
  • Page 204 Plasmacluster™ Do not disassemble or repair the system because it contains high voltage parts. Call your Toyota dealer if the system needs repair. NOTICE To prevent the 12-volt battery from being discharged Do not leave the air conditioning system on longer than necessary when the hybrid system is off.

  • Page 205: Rear Window And Outside Rear View Mirror Defoggers

    3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers Clear the rear window using the defogger. On/off The defoggers will automati- cally turn off the operation time. The operation time is between 15 minutes and 1 hour depending on the ambient temperature vehicle...

  • Page 206: Using The Audio System

    3-2. Using the audio system Audio system types Owners of models equipped with a navigation system should refer to the “Navigation System Owner's Manual”. CD player and AM/FM radio CD player with changer and AM/FM radio...
  • Page 207 3-2. Using the audio system Title Page Using the radio P. 186 Using the CD player P. 192 Playing MP3 and WMA discs P. 199 Optimal use of the audio system P. 207 Using the AUX adapter P. 210 Using the steering wheel audio switches P.
  • Page 208 3-2. Using the audio system NOTICE To prevent the 12-volt battery from being discharged Do not leave the audio system on longer than necessary with the hybrid sys- tem off. To avoid damaging the audio system Take care not to spill drinks or other fluids over the audio system.

  • Page 209: Using The Radio

    3-2. Using the audio system Using the radio Power Volume Adjusting frequency (AM, FM mode) or channel (SAT mode) Scanning for Station selector receivable stations AM⋅SAT/FM (“SCAN” button) Displaying radio text mes- mode buttons sages (“TEXT” button) Seeking the frequency Changing the channel ®...
  • Page 210 3-2. Using the audio system Scanning all radio stations within range STEP Press the “SCAN” button. All stations with reception will be played for 5 seconds each. STEP When the desired station is reached, press the “SCAN” button once again. ®...
  • Page 211 3-2. Using the audio system ® Scanning XM Satellite Radio channels l Scanning channels in the current category STEP Press the “SCAN” button. STEP When the desired channel is reached, press the “SCAN” button again. l Scanning preset channels STEP Press and hold the “SCAN”...
  • Page 212 3-2. Using the audio system When the 12-volt battery is disconnected Station presets are erased. Reception sensitivity Maintaining perfect radio reception at all times is difficult due to the continu- ally changing position of the antenna, differences in signal strength and sur- rounding objects, such as trains, transmitters, etc.
  • Page 213 XM antenna cable is attached securely. ANTENNA There is a short-circuit in the antenna or the sur- rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to XM Satellite Radio. The radio is being updated with the latest encryp- ®...
  • Page 214 3-2. Using the audio system The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to the previous channel or “CH001”. If it does not change automatically, select another channel. ® Contact the XM Listener Care Center at 1-800 967-2346 (U.S.A.) or 1-877 438-9677 (Canada).

  • Page 215: Using The Cd Player

    3-2. Using the audio system Using the CD player Power Volume CD load CD eject (with changer only) Playback Selecting a track Searching playback Fast-forward (“SCAN” button) Reverse Displaying text Selecting a CD message (“TEXT” button) Repeat play Random playback (with changer only) Loading CDs Loading a CD (CD player without changer)
  • Page 216 3-2. Using the audio system Loading multiple CDs (CD player with changer only) STEP Press and hold until you hear a beep. STEP Insert a CD when the indicator on the slot turns from amber to green. The indicator on the slot turns to amber when the CD is inserted. STEP Insert the next CD when the indicator on the slot turns from amber to green again.
  • Page 217 3-2. Using the audio system Fast-forwarding and reversing tracks ∧ To fast-forward or reverse, press and hold “ ” or “∨” on Scanning tracks STEP Press the “SCAN” button. The first ten seconds of each track will be played. STEP Press the switch again when the desired track is reached.
  • Page 218 The CD may be dirty, damaged or inserted up-side down. “WAIT”: Operation has stopped due to a high temperature inside the player. Wait for a while and then press . Contact your Toyota dealer if the CD still cannot be played back.
  • Page 219 3-2. Using the audio system Discs that can be used Discs with the marks shown below can be used. Playback may not be possible depending on the recording format or disc features, or due to scratches, dirt or deterioration. CDs with copy-protect features may not be used. CD player protection feature To protect the internal components, playback is automatically stopped when a problem is detected while the CD player is being used.
  • Page 220 3-2. Using the audio system NOTICE CDs and adapters that cannot be used Do not use the following types of CDs or 3 in. (8 cm) CD adapters or Dual Discs. Doing so may damage the CD player and/or the CD insert/eject function. CD player with changer and AM/FM radio: CDs that have a diameter that is not 4.7 in.
  • Page 221 3-2. Using the audio system NOTICE CDs with a transparent or translucent recording area CDs that have had tape, stickers or CD- R labels attached to them, or that have had the label peeled off CD player precautions Failure to follow the precautions below may result in serious damage to the CDs or the player itself.

  • Page 222: Playing Mp3 And Wma Discs

    3-2. Using the audio system Playing MP3 and WMA discs Power Volume Selecting a file CD eject CD load (with changer only) Selecting a folder Playback Selecting a file Selecting a CD Searching playback Repeat play (with changer only) (“SCAN” button) Random playback Displaying text message (“TEXT”...
  • Page 223 3-2. Using the audio system Selecting and scanning a folder Selecting folders one at a time Press “∧” or “∨” on to select the desired folder. Selecting the desired folder by cueing the first file of each folder Press and hold the “SCAN” button until you hear a beep. When the desired folder is reached, press the “SCAN”...
  • Page 224 3-2. Using the audio system Repeat play To repeat a file Press (RPT). To repeat all of the files in a folder Press and hold (RPT) until you hear a beep. Random playback To play files from a particular folder in random order Press (RAND).
  • Page 225 Operation has stopped due to a high temperature inside the player. Wait for a while and then press . Contact your Toyota dealer if the CD still cannot be played. “NO MUSIC”: This indicates that the MP3/WMA file is not included in the Discs that can be used →P.
  • Page 226 3-2. Using the audio system MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
  • Page 227 3-2. Using the audio system Compatible media Media that can be used for MP3 and WMA playback are CD-Rs and CD- RWs. Playback in some instances may not be possible, depending on the status of the CD-R or CD-RW. Playback may not be possible or the audio may jump if the disc is scratched or marked with fingerprints.
  • Page 228 3-2. Using the audio system ID3 and WMA tags ID3 tags can be added to MP3 files, making it possible to record the track title and artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags. (The number of characters is based on ID3 Ver.
  • Page 229 3-2. Using the audio system NOTICE CDs and adapters that cannot be used (→P. 197) CD player precautions (→P. 198)

  • Page 230: Optimal Use Of The Audio System

    3-2. Using the audio system Optimal use of the audio system Displays the current mode Changes the following set- tings • Sound quality and volume balance (→P. 208) The sound quality and bal- ance setting can be changed to produce the best sound. •...
  • Page 231 3-2. Using the audio system Adjusting sound quality Turning adjusts the level. Mode Sound qual- Turn to the Turn to the Level displayed ity mode left right Bass* -5 to 5 Mid-range* (CD player -5 to 5 High with changer) Treble* -5 to 5 Front/rear...
  • Page 232 3-2. Using the audio system CD player with changer When “ASL” is selected, turning to the right turns “ASL” on, and turning to the left turns “ASL” off. “ASL” automatically adjusts the volume and tone quality according to the noise level as you drive your vehicle. Trademark owned by SRS Labs, Inc.

  • Page 233: Using The Aux Adapter

    3-2. Using the audio system Using the AUX adapter This adapter can be used to connect a portable audio device and lis- ten to it through the vehicle’s speakers. Connect the portable audio STEP device. STEP Press Operating portable audio devices connected to the audio system The volume can be adjusted using the vehicle's audio controls.

  • Page 234: Using The Steering Wheel Audio Switches

    3-2. Using the audio system Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Control volume (volume control switch) Radio: Select radio stations Select tracks, files (MP3 and WMA) and discs (“∨...
  • Page 235 3-2. Using the audio system Selecting a radio station STEP Press the “MODE” switch to select the radio mode. Press the “∨ ∧” switch to select a preset station. STEP To scan for receivable stations, press and hold the switch until you hear a beep.
  • Page 236 3-3. Using the hands-free phone system (for cellular phone) Hands-free phone system (for cellular phone) features (CD player with changer only) ® This system supports Bluetooth , which allows you to make or receive calls without using cables to connect a cellular phone and the system, and without operating the cellular phone.

  • Page 237: Using The Hands-Free Phone System (For Cellular Phone)

    3-3. Using the hands-free phone system (for cellular phone) Trademark owned by Bluetooth SIG. Inc. Certification for the hands-free phone system FCC ID: HYQBTAU01A IC ID: 1551A-BTAU01A MADE IN JAPAN NOTE: This device complies with Part 15 of the FCC Rules and RSS-210 of industry Canada.

  • Page 238: Using The Hands-Free Phone System (For Cellular Phone)

    3-3. Using the hands-free phone system (for cellular phone) FCC WARNING: Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CAUTION: Radio Frequency Radiation Exposure This equipment complies with FCC radiation exposure limits set forth for...

  • Page 239: Using The Hands-Free Phone System

    3-3. Using the hands-free phone system (for cellular phone) Using the hands-free phone system (for cellular phone) Audio unit Displays such items as message, name, and phone number Lower-case characters and special characters, such as an umlaut, can- not be displayed. Press and hold: Displays information that is too long to be displayed at one time...
  • Page 240 3-3. Using the hands-free phone system (for cellular phone) Steering wheel Volume The voice guidance vol- ume cannot be adjusted by using this button. Hands-free phone system off/ends a call/refuses a call (on-hook switch) Hands-free phone system on/starts a call (off-hook switch) Press: Voice command sys- tem on...
  • Page 241 3-3. Using the hands-free phone system (for cellular phone) Operating the system by using a voice command By following voice guidance instructions output from the speaker, voice commands can be given to allow for operation of the hands- free phone system without checking the display or operating Operation procedure when using a voice command Press the talk switch and say the command for a desired function.
  • Page 242 3-3. Using the hands-free phone system (for cellular phone) Using the hands-free phone system for the first time Before using the hands-free phone system, it is necessary to register a cellular phone in the system. The phone registration mode will be entered automatically when starting the system with no cellular phone registered.
  • Page 243 3-3. Using the hands-free phone system (for cellular phone) Menu list of the hands-free phone system Normal operation Second First menu Third menu Operation detail menu Dialing a number stored in Callback the incoming call history memory Dialing a number stored in Redial the outgoing call history memory...
  • Page 244 3-3. Using the hands-free phone system (for cellular phone) Second First menu Third menu Operation detail menu Set PIN Setting a PIN code Phonebook Lock Locking the phone book Security Phonebook Unlocking the phone book Unlock Registering a cellular phone Pair Phone to be used Changing the registered...
  • Page 245 3-3. Using the hands-free phone system (for cellular phone) Using a short cut key First menu Second menu Operation detail Dialing a number registered Dial “XXX (name)” in the phone book Phone book add Adding a new number entry Changing the name of a Phone book change phone number in the phone name...
  • Page 246 3-3. Using the hands-free phone system (for cellular phone) Automatic adjustment of volume When vehicle speed is 50 mph (80 km/h) or more, the volume automatically increases. The volume returns to the previous volume setting when vehicle speed drops to 43 mph (70 km/h) or less. When using a voice command For numbers, say a combination of single digits from zero to nine, # (pound), ∗...

  • Page 247: Making A Phone Call

    3-3. Using the hands-free phone system (for cellular phone) Making a phone call Making a phone call l Dialing by inputting a number “Dial by number” l Dialing by inputting a name “Dial by name” l Speed dialing l Dialing a number stored in the outgoing history memory “Redial”...
  • Page 248 3-3. Using the hands-free phone system (for cellular phone) Dialing by inputting a name STEP Press the talk switch and say “Dial by name”. STEP Select a registered name to be input by either of the following methods: a. Press the talk switch and say a registered name. b.
  • Page 249 3-3. Using the hands-free phone system (for cellular phone) Transferring a call A call can be transferred between the cellular phone and system while dialing, receiving a call, or during a call. Use one of the follow- ing methods: a. Operate the cellular phone. Refer to the manual that comes with the cellular phone for the oper- ation of the phone.
  • Page 250 3-3. Using the hands-free phone system (for cellular phone) The following operations can be performed: Dialing: Press the off-hook switch or select “Dial” by using a voice command or Storing the number in the phone book: Select “Store” by using a voice command or Deleting: Select “Delete”...

  • Page 251: Setting A Cellular Phone

    3-3. Using the hands-free phone system (for cellular phone) Setting a cellular phone Registering a cellular phone in the hands-free phone system allows the system to function. The following functions can be used for reg- istered cellular phones: Functions and operation procedures To enter the menu for each function, follow the steps below by using a voice command or l Registering a cellular phone...
  • Page 252 3-3. Using the hands-free phone system (for cellular phone) Selecting the cellular phone to be used STEP Select “Select Phone” by using a voice command or Pattern A STEP Select the cellular phone to be used by either of the following methods, and select “Confirm”...
  • Page 253 3-3. Using the hands-free phone system (for cellular phone) STEP Press the talk switch or select “Record Name” by using , and say a new name. STEP Select “Confirm” by using a voice command or Listing the registered cellular phones Selecting “List Phones”...
  • Page 254 3-3. Using the hands-free phone system (for cellular phone) Deleting a cellular phone STEP Select “Delete” by using a voice command or Pattern A STEP Select the cellular phone to be deleted by either of the follow- ing methods and select “Confirm” by using a voice command a.
  • Page 255 3-3. Using the hands-free phone system (for cellular phone) Pattern B STEP Select a 4 to 8-digit number by using The number should be input 1 digit at a time. STEP When the entire number to be registered as a passkey has been input, press once again.

  • Page 256: Security And System Setup

    3-3. Using the hands-free phone system (for cellular phone) Security and system setup To enter the menu of each setting, follow the steps below: Security setting items and operation procedure l Setting or changing the PIN (Personal Identification Number) 1. “Setup” → 2. “Security” → 3. “Set PIN” l Locking the phone book 1.
  • Page 257 3-3. Using the hands-free phone system (for cellular phone) Changing the PIN STEP Select “Set PIN” by using a voice command or STEP Enter the registered PIN by using a voice command or STEP Enter a new PIN by using a voice command or When using , input the code 1 digit at a time.
  • Page 258 3-3. Using the hands-free phone system (for cellular phone) Setting voice guidance volume STEP Select “Guidance Vol” by using STEP Change the voice guidance volume. To decrease the volume: Turn counterclockwise. To increase the volume: Turn clockwise. Initialization STEP Select “Initialize” and then “Confirm” by using STEP Select “Confirm”...
  • Page 259 3-3. Using the hands-free phone system (for cellular phone) Initialization The following data in the system can be initialized: • Phone book • Outgoing and incoming call history • Speed dials • Registered cellular phone data • Security code Once the initialization has been completed, the data cannot be restored to its original state.

  • Page 260: Using The Phone Book

    3-3. Using the hands-free phone system (for cellular phone) Using the phone book To enter the menu of each setting, follow the steps below: l Adding a new phone number 1. “Phonebook” → 2. “Add Entry” l Setting speed dial 1.
  • Page 261 3-3. Using the hands-free phone system (for cellular phone) Adding procedure STEP Select “Add Entry” by using a voice command or STEP Use one of the following methods to input a telephone num- ber: Inputting a telephone number by using a voice command STEP2-1 Select “By Voice”...
  • Page 262 3-3. Using the hands-free phone system (for cellular phone) Inputting a phone number by using STEP2-1 Select “Manual Input” by using STEP2-2 Input a phone number by using , and press once again. Input the phone number 1 digit at a time. Selecting a phone number from outgoing or incoming call history STEP2-1 Select “Call History”...
  • Page 263 3-3. Using the hands-free phone system (for cellular phone) STEP Select the name to be registered by either of the following methods, and select “Confirm” by using a voice command or a. Press the talk switch and say the desired name. b.
  • Page 264 3-3. Using the hands-free phone system (for cellular phone) STEP Select the desired preset button, and register the data into speed dial by either of the following methods: a. Press the desired preset button, and select “Confirm” by using a voice command or b.
  • Page 265 3-3. Using the hands-free phone system (for cellular phone) Deleting registered data STEP Select “Delete Entry” by using a voice command or Pattern A STEP Select the data to be deleted by either of the following meth- ods, and select “Confirm” by using a voice command or a.
  • Page 266 3-3. Using the hands-free phone system (for cellular phone) Listing the registered data Selecting “List names” by using a voice command causes a list of the registered data to be read aloud. When listing is complete, the system returns to “Phonebook”. Pressing the talk switch while the desired data is being read aloud selects the data, and the following function will be available.

  • Page 267: Using The Interior Lights

    “DOOR” position, the light will go off automatically after 20 minutes. Customization that can be configured at Toyota dealer Settings (e.g. the time elapsed before lights turn off) can be changed. (Customizable features →P. 421)

  • Page 268: Interior Light

    3-4. Using the interior lights Interior light Interior light Vehicles without moon roof Door position Vehicles with moon roof Door position...

  • Page 269: Personal Lights

    3-4. Using the interior lights Personal lights Personal lights Front On/off Rear (vehicles with moon roof) On/off When either of the rear side doors is opened, the light on that side turns on automatically. Clos- ing the rear side doors will turn the lights off.

  • Page 270: Using The Storage Features

    3-5. Using the storage features List of storage features Auxiliary boxes Glove box Cup holders Console box...

  • Page 271: Glove Box

    3-5. Using the storage features Glove box and console box Glove box Open (pull the lever) Lock with the mechanical key Unlock with the mechanical Glove box light The glove box light turns on when the tail lights are turned on. CAUTION Caution while driving Keep the glove box closed.
  • Page 272 3-5. Using the storage features Console box Tray in the console box The tray slides forward/backward and can be removed. CAUTION Caution while driving Keep the console box closed. Injuries may result in the event of an accident or sudden braking.

  • Page 273: Cup Holders

    3-5. Using the storage features Cup holders Cup holders Front To open, pull up and release the right side of the cup holder lid. Rear Pull the armrest down. Using the cup holder (front) to store small items Remove the holder.

  • Page 274: Auxiliary Boxes

    3-5. Using the storage features Cup holders and auxiliary boxes CAUTION Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
  • Page 275 3-5. Using the storage features Auxiliary boxes Front console Push the lid. Cable pass-through The auxiliary box of the front console is provided with a hole that allows cables to be passed into the cabin from the inside power outlet and AUX adapter. Remove the lid.

  • Page 276: Other Interior Features

    3-6. Other interior features Sun visors Forward position: Flip down. Side position: Flip down, unhook, and swing to the side.

  • Page 277: Vanity Mirrors

    3-6. Other interior features Vanity mirrors Slide the cover. The light turns on when the cover is opened. (if equipped)

  • Page 278: Clock

    3-6. Other interior features Clock Adjusts the hour. Adjusts the minutes. The clock is displayed when The “POWER” switch is in ACCESSORY or ON mode.

  • Page 279: Ashtrays

    3-6. Other interior features Ashtrays (if equipped) An ashtray can be installed in a cup holder. (→P. 250) CAUTION When not in use Keep the ashtray closed. Injuries may result in the event of an accident or sudden braking. To prevent fire Fully extinguish matches and cigarettes before putting them in the ashtray, then make sure the ashtray is fully closed.

  • Page 280: Power Outlet

    3-6. Other interior features Power outlet The power outlet can be used for 12 V accessories that run on less than 10 A. Type A Type B The power outlet can be used when The “POWER” switch is in ACCESSORY or ON mode. Cable pass-through Connected cables can be passed through the hole in the auxiliary box to the front passenger’s side of the auxiliary box.
  • Page 281 3-6. Other interior features NOTICE To avoid damaging the power outlet Close the power outlet lid when the power outlet is not in use. Foreign objects or liquids that enter the power outlet may cause a short cir- cuit. To prevent the fuse from being blown Do not use an accessory that uses more than 12 V 10 A.

  • Page 282: Seat Heaters

    3-6. Other interior features Seat heaters (if equipped) Heats the left front seat Heats the right front seat The indicator light comes on. The seat heaters can be used when The “POWER” switch is in ON mode. When not in use Turn the seat heater off.
  • Page 283 3-6. Other interior features NOTICE To prevent seat heater damage Do not put unevenly weighted objects on the seat and do not stick sharp objects (needles, nails, etc.) into the seat. To prevent the 12-volt battery from being discharged Turn the switches off when the hybrid system is off.

  • Page 284: Armrest

    3-6. Other interior features Armrest Pull the armrest down for use. NOTICE To prevent damage to the armrest Do not place too much strain on the armrest.

  • Page 285: Floor Mat

    3-6. Other interior features Floor mat Securely place a mat that matches the size of the space on the car- pet. Secure the driver's floor mat using the hooks provided. CAUTION When inserting the floor mat Observe the following precautions. Failure to do so may result in the floor mat slipping and interfering with the movement of the pedals during driving, resulting in an accident.

  • Page 286: Trunk Features

    3-6. Other interior features Trunk features Grocery bag hooks Cargo net NOTICE To prevent damage to the cargo net hooks Avoid hanging things other than a cargo net on them.

  • Page 287: Garage Door Opener

    3-6. Other interior features Garage door opener (if equipped) The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, and security systems, and other devices. ® The garage door opener (HomeLink Universal Transceiver) is manufac- ®...
  • Page 288 3-6. Other interior features Press and hold down one of the STEP ® buttons on HomeLink and the button on the transmitter. When ® the indicator light on HomeLink changes from a slow to a rapid flash after 20 seconds, you can release both buttons.
  • Page 289 3-6. Other interior features Programming a Rolling Code system (for U.S. owners) If your device is Rolling Code equipped, follow the steps under the ® heading “Programming HomeLink ” before proceeding with the steps listed below. STEP Locate the training button on the ceiling-mounted garage door opener motor.
  • Page 290 ® the remaining HomeLink buttons. Programming other devices To program other devices such as home security systems, home door locks or lighting, contact your authorized Toyota dealer for assistance. Reprogramming a button ® The individual HomeLink buttons cannot be erased but can be reprogrammed.
  • Page 291 3-6. Other interior features Before programming Install a new battery in the transmitter. The battery side of the transmitter must be pointed away from ® HomeLink Certification for the garage door opener This device complies with Part 15 of the FCC Rules and with RSS-210 of the IC Rules.

  • Page 292: Compass

    3-6. Other interior features Compass (if equipped) The compass on the anti-glare inside rear view mirror indicates the direction in which the vehicle is heading. Operation To turn the compass on or off, press and hold “AUTO” for 3 seconds. Displays and directions Display Direction...
  • Page 293 3-6. Other interior features Calibrating the compass The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in the illustration, the compass will deviate.
  • Page 294 3-6. Other interior features Circling calibration STEP Stop the vehicle in a place where it is safe to drive in a circle. Press and hold “AUTO” for 9 STEP seconds. C appears on the compass dis- play. Drive the vehicle at 5 mph (8 km/ STEP h) or less in a circle until a direc- tion is displayed.
  • Page 295 3-6. Other interior features CAUTION While driving the vehicle Do not adjust the display. Be sure to adjust the display only when the vehicle is stopped. When doing the circling calibration Be sure to secure a wide space, and watch out for people and vehicles in the neighborhood.

  • Page 296: Maintenance And Care

    4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. l Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
  • Page 297 4-1. Maintenance and care To prevent deterioration and body corrosion Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads • If you see coal tar or tree sap on the paint surface •...

  • Page 298: Cleaning And Protecting The Vehicle Interior

    4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle's interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
  • Page 299 Wipe the window in strokes running parallel to the heater wires or antenna. Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle's interior. Shampooing the carpets There are several commercial foaming-type cleaners available.
  • Page 300 4-1. Maintenance and care NOTICE Cleaning detergents Do not use organic substances such as benzene or gasoline, acidic or alka- line solutions, dye, bleach or other detergent. Doing so may discolor the vehicle interior or cause streaks or damage to painted surfaces. Preventing damage to leather surfaces Observe the following precautions to avoid damage to and deterioration of leather surfaces.

  • Page 301: Maintenance

    It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
  • Page 302 4-2. Maintenance Allow inspection and repairs to be performed by a Toyota dealer Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.

  • Page 303: General Maintenance

    Booklet” “Owner’s Manual Supplement/Scheduled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items Check points Brake fluid At the correct level? (→P.
  • Page 304 4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be held securely Transmission “Park” mechanism on an incline with the shift lever in • Moves smoothly? • Does it have appropriate clear- Brake pedal ance and correct amount of free play?
  • Page 305 4-2. Maintenance Vehicle exterior Items Check points Door/trunk • Operate smoothly? Engine hood • The lock system works properly? • Is there any leakage after park- Fluid leaks ing? • Inflation pressure is correct? • Tire surfaces not worn or dam- aged? Tires •...

  • Page 306: Emission Inspection And Maintenance (I/M) Programs

    The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test:...

  • Page 307: Do-It-Yourself Maintenance

    (→P. 300) • Conventional wrench (for terminal clamp bolts) ⎯ Brake fluid level (→P. 298) • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
  • Page 308 4-3. Do-it-yourself maintenance Items Parts and tools • Fuse with same amperage rating Fuses (→P. 325) as original Radiator and condenser ⎯ (→P. 298) • Tire pressure gauge Tire inflation pressure (→P. 313) • Compressed air source • Water washer fluid containing Washer fluid (→P.
  • Page 309 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury observe the following precautions. When working on the engine compartment Make sure that the indicator on the “POWER” switch and the “READY” indicator are both off.

  • Page 310: Hood

    4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. STEP The hood will pop up slightly. Lift the hood catch and lift the STEP hood. CAUTION Pre-driving check Check that the hood is fully closed and locked.

  • Page 311: Positioning A Floor Jack

    4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. Front Rear...
  • Page 312 4-3. Do-it-yourself maintenance CAUTION When raising your vehicle Make sure to observe the following to reduce the possibility of death or seri- ous injury. Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.

  • Page 313: Engine Compartment

    4-3. Do-it-yourself maintenance Engine compartment Brake fluid reservoir Fuse box (→P. 325) (→P. 298) Condenser (→P. 298) Engine oil filler cap Electric cooling fans (→P. 293) Power control unit coolant Engine oil level dipstick radiator (→P. 298) (→P. 292) Washer fluid tank (→P. 299) Power control unit coolant Engine coolant reservoir reservoir...
  • Page 314 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil STEP Park the vehicle on level ground. After turning off the engine, wait a few minutes for the oil to drain back into the bottom of the engine.
  • Page 315 4-3. Do-it-yourself maintenance Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
  • Page 316 Oil consumption: Max. 1.1 qt./600 miles, 0.9 lmp.qt./600 miles (1.0 L per 1000 km) If you consume more than 1.1 qt. (1.0 L, 0.9 lmp.qt.) every 600 miles (1000 km), contact your Toyota dealer.
  • Page 317 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
  • Page 318 4-3. Do-it-yourself maintenance Coolant The coolant level is satisfactory if it is between the “FULL” and “LOW” lines on the reservoir when the hybrid system is cold. Engine coolant reservoir Reservoir cap FULL If the level is on or below the “L” line, add coolant up to the “F”...
  • Page 319 If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, coolant reservoir caps, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. Coolant selection Only use “Toyota Super Long Life Coolant”...
  • Page 320 Check the radiators and condenser and remove any foreign objects. If any of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION The radiators and condenser may be hot after driving Do not touch the radiators or condenser, as they may be hot and may be burned.
  • Page 321 4-3. Do-it-yourself maintenance NOTICE If the fluid level is low or high It is normal for the brake fluid level to go down slightly as the brake pads wear or when the fluid level in the accumulator is high. If the reservoir needs frequent refilling, it may indicate a serious problem. Washer fluid Add washer fluid in the following situations.

  • Page 322: 12-Volt Battery

    4-3. Do-it-yourself maintenance 12-volt battery Location The 12-volt battery is located in the right-hand side of the luggage compartment. Removing the 12-volt battery cover Remove the 12-volt battery cover. Exterior Make sure that the 12-volt battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps.
  • Page 323 With the shift lever in P and the “POWER” switch OFF, open and close the driver’s door, then attempt to start the hybrid system. If the system will not start even after multiple attempts at both methods, con- tact your Toyota dealer.
  • Page 324 4-3. Do-it-yourself maintenance CAUTION Chemicals in the 12-volt battery The 12-volt battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the 12-volt battery: Do not cause sparks by touching the 12-volt battery terminals with tools.
  • Page 325 Use a 12-volt battery designed for the CAMRY HYBRID. Failure to do so may cause gas (hydrogen) to enter the passenger compartment, causing a fire or explosion. For replacement of the 12-volt battery, contact your Toyota dealer. NOTICE When recharging the 12-volt battery Never recharge the 12-volt battery while the hybrid system is operating.

  • Page 326: Tires

    The tire pressure warning system Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (→P. 351) The compact spare tire is not equipped with a tire pressure warn- ing valve and transmitter.
  • Page 327 ID codes must be registered in the tire pressure warning computer and tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (→P. 306) Initializing the tire pressure warning system...
  • Page 328 The tire pressure warning valve and transmitter is equipped with a unique ID code. When replacing a tire pressure warning valve and transmitter, it is necessary to register the ID code of tire pressure warning valve and transmitter. Have the ID code registered by your Toyota dealer.
  • Page 329 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
  • Page 330 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. When operating the tire pressure warning reset switch, the tire pressure warning light does not flash 3 times.
  • Page 331 4-3. Do-it-yourself maintenance Tire types 1 Summer tires Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
  • Page 332 4-3. Do-it-yourself maintenance Tire pressure warning system certification For vehicles sold in the U.S.A. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 333 Do not mix tires of different makes, models, tread patterns or tread- wear. Do not use tire sizes other than those recommended by Toyota. Do not mix radial, bias-belted, or bias-ply tires. Do not mix summer, all season and winter tires.
  • Page 334 When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. To avoid damaging the tire pressure warning valves and transmit- ters Do not use liquid sealants on flat tires.

  • Page 335: Tire Inflation Pressure

    4-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (→P. 409) Type A Type B...
  • Page 336 4-3. Do-it-yourself maintenance Inspection and adjustment procedure Tire valve Tire pressure gauge STEP Remove the tire valve cap. STEP Press the tip of the tire pressure gauge onto the tire valve. STEP Read the pressure using the graduations of the gauge. STEP If the tire inflation pressure is not at the recommended level, adjust the pressure.
  • Page 337 Reduced driving comfort and tire life Reduced safety Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: Check only when the tires are cold.
  • Page 338 4-3. Do-it-yourself maintenance CAUTION Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. Excessive wear Uneven wear Poor handling Possibility of blowouts resulting from overheated tires Poor sealing of the tire bead Wheel deformation and/or tire separation A greater possibility of tire damage from road hazards...

  • Page 339: Wheels

    Used wheels l Bent wheel that have been straightened Aluminum wheel precautions l Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. l When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
  • Page 340 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.

  • Page 341: Air Conditioning Filter

    4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be cleaned or changed regularly to maintain air conditioning efficiency. Removal method STEP Turn the “POWER” switch OFF. Open the glove box. Slide off STEP the damper. Apply pressure to the glove STEP box as shown to disconnect the claws.
  • Page 342 2 minutes at 72 psi (500 kPa, 5.0 kgf/cm bar). If an air gun is not available, have the filter cleaned by your Toyota dealer. Replacement method Remove the air conditioning filter and replace it with a new one.
  • Page 343 4-3. Do-it-yourself maintenance NOTICE To prevent damage to the system When using the air conditioning system, make sure that a filter is always installed. When cleaning the filter, do not clean the filter with water.

  • Page 344: Key Battery

    4-3. Do-it-yourself maintenance Key battery Replace the battery with a new one if it is discharged. You will need the following items: l Flathead screwdriver (To prevent damage to the key, cover the tip of the screwdriver with rag.) l Small Phillips-head screwdriver l Lithium battery CR1632 Replacing the battery Take out the mechanical key.
  • Page 345 The smart key system and wireless remote control will not function prop- erly. The operational range is reduced. Use a CR1632 lithium battery Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. Replace only with the same or equivalent type recommended by your Toyota dealer.
  • Page 346 4-3. Do-it-yourself maintenance NOTICE For normal operation after replacing the battery Observe the following precautions to prevent accidents. Always work with dry hands. Moisture may cause the battery to rust. Do not touch or move any other components inside the remote control. Do not bend either of the battery terminals.

  • Page 347: Checking And Replacing Fuses

    4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. STEP Turn the “POWER” switch OFF. STEP Open the fuse box cover. Engine compartment Push the tab in and lift the lid off.
  • Page 348 4-3. Do-it-yourself maintenance Remove the fuse with the pull- STEP out tool. STEP Check if the fuse has blown. Type A Normal fuse Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type B Normal fuse Blown fuse...
  • Page 349 4-3. Do-it-yourself maintenance Type C Normal fuse Blown fuse Contact your Toyota dealer.
  • Page 350 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings Engine compartment Fuse box cover Fuse block Fuse Ampere Circuit SPARE 30 A Spare fuse SPARE 15 A Spare fuse SPARE 10 A Spare fuse...
  • Page 351 4-3. Do-it-yourself maintenance Fuse Ampere Circuit 7.5 A “POWER” switch ABS MAIN Electronically controlled brake sys- 10 A NO.2 ABS MAIN Electronically controlled brake sys- 10 A NO.1 ABS MAIN Electronically controlled brake sys- 10 A NO.3 BATT FAN 10 A Hybrid battery fan ETCS 10 A...
  • Page 352 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Fuel tank system, multiport fuel EFI NO.3 10 A injection system/sequential multi- port fuel injection system Hybrid system ECU, motor genera- IGCT No.2 10 A tor ECU Hybrid system ECU, hybrid battery (traction battery), DC/DC converter, INV W/P 15 A multiport fuel injection system/...
  • Page 353 4-3. Do-it-yourself maintenance Fuse Ampere Circuit “ABS MTR2”, “EPS”, “ABS MTR”, “AM2”, “DOOR NO.1”, “ETCS”, “IG2”, “HAZ”, “AMP”, “ABS MAIN1”, DC/DC 120 A “ABS MAIN2”, “STR LOCK”, “ABS MAIN3”, “BTT FAN”, “EFI MAIN”, “EFI NO.1” and “IGCT” fuses 80 A Electric power steering system Electronically controlled brake sys- ABS MTR2...
  • Page 354 4-3. Do-it-yourself maintenance Under the instrument panel Fuse Ampere Circuit RR DOOR RH 25 A Rear right power window RR DOOR LH 25 A Rear left power window FUEL OPN 7.5 A Fuel filter door opening system FR FOG 15 A No circuit 7.5 A On-board diagnosis system...
  • Page 355 4-3. Do-it-yourself maintenance Fuse Ampere Circuit DOOR NO.2 25 A Main body ECU S/ROOF 30 A Electric moon roof Front side marker lights, tail lights, TAIL 15 A rear side marker lights, license plate lights Navigation system, seat heaters, emergency flashers, air condition- PANEL 7.5 A ing system, audio system, clock,...
  • Page 356 (→P. 336) If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. If there is an overload in the circuits The fuses are designed to blow before the entire wiring harness is damaged.
  • Page 357 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix.

  • Page 358: Light Bulbs

    You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
  • Page 359 4-3. Do-it-yourself maintenance Replacing light bulbs Headlight Turn the bulb base counterclock- STEP wise. Headlight (low beam) Headlight (high beam) Unplug connector while STEP depressing the lock release. Headlight (low beam) Headlight (high beam)
  • Page 360 4-3. Do-it-yourself maintenance Rear turn signal lights Open the trunk lid and remove STEP the cover. Turn the bulb bases counter- STEP clockwise. Remove the light bulb. STEP...
  • Page 361 Water has built up inside the headlight. LED high mounted stoplight The high mounted stoplight consists of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
  • Page 362 4-3. Do-it-yourself maintenance CAUTION Replacing light bulbs Turn off the headlights. Do not attempt to replace the bulb immediately after turning off the headlights. The bulbs become very hot and may cause burns. Do not touch the glass portion of the light bulb with bare hands. Hold the bulb by the plastic or metal portion.

  • Page 363: Essential Information

    If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
  • Page 364 5-1. Essential information Towing with a sling-type truck NOTICE To prevent body damage Do not tow with a sling-type truck, either from the front or rear. Towing with a wheel-lift type truck from the front Release the parking brake. NOTICE To prevent damaging the vehicle When raising the vehicle, ensure adequate ground clearance for towing at the opposite end of the raised vehicle.
  • Page 365 5-1. Essential information Towing with a wheel-lift type truck from the rear Use a towing dolly under the front wheels. NOTICE To prevent causing serious damage to the transmission Never tow this vehicle from the rear with the front wheels on the ground. Using a flat bed truck If you use chains or cables to tie down your vehicle, the angles...

  • Page 366: If You Think Something Is Wrong

    5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms l Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)

  • Page 367: Event Data Recorder

    5-1. Essential information Event data recorder Your vehicle has computers that monitor and control certain aspects of your vehicle. These computers assist in driving and maintaining optimal vehicle performance. Besides storing data useful for troubleshooting, there is an event data recorder (EDR) that records data in a crash or a near car crash event.
  • Page 368 5-1. Essential information Disclosure of the data Toyota will not disclose the data recorded in an EDR to a third party except when: l An agreement from the vehicle's owner (or the leasing company for a leased vehicle) is obtained...

  • Page 369: Steps To Take In An Emergency

    Stop the vehicle immediately. The following warning indicates the possibility of damage to the vehi- cle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Charging system warning light...
  • Page 370 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Indicates a malfunction in: (U.S.A.)
  • Page 371 If it is, tighten it securely. The light will go off after taking several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. Brake system warning light operation...
  • Page 372 When the light comes on: Adjust the tire inflation Low tire inflation pressure. pressure. (U.S.A.) When the light comes on after blinking for 1 minute: Have the system checked Malfunction in the tire by your Toyota dealer. pressure warning system.
  • Page 373 5-2. Steps to take in an emergency Warning light Warning light/Details Correction procedure Master warning light A buzzer sounds and the warning light comes on →P. 357 and flashes to indicate that the master warning system has detected a malfunc- tion.
  • Page 374 If there is a lot of snow or ice on the vehicle, in particular around the wheels or wheel housings. If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.)
  • Page 375 The vehicle speed linked seat belt reminder buzzer can be disabled. (Customizable features →P. 421) However, Toyota recommends that the seat belt reminder buzzer be opera- tional to alert the driver and front passenger that the seat belts are not fas- tened.
  • Page 376 5-2. Steps to take in an emergency CAUTION Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
  • Page 377 5-2. Steps to take in an emergency CAUTION Your vehicle has also been equipped with a TPMS (tire pressure warning system) malfunction indicator to indicate when the system is not operat- ing properly. The TPMS (tire pressure warning system) malfunction indi- cator is combined with the low tire pressure telltale (tire pressure warning light).

  • Page 378: If A Warning Message Is Displayed

    Multi-information display If any of the warning lights turns on again after performing the fol- lowing actions, contact your Toyota dealer.
  • Page 379 Stop the vehicle immediately. l The following warning indicates the possibility of damage to the vehicle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning message Details Indicates an abnormal engine oil pressure.
  • Page 380 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning message Details Indicates a malfunction in the steering lock sys- tem.
  • Page 381 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turns off. Warning message Details Correction procedure Indicates that one or more of the doors is not fully closed.
  • Page 382 5-2. Steps to take in an emergency Warning message Details Correction procedure Indicates that the parking brake is still engaged with the vehicle having Release the parking reached a speed of brake. more than 3 mph (5 km/h). A buzzer also sounds. Indicates that the washer fluid level is Add washer fluid.
  • Page 383 5-2. Steps to take in an emergency Warning message Details Correction procedure Indicates that the hybrid battery (trac- Stop the vehicle and tion battery) is low. shift the shift lever to P. A buzzer also sounds. Indicates that the transmission is not in Shift the shift lever to P P when attempting to before pressing the...
  • Page 384 Messages displayed when refueling The following messages are displayed after the fuel lid opener is pressed. If the messages do not change or are displayed continu- ously, have the vehicle checked by your Toyota dealer. Message Details Preparing the vehicle for refueling.
  • Page 385 5-2. Steps to take in an emergency Other messages If the following message is displayed, take appropriate action and confirm that the message has disappeared. Message Details The driver’s door is opened when the transmis- sion is not in P with the hybrid system on. Shift the shift lever to P.
  • Page 386 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turns off. Interior Exterior Correction Warning message Details buzzer buzzer procedure Indicates that the electronic key is not Confirm the ⎯...
  • Page 387 5-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure Indicates that the driver’s door has been opened or closed with the Turn the shift lever in P, “POWER” the “POWER” switch OFF or 3 times Once switch in any...
  • Page 388 5-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure Indicates that a door has been opened or closed and the Press the “POWER” “POWER” ⎯ switch has been switch while Once turned twice to depressing the ACCESSORY brake pedal.

  • Page 389: If You Have A Flat Tire

    5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. Before jacking up the vehicle l Stop the vehicle on a hard, flat surface. l Set the parking brake. l Shift the shift lever to P.
  • Page 390 5-2. Steps to take in an emergency Taking out the jack and spare tire Remove the luggage floor cover. STEP Loosen the nut and remove it. STEP Remove the spare tire cover. Loosen the bolt and remove it. Remove the jack tray. Remove the hook.
  • Page 391 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Wheel Flat tire chock posi- tions Behind the Left- rear right- hand hand side side tire Front Behind the Right- rear left- hand hand side side tire In front of...
  • Page 392 5-2. Steps to take in an emergency Turn the tire jack portion “A” by STEP hand until the notch of the jack is in contact with the jack point. Raise the vehicle until the tire is STEP slightly raised off the ground. Remove all the wheel nuts and STEP the tire.
  • Page 393 5-2. Steps to take in an emergency Installing the tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
  • Page 394 5-2. Steps to take in an emergency Lower the vehicle. STEP Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) STEP Stow the flat tire, tire jack and all tools. The compact spare tire The compact spare tire is identified by the label “TEMPORARY USE ONLY”...
  • Page 395 5-2. Steps to take in an emergency If you have a flat front tire on a road covered with snow or ice Install the compact spare tire on the rear of the vehicle. Perform the fol- lowing steps and fit tire chains to the front tires. STEP Replace a rear tire with the compact spare tire.
  • Page 396 5-2. Steps to take in an emergency CAUTION Do not raise the vehicle while someone is in it. When raising the vehicle, do not put an object on or under the jack. Do not raise the vehicle to a height greater than that required to replace the tire.
  • Page 397 5-2. Steps to take in an emergency CAUTION Speed limit when using the compact spare tire Do not drive at speeds in excess of 50 mph (80 km/h) when a compact spare tire is installed on the vehicle. The compact spare tire is not designed for driving at high speeds. Failing to observe this precaution may lead to an accident causing death or seri- ous injury.
  • Page 398 When replacing the tires When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. To avoid damaging the tire pressure warning valves and transmit- ters Do not use liquid sealants on flat tires.

  • Page 399: If The Hybrid System Will Not Start

    5-2. Steps to take in an emergency If the hybrid system will not start Reasons for the hybrid system not starting vary depending on the situation. Check the following and perform the appropriate proce- dure: The hybrid system will not start, even though the correct starting procedure is being followed.
  • Page 400 The 12-volt battery may be discharged. (→P. 385) l There may be a malfunction in the steering lock system. Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function...

  • Page 401: If The Shift Lever Cannot Be Shifted From P

    (a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.

  • Page 402: If You Lose Your Keys

    5-2. Steps to take in an emergency If you lose your keys New genuine Toyota keys can be made by your Toyota dealer using the other key and the key number stamped on your key number plate.

  • Page 403: If The Electronic Key Does Not Operate Properly

    5-2. Steps to take in an emergency If the electronic key does not operate properly If communication between the electronic key and the vehicle is inter- rupted (→P. 40) or the electronic key cannot be used because the battery is depleted, the smart key system and wireless remote con- trol cannot be used.
  • Page 404 Changing “POWER” switch modes and starting the hybrid system STEP Shift the shift lever to P and apply the brakes. Touch the Toyota emblem side of STEP electronic “POWER” switch. If any of the doors is opened and closed and while the key is touched to the “POWER”...
  • Page 405 5-2. Steps to take in an emergency Stopping the hybrid system Shift the shift lever to P and press the “POWER” switch as you normally do when stopping the hybrid system. Replacing the key battery As the above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery is depleted.

  • Page 406: If The Vehicle's 12-Volt Battery Is Discharged

    You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your Toyota following the steps below. STEP Open the trunk lid and remove the 12-volt battery cover.
  • Page 407 “POWER” switch to ON mode, then start the hybrid sys- tem. Make sure the “READY” indicator comes on. If the indicator does not comes on, contact your Toyota dealer. STEP Once the hybrid system has started, remove the jumper cables in the exact reverse order in which they were con- nected.
  • Page 408 5-2. Steps to take in an emergency CAUTION Avoiding 12-volt battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the 12-volt battery. Make sure each jumper cable is connected to the correct terminal. Do not allow the ends of the jumper cable used for the “+”...
  • Page 409 5-2. Steps to take in an emergency NOTICE When handling jumper cables Be careful that the jumper cables do not become tangled in the cooling fans or any of the belts when connecting or disconnecting them.

  • Page 410: If Your Vehicle Overheats

    If the fans are operating: Wait until the temperature of the engine (shown on the instrument cluster) begins to fall and then stop the hybrid system. If the fans are not operating: Stop the hybrid system immediately and call your Toyota dealer.
  • Page 411 If the fans are operating: Wait until “HYBRID SYSTEM OVER HEAT” disappears and then stop the hybrid system. If the message does not disappear, call your Toyota dealer. If the fans are not operating: Stop the hybrid system immediately and call your local...
  • Page 412 Water can be used in an emer- gency if power control unit cool- ant is unavailable. (→P. 401) Have the vehicle checked at the nearest Toyota dealer as soon as possible. Overheating The following symptoms may occur when your vehicle is overheating: Hybrid system output decreases.
  • Page 413 5-2. Steps to take in an emergency CAUTION To prevent an accident or injury when inspecting under the hood of your vehicle If steam is seen coming from under the hood, do not open the hood until the steam has subsided. The engine compartment may be very hot, caus- ing serious injury such as burns.

  • Page 414: If The Vehicle Becomes Stuck

    5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. STEP Stop the hybrid system. Set the parking brake and put the shift lever in P.
  • Page 415 5-2. Steps to take in an emergency NOTICE To avoid damaging the transmission and other components Avoid spinning the wheels. If the vehicle remains stuck after trying these procedures, the vehicle may require towing to be freed.

  • Page 416: Specifications

    Vehicle identification number The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the...
  • Page 417 6-1. Specifications This number is also on the Certi- fication label on the driver’s side center pillar. Gasoline engine number and electric motor (traction motor) number The gasoline engine number and electric motor (traction motor) num- ber are stamped as shown. Gasoline engine number Electric motor (traction motor) number...
  • Page 418 6-1. Specifications Engine Model 2AZ-FXE engine Type 4 cylinder in-line, 4 cycle, gasoline 3.48 × 3.78 in. (88.5 × 96.0 mm) Bore and stroke Displacement 144.1 cu.in. (2362 cm Drive belt tension Automatic adjustment Valve clearance (engine cold) 0.007 ⎯ 0.011 in. (0.19 ⎯ 0.29 mm) Intake 0.015 ⎯...
  • Page 419 6-1. Specifications Hybrid battery (traction battery) Type Nickel-Metal hydride battery Voltage 7.2 V/module Capacity 6.5 Ah (3HR) Quantity 34 modules Overall voltage 244.8 V...
  • Page 420 4.5 qt. (4.3 L, 3.8 Imp.qt.) Without filter 4.3 qt. (4.1 L, 3.6 Imp.qt.) Oil grade ILSAC multi-grade engine oil Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the grade and vis- cosity shown below. Recommended oil viscosity Outside temperature *: 0W-20 is the oil that provides the optimal level of fuel efficiency.
  • Page 421 6.6 qt. (6.2 L, 5.5 Imp.qt.) Power control 3.1 qt. (2.9 L, 2.6 Imp.qt.) unit Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non-silicate, Coolant type non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
  • Page 422 Toyota dealer. NOTICE Transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle.
  • Page 423 6-1. Specifications Brakes Pedal clearance 3.1 in. (80 mm) 0.04 ⎯ 0.08 in. (1 ⎯ 2 mm) Pedal free play Brake pad wear limit 0.04 in. (1.0 mm) ⎯ 10 clicks Parking brake pedal travel Fluid type SAE J1703 or FMVSS No.116 DOT 3 : Minimum pedal clearance when depressed with a force of 110 lbf (490 N, 50 kgf) while the hybrid system is running : Parking brake pedal travel when depressed with a force of 67 lbf (300 N, 31...
  • Page 424 6-1. Specifications Tires and wheels Tire size P215/60R16 94V, T155/70D17 110M Driving under normal conditions Front: 32 psi (220 kPa, 2.2 kgf/cm bar)* Rear: 32 psi (220 kPa, 2.2 kgf/cm bar)* Spare: 60 psi (420 kPa, 4.2 kgf/cm Tire inflation pressure bar) (Recommended cold tire *: When driving at high speeds above...
  • Page 425 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights ⎯ Low beam High beam 9005 Front side marker ⎯ lights Exterior Front turn signal/park- 3457NAK 27/8 ing lights ⎯ Rear turn signal lights ⎯ License plate lights Back-up lights ⎯...

  • Page 426: Fuel Information

    ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. If your engine knocks Consult your Toyota dealer.
  • Page 427 Toyota allows the use of oxygenate blended gasoline where the oxygen- ate content is up to 10% ethanol or 15% MTBE. If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 87.
  • Page 428 6-1. Specifications NOTICE Notice on gasoline quality Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle’s catalytic converters causing the emission control system to malfunction. Do not use gasohol other than that stated here. Other gasohol may cause fuel system damage or vehicle performance problems.

  • Page 429: Tire Information

    6-1. Specifications Tire information Typical tire symbols (standard tire) Typical tire symbols (compact spare tire) Tire size (→P. 412) DOT and Tire Identification Number (TIN) (→P. 411) Uniform tire quality grading For details, see “Uniform Tire Quality Grading” that follows. Location of treadwear indicators (→P.
  • Page 430 6-1. Specifications Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire. Radial tires or bias-ply tires A radial tire has “RADIAL” on the sidewall. A tire not marked “RADIAL”...
  • Page 431 6-1. Specifications Typical DOT and Tire Identification Number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer's identifica- tion mark Tire size code Manufacturer's optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year : The DOT symbol certifies that the tire conforms to applicable Federal...
  • Page 432 6-1. Specifications Tire size Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 or 3 digits) Speed symbol...
  • Page 433 U.S.A. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades.
  • Page 434 6-1. Specifications Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci- fied government test course. For example, a tire graded 150 would wear one and a half (1-1/2) times as well on the government course as a tire graded 100.
  • Page 435 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either sepa- rately or in combination, can cause heat buildup and possible tire fail- ure.
  • Page 436 6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb.
  • Page 437 6-1. Specifications Tire related term Meaning The surface area of the rim not covered by the Weather side inflated tire The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components Bead separation...
  • Page 438 6-1. Specifications Tire related term Meaning The parting of the innerliner from cord material Innerliner separation in the carcass (a) The sidewall that contains a whitewall, bears white lettering, or bears manufac- turer, brand, and/or model name molding that is higher or deeper than the same Intended outboard molding on the other sidewall of the tire, or sidewall...
  • Page 439 6-1. Specifications Tire related term Meaning A layer of rubber-coated parallel cords A parting of rubber compound between adja- Ply separation cent plies A mechanical device made of rubber, chemi- cals, fabric and steel or other materials, that, Pneumatic tire when mounted on an automotive wheel, pro- vides the traction and contains the gas or fluid that sustains the load...
  • Page 440 6-1. Specifications Tire related term Meaning That portion of a tire that comes into contact Tread with the road A tread section running circumferentially Tread rib around a tire Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear indicators designed to give a visual indication of the...

  • Page 441: Customization

    Your vehicle includes a variety of electronic features that can be per- sonalized to your preferences. Programming these preferences requires specialized equipment and may be performed by your Toy- ota dealer. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer. Customized Item Function Default setting...
  • Page 442 6-2. Customization Customized Item Function Default setting setting Wireless remote control Driver's door unlocked in one All doors Unlocking operation step, all doors unlocked in one unlocked in two step. steps Automatic door lock function to be activated if door is not opened after being unlocked Time elapsed before 30 seconds...
  • Page 443 6-2. Customization Customized Item Function Default setting setting Driver's door unlocked in one All doors Unlocking using a key step, all doors unlocked in one unlocked in two step. steps Speed-detecting auto- matic door lock function Door lock → P. 50) Opening driver's door unlocks all doors Shifting gears to P...

  • Page 444: Initialization

    6-3. Initialization Items to initialize The following items must be initialized for normal system operation in cases such as after the 12-volt battery is reconnected, or mainte- nance is performed on the vehicle. Item When to initialize Reference Engine oil mainte- After changing engine oil P.

  • Page 445: Reporting Safety Defects For U.s. Owners

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 446: Seat Belt Instructions For Canadian Owners (In French)

    Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation correcte des ceintures de sécurité...
  • Page 447 Guide de confort de ceinture de sécurité (siège arrière extérieur) Si la sangle diagonale gêne la personne au niveau du cou, utilisez le guide confort de la ceinture de sécurité. Sortez le guide confort de sa ÉTAPE poche. Engagez la ceinture dans le ÉTAPE guide.
  • Page 448 ■ Ceintures de sécurité arrière Si la ceinture de sécurité est sortie de son guide, repassez-la dedans avant de l'utiliser. Entretien et soin ■ Ceintures de sécurité Nettoyez avec un chiffon ou une éponge humectée d'eau savonneuse tiède. Profitez de l'occasion pour vérifier régulièrement que les ceintures ne sont pas effilochées, entaillées, ou ne paraissent pas exagérément usées.

  • Page 450: Alphabetical Index

    Alphabetical index Alphabetical index A/C ..........174 Portable music player....210 ABS........... 158 Radio........186 Air conditioning filter....319 Steering wheel audio Air conditioning system switch........211 Air conditioning filter ..... 319 Type ........183 Automatic air conditioning Automatic air conditioning system........ 174 system ........174 Airbags Automatic light control Airbag operating conditions..
  • Page 451 Alphabetical index Child restraint system Cleaning Booster seats, definition..105 Exterior........274 Booster seats, installation ..109 Interior........276 Convertible seats, Seat belts ......277 definition ......105 Clock ......... 255 Convertible seats, Compass........269 installation......109 Condenser ........ 298 Front passenger occupant Console box ......248 classification system ...100 Cooling system Infant seats, definition ...105...
  • Page 452 Alphabetical index “ECO HEAT/COOL” switch ..174 Engine/power control unit coolant Electronic key Capacity ........401 If your electronic key Checking .......296 battery is discharged..382 Preparing and checking before Electric power steering... 158 winter ........166 Emergency, in case of Engine coolant temperature If a warning light turns on ..
  • Page 453 Alphabetical index Garage door opener....264 Initialization Gas station information...444 Items to initialize ....424 Gauges........139 Inside rear view mirror ....69 Glove box........248 Interior lights Glove box light ......248 Interior lights ......244 Grocery bag hooks ....263 Switch ........245 Wattage......... 405 Hands-free phone system (for cellular phone) Jack...
  • Page 454 Alphabetical index Maintenance Power outlet ......257 Do-it-yourself Power switch ......131 maintenance ...... 285 Power windows ......73 General maintenance ... 281 Maintenance data....396 Radiator ........298 Maintenance requirements... 279 Radio .........186 Meter Rear seats Instrument panel light Folding down......58 control ........ 140 Rear turn signal lights Meters ........
  • Page 455 Alphabetical index Seats Stuck Adjustment ......56 If your vehicle becomes Adjustment precautions...57 stuck ........393 Child seats/child restraint Sun visors ........ 253 system installation ....109 Sunshade Cleaning ........276 Roof ........76 Head restraint......59 Switch Properly sitting in the seat..86 “ECO HEAT/COOL” switch ... 174 Seat heaters......259 Engine switch .......
  • Page 456 Alphabetical index Towing Electric power steering..349 Dinghy towing....... 171 Low fuel level ......351 Trailer towing......170 Low tire pressure warning TRAC ........158 light ........351 Traction control....... 158 Malfunction indicator lamp ..349 Transmission......135 Master warning light ....351 If the shift lever cannot be Open door ......351 shifted from P.....
  • Page 457 Alphabetical index Wireless remote control key Replacing the battery ....322 Wireless remote control ..47 WMA disc........199...
  • Page 458 Alphabetical index...

  • Page 459: What To Do If

    What to do if... What to do if... If you have a flat tire A tire is punctured P. 368 P. 378 If the hybrid system will not start P. 83 Immobilizer system The hybrid system does not start P. 385 If the 12-volt battery is discharged If the electronic key does not oper- P.
  • Page 460 What to do if... nWarning lights Brake system warning Tire pressure warning light (red indicator) light P. 351 Open door warning light P. 348 P. 351 Charging system warn- Low fuel level warning ing light light P. 348 P. 351 Malfunction indicator Driver’s seat belt lamp...

  • Page 461: Gas Station Information

    (L, lmp.qt.) capacity With filter 4.5 (4.3, 3.8) (Drain and refill) Without filter 4.3 (4.1, 3.6) Toyota Genuine Motor Oil or equivalent Oil grade: ILSAC multigrade engine oil Engine oil type P. 400 Recommended oil viscosity: SAE 5W-20 or 0W-20...

Table of Contents
