Page 1 TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. When driving Driving, stopping, and safe-driving information. Interior and Air conditioning and audio systems, as well as other in- exterior features terior features for a comfortable driving experience. Maintenance Cleaning and protecting your vehicle, performing do-it- and care...
Page 2: Table Of Contents
TABLE OF CONTENTS Index Moon roof ......99 Before driving 1-5. Refueling ......103 Opening the fuel tank 1-1. Key information ....42 cap........103 Keys ........42 1-6. Theft deterrent system..108 1-2. Opening, closing and Engine immobilizer locking the doors ....44 system ......
Page 3 Accessory meter ....204 Outside rear view mirror defoggers and front windshield wiper de-icer 2-3. Operating the lights and (if equipped on Regular wipers .......207 Cab and Double Cab Headlight switch....207 models) ......293 Fog light switch ....210 Back window, outside Windshield wipers and rear view mirror defoggers...
Page 4 TABLE OF CONTENTS Index 3-4. Using the hands-free 3-7. Other interior features..424 phone system Sun visors......424 (for cellular phone)..360 Vanity mirrors ..... 425 Hands-free phone system Clock........426 (for cellular phone) ... 360 Outside temperature Using the hands-free display ......
Page 5 4-3. Do-it-yourself If you have a flat tire ... 558 maintenance.....471 If the engine will not start..575 Do-it-yourself service If the shift lever cannot precautions ....... 471 be shifted from P ....577 Hood ........475 If you lose your keys... 580 Engine compartment...
Page 6 TABLE OF CONTENTS Index Index Abbreviation list......654 Alphabetical index ..... 656 What to do if....... 666...
Page 8 Pictorial index Exterior Regular Cab models Outside rear view mirrors P. 88 Windshield wipers P. 211 Hood P. 475 Front turn signal/parking Front side marker lights P. 185, 207 lights P. 207 Headlight Headlight high beam low beam P. 207 P.
Page 9 ∗ Back window P. 96 Cargo lamps P. 397 Stop/tail and rear side marker lights P. 207 Rear turn signal lights P. 185 Side doors P. 47 Tailgate P. 52 License plate lights Fuel filler door P. 103 P. 207 Tires Rotation P.
Page 10 Pictorial index Exterior Double Cab models Outside rear view mirrors P. 88 Windshield wipers P. 211 Hood P. 475 Front turn signal/ Front side marker lights P. 207 parking lights P. 185, 207 Headlight Headlight high beam low beam P. 207 P.
Page 11 ∗ Back window P. 96 Stop/tail and rear side Cargo lamps P. 397 marker lights P. 207 Fuel filler door P. 103 Rear turn signal lights P. 185 Side doors Tailgate P. 47 P. 52 Tires License plate lights P. 207 Rotation P.
Page 12 Pictorial index Exterior CrewMax models ∗ Moon roof P. 99 Outside rear view mirrors P. 88 Windshield wipers P. 211 Hood P. 475 Front turn signal/ Front side marker lights P. 207 parking lights P. 185, 207 Headlight Headlight high beam low beam P.
Page 13 Power back window P. 97 Stop/tail and rear side Cargo lamps P. 397 marker lights P. 207 Fuel filler door P. 103 Rear turn signal lights P. 185 Tailgate Side doors P. 52 P. 47 Tires License plate lights P. 207 Rotation P.
Page 14 Pictorial index Interior Front separated type seats Seat belts Console box P. 75 P. 401 Head restraints P. 71 Horn P. 187 Bottle holders SRS driver airbag P. 417 P. 115 SRS front passenger airbag P. 115 Glove boxes P. 400 ∗...
Page 15 Type A Personal/interior SRS curtain shield airbags P. 115 lights P. 395 ∗ ∗ Moon roof switches Personal light ∗ P. 99 interior light P. 395 Rear seat entertainment Overhead console ∗ system P. 329 P. 413 Sun visors P. 424 Anti-glare inside rear view mirror P.
Page 16 Pictorial index Interior Type B (If equipped on Double Cab and CrewMax models) SRS curtain shield airbags P. 115 Personal/interior ∗ Personal light P. 395 lights P. 395 Rear seat entertainment Overhead console ∗ system P. 329 P. 413 Sun visors P.
Page 17 Driving position memory Inside door lock Door lock ∗ switches switch P. 48 P. 68 button P. 48 Power window Auxiliary box Window lock switches switch P. 94 P. 419 P. 95 ∗ ∗ : CrewMax models : If equipped ∗...
Page 18 Pictorial index Interior Front cup holders P. 414 Ashtray P. 429 Shift lever P. 180 Map holder P. 406 Shift lock override button P. 577...
Page 19 Double Cab models Rear cup holders P. 416 Power outlet P. 432 CrewMax models ∗ A/V input adapter P. 350 Power outlet (12V DC) P. 432 ∗ Power outlet (115V AC) P. 437 ∗ : If equipped...
Page 20 Pictorial index Interior Front bench type seat Seat belts P. 75 Head restraints P. 71 Horn P. 187 Bottle holders P. 417 SRS driver airbag P. 115 SRS front passenger airbag P. 115 Glove boxes P. 400 ∗ Floor mats P.
Page 21 Type A Personal/interior SRS curtain shield airbags P. 115 lights P. 395 ∗ Moon roof switches ∗ Personal light ∗ P. 99 interior light P. 395 Rear seat entertainment Overhead console ∗ system P. 329 P. 413 Sun visors P. 424 Anti-glare inside rear view mirror P.
Page 22 Pictorial index Interior Type B (If equipped on Double Cab and CrewMax models) SRS curtain shield airbags P. 115 Personal/interior ∗ Personal light P. 395 lights P. 395 Rear seat entertainment Overhead console ∗ system P. 329 P. 413 Sun visors P.
Page 23 Door lock Inside door lock ∗ switch P. 48 button P. 48 ∗ Power window Auxiliary box Window lock ∗ ∗ switches switch P. 94 P. 419 P. 95 ∗ ∗ : CrewMax models : If equipped ∗ : If equipped on CrewMax models...
Page 24 Pictorial index Interior Shift lever P. 180 Shift lock override ∗ TOW HAUL switch button P. 577 P. 183...
Page 25 Pen holder P. 409 Front cup holders P. 414 Auxiliary box P. 419 Auxiliary box P. 419 ∗ : If equipped...
Page 26 Pictorial index Interior Double Cab models Power outlet P. 432 Rear cup holders P. 416...
Page 27 CrewMax models ∗ Power outlet (12V DC) P. 432 A/V input adapter ∗ P. 350 Power outlet (115V AC) P. 437 ∗ : If equipped...
Page 28 Pictorial index Instrument panel Headlight switch P. 207 Turn signal lever P. 185 ∗ Fog light switch P. 210 Gauges and meters P. 188 Windshield wipers and washer switch P. 211 Passenger airbag off ∗ switch P. 127 Tire pressure warning reset switch P.
Page 29 Vehicles with manual air conditioning system (front separated type seats) ∗ Outside rear view mirror defogger switch / outside rear view mirror ∗ defogger and front windshield wiper de-icer switch P. 293 ∗ Back window defogger switch / back window defogger and outside rear ∗...
Page 30 Pictorial index Instrument panel Vehicles with manual air conditioning system (front bench type seat) ∗ Outside rear view mirror defogger switch / outside rear view mirror ∗ defogger and front windshield wiper de-icer switch P. 293 ∗ Back window defogger switch / back window defogger and outside rear ∗...
Page 31 Vehicles with an automatic air conditioning system ∗ Outside rear view mirror defogger switch / outside rear view mirror ∗ defogger and front windshield wiper de-icer switch P. 293 ∗ Back window defogger and outside rear view mirror defogger switch back window defogger, outside rear view mirror defogger and front ∗...
Page 32 Pictorial index Instrument panel Front separated type seats Emergency flasher switch P. 534 Accessory meter ∗ Intuitive parking assist control switches P. 204 ∗ switch P. 217 Multi-information display ∗ control switches P. 198 Front wheel drive control ∗ switch P.
Page 33 Front bench type seat Emergency flasher switch P. 534 Intuitive parking assist Accessory meter ∗ ∗ switch P. 217 control switches P. 204 Front wheel drive control ∗ switch P. 223 Ashtray P. 429 Power outlet P. 432 Cigarette lighter P.
Page 34 Pictorial index Instrument panel ∗ Power outlet main switch P. 437 VSC OFF switch P. 227, 232, 233 Engine (ignition) ∗ Power back window switch P. 97 switch P. 177 ∗ Audio remote control switches P. 327 ∗ ∗ Telephone switches Talk switch Cruise control ∗...
Page 35 Personal/interior light Instrument panel light main switch P. 394 control dial P. 193 Outside rear view mirror Tilt and telescopic steering ∗ ∗ switches P. 88 control switch P. 84 ∗ Cargo lamp main switch Tilt steering lock release lever P.
Page 36: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehicles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 37 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 38 CAUTION General precaution regarding children’s safety Never leave children unattended in the vehicle, and never allow children to have or use the key. Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the cigarette lighter, the windows, or other features of the vehicle.
Page 39 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Page 41: Key Information
Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (→P. 580)
Page 42 1-1. Key information NOTICE To prevent key damage (vehicles with engine immobilizer system) Do not subject the keys to strong shocks, expose them to high tempera- tures by placing them in direct sunlight, or get them wet. Do not expose the keys to electromagnetic materials or attach any mate- rial that blocks electromagnetic waves to the key surface.
Page 43: Opening, Closing And Locking The Doors
1-2. Opening, closing and locking the doors Wireless remote control (if equipped) The wireless remote control can be used to lock and unlock the vehi- cle from outside the vehicle. Locks all doors Unlocks all doors Pressing the button unlocks the driver’s door.
Page 44 When the wireless key has been left near an electrical appliance such as a personal computer Customization That can be configured at Toyota dealer (vehicles without multi-informa- tion display) Settings (e.g. wireless remote control) can be changed. (Customizable features →P. 633) It is possible to change the settings (vehicles with multi-information dis- play) (Feature customization →P.
Page 45 1-2. Opening, closing and locking the doors Certification for wireless remote control For vehicles sold in U.S.A. NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 46: Side Doors
1-2. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the wireless remote control, key or door lock switch. Wireless remote control (if equipped) →P. 44 Vehicles without power door lock system Locks the door Unlocks the door Vehicles with power door lock system Locks all doors...
Page 47 1-2. Opening, closing and locking the doors Door lock switch (if equipped) Driver’s door lock switch Locks all doors Unlocks all doors Passenger’s door lock switch Locks all doors Unlocks all doors Inside lock button Locks the door Unlocks the door Pulling the door handle can open the front door even if the lock button is in the lock posi-...
Page 48 1-2. Opening, closing and locking the doors Locking the front doors from the outside without a key Move the inside door lock button to the lock position. Close the door. Vehicles with power door lock system The door cannot be locked if a front door is open and the key is in the engine switch.
Page 49 Setting and canceling the functions Vehicles with multi-information display →P. 200 Vehicles without multi-information display To switch between setting and canceling, contact your Toyota dealer. When locking the doors using the key (vehicles with power door lock system) The door cannot be locked if the key is in the engine switch.
Page 50 1-2. Opening, closing and locking the doors CAUTION To prevent an accident Observe the following precautions while driving the vehicle. Failing to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. Always use a seat belt.
Page 51: Tailgate
1-2. Opening, closing and locking the doors Tailgate The tailgate can be opened using the tailgate handle. The tailgate can be locked/unlocked using a key. Tailgate handle Pull the handle Open the tailgate slowly The support cables will hold the tailgate horizontal. After closing the tailgate, try pulling it toward you to make sure it is securely locked.
Page 52 1-2. Opening, closing and locking the doors Removing the tailgate Before removing the tailgate (vehicles with rear view monitor system) These connector covers are used when removing the tailgate, to prevent the back-up camera wire harness connectors from being contaminated. Connector cover (Gray) Connector cover (White) Store the connector covers in the...
Page 53 1-2. Opening, closing and locking the doors Open the tailgate. Pull out the plastic wire protector located in the vehicle bed by pressing the tabs and pulling the protector. Plastic wire protector Pull out the wire harness from the vehicle bed. Attach connector cover...
Page 54 1-2. Opening, closing and locking the doors Removing the tailgate Open the tailgate to the angle where you can release the brackets on the support cables from the lugs on both sides. Lift the support cable bracket up and slide it off. To unhook the support cable bracket, keep pulling up the clip on the bracket and unhook the...
Page 55 1-2. Opening, closing and locking the doors Rear step bumper Type A For rear end protection and eas- ier step-up loading. To get on the rear step bumper, use the shaded area in the illus- tration. Type B CAUTION Before removing the tailgate (vehicles with rear view monitor system) Disconnect the wire harness between the back-up camera and the vehicle.
Page 56 1-2. Opening, closing and locking the doors NOTICE To prevent damage to the tailgate wire harness (vehicles with rear view monitor system) Do not pull out all of the tailgate wire harness before open the tailgate. To prevent damage to the camera lens (vehicles with rear view monitor system) Store the removed tailgate with the back-up camera lens facing upward.
Page 57: Adjustable Components (Seats, Mirrors, Steering Wheel)
1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Manual seats (Separated type seats) Passenger’s seat Driver’s seat Seat position adjustment lever Seatback angle adjustment lever Double Cab and CrewMax models Driver’s seat vertical height adjustment lever Driver’s seat cushion (front) angle adjustment knob Driver’s seat lumbar support adjustment switch (if equipped)
Page 58 1-3. Adjustable components (seats, mirrors, steering wheel) Manual seat (Bench type seat) Seat position adjustment levers Seatback angle adjustment levers Center seat seatback angle adjustment lever Double Cab and CrewMax models Driver’s seat vertical height adjustment lever Driver’s seat cushion (front) angle adjustment knob...
Page 59 1-3. Adjustable components (seats, mirrors, steering wheel) Power seat Passenger’s seat Driver’s seat Seat position adjustment switch Seatback angle adjustment switch Driver’s seat cushion (front) angle adjustment switch Driver’s seat vertical height adjustment switch Driver’s seat leg support adjustment switch (if equipped) Seat lumbar support adjustment switch...
Page 60 1-3. Adjustable components (seats, mirrors, steering wheel) Folding passenger’s seat (if equipped on Regular Cab models) Before folding passenger’s seat Push the seat belt hanger down as far as it will go when it is in the raised position. Pass the seat belts through the seat belt hanger.
Page 61 1-3. Adjustable components (seats, mirrors, steering wheel) Pull the seatback folding lever and fold the seatback down. CAUTION Seat adjustment Be careful that the seat does not hit passengers or luggage. Do not recline the seat more than necessary when the vehicle is in motion to reduce the risk of sliding under the lap belt.
Page 62: Rear Seats (Double Cab And Crewmax Models)
1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats (Double Cab and CrewMax models) CrewMax models Seat position adjustment lever Seatback angle adjustment lever Double Cab models The rear seats do not have a seat adjustment function.
Page 63 1-3. Adjustable components (seats, mirrors, steering wheel) Raising the bottom cushion (Double Cab models) Before raising the bottom cushion Stow the seat belt buckles. This prevents the seat belt buck- les from falling out when you fold the seatback. Pass the seat belts through the seat belt hangers.
Page 64 1-3. Adjustable components (seats, mirrors, steering wheel) Folding down rear seats (CrewMax models) Before folding down rear seats Stow the rear seat belt buckles. This prevents the seat belt buck- les from falling out when you fold the seatback. Pass the seat belts through the seat belt hangers.
Page 65 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION When adjusting a rear seat (CrewMax models) Be careful that the seat does not hit passengers or luggage. Do not recline the seat more than necessary when the vehicle is in motion to reduce the risk of sliding under the lap belt.
Page 66 1-3. Adjustable components (seats, mirrors, steering wheel) NOTICE When folding the seats The seat belts and buckles must be stowed. CrewMax models: Do not fold the rear seat seatback forward with the lug- gage cover hooks attached.
Page 67: Driving Position Memory System
1-3. Adjustable components (seats, mirrors, steering wheel) Driving position memory system (if equipped) Your preferred driving position (the position of the driver’s seat, steering wheel and outside rear view mirrors) can be entered into the computer’s memory and recalled with the touch of a button. Two different driving positions can be entered into memory.
Page 68 1-3. Adjustable components (seats, mirrors, steering wheel) Linking driving position memory with door unlock operation Memorized driving positions can be recalled when you unlock the driver’s door using the wireless remote control and open the driver’s door. Setting the linked door unlock operation Set the driving positions into the memory system using the “1”...
Page 69 1-3. Adjustable components (seats, mirrors, steering wheel) Retained accessory power Each memorized position (except for the tilt and telescopic steering column) can be activated within 30 seconds after the driver’s door is opened, even if the key is not in the engine switch. If any position memory button is pushed while the adjustments are being made The operation will stop.
Page 70: Head Restraints
1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints Adjusting the head restraints Front separated type seats Vertical adjustment Down Push the head restraint down while pushing the lock release button. Lock release button Angle adjustment (if equipped) Front bench type seat Vertical adjustment Down Push the head restraint down...
Page 71 1-3. Adjustable components (seats, mirrors, steering wheel) Rear seat (Double Cab models) Vertical adjustment Down Push the head restraint down while pushing the lock release button. Lock release button Rear seat (CrewMax models) Vertical adjustment Down Push the head restraint down while pushing the lock release button.
Page 72 1-3. Adjustable components (seats, mirrors, steering wheel) Removing the rear head restraints Double Cab models Pull the head restraint up while pushing the lock release button. CrewMax models Pull the head restraint up while pushing the lock release button. Adjusting the height of the head restraints Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears.
Page 73 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. Use the head restraints designed for each respective seat. Adjust the head restraints to the correct position at all times. Do not drive with the head restraints removed.
Page 74: Seat Belts
1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. Correct use of the seat belts l Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 75 1-3. Adjustable components (seats, mirrors, steering wheel) Releasing the belt Press the release button. Release button Using front seat belt (Regular Cab models) Raise the front seat belt hanger until it locks.
Page 76 1-3. Adjustable components (seats, mirrors, steering wheel) Adjusting the height of the belt Front seats (Double Cab and CrewMax models) Down Push the lock release button and slide the height adjuster down. Move the height adjuster up as needed until you hear a click.
Page 77 1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats (CrewMax models) Down Push the lock release button and slide the height adjuster down. Move the height adjuster up as needed until you hear a click. Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt...
Page 78 1-3. Adjustable components (seats, mirrors, steering wheel) Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
Page 79 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system.
Page 80 If the pretensioner has activated, the seat belt becomes locked: it cannot be further extended, nor will it return to the stowed position. The seat belt cannot be used again and must be replaced at your Toyota dealer. Child restraint lock function belt Do not allow children to play with the child restraint lock function belt.
Page 81 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Before using a front seat belt (Regular Cab models) Make sure the seat belt hanger is secured in the raised position before you fasten the seat belt. Using a seat belt extender Do not wear the seat belt extender if you can fasten the seat belt without the extender.
Page 82: Steering Wheel (Manually Adjustable Type)
1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel (manually adjustable type) The steering wheel can be adjusted to a comfortable position. To change the angle Hold steering wheel and press the lever down. Adjust to the ideal position by moving the steering wheel verti- cally.
Page 83: Steering Wheel (Power-Adjustable Type)
1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel (power-adjustable type) The steering wheel can be adjusted to a comfortable position. Down Toward the driver Away from the driver Auto tilt away When the key is removed from the engine switch, the steering wheel returns to its stowed posi- tion by moving up and away to enable easier driver entry and...
Page 84: Anti-Glare Inside Rear View Mirror
1-3. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions. Manual anti-glare inside rear view mirror Normal position Anti-glare position...
Page 85 1-3. Adjustable components (seats, mirrors, steering wheel) Auto anti-glare inside rear view mirror In automatic mode, sensors are used to detect the headlights of vehicles behind and automatically reduces the reflected light. Turns automatic mode ON/ The indicator comes on when automatic mode is turned on.
Page 86 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Caution while driving Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and an accident, resulting in death or serious injury.
Page 87: Outside Rear View Mirrors
1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted. Power-adjustable type (Type A) Select a mirror to adjust. (L: left or R: right) Adjust the mirror up, down, in or out using the switch.
Page 88 1-3. Adjustable components (seats, mirrors, steering wheel) Power-adjustable type (Type B) Select a mirror to adjust. (L: left or R: right) Adjust the mirror up, down, in or out using the switch. Power-adjustable type (Type C) Upper part mirror: Select a mirror to adjust. (L: left or R: right) Adjust the mirror up, down, in or out using the switch.
Page 89 1-3. Adjustable components (seats, mirrors, steering wheel) Manually adjustable type Adjust the mirror up, down, in or out by pushing the mirror surface. Folding back the mirrors From outside (Type A) Push backward to fold the mir- rors. From outside (Type B) Push backward to fold the mir- rors.
Page 90 1-3. Adjustable components (seats, mirrors, steering wheel) From inside (if equipped) Press the switch. Pressing again will extend the mirrors. Extending the mirrors (if equipped) The mirrors can be slid outward to improve visibility around wide trailers.
Page 91 1-3. Adjustable components (seats, mirrors, steering wheel) Recommended mirror angle when towing a trailer (vehicles with extending mirrors) Power adjust the upper part of the mir- ror until an appropriate view is obtained. It is recommended that the outer 2/3 of the upper mirror be filled with images other than the vehicle and trailer.
Page 92 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION When driving the vehicle Observe the following precautions while driving. Failing to do so may result in loss of control of the vehicle and cause an acci- dent, resulting in death or serious injury. Do not adjust the mirrors while driving.
Page 93: Opening And Closing The Windows And Moon Roof
1-4. Opening and closing the windows and moon roof Power windows (if equipped) The power windows can be opened and closed using the following switches. Driver’s power window switches Closing Opening One-touch opening (driver’s window only) Pressing the switch in the opposite direction will stop win- dow travel partway.
Page 94 1-4. Opening and closing the windows and moon roof Lock switch Press the switch down to lock passenger window switches. Use this switch to prevent chil- dren from accidentally opening or closing a passenger window. The power windows can be operated when The engine switch is in the ON position.
Page 95: Back Window
1-4. Opening and closing the windows and moon roof Back window (if equipped) The back window can be opened and closed using the lock release lever. OPEN/CLOSE Push the lock release lever and slide the back window. Closing the back window Make sure that the back window is securely closed after closing it.
Page 96: Power Back Window (Crewmax Models Only)
1-4. Opening and closing the windows and moon roof Power back window (CrewMax models only) The back window can be opened and closed using the switch. Opening Closing The power back window can be operated when The engine switch is in the ON position. Operating the power back windows after turning the engine switch off The power back windows can be operated for approximately 43 seconds even after the engine switch is turned to the ACC position or turned off.
Page 97 1-4. Opening and closing the windows and moon roof CAUTION Closing the back window Observe the following precautions. Failing to do so may result in death or serious injury. Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.
Page 98: Moon Roof
1-4. Opening and closing the windows and moon roof Moon roof (if equipped) Use the overhead switches to open, close, and tilt the moon roof up and down. Opening and closing Open Close To stop partway, press the switch lightly.
Page 99 1-4. Opening and closing the windows and moon roof Tilt up and down Tilt up Tilt down To stop partway, press the switch lightly. The moon roof can be operated when The engine switch is in the ON position. Door lock linked moon roof operation The moon roof can be opened and closed using the key.
Page 100 After the moon roof will tilt up and down, release the switch. To ensure the initialization is complete, make sure automatic open- ing and closing functions work properly. Customization that can be configured at Toyota dealer Settings (e.g. moon roof) can be changed. (Customizable features →P. 633)
Page 101 1-4. Opening and closing the windows and moon roof CAUTION Opening the moon roof Observe the following precautions. Failing to do so may cause death or serious injury. Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving.
Page 102: Refueling
1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. Before refueling the vehicle Turn the engine switch off and ensure that all the doors and win- dows are closed. Opening the fuel tank cap Open the fuel filler door.
Page 103 1-5. Refueling Hang the fuel tank cap on the back of the fuel filler door. Closing the fuel tank cap When installing the fuel tank cap, turn it until you hear a click. The cap will turn slightly to the opposite direction when released.
Page 104 1-5. Refueling Identifying flex-fuel vehicles Flex-fuel vehicles can be identified by the fuel tank cap, which is marked “FLEXFUEL E85/GASOLINE”. Fuel tank capacity Approximately 26.4 gal. (100 L, 22.0 Imp. gal.) E85 Fueling Stations (Flex-fuel vehicles) E85 fueling stations and fuel pumps can be identified by the indication “E85 85% Ethanol”.
Page 105 This may cause static electricity to build up, resulting in a possible ignition hazard. When replacing the fuel cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 106 1-5. Refueling NOTICE Refueling Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the exhaust systems to operate abnormally or damaging fuel system components or the vehicle’s painted surface. To prevent damage to the fuel filler door Do not apply excessive force.
Page 107: Theft Deterrent System
1-6. Theft deterrent system Engine immobilizer system (if equipped) The vehicle’s keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. The indicator flashes after the key has been removed from the engine switch to indicate...
Page 108 1-6. Theft deterrent system For vehicles sold in Canada This device complied with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, includ- ing interference that may cause undesired operation of the device.
Page 109: Alarm
1-6. Theft deterrent system Alarm (if equipped) The system sounds the alarm and flashes lights when forcible entry is detected. Triggering of the alarm The alarm is triggered in the following situations. l A locked door is unlocked or opened in any way other than using the wireless remote control door lock function or key.
Page 110 1-6. Theft deterrent system Items to check before locking the vehicle To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following. Nobody is in the vehicle. The windows and moon roof are closed before the alarm is set. No valuables or other personal items are left in the vehicle.
Page 111: Theft Prevention Labels (U.s.a.)
1-6. Theft deterrent system Theft prevention labels (U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from sto- len vehicles. Do not remove under penalty of law.
Page 112: Safety Information
1-7. Safety information Correct driving posture Drive in a good posture as follows: Sit upright and well back in the seat. (→P. 58) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 113 1-7. Safety information CAUTION While driving Do not adjust the position of the driver’s seat while driving. Doing so could cause the driver to lose control of the vehicle. Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
Page 114: Srs Airbags
1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and right front...
Page 115 1-7. Safety information Airbag system components Regular Cab models Double Cab and CrewMax models...
Page 116 1-7. Safety information Side airbags Occupant detection system (ECU and sensors) AIR BAG ON and AIR BAG OFF indicator lights warning light RSCA OFF indicator light Curtain shield airbags RSCA OFF switch Front passenger airbag Driver’s seat position sen- Side and curtain shield air- bag sensors Driver airbag Front airbag sensors...
Page 117 1-7. Safety information SRS warning light This warning light system monitors the airbag sensor assembly, front airbag sensors, side and curtain shield airbag sensor assemblies, curtain shield air- bag sensor assemblies, driver’s seat position sensor, driver’s seat belt buckle switch, front passenger occupant classification system, AIR BAG ON and AIR BAG OFF indicator lights, front passenger’s seat belt buckle switch, passenger airbag off switch (Regular Cab models), front seat belt preten- sioner assemblies, RSCA OFF indicator light, inflators, interconnecting wir-...
Page 118 1-7. Safety information Operating conditions (side airbags) The SRS side airbags are designed to inflate when the passenger com- partment is subjected to a severe impact from the side. The SRS side airbag on the passenger seat will not activate if there is no passenger sitting in the right front passenger seat.
Page 119 1-7. Safety information Types of collisions that may not deploy the SRS airbag (front airbags) The SRS front airbags are generally not designed to inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low- speed frontal collision.
Page 120 Pitching end over end When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. Do not disconnect the battery cables before contacting your Toyota dealer. Any of the SRS airbags have been inflated.
Page 121 1-7. Safety information The surface of the seats with the side airbag is scratched, cracked or other- wise damaged. The portion of the front pillars, rear pil- lars or roof side rail garnishes (padding) containing the curtain shield airbags inside is scratched, cracked or other- wise damaged.
Page 122 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are...
Page 123 1-7. Safety information CAUTION SRS airbag precautions Do not sit on the edge of the seat or lean against the dashboard. Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger. Do not drive the vehicle while the driver or passenger has items resting on their knees.
Page 124 Wash off any residue as soon as possible to prevent skin irritation. If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer.
Page 125 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 126 1-7. Safety information Passenger airbag off switch (Regular Cab models) The passenger airbag off switch is designed to disable the front pas- senger airbag in order to allow usage, if necessary, of the right pas- senger seat by a member of a passenger risk group identified in TABLE 1 (→P.
Page 127 1-7. Safety information Passenger risk group TABLE 1: A PASSENGER RISK GROUP Infant. An infant (less than 1 year old) who must ride in the front seat because: • Vehicle has no rear seat; • Vehicle has a rear seat too small to accommodate a rear-facing infant seat;...
Page 128 1-7. Safety information CAUTION When the passenger airbag off switch is turned off Do not turn the passenger airbag off switch to the OFF position except when a member of a passenger risk group identified in TABLE 1 is occupy- ing the right passenger seating position.
Page 129 1-7. Safety information CAUTION For normal driving Make sure the RSCA OFF indicator is not turned on. If it is left on, the curtain shield airbag will not activate in the event of an accident, which may result in death or serious injury.
Page 130: Front Passenger Occupant Classification System
1-7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the right front passenger seat and activates or deactivates the devices for the front passenger.
Page 131 1-7. Safety information Conditions and operation of the front passenger occupant classification system Regular Cab models l Indicator/warning light Condition detected AIR BAG Front by the front Passenger ON and passenger’s passenger airbag off AIR BAG warning seat belt occupant switch reminder light...
Page 132 1-7. Safety information l Devices Condition detected by Passen- Side air- Curtain Front Front pas- the front pas- ger air- bag on shield air- passen- senger’s senger occu- bag off the pas- bag in the ger air- seat belt passen- pant switch senger...
Page 133 1-7. Safety information : In case the indicator is not illuminated, consult this manual for installing the child restraint system properly. (→P. 138) Double Cab and CrewMax models l Indicator/warning light Condition detected AIR BAG ON Front passen- by the front passen- and AIR BAG SRS warning ger’s seat belt...
Page 134 1-7. Safety information : The right front passenger on the bench type seat. : The system judges a person of adult size as an adult. When a smaller adult sits in the front passenger seat, the system may rec- ognize him/her as a child depending on his/her physique and pos- ture.
Page 135 Do not modify or remove the front seats. Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately.
Page 136 1-7. Safety information CAUTION Front passenger occupant classification system precautions Double Cab and CrewMax models: Child restraint systems installed on the rear seat should not contact the front seatbacks. Do not use a seat accessory, such as a cushion or seat cover, that covers the seat cushion surface.
Page 137: Child Restraint Systems
1-7. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 138 1-7. Safety information Forward facing ⎯ Convertible seat Booster seat Selecting an appropriate child restraint system Use a child restraint system appropriate for the child until the child becomes large enough to properly wear the vehicle’s seat belts. If a child is too large for a child restraint system, sit the child on a rear seat and use the vehicle’s seat belt.
Page 139 In an accident, the child can be crushed against the windshield, or between you and the vehicle’s interior. Regular Cab models: Toyota strongly urges use of a proper child restraint system which conforms to the size of the child.
Page 140 1-7. Safety information CAUTION Child restraint precautions Regular Cab models: Never install a rear-facing child restraint system on the right passenger seat with the passen- ger airbag off switch in the AUTO posi- tion. In the event of an accident, the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child if the rear-fac-...
Page 141 1-7. Safety information CAUTION Child restraint precautions Regular Cab models: A forward-facing child restraint system which belongs to a passenger risk group should never be installed on the right passenger seat with the passenger airbag off switch in the AUTO position, because the force of the deploying airbag could cause death or serious injury to the child in forward seating position.
Page 142 1-7. Safety information CAUTION When the child restraint system is not in use Keep the child restraint system properly secured on the seat even if it is not in use. Do not store the restraint unsecured in the passenger compart- ment.
Page 143: Installing Child Restraints
1-7. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tether for Chil- dren) system.
Page 144 1-7. Safety information Seat belts equipped with a child restraint locking mecha- nism (ALR/ELR belts except driver’s seat belt) (→P. 79) Anchor bracket (for top tether strap) Regular Cab models Anchor brackets are pro- vided passenger seats. Separated type seat Bench type seat Double Cab models Anchor brackets are pro-...
Page 145 1-7. Safety information Installing the child restraint system on the right passenger seat (Regular Cab models) When you install a child restraint system which belongs to a passen- ger risk group on the right passenger seat, do the following proce- dure.
Page 146 1-7. Safety information Installation with LATCH system (Regular Cab models) Installing on the right passenger seat (vehicles without seat- back table) Fold the seatback while pulling the lever. Return the seatback and secure it at the 1st lock posi- tion (most upright position).
Page 147 1-7. Safety information Type B Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto tether strap anchor. (→P. 156) For owners in Canada: The symbol on a child restraint system indicates the presence of a lower connector system.
Page 148 1-7. Safety information Type A Widen the slits of the seat cushion slightly. Latch the hooks of the lower straps onto the LATCH anchors tighten the lower straps. If the child restraint has a top tether strap, the top tether strap should be latched onto tether strap anchor.
Page 149 1-7. Safety information Installation with LATCH system (Double Cab models) Type A Widen the gap between the seat cushion and seatback slightly. Latch the hooks of the lower straps onto the LATCH anchors tighten the lower straps. If the child restraint has a top tether strap, the top tether strap should be latched...
Page 150 1-7. Safety information Type B Widen the gap between the seat cushion and seatback slightly. Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto tether strap anchor. (→P.
Page 151 1-7. Safety information Type A Widen the gap between the seat cushion and seatback slightly. Latch the hooks of the lower straps onto the LATCH anchors tighten the lower straps. For owners in Canada: The symbol on a child restraint system indicates the presence of a lower connector system.
Page 152 1-7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing ⎯ Infant seat/convertible seat Place the child seat on the rear seat facing the rear of the vehi- cle. Run the seat belt through the child seat and insert the plate into the buckle.
Page 153 1-7. Safety information While pushing the child seat down into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 154 1-7. Safety information Fully extend the shoulder belt and then allow it to retract slightly in order to activate the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing the child seat into the seat, allow the shoulder belt to retract until the child seat is securely in place.
Page 155 1-7. Safety information Sit the child in the booster seat. Fit the seat belt to the booster seat according to the manufac- turer’s instructions and insert the plate into the buckle. Make sure that the belt is not twisted. Check that the shoulder belt is correctly positioned over...
Page 156 1-7. Safety information Remove the anchor bracket cover. Installing position: Right side passenger seat Center passenger seat (Bench type seat) Store the removed cover in a safe place such as the glove box. Right side passenger seat Latch the hook onto the anchor bracket and tighten the top tether strap.
Page 157 1-7. Safety information Replace the head restraint. Installing position: Right side passenger seat Center passenger seat (Bench type seat) Child restraint systems with a top tether strap (Double Cab models) Right rear seat or center rear seat Raise the head restraints of right and center seats.
Page 158 1-7. Safety information Right rear seat Route tether strap through the routing device as shown in the illustration. Make sure the top tether strap is not twisted. Routing device Center rear seat Route tether strap through the routing device as shown in the illustration.
Page 159 1-7. Safety information Center rear seat Latch the hook onto the inner anchor strap ring and tighten the top tether strap. Make sure the top tether strap is securely latched. Inner anchor strap ring Lower the head restraints of right and center seats.
Page 160 1-7. Safety information Pull up the straps of center and left seats. Route tether strap through the routing device as shown in the illustration. Make sure the top tether strap is not twisted. Routing device Latch the hook onto the inner anchor strap ring and tighten the top tether strap.
Page 161 1-7. Safety information Child restraint systems with a top tether strap (CrewMax models) Remove the head restraint. Installing position: Outside passenger seat Center passenger seat Outside passenger seat Swing the seatback forward slightly. (→P. 63) Open anchor bracket cover. Latch the hook onto the anchor bracket.
Page 162 1-7. Safety information Center passenger seat Swing the seatback forward slightly. (→P. 63) Open anchor bracket cover. Latch the hook onto the anchor bracket. Return the seatback to its orig- inal position. Make sure seatback securely locked by pushing for- ward and rearward on the top of the seatback.
Page 163 1-7. Safety information CAUTION When installing a booster seat Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode. (→P. 79) ALR mode causes the belt to tighten only which could cause injury or dis- comfort to the child.
Page 164 1-7. Safety information CAUTION When installing a child restraint system Regular Cab models (bench type seat): In order to firmly secure the child restraint system, align the seatback angle and seat position of the right pas- senger seat to match the center pas- senger seat.
Page 165 1-7. Safety information CAUTION When installing a child restraint system Follow all installation instructions provided by the child restraint system manufacturer. After securing the child restraint system, never slide or recline the seat. Do not use a seat belt extender If a seat belt extender is used when installing a child restraint system, the seat belt will not securely hold the child restraint system, which could cause death or serious injury to the child or other passengers in the event of a colli-...
Page 166: Driving Procedures
2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. Starting the engine (→P. 177) Driving With the brake pedal depressed, shift the shift lever to D. (→P. 180) Release the parking brake. (→P.
Page 167 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or when- ever the parking brake shoes and/or drum are replaced. Have your Toyota dealer perform the bedding down.
Page 168 2-1. Driving procedures Operating your vehicle in a foreign country Comply with the relevant vehicle registration laws and confirm the availability of the correct fuel. (→P. 606) Normal characteristics after turning off the engine Approximately five hours after the engine is turned off, you may hear sound coming from under the vehicle for several minutes.
Page 169 Large amounts of exhaust in the vehicle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immediately. Do not under any circumstances shift the shift lever to P, R or N while the vehicle is moving.
Page 170 2-1. Driving procedures CAUTION When driving on slippery road surfaces Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle, resulting in an accident. Sudden changes in engine speed, such as engine braking caused by up- shifting or down-shifting, may cause the vehicle to skid, resulting in an accident.
Page 171 2-1. Driving procedures CAUTION When the vehicle is parked Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Doing so may result in the following. • Gas may leak from a cigarette lighter or spray can, and may lead to a fire.
Page 172 Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard. Toyota does not recommend occupying the rear cargo area when it is fitted with a slide-in camper, camper shell or other type cover while the engine is running.
Page 173 2-1. Driving procedures CAUTION When braking the vehicle If the power brake assist function does not operate, do not follow other vehicles closely and avoid downhills or sharp turns that require braking. In this case, braking is still possible, but it will require more force on the pedal than usual.
Page 174 If you hear a squealing or scraping noise while driving (brake pad wear limit indicators) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. The rotor damage can result if the pads are not replaced when needed.
Page 175: Engine (Ignition) Switch
2-1. Driving procedures Engine (ignition) switch Engine switch LOCK The steering wheel is locked and the key can be removed. Some electrical components such as the audio system can be used. All electrical components can be used. START For starting the engine. Starting the engine Check that the parking brake is set.
Page 176 2-1. Driving procedures Turning the key from ACC to LOCK Shift the shift lever to P. (→P. 180) Push in the key and turn to the LOCK position. Steering lock release When starting the engine, the engine switch may seem stuck in the LOCK posi- tion.
Page 177 2-1. Driving procedures NOTICE To prevent battery discharge Do not leave the engine switch in the ACC or ON position for long periods if the engine is not running. When starting the engine Do not crank for more than 30 seconds at a time. This may overheat the starter and wiring systems.
Page 178: Automatic Transmission
2-1. Driving procedures Automatic transmission Select a shift position appropriate for the driving conditions. Shifting the shift lever Floor shift type While the engine switch is on, depress the brake pedal and move the shift lever. Column-shift type While the engine switch is on, depress the brake pedal and move the shift lever.
Page 179 2-1. Driving procedures Shift position uses Shift position Function Parking the vehicle or starting the engine Reversing Neutral Normal driving S mode driving : To improve fuel consumption and reduce noises, set the shift lever in D for normal driving. : Selecting shift ranges S mode restricts the upper limit of the possible gear ranges, control engine braking forces, and prevents unneces- sary upshifting.
Page 180 2-1. Driving procedures Column-shift type Upshift range Downshift range The initial shift range in S mode is automatically set to 5 or 4 (6-speed models) or 4 (5-speed models) according to vehicle speed. However, the initial shift range may be set to 3 or 2 (6-speed models) or 3 (5- speed models) if the AI-SHIFT has operated while the shift lever was in the D position.
Page 181 2-1. Driving procedures TOW/HAUL switch (6-speed models with towing package) Use TOW/HAUL mode when pulling a trailer or hauling a heavy load. Floor shift type Press the TOW/HAUL switch. The indicator will come on. Press the switch once more to cancel the mode.
Page 182 If the S indicator does not come on even after shifting the shift lever to This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer, immediately. (In this situation, the vehicle will operate as if the shift lever is in D.)
Page 183: Turn Signal Lever
2-1. Driving procedures Turn signal lever Left turn Right turn Move and hold the lever partway to signal a lane change. The left hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change.
Page 184: Parking Brake
2-1. Driving procedures Parking brake Sets parking brake*. (Depressing the pedal again releases the parking brake.) U.S.A. Canada At this time, the indicator will come on. *: Fully depress the parking brake pedal with your left foot while depressing the brake pedal with your right foot.
Page 185: Horn
2-1. Driving procedures Horn To sound the horn, press on or close to the mark. After adjusting the steering wheel (manually adjustable type) Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (→P.
Page 186: Instrument Cluster
2-2. Instrument cluster Gauges and meters Vehicles with multi-information display The following gauges, meters and displays illuminate when the engine switch is in the ON position. Tachometer Displays the engine speed in revolutions per minute. Speedometer Displays the vehicle speed. Fuel gauge Displays the quantity of fuel remaining in the tank.
Page 187 2-2. Instrument cluster Multi-information display →P. 198 Automatic transmission fluid temperature gauge Displays the automatic transmission fluid temperature.
Page 188 2-2. Instrument cluster Vehicles without multi-information display (type A) Vehicles without multi-information display (type B) The following gauges, meters and displays illuminate when the engine switch is in the ON position. Tachometer (if equipped) Displays the engine speed in revolutions per minute. Speedometer Displays the vehicle speed.
Page 189 2-2. Instrument cluster Fuel gauge Displays the quantity of fuel remaining in the tank. Voltmeter (if equipped) Displays the charge state. Engine oil pressure gauge (if equipped) Displays the engine oil pressure. Engine coolant temperature gauge Displays the engine coolant temperature. Odometer/trip meter switching and trip meter resetting button Switches between odometer and trip meter displays.
Page 190 2-2. Instrument cluster Odometer and trip meter display button Pressing this button switches between odometer and trip meter dis- plays. Vehicles with multi-information display Odometer Trip meter A Trip meter B :Pushing and holding the button will reset the trip meter. Vehicles without multi-information display Odometer Trip meter A...
Page 191: Instrument Panel Light Control
While driving When the voltmeter indicates more than 19 V or less than 9 V, the battery may be malfunctioning. Have your vehicle checked at your Toyota dealer. When the engine oil pressure gauge does not work properly, immediately stop the engine and contact your Toyota dealer.
Page 192: Indicators And Warning Lights
2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. Instrument cluster Vehicles with multi-information display Vehicles without multi-information display (type A)
Page 193 2-2. Instrument cluster Vehicles without multi-information display (type B) Center panel...
Page 194: Systems
2-2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Headlight indicator (→P. 185) (→P. 207) (U.S.A.) Headlight high beam Tail light indicator indicator (→P. 207) (→P. 207) (Canada) Security indicator AUTO LSD indicator (→P.
Page 195: Warning Lights
There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer for details.
Page 196: Multi-Information Display
2-2. Instrument cluster Multi-information display (if equipped) The multi-information display presents the driver with a variety of driving-related data. l Trip information Displays driving range, fuel consumption and other cruis- ing-related information. l Warning messages (→P. 554) Automatically displayed when a malfunction occurs in one of the vehicle’s systems.
Page 197 2-2. Instrument cluster Zoom display of odometer and trip meters Displays the odometer and one of the trip meters simultaneously. Average Fuel Economy Displays the average fuel consumption since the function was reset. The function can be reset by pushing the SELECT RESET button for more than 2 seconds.
Page 198: Feature Customization
2-2. Instrument cluster Average Speed Displays the average vehicle speed since the engine was started or the function was reset. The function can be reset by pushing the SELECT RESET button for more than 2 seconds. Feature customization The vehicle can be customized while the vehicle is stopped. Press the SETUP US/M button to select the item you want to customize unit.
Page 199 2-2. Instrument cluster Press the SELECT RESET button to customize the items. Items Screen text Select in this order To select Unit A or Unit B UNITS Unit A Unit B (→P. 202) Door lock/ LAMPS + TONE LAMPS KEYLESS ENTRY unlock warning FEEDBACK function...
Page 200 Feature customization error • If SYSTEM ERROR message is indicated, turn the engine switch off and then on again. • If SYSTEM ERROR message is indicated again, contact your Toyota dealer. CAUTION Caution while driving Do not adjust the display.
Page 201 2-2. Instrument cluster NOTICE The multi-information display at low temperatures Allow the interior of the vehicle to warm up before using the liquid crystal information display. At extremely low temperatures, the information display monitor may respond slowly, and display changes may be delayed.
Page 202: Accessory Meter
2-2. Instrument cluster Accessory meter Outside temperature display (if equipped) Displays the outside air temperature. (→P. 427) Outside temperature and trip information display (if equipped) Displays the outside temperature and trip information. (→P. 205, 427) Clock (→P. 426) H (Hour) button (→P.
Page 203 2-2. Instrument cluster Outside temperature and trip information display (if equipped) Every time the INFO button is pushed, the display toggles through these information. l OUTSIDE (outside temperature display) Displays the outside air temperature. l AVG (average fuel consumption after refueling) Displays the average fuel consumption since the vehi- cle was last refueled.
Page 204 2-2. Instrument cluster The accessory meter can be operated when The engine switch must be in the ON position. To select the unit A (English/U.S. customary system) or unit B (metric unit) (vehicles without multi-information display) Press the SETUP US/M button to change the units. Information Unit A Unit B...
Page 205: Operating The Lights And Wipers
2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. The side marker, park- ing, tail, license plate and instrument panel lights turn on. The headlights and all lights listed above turn U.S.A. Canada The headlights and all lights listed above turn (if equipped)
Page 206 To turn the lights on again, turn the engine switch to the ON position, or turn the headlight switch off once and then back to the position. Customization That can be configured at Toyota dealer (vehicles without multi-informa- tion display) Settings (automatic light off system) can be changed. (Customizable features →P. 633) It is possible to change the settings (vehicles with multi-information dis- play) (Feature customization →P.
Page 207 2-3. Operating the lights and wipers NOTICE To prevent battery discharge Do not leave the lights on longer than necessary when the engine is not run- ning.
Page 208: Fog Light Switch
2-3. Operating the lights and wipers Fog light switch (if equipped) The fog lights improve visibility in difficult driving conditions, such as in rain or fog. The fog lights can be turned on only when The headlights are on low beam.
Page 209: Windshield Wipers And Washer
2-3. Operating the lights and wipers Windshield wipers and washer Without intermittent type Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Washer operation...
Page 210 2-3. Operating the lights and wipers Intermittent wiper with interval adjuster Wiper intervals can be adjusted for intermittent operation (when selected). Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Intermittent wiper interval adjustment (decrease) Intermittent wiper interval adjustment (increase)
Page 211 2-3. Operating the lights and wipers Washer/wiper dual opera- tion Wipers will automatically oper- ate a couple of times after the washer squirts. The windshield wiper and washer can be operated when The engine switch must be in the ON position. If no windshield washer fluid sprays Check that the washer nozzles are not blocked and if there is washer fluid in the windshield washer fluid reservoir.
Page 212: Using Other Driving Systems
2-4. Using other driving systems Cruise control (if equipped) Use cruise control to maintain a set speed without using the acceler- ator. Indicator Cruise control switch Set the vehicle speed Press the ON-OFF button to turn the cruise control on. At this time, the cruise control indicator will come on.
Page 213 2-4. Using other driving systems Adjusting the speed setting Increase speed Decrease speed Hold the lever until the desired speed setting is obtained. Fine adjustment of the set speed (approximately 1.0 mph [1.6 km/h]) can be made by lightly pushing the lever up or down and releasing it.
Page 214 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. CAUTION To avoid operating the cruise control by mistake Keep the ON-OFF button off when not in use.
Page 215: Intuitive Parking Assist
2-4. Using other driving systems Intuitive parking assist (if equipped) The intuitive parking assist is designed to inform you of the approxi- mate distance between your vehicle and an obstruction by indicator and buzzer when parking the vehicle. This system uses sensors to detect obstructions.
Page 216 2-4. Using other driving systems The distance and buzzer When a sensor detects an obstacle. The buzzer sounds. Back sensors Distance Indicator Zone shown as and buzzer in in. (mm) Approximately 70.9—45.3 Intermittent (1800—1150) Approximately Fast 45.3—33.5 intermittent (1150—850) Approximately Near 33.5 (850) or Continuous...
Page 217 2-4. Using other driving systems Front corner sensors Distance Indicator Zone shown as and buzzer in in. (mm) Approximately 23.6—15.7 Intermittent (600—400) Approximately Fast 15.7—9.8 intermittent (400—250) Approximately Near 9.8 (250) or Continuous less When two or more obstacles are detected simultaneously The buzzer system responds to the nearest zone.
Page 218 2-4. Using other driving systems Sensors that operate and detection range The following diagrams show the sensor detection range. Note that sensors may not be able to detect obstacles that are extremely close to the vehicle. Detection range of the sensors Back sensors Rear corner sensors Front corner sensors...
Page 219 Objects lower than the sensors or thin stakes etc. may be detected ini- tially, but as they draw closer, they may cease to be detected. • A towing hitch is mounted to the vehicle. • A non-genuine Toyota suspension (lowered suspension etc.) is installed. • When attaching a two-way radio antenna.
Page 220 Certification (Canada only) This ISM device complies with Canadian ICES-001. If the indicator is continuously on Have the vehicle inspected by your Toyota dealer. If the indicator remains blinking but do not sound the buzzer Clean the sensors with soft cloth.
Page 221: Four-Wheel Drive System
2-4. Using other driving systems Four-wheel drive system (if equipped) Use the front-wheel drive control switch to select the following transfer modes. : Vehicles with multi-information display : Vehicles without multi-information display 2WD (high speed position, two-wheel drive) Normal driving. 4H (high speed position, four-wheel drive) Greater traction than two-wheel drive.
Page 222 2-4. Using other driving systems Shifting between 4H and 4L Shifting from 4H to 4L Stop the vehicle completely. Shift the shift lever to N. Push and turn the front-wheel drive control switch fully clock- wise. Maintain this condition until the 4LO indicator comes on. Shifting from 4L to 4H Stop the vehicle completely.
Page 223 In this case, you may not be able to shift between 4H and 4L. Have the vehicle inspected by your Toyota dealer immediately. Shifting to 4L VSC is automatically turned off.
Page 224 2-4. Using other driving systems CAUTION Caution while driving Never operate the front-wheel drive control switch if the wheels are slipping. Stop the slipping or spinning before shifting. When the vehicle is parked If the shift lever is moved before the 4LO indicator turns on/off, the transfer mode may not be shifted completely.
Page 225: Auto Lsd System
2-4. Using other driving systems AUTO LSD system The AUTO LSD system aids traction by using the traction control system to control engine performance and braking when one of the rear wheels begins to spin. The system should be used only when one of the rear wheels spin- ning occurs in a ditch or rough surface.
Page 226 2-4. Using other driving systems When the AUTO LSD system is operating Vehicles with multi-information display If the rear wheels spin, the slip indicator flashes to indicate that the AUTO LSD system have been controlled the spinning of the rear wheels. Vehicles without multi-information display If the engine is turned off and restarted The AUTO LSD system and the indicators are automatically turned off.
Page 227 2-4. Using other driving systems CAUTION To avoid an accident Do not use the AUTO LSD system in conditions other than the above. A much greater steering effort and more careful cornering control will be required. Do not drive with the AUTO LSD system continuously turned on.
Page 228: Driving Assist Systems
2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ABS (Anti-lock Brake System) Helps to prevent wheel lock when the brakes are applied suddenly, or if the brakes are applied while driving on a slippery road surface.
Page 229 2-4. Using other driving systems When VSC/TRAC/A-TRAC are operating Vehicles with multi-information display If the vehicle is in danger of slip- ping, or if the rear wheels (2WD models and 2WD mode on 4WD models) or all wheels (4WD mode on 4WD models) spin, the slip indicator flashes to indicate that VSC/TRAC/A-TRAC have been engaged.
Page 230 2-4. Using other driving systems To disable VSC and/or TRAC (2WD models and 2WD mode on 4WD models) If the vehicle gets stuck in fresh snow or mud, VSC and TRAC may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it.
Page 231 2-4. Using other driving systems To disable VSC and A-TRAC (4WD mode on 4WD models) If the vehicle gets stuck in fresh snow or mud, VSC may reduce power from the engine to the wheels. You may need to turn VSC and A-TRAC off to enable you to rock the vehicle in order to free it.
Page 232 In addition, make sure that the tires are inflated to the appro- priate tire pressure level. The ABS and VSC will not function correctly if different tires are fitted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels.
Page 233 2-4. Using other driving systems CAUTION Handling of tires and suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause the system to malfunction.
Page 234: Driving Information
2-5. Driving information Off-road precautions This vehicle has higher ground clearance and narrower tread in rela- tion to the height of its center of gravity to make it capable of per- forming in a wide variety of off-road applications. Off-road vehicle feature l Specific design characteristics give it a higher center of gravity than ordinary passenger cars.
Page 235 2-5. Driving information CAUTION Off-road vehicle precautions Always observe the following precautions to minimize the risk of serious per- sonal injury or damage to your vehicle: In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt. Therefore, the driver and all passengers should fasten their seat belts whenever the vehicle is moving.
Page 236 2-5. Driving information Off-road driving When driving your vehicle off-road, please observe the following pre- cautions to ensure your driving enjoyment and to help prevent the closure of areas to off-road vehicles. l Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
Page 237 2-5. Driving information CAUTION Off-road driving precautions Always observe the following precautions to minimize the risk of serious per- sonal injury or damage to your vehicle: Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places. Do not grip the steering wheel spokes when driving off-road.
Page 238 2-5. Driving information NOTICE To prevent the water damage Take all necessary safety measures to ensure that water damage to the engine or other components does not occur. Water entering the engine air intake will cause severe engine damage. Water entering the automatic transmission will cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ulti- mately damage.
Page 239: Cargo And Luggage
2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. l Stow cargo and luggage in the rear deck whenever possible. l Be sure all items are secured in place. l Be careful to keep the vehicle level.
Page 240 2-5. Driving information (6) If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. Example on your vehicle Cargo capacity Total load capacity...
Page 241 2-5. Driving information CAUTION Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compart- ment. Receptacles containing gasoline Aerosol cans Storage precautions Do not stack anything behind the front seats higher than the seat- backs.
Page 242: Vehicle Load Limits
2-5. Driving information Vehicle load limits Vehicle load limits include total load capacity, seating capacity, towing capacity and cargo capacity. Total load capacity: (→P. 594) Total load capacity means the combined weight of occupants, cargo and luggage. Seating capacity: Regular Cab models With front separated type seats—...
Page 243 2-5. Driving information CAUTION Overloading the vehicle Do not overload the vehicle. It may not only cause damage to the tires, but also degrade steering and braking ability, resulting in an accident.
Page 244: Winter Driving Tips
2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. Pre-winter preparations l Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 245 2-5. Driving information When driving the vehicle Accelerate the vehicle slowly and drive at a reduced speed suit- able to road conditions. When parking the vehicle Park the vehicle and move the shift lever to P without setting the parking brake. The parking brake may freeze up, preventing it from being released.
Page 246 2-5. Driving information Regulations on the use of snow chains l Regulations regarding the use of tire chains vary according to loca- tion and type of road. Always check local regulations before install- ing chains. l Install the chains on the rear tires. l Retighten the chains after driving 1/4 - 1/2 mile (0.5 - 1.0 km).
Page 247 NOTICE Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota deal- ers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the operation of the tire pressure warning valves and transmitters.
Page 248: Trailer Towing
The vehicle stability and braking performance are affected by trailer stability, brake setting and performance, and the hitch. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Toyota dealer for further information about additional...
Page 249 2-5. Driving information Weight limits Confirm that the gross trailer weight, gross combination weight, gross vehicle weight, gross axle weight and trailer tongue load are all within the limits. Regular Cab models Driving Towing Model code Engine GCWR system type capacity 5100 lb.
Page 250 2-5. Driving information Driving Towing Model code Engine GCWR system type capacity 14000 lb. 8900 lb. (6350 kg) (4035 kg) 15500 lb. 10400 lb. USK50L-TRTDKA Standard (7030 kg) (4715 kg) 15000 lb. 9900 lb. *3,4 (6800 kg) (4490 kg) 14000 lb. 8800 lb.
Page 251 2-5. Driving information Driving Towing Model code Engine GCWR system type capacity 14000 lb. 8700 lb. (6350 kg) (3945 kg) 15500 lb. 10100 lb. USK55L-TRTDGA Standard (7030 kg) (4580 kg) 5.7L V8 15000 lb. 9600 lb. (3UR-FBE) *3,4 *3,4 (6800 kg) (4350 kg) engine 14000 lb.
Page 252 2-5. Driving information Double Cab models Driving Towing Model code Engine GCWR system type capacity 4.0L V6 10000 lb. 4800 lb. GSK51L-CRASKA (1GR-FE) Standard (4535 kg) (2175 kg) engine 12000 lb. 6700 lb. (5440 kg) (3035 kg) UCK51L-CRASKA 13500 lb. 8100 lb.
Page 253 2-5. Driving information Driving Towing Model code Engine GCWR system type capacity 14000 lb. 8600 lb. (6350 kg) (3900 kg) USK51L-CRTSKA 16000 lb. 10600 lb. (7255 kg) (4805 kg) Standard 14000 lb. 8600 lb. (6350 kg) (3900 kg) USK51L-CRTLKA 16000 lb. 10600 lb.
Page 254 2-5. Driving information CrewMax models Driving Towing Model code Engine GCWR system type capacity 12000 lb. 6500 lb. (5440 kg) (2945 kg) UCK51L-PSASKA 13500 lb. 8000 lb. (6120 kg) (3625 kg) 12000 lb. 6500 lb. (5440 kg) (2945 kg) UCK51L-PSALKA 13500 lb.
Page 255 2-5. Driving information Driving Towing Model code Engine GCWR system type capacity 14000 lb. 8400 lb. (6350 kg) (3810 kg) USK51L-PSTSKA 16000 lb. 10400 lb. (7255 kg) (4715 kg) 14000 lb. 8400 lb. (6350 kg) (3810 kg) USK51L-PSTLKA 16000 lb. 10400 lb.
Page 256 2-5. Driving information l The gross trailer weight must never exceed towing capacity described in the table above. l The gross combination weight must never exceed the GCWR described in the table above. l The gross vehicle weight must never exceed the GVWR indi- cated the Certification Label.
Page 257 2-5. Driving information Towing related term Meaning The maximum allowable gross trailer weight. Towing capacity is calculated considering base vehicle with necessary vehicle equipment and 150 pound driver. Towing capacity Additional optional equipment, passengers and cargo in the vehicle will reduce the towing capacity, gross trailer weight includes the trailer, cargo and necessary equipment for towing.
Page 258 2-5. Driving information Gross trailer weight Tongue load 2. Fifth wheel Towing The king pin weight is 15 to 25% of the Gross Trailer weight. (King pin weight/Gross trailer weight x 100 = 15 to 25%) CrewMax models: Current fifth wheel trailer designs are not compatible with short bed.
Page 259 2-5. Driving information Hitch l If you wish to install a trailer hitch, contact your Toyota dealer. l Use only a hitch that conforms to the gross trailer weight require- ment. l Follow the directions supplied by the hitch manufacturer.
Page 260 2-5. Driving information Selecting trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer coupler. Most couplers stamped with the required trailer ball size.
Page 261 2-5. Driving information Connecting trailer lights Use the wire harness stored in the rear end under body. 4 pin, 7 pin connectors 4 pin connector...
Page 262 2-5. Driving information Trailer towing tips Your vehicle will handle differently when towing a trailer. The three main causes of vehicle-trailer accidents are driver error, excessive speed and improper trailer loading. Keep the following in mind when towing. l Speed limits for towing a trailer vary by state or province. Do not exceed the posted towing speed limit.
Page 263 2-5. Driving information l Crosswinds and rough roads will adversely affect handling of your vehicle and trailer, causing sway. Periodically check the rear to prepare for being passed by large trucks or buses, which may cause your vehicle and trailer to sway. If swaying occurs, firmly grip the steering wheel, reduce speed immediately but gradually, and steer straight ahead.
Page 264 2-5. Driving information Shift into P and turn off the engine. l When restarting after parking on a slope: With the transmission in P, start the engine. Be sure to keep the brake pedal pressed. Shift into D or R (if reversing). Release the parking brake and brake pedal, and slowly pull or back away from the wheel blocks.
Page 265 Break-in schedule If your vehicle is new or equipped with any new power train components (such as an engine, transmission, differential and wheel bearing), Toyota recommends that you do not tow a trailer until it has been driven for over 500 miles (800 km).
Page 266 2-5. Driving information Maintenance If you tow a trailer, your vehicle will require more frequent maintenance due to the additional load. (See “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”.) Retighten the fixing bolts of the towing ball and bracket after approxi- mately 600 miles (1000 km).
Page 267 2-5. Driving information CAUTION Tongue load or king pin weight A recommended tongue load or king pin weight varies in accordance with the types of trailers or towing as described below. In order to ensure the recommended values shown below, the trailer must be loaded by referring to the following instructions.
Page 268 When towing a trailer If the gross trailer weight exceeds 1000 lb. (453 kg), trailer brakes are required. Toyota recommends trailers with brakes that conform to all appli- cable federal and state/provincial regulations. Never tap into your vehicle’s hydraulic system, as this will lower the vehi- cle’s braking effectiveness.
Page 269 2-5. Driving information NOTICE When installing a trailer hitch Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. Safety chain A safety chain must always be used between the towing vehicle and the trailer.
Page 270: Dinghy Towing
2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground.
Page 271 2-5. Driving information...
Page 272: Using The Air Conditioning System And Defogger
3-1. Using the air conditioning system and defogger Automatic air conditioning system (if equipped) Airflow and outlets are automatically adjusted according to the tem- perature setting. Control panel Windshield defogger Air outlet selection dial Driver’s side temperature control dial Front passenger’s Air conditioning ON/OFF switch side temperature control dial...
Page 273 3-1. Using the air conditioning system and defogger Display Fan speed display Airflow display Front passenger’s side Driver’s side temperature temperature setting display setting display Using the automatic mode Press The air conditioning system will begin to operate. Air outlets and fan speed are automatically adjusted according to the temperature set- ting.
Page 274 3-1. Using the air conditioning system and defogger Adjusting the settings Adjusting the temperature setting Turn the temperature control dial clockwise (warm) or counter- clockwise (cool). The air conditioning system switches between individual and simultaneous modes each time is pressed. l Individual mode (the indicator on is on) The temperature for the driver and front passenger seats can be...
Page 275 3-1. Using the air conditioning system and defogger Changing the air outlets Turn the air outlet selection dial. The air outlets switch each time either side of air outlet selection dial is turned. Air flow as shown according to the mode selected. When the dial is set to , air flows to the upper body.
Page 276 3-1. Using the air conditioning system and defogger When the dial is set to , air flows to the feet. : Double Cab and CrewMax models only : CrewMax models only When the dial is set to , air flows to the feet and the wind- shield defogger operates.
Page 277 3-1. Using the air conditioning system and defogger Defogging the windshield Press The indicator comes on. The air conditioning system con- trol operates automatically. Recirculated air mode will auto- matically switch to outside air mode. Adjusting the position and opening and closing the air outlets Driver side outlets Direct air flow to the left or right, up or down.
Page 278 3-1. Using the air conditioning system and defogger Front passenger side outlets Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. Rear outlets (CrewMax models only) Direct air flow to the left or right, up or down.
Page 279 There may be a problem in the air conditioning system if the indi- cator continues to flash. Turn the air conditioning system off and have it inspected by your Toyota dealer.
Page 280 3-1. Using the air conditioning system and defogger CAUTION To prevent the windshield from fogging up Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the wind- shield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 281: Manual Air Conditioning System
3-1. Using the air conditioning system and defogger Manual air conditioning system (if equipped) Air conditioning ON/OFF switch Outside air or recirculated Driver’s side temperature air mode control dial Front passenger’s side temperature control dial Fan speed control dial Air outlet selection dial Adjusting the settings Adjusting the temperature setting Driver’s side temperature control dial...
Page 282 3-1. Using the air conditioning system and defogger Front passenger’s side temperature control dial Turn the temperature control dial clockwise (warm) or counter- clockwise (cool). l Individual mode When the front passenger’s side temperature control dial in a posi- tion other than the SYNC position, the temperature for the driver and front passenger seats can be adjusted separately.
Page 283: Crewmax Models)
3-1. Using the air conditioning system and defogger Air flow as shown according to the mode selected. When the dial is set to , air flows to the upper body. : CrewMax models only When the dial is set to , air flows to the upper body and feet.
Page 284 3-1. Using the air conditioning system and defogger When the dial is set to , air flows to the feet and the wind- shield defogger operates. The air intake selector is automat- ically set to outside air mode. To return the recirculated air mode, press : Double Cab and CrewMax models only : CrewMax models only...
Page 285 3-1. Using the air conditioning system and defogger If the ambient temperature drops while using the recirculated air mode The air intake mode automatically changes from recirculated air mode to outside air mode after a few minutes. To cancel this function: Press and hold for longer than 2 seconds.
Page 286 3-1. Using the air conditioning system and defogger Front passenger side outlets Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. Rear outlets (CrewMax models only) Direct air flow to the left or right, up or down.
Page 287 There may be a problem in the air conditioning system if the indi- cator continues to flash. Turn the air conditioning system off and have it inspected by your Toyota dealer. CAUTION To prevent the windshield from fogging up...
Page 288 3-1. Using the air conditioning system and defogger NOTICE To prevent battery discharge Do not leave the air conditioning system on longer than necessary when the engine is stopped.
Page 289 3-1. Using the air conditioning system and defogger Outside rear view mirror defoggers and front windshield wiper de-icer (if equipped on Regular Cab and Double Cab models) Clear the outside rear view mirrors using the defogger. Vehicles with an automatic air conditioning system On/off Press the button to turn on the outside rear view mirror defog-...
Page 290 3-1. Using the air conditioning system and defogger Vehicles with a manual air conditioning system On/off Press the button to turn on the outside rear view mirror defog- gers. The indicator will come on. The defoggers will auto- matically turn off after about 15 minutes.
Page 291 3-1. Using the air conditioning system and defogger Back window, outside rear view mirror defoggers and front windshield wiper de-icer (if equipped on CrewMax models) Clear the back window using the defogger. Vehicles with an automatic air conditioning system On/off Press the button to turn on the back window defogger.
Page 292 3-1. Using the air conditioning system and defogger Vehicles with a manual air conditioning system On/off Press the button to turn on the back window defogger. The indicator will come on. The defoggers will automatically turn off after about 15 minutes. Pressing the button again also turns the defogger off.
Page 293 3-1. Using the air conditioning system and defogger CAUTION Back window defogger The surface of the back window becomes hot. Do not touch it to prevent from burning yourself. Outside rear view mirror defoggers (if equipped) The surfaces of the outside rear view mirrors become hot. Do not touch them to prevent from burning yourself.
Page 294: Using The Audio System
3-2. Using the audio system Audio system (without navigation system) Owners of models equipped with a navigation system should refer to the “Navigation System Owner’s Manual”. Type A: CD player with external CD changer controller and AM/FM radio Type B and C: CD player with changer and AM/FM radio Type A Type B...
Page 295 3-2. Using the audio system Type C Title Page Using the radio P. 301 Using the CD player P. 307 Playing back MP3 and WMA discs P. 314 Optimal use of the audio system P. 323 Using the AUX adapter P.
Page 296 3-2. Using the audio system CAUTION For vehicles sold in U.S.A. and Canada Part 15 of the FCC Rules FCC Warning: Any unauthorized changes or modifications to this equipment will void the user’s authority to operate this device. Laser products •...
Page 297: Using The Radio
3-2. Using the audio system Using the radio Power Volume Station selector Text message display (SAT mode) Frequency seek Frequency Frequency adjust (AM, adjust (AM, FM mode) FM mode) or channel or channel (SAT mode) (SAT mode) Station scan AM·SAT/FM mode buttons ®...
Page 298 3-2. Using the audio system ® Scanning radio stations (excluding XM Satellite Radio) Scanning the preset radio stations Press and hold until you hear a beep. Preset stations will be played for 5 seconds each. When the desired station is reached, press the button once again to stop scanning.
Page 299 3-2. Using the audio system ® Setting XM Satellite Radio channel presets Select the desired channel. Press and hold the button (from ) that the channel is to be set to until you hear a beep. Changing the channel category ∧...
Page 300 3-2. Using the audio system The display changes as follows each time the button is pressed. l CH NAME l TITLE (SONG/PROGRAM TITLE) l NAME (ARTIST NAME/FEATURE) l CH NUMBER When the battery is disconnected Stations presets are erased. Reception sensitivity Objects, especially metal objects, such as cargo, a camper, or a truck ®...
Page 301 XM antenna cable is attached securely. ANTENNA There is a short-circuit in the antenna or the sur- rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to the XM Satellite Radio. The radio is being updated with the latest ®...
Page 302 3-2. Using the audio system There is no song/program title or artist name/fea- ----- ture associated with the channel at that time. No action needed. The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to the previous channel or “CH001”.
Page 303: Using The Cd Player
3-2. Using the audio system Using the CD player CD selection (with external Volume Power CD changer only for Type A) Fast-forward Reverse CD insert (Type B and C) CD eject Track selection Display text message Random playback Playback Search playback Repeat play Loading CDs Loading a CD (type A)
Page 304 3-2. Using the audio system Loading multiple CDs (type B and C) Press and hold until you hear a beep. WAIT is shown on the display. Insert a CD when the indicator on the slot turns from amber to green. The display changes from WAIT to LOAD.
Page 305 3-2. Using the audio system Selecting and scanning CDs (with CD changer only) Selecting the desired CD Type A and B: Press Type C: Press Scanning loaded CDs Press and hold until you hear a beep. The first 10 seconds of the first track on each CD will be played. Press the button again when the desired CD is reached.
Page 306 3-2. Using the audio system Repeat play Repeating a track Press Repeating all of the tracks on a CD (with CD changer only) Press and hold until you hear a beep. Random playback Current CD Press Tracks are played in random order until the button is pressed once more. All CDs (with CD changer only) Press and hold until you hear a beep.
Page 307 3-2. Using the audio system Display Up to 12 characters can be displayed at a time. If there are 13 characters or more, pressing and holding for 1 second or more will display the remaining characters. A maximum of 24 characters can be displayed. is pressed for 1 second or more again or has not been pressed for 6 seconds or more, the display will return to the first 12 characters.
Page 308 3-2. Using the audio system If CDs are left inside the CD player or in the ejected position for extended periods CDs may be damaged and may not play properly. Lens cleaners Do not use lens cleaners. Doing so may damage the CD player. NOTICE CDs and adapters that cannot be used Do not use the following types of CDs, 3 in.
Page 309 3-2. Using the audio system NOTICE CDs that have had tape, stickers or CD- R labels attached to them, or that have had the label peeled off CD player precautions Failure to follow the precautions below may result in serious damage to the CDs or the player itself.
Page 310: Playing Back Mp3 And Wma Discs
3-2. Using the audio system Playing back MP3 and WMA discs Disc selection Power Volume (Type B and C) Reverse Disc insert Fast-forward (Type B and C) Disc eject Folder selection File selection Display text message Random playback Playback Repeat play Search playback Loading MP3 and WMA discs Loading a disc (type A)
Page 311 3-2. Using the audio system Loading multiple discs (type B and C) Press and hold until you hear a beep. WAIT is shown on the display. Insert a disc when the indicator on the slot turns from amber to green. The display changes from WAIT to LOAD.
Page 312 3-2. Using the audio system Selecting a disc (type B and C) Selecting the desired disc Type B: Press Type C: Press Selecting and scanning folders Selecting folders one at a time To select the desired folder, press “∧” or “∨” on Scanning the desired folder by cueing the first file of each folder Press and hold...
Page 313 3-2. Using the audio system Scanning the desired file by cueing the files in the folder Press The first 10 seconds of all files in the folder will be played. When the desired file is reached, press the button once again. Fast-forwarding and reversing files To fast-forward or reverse.
Page 314 3-2. Using the audio system Switching the display Press Each time the button is pressed, the display changes in the order of Folder no./File no./Elapsed time→Folder name→File name→Album title (MP3 only)→Track title→Artist name. Display Up to 12 characters can be displayed at a time. If there are 13 characters or more, pressing and holding for 1 second or more will display the remaining characters.
Page 315 3-2. Using the audio system Discs that can be used Discs with the marks shown below can be used. Playback may not be possible depending on recording format or disc fea- tures, or due to scratches, dirt or deterioration. MP3 and WMA player protection feature To protect the internal components, playback is automatically stopped when a problem is detected while the MP3 and WMA player is being used.
Page 316 3-2. Using the audio system MP3 file compatibility • Compatible standards MP3 (MPEG1 LAYER3, MPEG2 LSF LAYER3) • Compatible sampling frequencies MPEG1 LAYER3: 32, 44.1, 48 (kHz) MPEG2 LSF LAYER3: 16, 22.05, 24 (kHz) • Compatible bit rates (compatible with VBR) MPEG1 LAYER3: 64, 80, 96, 112, 128, 160, 192, 224, 256, 320 (kbps) MPEG2 LSF LAYER3: 64, 80, 96, 112, 128, 144, 160 (kbps) •...
Page 317 3-2. Using the audio system Compatible disc formats The following disc formats can be used. • Disc formats: CD-ROM Mode 1 and Mode 2 CD-ROM XA Mode 2, Form 1 and Form 2 • File formats: ISO9660 Level 1, Level 2, (Romeo, Joliet) MP3 and WMA files written in any format other than those listed above may not play correctly, and their file names and folder names may not be displayed correctly.
Page 318 3-2. Using the audio system Extensions If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files, they will be mistakenly recognized and played as MP3 and WMA files. This may result in large amounts of interference and damage to the speakers.
Page 319: Optimal Use Of The Audio System
3-2. Using the audio system Optimal use of the audio system Displays the current mode Changes the following set- tings l Sound quality and vol- ume balance The sound quality and bal- ance settings changed to produce the best sound. l Automatic Sound Level- izer on/off (→P.
Page 320 3-2. Using the audio system Mode Sound qual- Turn to the Turn to the Level displayed ity mode left right Bass* -5 to 5 Mid-range* -5 to 5 High (type C only) Treble* -5 to 5 Front/rear Shifts to volume R7 to F7 Shifts to rear front...
Page 321: Using The Aux Adapter
3-2. Using the audio system Using the AUX adapter This adapter can be used to connect a portable audio device and lis- ten to it through the vehicle’s speakers. Connect the portable audio device. Press...
Page 322 3-2. Using the audio system Operating portable audio devices connected to the audio system The volume can be adjusted using the vehicle’s audio controls. All other adjustments must be made on the portable audio device itself. When using a portable audio device connected to the power outlet or cigarette lighter Noise may occur during playback.
Page 323: Using The Steering Wheel Audio Switches
3-2. Using the audio system Using the steering wheel audio switches (if equipped) Some audio features can be controlled using the switches on the steering wheel. Volume Radio: Select radio stations Select tracks, files (MP3 and WMA) and discs Power on, select audio source Turning on the power...
Page 324 3-2. Using the audio system Adjusting the volume Press “+” on to increase the volume and “–” to decrease the volume. Press and hold “+” or “–” on to continue increasing or decreasing the volume. Selecting a radio station Press to select the radio mode.
Page 325: Using The Rear Audio/Video System
3-3. Using the rear audio/video system Rear seat entertainment system (if equipped) The rear seat entertainment system is designed for the rear passen- gers to enjoy audio and DVD video separately from the front audio system. Front separated type seats Power outlet main switch Front audio system DVD player...
Page 326 3-3. Using the rear audio/video system Front bench type seat Power outlet main switch Front audio system DVD player Display Rear seat entertainment system remote controller Power outlet A/V input adapter...
Page 327 3-3. Using the rear audio/video system Opening and closing the display Press the lock release button to open the display. Pull the display down to an easily viewable angle (between 90° and 125°). To close the display, push the display up until a click is heard. The illumination of the screen is automatically turned off when the display is closed.
Page 328 REGION CODE ERROR:Indicates that the DVD region code is not set prop- erly. DVD ERROR: Indicates that there is a problem inside the player. Eject the disc. Set the disc again. If the malfunction still exists, take the vehicle to your Toyota dealer.
Page 329 The rear seat entertainment system control will not function properly. The operational range is reduced. When replacing the AA batteries Batteries can be purchased at your Toyota dealer, electric appliance shop, or camera stores. Replace only with the same or equivalent type recommended by a Toyota dealer.
Page 330 3-3. Using the rear audio/video system Headphones With some headphones generally available in the market, sound quality may be poor. Toyota recommends the use of Toyota genuine wireless head- phones. Please contact your Toyota dealer for further details. Volume Conversational speech on some DVDs is recorded at a low volume to emphasize the impact of sound effects.
Page 331 3-3. Using the rear audio/video system NOTICE For normal operation after replacing the batteries Observe the following precautions to prevent accidents. Always work with dry hands. Moisture may cause the battery to rust. Do not touch or move any other components inside the remote controller. Do not bend any of the battery terminals.
Page 332: Using The Dvd Player (Dvd Video)
3-3. Using the rear audio/video system Using the DVD player (DVD video) Remote controller Turning on the DVD mode Turning on/off the control icon screen Selecting a chapter Reversing a disc Turning on the menu screen Turning on the title selection screen Searching the title Changing the screen angle...
Page 333 3-3. Using the rear audio/video system Unit Ejecting a disc Turning on the DVD mode Skipping to the desired chapter Playing/pausing a disc Turning on/off the control icon screen Selecting a control icon Inputting the selected con- trol icon...
Page 334 3-3. Using the rear audio/video system Control icon screen (Page1) Turning off the control icon screen on the screen Displaying control icon screen page 2 Turning on/off title selection screen for the disc Turning on/off the menu screen for the disc Reversing a disc Stopping a disc Playing/pausing a disc...
Page 335 3-3. Using the rear audio/video system NOTICE Cleaning the screen Wipe the screen with a dry soft cloth. If the screen is wiped with a rough cloth, the surface of the screen may be scratched. To prevent damage to the remote controller Keep the remote controller away from direct sunlight, heat and high humidity.
Page 336 3-3. Using the rear audio/video system Returning to the previous screen Select to return to the previous screen. For the operation of the menu screen, see the separate manual for the DVD disc. Searching for a title Press or select display the screen to search for a title.
Page 337 3-3. Using the rear audio/video system Changing the audio language Press or select display audio language screen. Each time is pressed or is selected, another lan- guage stored on the disc is selected. Select to return to the pre- vious screen. Changing the angle Press or select...
Page 338 3-3. Using the rear audio/video system DVD player and DVD video discs This DVD player is compatible with NTSC color TV formats. DVD video discs conforming to other formats such as PAL or SECAM cannot be used. Region codes Some DVD video discs have a region code indicating where you can use them.
Page 339 3-3. Using the rear audio/video system DVD video disc glossary DVD video discs: Digital Versatile Discs that hold world’s standard video. DVD video discs have adopted “MPEG2”, one of the world standards of digital compression technologies. The picture data is compressed by 1/ 40 on average and stored.
Page 340 3-3. Using the rear audio/video system Audio Manufactured under license from Dolby Laboratories. “Dolby”, “Dolby Digital”, “Pro Logic”, and the double-D symbol are trademarks of Dolby Laboratories. Confidential unpublished works. © 1992-1997 Dolby Laboratories. All rights reserved. “dts” is a trademark of Digital Theater Systems, Inc.
Page 341: Using The Dvd Player (Video Cd)
3-3. Using the rear audio/video system Using the DVD player (video CD) Remote controller Turning on the DVD mode Turning on/off the control icon screen Selecting a chapter Reversing a disc Searching the disc menu number Inputting the selected con- trol icon Turning off the screen Selecting a control icon...
Page 342 3-3. Using the rear audio/video system Control icon screen (Page1) Selecting a disc menu num- Turning off the menu screen Displaying control icon screen page 2 Turning on the disc menu Returning to the previous page screen (with the disc menu displayed) Proceeding to the next page screen (with the disc menu...
Page 343: Using The Dvd Player (Audio Cd/Cd Text)
3-3. Using the rear audio/video system Using the DVD player (audio CD/CD text) Control screen Press to dis- play the control screen. Repeat play Random playback Search playback Repeat play Repeating a track Select Random playback Playing all of the tracks on a CD in random order Select Search playback Scanning tracks...
Page 344: Using The Dvd Player (Mp3 Discs)
3-3. Using the rear audio/video system Using the DVD player (MP3 discs) Control screen Press to dis- play the control screen. Repeat play Random playback Search playback Displaying file information Selecting a folder Repeat play Repeating a file Select Repeating all of the files in the folder Select , and press and hold Random playback...
Page 345 3-3. Using the rear audio/video system Selecting and scanning folders Selecting folders one at a time To select the desired folder, select Scanning the desired folder by cueing the first file of each folder Select , and press and hold The first 10 seconds of the first file in the each folder will be played.
Page 346: Using The Video Mode
3-3. Using the rear audio/video system Using the video mode Press to select the video mode. Before switching to the video mode, connect audio source input adapter. Using the A/V input adapter Front separated type seats Open the cover. The A/V input adapter is com- posed of 3 input adapters.
Page 347 3-3. Using the rear audio/video system A/V input adapter The rear seat entertainment system plays videos and sound when audio- visual equipment is connected to the A/V input adapter. For details, refer to the manufacturer’s instructions. Power outlet The power outlet can be used to connect the audio-visual device. (→P.
Page 348: Changing The Setup Menu Settings
3-3. Using the rear audio/video system Changing the Setup Menu settings Press or select display initial setting screen. The following settings can be customized here. l Audio language l Subtitle language l DVD language l Angle mark l Parental lock Changing the audio language Select Select the language you want to...
Page 349 3-3. Using the rear audio/video system Select if you cannot find the language you would like to hear. Enter the appropriate 4-digit lan- guage code. (→P. 357) Select a number, and press to input it. If a code that is not in the list is entered, “Incorrect Code”...
Page 350 3-3. Using the rear audio/video system Changing the DVD language Select Select the language you would like to hear and press to input it. Select if you cannot find the language you would like to hear. Enter the appropriate 4-digit lan- guage code.
Page 351 3-3. Using the rear audio/video system Setting viewer restriction levels Setting a personal code allows the viewer restriction to be used. Select Enter a personal code and press The setting cannot be changed unless personal code entered. When you forget a personal code, initialize a personal code.
Page 352 3-3. Using the rear audio/video system Setting the display mode Pressing changes the dis- play mode sequentially as fol- lows: Normal → Wide 1 → Wide 2 Returning to the previous screen Select to return to the previous screen.
Page 353 3-3. Using the rear audio/video system To initialize the password Press on the remote controller or unit ten times when the Enter Personal Code screen is displayed. Language code list Code Language Code Language 0514 English 0208 Bihari 0618 French 0209 Bislama 0405...
Page 354 3-3. Using the rear audio/video system Code Language Code Language 0721 Gujarati 1311 Macedonian 0801 Hausa 1312 Malayalam 0809 Hindi 1314 Mongolian 0818 Croatian 1315 Moldavian 0821 Hungarian 1318 Marathi 0825 Armenian 1319 Malay 0901 Interlingua 1320 Maltese 0905 Interlingue 1325 Burmese 0911...
Page 355 3-3. Using the rear audio/video system Code Language Code Language 1914 Shona 2014 Setswana 1915 Somali 2015 Tonga 1917 Albanian 2018 Turkish 1918 Serbian 2019 Tsonga 1919 Siswati 2020 Tatar 1920 Sesotho 2023 1921 Sundanese 2111 Ukrainian 1923 Swahili 2118 Urdu 2001 Tamil...
Page 356: Using The Hands-Free Phone System (For Cellular Phone)
3-4. Using the hands-free phone system (for cellular phone) Hands-free phone system (for cellular phone) (if equipped) ® This system supports Bluetooth , which allows you connect a cellu- lar phone without using cables and to make or receive calls without operating the cellular phone buttons.
Page 357 3-4. Using the hands-free phone system (for cellular phone) Conditions under which the system will not operate ® If using a cellular phone that does not support Bluetooth If the cellular phone is switched off If you are outside service range If the cellular phone is not connected If the cellular phone’s battery is low ®...
Page 358 3-4. Using the hands-free phone system (for cellular phone) Certification for the hands-free phone system FCC ID: HYQBTAU01A IC ID: 1551A-BTAU01A MADE IN MEXICO This device complies with Part 15 of the FCC Rules and RSS-210. Opera- tion is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 359 3-4. Using the hands-free phone system (for cellular phone) FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CAUTION: Radio Frequency Radiation Exposure This equipment complies with FCC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65.
Page 360: Using The Hands-Free Phone System
3-4. Using the hands-free phone system (for cellular phone) Using the hands-free phone system Audio unit ® Displays Bluetooth con- nection condition If “BT” is not displayed, the hands-free phone system cannot be used. Displays the reception level Displays such items as numbers, names, mes-...
Page 361 3-4. Using the hands-free phone system (for cellular phone) Steering wheel telephone switches Volume The voice guidance volume cannot be adjusted by using this switch. Hands-free phone system off/ends a call/refuses a call Hands-free phone system on/starts a call Press: Voice command sys- tem on Press and hold: Voice com- mand system off...
Page 362 3-4. Using the hands-free phone system (for cellular phone) Operating the system by using a voice command By following voice guidance instructions output from the speaker, you can speak voice commands aloud to control the hands-free phone system without looking at the display or operating Operation procedure when using voice commands Press and say a voice command for a desired function.
Page 363 3-4. Using the hands-free phone system (for cellular phone) Register a phone name by either of the following methods. a. Select “(RECORD NAME)” by using , and say aloud the name you would like to register for the phone. b. Press and say aloud the name you would like to reg- ister for the phone.
Page 364 3-4. Using the hands-free phone system (for cellular phone) Second First menu Third menu Operation detail menu Dialing a phone number Callback stored in the incoming his- (CALLBACK) tory memory By voice (BY VOICE) By phone (BY PHONE) Add entry Adding a new phone num- (ADD Call history...
Page 365 3-4. Using the hands-free phone system (for cellular phone) Second First menu Third menu Operation detail menu Set PIN Setting a PIN (SET PIN) Phone book lock Security Locking the phone book (PHBK (SECU- LOCK) RITY) Phone book unlock Unlocking the phone book (PHBK UNLOCK) Pair phone...
Page 366 3-4. Using the hands-free phone system (for cellular phone) Using a short cut voice command First menu Second menu Operation detail Dialing a phone number reg- Dial “XXX (name)” istered in the phone book Phone book add Adding a new phone number entry Changing the name of a Phone book change...
Page 367 3-4. Using the hands-free phone system (for cellular phone) Automatic adjustment of volume When vehicle speed is 50 mph (80 km/h) or more, the volume automatically increases. The volume returns to the previous volume setting when vehicle speed drops to 43 mph (70 km/h) or less. When using a voice command For numbers, speak a combination of single digits from zero to nine, # (pound), ∗...
Page 368: Making A Phone Call
3-4. Using the hands-free phone system (for cellular phone) Making a phone call Making a phone call l Dialing by inputting a phone number “Dial by number” l Dialing by inputting a name “Dial by name” l Speed dialing l Dialing a phone number stored in the outgoing history mem- “Redial”...
Page 369 3-4. Using the hands-free phone system (for cellular phone) Dial by one of the following methods: a. Press b. Press and say “Dial”. c. Select “Dial” by using Dialing by inputting a name Press and say “Dial by name”. Select a registered name to be input by either of the following methods: a.
Page 370 3-4. Using the hands-free phone system (for cellular phone) Speed dialing Press Press the preset button in which the desired phone number is registered. Press When receiving a phone call Answering the phone Press Refusing the call Press Transferring a call A call can be transferred between the cellular phone and system while dialing, receiving a call, or conversing a call.
Page 371 3-4. Using the hands-free phone system (for cellular phone) Using a call history memory Follow the procedure below to use a phone number stored in call his- tory memory: Press and say “Redial” (when using a phone number stored in the outgoing history memory) or “Callback” (when using a phone number stored in the incoming history mem- ory).
Page 372 3-4. Using the hands-free phone system (for cellular phone) A shortcut to Redial is available Press the twice. Muting your voice Your voice can be muted so that the other party cannot hear your voice dur- ing a call. To set or cancel: Press and say “Mute”.
Page 373: Setting A Cellular Phone
3-4. Using the hands-free phone system (for cellular phone) Setting a cellular phone Registering a cellular phone in the hands-free phone system allows the system to function. The following function can be used for regis- tered cellular phones: Functions and operation procedures To enter a menu for each function, follow the steps below by using voice commands or l Registering a cellular phone...
Page 374 3-4. Using the hands-free phone system (for cellular phone) Selecting a cellular phone to be used Select “Select phone” by using a voice command or Pattern A Select a cellular phone to be used by either of the following methods, and select “Confirm” by using a voice command or a.
Page 375 3-4. Using the hands-free phone system (for cellular phone) b. Press and say “List phones”. While the desired phone name is being read aloud, press c. Select the desired phone name by using Press or select “(RECORD NAME)” by using and say a new name.
Page 376 3-4. Using the hands-free phone system (for cellular phone) Changing the passkey Select “Set passkey” by using a voice command or Pattern A Press , say a four to eight-digit number, and select “Confirm” by using a voice command or Pattern B Select a four to eight-digit number by using The number should be input one digit at a time.
Page 377 3-4. Using the hands-free phone system (for cellular phone) b. Press and say “List phones”. While the name of the desired cellular phone is being read aloud, press Pattern B Select a cellular phone to be deleted by using The number of cellular phones that can be registered Up to 6 cellular phones can be registered in the system.
Page 378: Security And System Setup
3-4. Using the hands-free phone system (for cellular phone) Security and system setup To enter the menu of each setting, follow the steps below: Security setting items and operation procedure l Setting or changing the PIN (Personal Identification Number) 1. “Setup” → 2. “Security” → 3. “Set PIN” l Locking the phone book 1.
Page 379 3-4. Using the hands-free phone system (for cellular phone) Changing the PIN Select “Set PIN” by using a voice command or Enter the registered PIN by using a voice command or Enter a new PIN by using a voice command or When using , input the number one digit at a time.
Page 380 3-4. Using the hands-free phone system (for cellular phone) Setting voice guidance volume Select “(GUIDANCE VOL)” by using Change the voice guidance volume. To decrease the volume: Turn counterclockwise. To increase the volume: Turn clockwise. Initialization Select “(INITIALIZE)” and then “(CONFIRM)” by using Select “(CONFIRM)”...
Page 381 3-4. Using the hands-free phone system (for cellular phone) When the phone book is locked The following functions cannot be used: Dialing by inputting a name Speed dialing Dialing a phone number stored in the call history memory Using the phone book Initialization The following data in the system can be initialized: •...
Page 382: Using The Phone Book
3-4. Using the hands-free phone system (for cellular phone) Using the phone book To enter the menu of each setting, follow the steps below: l Adding a new phone number 1. “Phone book” → 2. “Add entry” l Changing a registered name 1.
Page 383 3-4. Using the hands-free phone system (for cellular phone) Use one of the following methods to input a phone number: Inputting a phone number by using voice commands STEP2-1 Select “By voice” by using a voice command or STEP2-2 Press , say the desired phone number, and select “Confirm”...
Page 384 3-4. Using the hands-free phone system (for cellular phone) Selecting a phone number from outgoing or incoming history mem- STEP2-1 Select “Call history” by using a voice command or STEP2-2 Select “Outgoing” or “Incoming” by using a voice command or STEP2-3 Select the data to be registered by either of the fol- lowing methods: a.
Page 385 3-4. Using the hands-free phone system (for cellular phone) Select the name to be registered by either of the following methods, and select “Confirm” by using a voice command or a. Press and say the desired name. b. Select “(RECORD NAME)” by using , and say the desired name.
Page 386 3-4. Using the hands-free phone system (for cellular phone) b. Press , and say “List names”. While the desired name is being read aloud, press , and select “Confirm” by using a voice command or c. Select the desired data by using Select the desired preset button, and register the data into speed dial by either of the following methods: a.
Page 387 3-4. Using the hands-free phone system (for cellular phone) c. Select the desired name by using Select “(RECORD NAME)” by using Say a new name, and select “Confirm” by using a voice com- mand or Deleting registered data Select “Delete entry” by using a voice command or Pattern A Select data to be deleted by either of the following methods, and select “Confirm”...
Page 388 3-4. Using the hands-free phone system (for cellular phone) Deleting speed dial Select “Delete speed dial (DEL SPD DIAL)” by using a voice command or Press the preset button for which the desired speed dial is registered, and select “Confirm” by using a voice command or Listing the registered data Select “List names”...
Page 389: Using The Interior Lights
3-5. Using the interior lights Interior lights list Your Toyota is equipped with an illuminated entry system to assist in entering the vehicle. Due to the function of the system, the lights shown in the following illustration automatically turn on/off accord- ing to whether the doors are locked/unlocked, whether the doors are opened/closed, and the engine switch position.
Page 390: Personal/Interior Light Main Switch
DOOR position, the lights will turn off automati- cally after 20 minutes. Customization That can be configured at Toyota dealer (vehicles without multi-informa- tion display) Settings (e.g. The time elapsed before lights turn off) can be changed.
Page 391: Personal/Interior Lights
3-5. Using the interior lights Personal/interior lights Personal/interior lights Front (type A) On/off Front (type B) On/off Front (type C) On/off...
Page 392 3-5. Using the interior lights Personal/interior lights Rear (type A) On/off Rear (type B) On/off Rear (type C) On/off...
Page 393: Cargo Lamp Main Switch
3-5. Using the interior lights Personal/interior lights and cargo lamp main switch Rear (type D) On/off Cargo lamp main switch The cargo lamp can not be indi- vidually turned off. Door position The cargo lamp comes on when a door is opened. They turn off when the doors are closed.
Page 394: Using The Storage Features
3-6. Using the storage features List of storage features Front separated type seats Bottle holders Auxiliary boxes (if equipped) Card holder (if equipped) Overhead console (if equipped) Glove boxes Front cup holders Map holder Console box • Card holder • Map holder •...
Page 395 3-6. Using the storage features Front bench type seat Bottle holders Auxiliary boxes Card holder (if equipped) Overhead console Glove boxes Front cup holders Pen holder Auxiliary box • Card holder • Map holder • Tissue pocket Rear cup holders (if equipped) Storage box (if equipped)
Page 396 3-6. Using the storage features Glove boxes Glove boxes Upper glove box Press the button. Lower glove box Unlock with the master key Lock with the master key Pull the lever up.
Page 397 3-6. Using the storage features Glove boxes and console box CAUTION Items that should not be left in the upper glove box Do not leave glasses or lighters in the box. If the interior of the vehicle become hot, lighters may explode and glasses may warp or becomes cracked.
Page 398 3-6. Using the storage features Console box When using the console box lid as an armrest Pull the knob up and slide the lid forward. If necessary, the console box lid can slide forward. Pull the lid forward by grasping the front of the lid. When the lid is forward, it cannot be lifted.
Page 399 3-6. Using the storage features Console box and card holder The box can be removed. Hanging file folders can be hung on the rails when the box is removed. CAUTION Caution while driving Keep the console box closed. Injuries may result in the event of an accident or sudden braking. Card holder Overhead console (type A) Press the lid.
Page 400 3-6. Using the storage features Card holder Overhead console (type B) Press the lid. Console box (front separated type seats) Pull the knob up and lift the lid.
Page 401 3-6. Using the storage features Card holder Back of the front center seatback (front bench type seat) Pull the lever up and fold down the seatback. Push the knob and lift the lid. CAUTION Caution while driving Keep the auxiliary box, console box or holder closed. Injuries may result in the event of an accident or sudden braking.
Page 402 3-6. Using the storage features Map holder Map holder Center console (front separated type seats) Push the tab down to release the lock and remove the lid. Stow the lid.
Page 403 3-6. Using the storage features Map holder Console box (front separated type seats) Pull the lever up and lift the lid. Back of the front center seatback (front bench type seat) Pull the lever up and fold down the seatback.
Page 404 3-6. Using the storage features Map holder Push the knob and lift the lid. CAUTION Caution while driving Keep the auxiliary or console box closed. Injuries may result in the event of an accident or sudden braking.
Page 405 3-6. Using the storage features Pen holder Pen holder Front separated type seats Pull the knob up and lift the lid.
Page 406 3-6. Using the storage features Pen holder Front bench type seat Pull the lever up and fold down the seatback. CAUTION Caution while driving (front separated type seats only) Keep the console box closed. Injuries may result in the event of an accident or sudden braking.
Page 407 3-6. Using the storage features Tissue pocket Tissue pocket Front separated type seats Pull the knob up and lift the lid. Front bench type seat Pull the lever up and fold down the seatback.
Page 408 3-6. Using the storage features Tissue pocket Push the knob and lift the lid. CAUTION Caution while driving Keep the auxiliary or console box closed. Injuries may result in the event of an accident or sudden braking.
Page 409 3-6. Using the storage features Overhead console Overhead console The overhead console is useful for temporarily storing sunglasses and similar small items. Type A Push the knob forward to open the console. Type B Push the knob forward to open the console.
Page 410 3-6. Using the storage features Front cup holders Front cup holders Separated type seats Bench type seat Pull the lever up and fold down the seatback.
Page 411 3-6. Using the storage features Front cup holders Removing the cup holder (separated type seats only) Push the tab down to release the lock and remove the lid. Stow the lid. Pull the cup holder up and remove it. CAUTION Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders.
Page 412: Rear Cup Holders
3-6. Using the storage features Rear cup holders Rear cup holders Double Cab models with front separated type seats Pull the lid down. Double Cab models with front bench type seat Pull the lid down. CrewMax models Pull the armrest down.
Page 413: Bottle Holders
3-6. Using the storage features Rear cup holders and bottle holders CAUTION Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 414 3-6. Using the storage features Bottle holders Rear door (type A) Rear door (type B) Removing the hold separator (front bench type seat only) Remove the hold separator. CAUTION When not in use (front bench type seat only) Keep the bottle holders closed. Injuries may result in the event of an accident or sudden braking.
Page 415: Auxiliary Boxes
3-6. Using the storage features Bottle holders and auxiliary boxes NOTICE Items that should not be stowed in the bottle holders. Put the cap on before stowing a bottle. Do not place open bottles in the bot- tle holders, or glasses and paper cups containing liquid. The contents may spill and glasses may break.
Page 416 3-6. Using the storage features Auxiliary boxes Front bench type seat (type B) Pull the lever up and fold down the seatback. Push the knob and lift the lid. Front bench type seat (type C) Pull the lever up and fold down the seatback.
Page 417: Storage Box
3-6. Using the storage features Auxiliary boxes and storage box Push the knob and lift the lid. CAUTION Caution while driving Keep the auxiliary boxes closed. Injuries may result in the event of an accident or sudden braking. Storage box (if equipped) Using the storage box Pull the lever up and raise the rear seat cushion.
Page 418 3-6. Using the storage features Storage box Turn the knob in the OPEN direction. Lift the lid. Remove the storage box Pull the lever up and raise the rear seat cushion. Turn the knob in the OPEN direction. Lift the lid. Remove the lids.
Page 419 3-6. Using the storage features CAUTION Caution while driving Keep the storage box lids closed. Injuries in the event of an accident or sudden braking. To prevent damage to the storage box Do not put heavy loads on the lids.
Page 420: Other Interior Features
3-7. Other interior features Sun visors Main visor Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Side extender: Place in side position then slide backwards. Sub visor (if equipped) Flip down.
Page 421: Vanity Mirrors
3-7. Other interior features Vanity mirrors Vehicles without vanity light Open the cover. Vehicles with vanity light Open the cover. The light turns on when the cover is opened. Adjust the brightness of the light.
Page 422: Clock
3-7. Other interior features Clock Adjusts the hours. Adjusts the minutes. For quicker adjustment of the clock (if equipped) Hold down the M or H button continuously. This allows faster advancement of the minutes and hours. The clock is displayed when The engine switch is in the ACC or ON position.
Page 423: Outside Temperature Display
3-7. Other interior features Outside temperature display (if equipped) Displays the outside air temperature. The temperature range that can be displayed is from -40°F (-40°C) to 122°F (50°C). Switches the outside air temperature display between °C (Celsius) and °F (Fahrenheit). equipped) Vehicles without multi-informa- tion display:...
Page 424 3-7. Other interior features When – –°C or – –°F is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer. The outside air temperature is displayed when The engine switch is in the ON position. When disconnecting and reconnecting battery terminals The display will automatically be set to the initial mode.
Page 425: Ashtray
3-7. Other interior features Ashtray Front separated type seats The ashtray can be installed in a cup holder. Front bench type seat Pull the ashtray out.
Page 426 3-7. Other interior features The ashtray can be removed Front separated type seats Pull the ashtray out. Front bench type seat Push down on the lock spring plate and pull out. CAUTION When not in use Keep the ashtray closed. Injuries may result in the event of an accident or sudden braking.
Page 427: Cigarette Lighter
3-7. Other interior features Cigarette lighter Front separated type seats Push the cigarette lighter in. The cigarette lighter will pop out when it is ready for use. Front bench type seat Push the cigarette lighter in. The cigarette lighter will pop out when it is ready for use.
Page 428: Power Outlets (12V Dc)
3-7. Other interior features Power outlets (12V DC) The power outlet can be used for accessories that run on less than 10 A. Type A (Instrument panel)
Page 429 3-7. Other interior features Type B (Instrument panel) Type C (Under the seat cushion of the front center seat)
Page 430 3-7. Other interior features Type D (Back of the front center seatback) Type E (Inside of the console box)
Page 431 3-7. Other interior features Type F (Back of the console box) Type G (Back of the front center seatback) Type H (Back of the console box)
Page 432 3-7. Other interior features The power outlet can be used when The engine switch is in the ACC or ON position. Depending on operating time and current consumption The power outlets may not be used due to the electrical component protec- tion function.
Page 433: Power Outlets (If 115V Ac Equipped)
3-7. Other interior features Power outlets (if 115V AC equipped) The power outlet can be used for accessories that use less than 100W. Front separated type seats Main switch To use the power outlet, turn on the main switch. The indicator comes on. Power outlet socket...
Page 434 3-7. Other interior features Front bench type seat Main switch To use the power outlet, turn on the main switch. The indicator comes on. Power outlet socket The power outlet can be used when The engine switch is in the ON position. CAUTION Using a power outlet Observe the following precautions to reduce the risk of injury.
Page 435 Do not modify, disassemble or repair the power outlet or its inverter, in any way. Doing so may result in unexpected malfunctions or accidents, which could cause serious damage or injuries. Contact a Toyota dealer for any necessary repairs. To prevent injuries and accidents, securely fix all electric appliances before use and do not use any appliances that may do any of the fol- lowing.
Page 436 3-7. Other interior features NOTICE To avoid damaging the power outlet and the plug Close the power outlet lid when not in use. Foreign objects or liquids that enter the power outlet may cause a short circuit. Do not use plug adaptors to connect too many plugs to the power outlet. After inserting a plug, gently close the power outlet lid.
Page 437 If the power outlet is loose when an electrical appliance plug is con- nected Replace the outlet. Contact a Toyota dealer for any necessary replacements. If the power outlet gets dirty Turn the main switch off and use a soft, clean cloth to wipe it gently.
Page 438: Seat Heaters
3-7. Other interior features Seat heaters (if equipped) The indicator comes on. Adjusts the seat tempera- ture. The further you turn the dial upward, the warmer the seat becomes. The seat heaters can be used when The engine switch is in the ON position. When not in use Turn the dial fully downward.
Page 439 3-7. Other interior features CAUTION Burns Use caution when seating the following persons in a seat with the seat heater on to avoid the possibility of burns: • Babies, small children, the elderly, the sick and the disabled • Persons with sensitive skin •...
Page 440: (Crewmax Models Only)
3-7. Other interior features Armrest (CrewMax models only) Pull the armrest down for use. NOTICE To prevent damage to the armrest Do not place too much strain on the armrest. Do not sit on the armrest.
Page 441: Seatback Table
3-7. Other interior features Seatback table (if equipped) Front passenger’s seatback can be used as a temporary table only when the vehicle is stopped. Fold down the front passen- ger’s seat to use the seatback table. (→P. 61) CAUTION Caution while driving Observe the following precautions to avoid death or serious injury.
Page 442: Floor Mat
3-7. Other interior features Floor mat Securely place a mat that matches the size of the space on the car- pet. Secure the driver’s floor mat using the hooks provided. CAUTION When inserting the floor mat Observe the following precautions. Failure to do so may result in the floor mat slipping and interfering with the movement of the pedals during driving, resulting in an accident.
Page 443: Luggage Compartment Features
3-7. Other interior features Luggage compartment features Deck hooks Deck hooks are provided for securing loose items.
Page 444 3-7. Other interior features Cargo net hooks (CrewMax models only) To hang the cargo net, use the cargo net hooks. The cargo net itself is not included as original equipment. Shopping bag hooks (CrewMax models only) To hang shopping bags, use the shopping bag hooks.
Page 445 3-7. Other interior features NOTICE To prevent damage to the cargo net hooks and shopping bag hooks Avoid hanging heavy loads on the cargo net hooks or shopping bag hooks. Avoid hanging things other than the cargo net when using the shopping bag hooks as cargo net hooks.
Page 446: Garage Door Opener
3-7. Other interior features Garage door opener (if equipped) The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, secu- rity systems, and other devices. ® The garage door opener (HomeLink Universal Transceiver) is manufac- ®...
Page 447 3-7. Other interior features ® Programming the HomeLink Point the remote control trans- mitter for the device 1 to 3 in. (25 ® to 75 mm) from the HomeLink control buttons. Keep indicator ® HomeLink in view while pro- gramming. Press and hold down one of the ®...
Page 448 3-7. Other interior features Repeat the steps above to program another device for each of ® the remaining HomeLink buttons. Programming a Rolling Code system (for U.S.A. owners) If your device is Rolling Code equipped, follow the steps under the ®...
Page 449 ® the remaining HomeLink buttons. Programming other devices To program other devices such as home security systems, home door locks or lighting, contact your authorized Toyota dealer for assistance. Reprogramming a button ® The individual HomeLink buttons cannot be erased but can be reprogrammed.
Page 450 3-7. Other interior features Before programming Install a new battery in the remote control transmitter. The battery side of the remote control transmitter must be pointed away ® from the HomeLink Certification for the garage door opener This device complies with Part 15 of the FCC Rules and with RSS-210 of the IC Rules.
Page 451: Compass
3-7. Other interior features Compass (if equipped) The compass on the inside rear view mirror indicates the direction in which the vehicle is heading. Operation To turn the compass on or off, press the switch. Displays and directions Display Direction North Northeast East...
Page 452 3-7. Other interior features Calibrating the compass Samoa: 5 Guam: 8 Saipan: 8 The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in illustration, the compass will deviate.
Page 453 3-7. Other interior features Circling calibration When “CAL” appears on the dis- play, drive the vehicle at 5 mph (8 km/h) or less in a circle until a direction is displayed. If there is not enough space to drive in a circle, drive around the block until the direction is dis- played.
Page 454 3-7. Other interior features NOTICE To avoid the compass malfunctions Do not place magnets or any metal objects near the inside rear view mirror. Doing this may cause a malfunction of the compass sensor. To ensure normal operation of the compass Do not perform circling calibration of the compass in a place where the earth’s magnetic field is subject to interference by artificial magnetic fields.
Page 455: Maintenance And Care
4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. l Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 456 4-1. Maintenance and care To prevent deterioration and body corrosion Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads • If you see coal tar or tree sap on the paint surface •...
Page 457: Cleaning And Protecting The Vehicle Interior
4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
Page 458 Wipe the window in strokes running parallel to the heater wires. Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. Shampooing the carpets There are several commercial foaming-type cleaners available.
Page 459 4-1. Maintenance and care NOTICE Cleaning detergents Do not use organic substances such as benzene or gasoline, acidic or alka- line solutions, dye, bleach or other detergent. Doing so may discolor the vehicle interior or cause streaks or damage to painted surfaces. Preventing damage to leather surfaces Observe the following precautions to avoid damage to and deterioration of leather surfaces.
Page 460: Maintenance
Warranty Information Booklet”, “Owner’s Manual Supplement”. Repair and replacement It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 461 4-2. Maintenance Allow inspection and repairs to be performed by a Toyota dealer Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.
Page 462: General Maintenance
“Scheduled Maintenance Guide” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items...
Page 463 4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be held securely Automatic transmission “Park” on an incline with the shift lever in mechanism • Moves smoothly? •...
Page 464: Vehicle Exterior
4-2. Maintenance Vehicle exterior Items Check points Doors • Operate smoothly? Engine hood • The lock system works properly? • Is there any leakage after park- Fluid leaks ing? • Inflation pressure is correct? • Tire surfaces not worn or dam- aged? Tire •...
Page 465: Emission Inspection And Maintenance (I/M) Programs
The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test:...
Page 466: Do-It-Yourself Maintenance
• FMVSS No.116 DOT 3 or SAE Brake fluid level (→P. 486) J1703 brake fluid • Rag or paper towel • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
Page 467 4-3. Do-it-yourself maintenance Items Parts and tools • Bulb with same number and watt- age rating as original Light bulbs (→P. 522) • Phillips-head screwdriver • Flathead screwdriver • Automatic transmission fluid Power steering fluid level ® DEXRON II or III (→P.
Page 468 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury observe the following precautions. When working on the engine compartment Keep hands, clothing, and tools away from the moving fan and engine drive belt.
Page 469 4-3. Do-it-yourself maintenance NOTICE If you remove the air cleaner Driving with the air cleaner removed may cause excessive engine wear due to dirt in the air. Also a backfire could cause a fire in the engine compart- ment. If the brake fluid level is low or high It is normal for the brake fluid level to go down slightly as the brake pads wear or when the brake fluid level in the accumulator is high.
Page 470: Hood
4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. The hood will pop up slightly. Pull up the hood catch lever and lift the hood. CAUTION Pre-driving check Check that the hood is fully closed and locked.
Page 471: Engine Compartment
4-3. Do-it-yourself maintenance Engine compartment 4.0 L V6 (1GR-FE) engine Washer fluid tank (→P. 492) Brake fluid reservoir (→P. 486) Engine oil level dipstick (→P. 479) Fuse box (→P. 512) Engine coolant reservoir Battery (→P. 489) (→P. 484) Radiator (→P. 486) Engine oil filler cap Condenser (→P.
Page 472 4-3. Do-it-yourself maintenance 4.7 L V8 (2UZ-FE) engine Washer fluid tank (→P. 492) Brake fluid reservoir (→P. 486) Engine oil level dipstick (→P. 479) Fuse box (→P. 512) Engine coolant reservoir Battery (→P. 489) (→P. 484) Radiator (→P. 486) Engine oil filler cap Condenser (→P.
Page 473 4-3. Do-it-yourself maintenance 5.7 L V8 (3UR-FE, 3UR-FBE) engine Washer fluid tank (→P. 492) Brake fluid reservoir (→P. 486) Engine oil level dipstick (→P. 479) Fuse box (→P. 512) Engine coolant reservoir Battery (→P. 489) (→P. 484) Radiator (→P. 486) Engine oil filler cap Condenser (→P.
Page 474 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil Park the vehicle on level ground. After turning off the engine, wait a few minutes for the oil to drain back into the bottom of the engine.
Page 475 4-3. Do-it-yourself maintenance 5.7 L V8 (3UR-FE, 3UR-FBE) engine Full Adding engine oil 4.0 L V6 (1GR-FE) engine If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine.
Page 476 4-3. Do-it-yourself maintenance 5.7 L V8 (3UR-FE, 3UR-FBE) engine If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 477 4-3. Do-it-yourself maintenance Recommended viscosity 4.0 L V6 (1GR-FE) and 4.7 L V8 (2UZ-FE) engines SAE 5W-30 is the best choice for good fuel economy, and good starting in cold weather. : If SAE 5W-30 oil is not avail- able, SAE 10W-30 oil may be used.
Page 478 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 479: Engine Coolant
If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer pressure test the cap and check for leaks in the cooling system.
Page 480 U.S.A.: “Toyota Super Long Life Coolant” is a mixture of 50% coolant and 50% deionized water. (Enabled: -31°F [-35°C]) Canada: “Toyota Super Long Life Coolant” is a mixture of 55% coolant and 45% deionized water.
Page 481 Check the radiator and condenser and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION When the engine is hot Do not touch the radiator or condenser as they may be hot and may cause burns.
Page 482 4-3. Do-it-yourself maintenance CAUTION When filling the reservoir Take care because brake fluid can harm your hands or eyes and damage painted surfaces. If fluid gets on your hands or in your eyes, flush the affected area with clean water immediately. If you still experience discomfort, see a doctor.
Page 483 4-3. Do-it-yourself maintenance Power steering fluid Fluid level The fluid level should be within the appropriate range. Full (when cold) Add fluid (when cold) Full (when hot) Add fluid (when hot) Hot: Vehicle has been driven around 50 mph (80 km/h) for 20 minutes, or slightly longer in frigid temperatures.
Page 484 Checking battery condition Check the battery condition using the indicator color. Type A Blue: Good condition White: Charging is necessary. Have the vehicle inspected by your Toyota dealer. Red: Not working properly, have the battery checked by your Toyota dealer.
Page 485 4-3. Do-it-yourself maintenance Type B Green: Good condition Dark: Charging is necessary. Have the vehicle inspected by your Toyota dealer. Clear or light yellow: Not work- ing properly, have the battery checked your Toyota dealer. Before recharging When recharging, the battery produces hydrogen gas which is flammable and explosive.
Page 486 4-3. Do-it-yourself maintenance CAUTION Where to safely charge the battery Always charge the battery in an open area. Do not charge the battery in a garage or closed room where there is not sufficient ventilation. How to recharge the battery Only perform a slow charge (5A or less).
Page 487 4-3. Do-it-yourself maintenance Washer fluid Add washer fluid in the following situations. l Any washer does not work. l The low washer fluid warning light comes on. (if equipped) l The warning message appears on the multi-information display. (if equipped) Open the lid.
Page 488 4-3. Do-it-yourself maintenance NOTICE Do not use any fluid other than washer fluid Do not use soapy water or engine antifreeze instead of washer fluid. Doing so may cause streaking on the vehicle’s painted surfaces. Diluting washer fluid Dilute washer fluid with water as necessary. Refer to the freezing temperatures listed on the washer fluid tank.
Page 489: Tires
The tire pressure warning system Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (→P. 548)
Page 490 Have tire pressure warning valve and trans- mitter ID codes registered by your Toyota dealer. (→P. 496) Initializing the tire pressure warning system The tire pressure warning system must be initialized in the fol-...
Page 491 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer.
Page 492 4-3. Do-it-yourself maintenance Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly. After driving for about 20 minutes, the tire pressure warning light comes on after blinking for 1 minute to indicate a system malfunction.
Page 493 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. When operating the tire pressure warning reset switch, the tire pres- sure warning light does not flash 3 times.
Page 494 Do not mix tires of different makes, models, tread patterns or tread- wear. Do not use tire sizes other than those recommended by Toyota. Do not mix radial, bias-belted, or bias-ply tires. Do not mix summer, all season and winter tires.
Page 495 When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. To avoid damaging the tire pressure warning valves and transmit- ters Do not use liquid sealants on flat tires.
Page 496: Tire Inflation Pressure
4-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (→P. 622)
Page 497 Driving with incorrect tire inflation pressure may result in the following: Reduced fuel efficiency Reduced driving comfort and tire life Reduced safety Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer.
Page 498 4-3. Do-it-yourself maintenance Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: Check only when the tires are cold. If your vehicle has been parked for at least 3 hours and has not been driven for more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure reading.
Page 499 4-3. Do-it-yourself maintenance NOTICE When inspecting and adjusting tire inflation pressure Be sure to reinstall the tire valve caps. Without the valve caps, dirt or moisture could get into the valve and cause air leakage, which could result in an accident. If the caps have been lost, replace them as soon as possible.
Page 500: Wheels
Used wheels l Bent wheels that have been straightened Wheel precautions l Use only Toyota wheel nuts and wrench designed for use with your aluminum wheels. l When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 100 miles (160 km).
Page 501 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 502: Air Conditioning Filter
4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be cleaned or changed regularly to maintain air conditioning efficiency. Removal method Turn the engine switch off. Open the glove box. Slide off the damper. Push in each side of the glove box to disconnect the claws.
Page 503 Hold the air gun 2 in. (5 cm) from the filter and blow for approximately 2 minutes at 72 psi (500 kPa, 5.0 kgf/cm or bar). If it is not available, have the filter cleaned by your Toyota dealer.
Page 504 4-3. Do-it-yourself maintenance Replacement method Remove the air conditioning filter and replace it with a new one. The “↑UP” marks shown on the filter should be pointing up. Checking interval Inspect, clean and replace the air conditioning filter according to the mainte- nance schedule.
Page 505: Wireless Remote Control Battery
4-3. Do-it-yourself maintenance Wireless remote control battery Replace the battery with a new one if it is discharged. You will need the following items: Lithium battery CR2032 Replacing the battery Remove the cover using a coin protected with tape etc. Remove the discharged trans- mitter battery.
Page 506 The wireless remote control will not function properly. The operational range is reduced. Use a CR2032 lithium battery Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. Replace only with the same or equivalent type recommended by your Toyota dealer.
Page 507: Checking And Replacing Fuses
4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the engine switch off. The fuses are located in the following places. To check the fuses, follow the instructions below.
Page 508 4-3. Do-it-yourself maintenance Remove the fuse with the pull- out tool.
Page 509 Type B Normal fuse Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type C Normal fuse Blown fuse Contact your Toyota dealer.
Page 510 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings Engine compartment Fuse Ampere Circuit Multiport fuel injection system/ 15 A sequential multiport fuel injection system HORN 10 A Horn Multiport fuel injection system/ EFI NO.1 25 A sequential multiport fuel injection system IG2 MAIN 30 A...
Page 511 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Stop lights, high mounted stop- light, vehicle stability control sys- tem, anti-lock brake system, shift STOP 15 A lock system, multiport fuel injection system/sequential multiport fuel injection system, towing converter TOW BRK 30 A Trailer brake controller 7.5 A Engine immobilizer system...
Page 512 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Interior lights, personal lights, van- ity lights, engine switch light, foot DOME 7.5 A light, door courtesy lights, acces- sory meter Left-hand headlight HEAD LH 15 A (high beam) Left-hand headlight HEAD LL 15 A (low beam) Multiport fuel injection system/ 10 A...
Page 513 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Anti-lock brake system, vehicle sta- ABS2 40 A bility control system 30 A Starting system 50 A Air conditioning system AM1, TAIL, PANEL, ACC, CIG, LH- IG, 4WD, ECU-IG No.1, BK/UP LP, SEAT-HTR, A/C IG, ECU-IG No.2, LH-J/B 150 A WSH, WIPER, OBD, A/C, TI&TE,...
Page 514 4-3. Do-it-yourself maintenance Under the instrument panel Fuse Ampere Circuit INVERTER 15 A Power outlet (115 V) FR P/SEAT LH 30 A Power front driver’s seat DR/LCK 25 A Multiplex communication system 7.5 A On-board diagnosis system PWR OUTLET 15 A Power outlets CARGO LP 7.5 A...
Page 515 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Back-up lights, charging system, gauge and meters, turn signal LH-IG 7.5 A lights, air conditioning system, seat heaters, back window defogger 20 A Four-wheel drive control system 20 A Window washer WIPER 30 A Wiper and washer ECU-IG No.2 7.5 A...
Page 516 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix.
Page 517: Light Bulbs
You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 518: Replacing Light Bulbs
4-3. Do-it-yourself maintenance Rear bulb locations High mounted stoplight Stop/tail and rear and cargo lamps side marker lights Rear turn signal lights License plate lights Back-up lights Replacing light bulbs Headlight high beam Unplug connector while depressing the lock release.
Page 519 4-3. Do-it-yourself maintenance Turn the bulb base counterclock- wise. Headlight low beam Unplug connector while depressing the lock release. Turn the bulb base counterclock- wise.
Page 520 4-3. Do-it-yourself maintenance Front turn signal/parking lights Turn the bulb base counterclock- wise. Remove the light bulb.
Page 521 4-3. Do-it-yourself maintenance Front side marker lights Remove the fender liner clip. Partly remove the fender liner and turn the bulb base counter- clockwise.
Page 522 4-3. Do-it-yourself maintenance Remove the light bulb. Front fog lights (if equipped) Remove the bolts and partly remove the fender liner. Turn the bulb counterclockwise.
Page 523 4-3. Do-it-yourself maintenance Unplug connector while depressing the lock release. Stop/tail and rear side marker lights, rear turn signal lights and back-up lights Remove the bolts and rear com- bination assembly. Turn the bulb bases counter- clockwise. Stop/tail and rear side marker light Rear turn signal light Back-up light...
Page 524 4-3. Do-it-yourself maintenance Remove the light bulb. Stop/tail and rear side marker light Rear turn signal light Back-up light High mounted stoplight and cargo lamps Remove the screws and cover. Remove the light bulb. High mounted stoplight Cargo lamps...
Page 525 4-3. Do-it-yourself maintenance License plate lights Remove the screw and light unit. Turn the bulb base counterclock- wise. Remove the light bulb.
Page 526 LED side turn signal lights The side turn signal light consists of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. Installing the fender liner clips...
Page 527 4-3. Do-it-yourself maintenance CAUTION Replacing light bulbs Turn off the headlights. Do not attempt to replace the bulb immediately after turning off the headlights. The bulbs become very hot and may cause burns. Do not touch the glass portion of the light bulb with bare hands. Hold the bulb by the plastic or metal portion.
Page 528: Essential Information
5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, push the switch once again. NOTICE To prevent battery discharge Do not leave the emergency flashers on longer than necessary when the engine is not running.
Page 529: If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
Page 530 5-1. Essential information Type B Towing eyelet Emergency towing procedure The engine switch must be in the ACC (engine off) or the ON (engine running) position. 4WD models: Put the front wheel drive control switch in 2WD. Put the shift lever in N. Release the parking brake.
Page 531 5-1. Essential information NOTICE To prevent causing serious damage to the transmission Never tow this vehicle from the rear with the four wheels on the ground. This may cause serious damage to the transmission. Emergency towing eyelet precautions Before emergency towing, check that the eyelet is not broken or damaged and that the installation bolts are not loose.
Page 532 5-1. Essential information Towing with a wheel lift-type truck from the front Use a towing dolly under the rear wheels. NOTICE To prevent causing serious damage to the transmission Never tow this vehicle wheels on the ground. Towing with a wheel lift-type truck from the rear 2WD models Turn the engine switch to the ACC position.
Page 533 Without adequate clearance, the vehicle could be damaged while being towed. Using a flat bed truck If your Toyota is transported by a Front flat bed truck, it should be tied down at the locations shown in...
Page 534 5-1. Essential information If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°. Do not overly tighten the tie downs or the vehicle may be damaged. Apply the parking brake firmly.
Page 535: If You Think Something Is Wrong
5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms l Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 536: Fuel Pump Shut Off System
5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an air- bag inflates upon collision, the fuel pump shut off system stops sup- plying fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 537: Event Data Recorder
5-1. Essential information Event data recorder Your vehicle has computers that monitor and control certain aspects of your vehicle. These computers assist in driving and maintaining optimal vehicle performance. Besides storing data useful for troubleshooting, there is an event data recorder (EDR) that records data in a crash or a near car crash event.
Page 538 5-1. Essential information Disclosure of the data Toyota will not disclose the data recorded in an EDR to a third party except when: l An agreement from the vehicle’s owner (or the leasing company for a leased vehicle) is obtained...
Page 539: Steps To Take In An
Stop the vehicle immediately. The following warnings indicate the possibility of damage to the vehi- cle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Charging system warning light Indicates a malfunction in the vehicle’s charging sys-...
Page 540 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Indicates a malfunction in: •...
Page 541 5-2. Steps to take in an emergency Warning light Warning light/Details Slip indicator and VSC OFF indicator (Flashing) The indicator comes on to indicate a malfunction in: • The VSC; • The TRAC; • The A-TRAC or • The AUTO LSD system. (Flashing) Automatic transmission fluid temperature warn- ing light...
Page 542 • When the light comes on Have the system after blinking for 1 checked by your minute: Malfunction in Toyota dealer. the tire pressure warning system. Low fuel level warning light Refuel the vehicle. Low level of fuel.
Page 543 5-2. Steps to take in an emergency : Open door warning buzzer: The buzzer sounds to indicate that any door is opened (with the vehicle hav- ing reached a speed of 3 mph [5 km/h]) : Driver’s seat belt reminder: The driver’s seat belt reminder sounds to alert the driver that his or her seat belt is not fastened.
Page 544 5-2. Steps to take in an emergency The light will go off after taking several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. Front passenger detection sensor and passenger seat belt reminder If luggage or other load is placed on the right front passenger seat, depend- ing on its weight, the reminder light to flash and buzzer to sound.
Page 545 If there is a lot of snow or ice on the vehicle, in particular around the wheels or wheel housings. If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.)
Page 546 5-2. Steps to take in an emergency CAUTION Maintenance of the tire Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 547 5-2. Steps to take in an emergency CAUTION TPMS (tire pressure warning system) malfunctions may occur for a vari- ety of reasons, including the installation of replacement or alternate tires or wheels on the vehicle that prevent the TPMS (tire pressure warning system) from functioning properly.
Page 548: If A Warning Message Is Displayed (Vehicles With Multi-Information Display)
Stop the vehicle immediately. The following warnings indicate the possibility of damage to the vehi- cle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning message Details Indicates that the engine coolant temperature is too high A buzzer also sounds.
Page 549 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turns off. Warning message Details Correction procedure Indicates that one or more of the doors is not fully closed.
Page 550 5-2. Steps to take in an emergency Warning message Details Correction procedure Indicates that the engine oil is scheduled to be changed. A buzzer also sounds. Comes on approxi- Check the engine oil, mately 4500 miles (7200 and change if neces- km) after the engine oil sary.
Page 551 5-2. Steps to take in an emergency After changing the engine oil (U.S.A. only) Make sure to reset the oil maintenance data. (→P. 483)
Page 552: If You Have A Flat Tire
5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. Before jacking up the vehicle l Stop the vehicle on a hard, flat surface. l Set the parking brake. l Shift the shift lever to P.
Page 553 5-2. Steps to take in an emergency Double Cab models without storage box Tool bag Jack Double Cab models with storage box Tool bag Jack CrewMax models Tool bag Jack...
Page 554 5-2. Steps to take in an emergency Taking out the jack and tool bag (Regular Cab models) Pull the lever and fold down the seatback. Remove the cover. Unhook the strap and remove the tool bag.
Page 555 5-2. Steps to take in an emergency Unhook the strap. Loosen and remove the jack. Loosen Tighten Taking out the jack and tool bag (Double Cab models) Pull up the lever. Raise the bottom cushion up.
Page 556 5-2. Steps to take in an emergency Vehicles with storage box Turn the knob to the OPEN direction. Remove the lid. Vehicles with storage box Remove the jack cover panel. Unhook the strap and remove the tool bag. Loosen and remove the jack. Loosen Tighten...
Page 557 5-2. Steps to take in an emergency Taking out the jack and tool bag (CrewMax models) Pull the lever and fold down the seatback. Remove the cover. Unhook the strap and remove the tool bag.
Page 558 5-2. Steps to take in an emergency Unhook the strap. Loosen and remove the jack. Loosen Tighten Assemble the jack handle (in the tool bag) Type A Assemble the jack handle exten- sion as shown.
Page 559 5-2. Steps to take in an emergency Type B Taking out the spare tire Type A Insert the end of the jack handle extension into lowering screw and turn it counterclock- wise. After the tire is lowered com- pletely to the ground, remove the holding bracket.
Page 560 5-2. Steps to take in an emergency Type B...
Page 561 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Wheel Flat tire chock positions Behind the Left- rear right- hand hand side side tire Front Behind the Right- rear left- hand hand side side tire In front of Left- the front...
Page 562 5-2. Steps to take in an emergency Assemble the jack handle exten- sion as shown. Position the jack at the correct jack point as shown. Front Front Rear Make sure the jack is positioned on a level and solid place. Raise the vehicle until the tire is slightly raised off the ground.
Page 563 5-2. Steps to take in an emergency Installing the tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
Page 564 5-2. Steps to take in an emergency Lower the vehicle. Firmly tighten each nut two or three times in the order shown in the illustration. Tightening torque Flat washer type (Aluminum wheels) 97 ft·lbf (131 N·m, 13.4 kgf·m) Taper type (Steel wheels) 154 ft·lbf (209 N·m, 21.3 kgf·m) : When temporarily used on...
Page 565 5-2. Steps to take in an emergency Stowing the flat tire, jack and all tools Remove the center wheel ornament by pushing from the reverse side. Lay down the tire with the outer side facing up, and install the holding bracket. Then secure the tire, taking care that the tire goes straight up without catching on any other part, to prevent it from flying for- ward during a collision or sudden braking.
Page 566 5-2. Steps to take in an emergency CAUTION Using the jack Do not raise the vehicle while someone is in it. When raising the vehicle, do not put an object on or under the jack. Do not raise the vehicle to a height greater than that required to replace the tire.
Page 567 5-2. Steps to take in an emergency CAUTION Replacing a flat tire Do not attach a heavily damaged wheel ornament, as it may fly off the wheel while the vehicle is moving. When using the temporary spare tire Remember that your temporary spare tire is specifically designed for use with your vehicle.
Page 568 When replacing the tires When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled cor- rectly.
Page 569: If The Engine Will Not Start
5-2. Steps to take in an emergency If the engine will not start If the engine still does not start after following the correct starting procedure (→P. 177) or releasing the steering lock (→P. 178), confirm the following points. The engine will not start even when the starter motor oper- ates normally.
Page 570 One of the following may be the cause of the problem. l One or both of the battery terminals may be disconnected. l The battery may be discharged. (→P. 581) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown.
Page 571: If The Shift Lever Cannot Be Shifted From P
(a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 572 5-2. Steps to take in an emergency Column-shift type Press the shift lock override button. The shift lever can be shifted while the button is pressed. Floor shift type...
Page 573 5-2. Steps to take in an emergency Column-shift type...
Page 574: If You Lose Your Keys
5-2. Steps to take in an emergency If you lose your keys New genuine Toyota keys can be made by your Toyota dealer using the key number stamped on your key number plate. Vehicles with engine immobilizer system, the dealer will also need the master key.
Page 575: If The Vehicle Battery Is Discharged
You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your Toyota following the steps below. Connect the jumper cables.
Page 576 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible.
Page 577 5-2. Steps to take in an emergency Starting the engine when the battery is discharged The engine cannot be started by push-starting. Avoiding a discharged battery Turn off the headlights and the audio system while the engine is turned off. Turn off any unnecessary electrical components when the vehicle is run- ning at a low speed for an extended period, such as in heavy traffic, etc.
Page 578 5-2. Steps to take in an emergency CAUTION Battery precautions The battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following pre- cautions when handling the battery. When working with the battery, always wear safety glasses and take care not to allow any battery fluids (acid) to come into contact with skin, clothing or the vehicle body.
Page 579: If Your Vehicle Overheats
If the fan is operating: Wait until the temperature of the engine (shown on the instrument cluster) begins to fall and then stop the engine. If the fan is not operating: Stop the engine immediately and call your local Toyota dealer.
Page 580 Note that water draining from the air conditioning is normal if it has been used. Add engine coolant if required. Water can be used in an emer- gency if engine coolant is unavailable. (→P. 609) Have the vehicle checked at your nearest Toyota dealer as soon as possible.
Page 581 5-2. Steps to take in an emergency Overheating If you observe the following, your vehicle may be overheating. The engine coolant temperature gauge enters the red zone or a loss of power is experienced. Steam is coming from under the hood. “ENGINE COOLANT HOT”...
Page 582: If The Vehicle Becomes Stuck
5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the engine. Set the parking brake and put the shift lever in P.
Page 583: Specifications
6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions 2WD models Cab type Regular Cab Double Cab Bed type Standard Long Standard Long Overall 209.8 in. 228.7 in. 228.7 in. 247.6 in. length (5330 mm) (5810 mm) (5810 mm) (6290 mm) 79.9 in.
Page 584 6-1. Specifications Cab type CrewMax Bed type Short Overall 228.7 in. (5810 mm) length Overall width 79.9 in. (2030 mm) 75.7 in. (1925 mm) Overall height *3,*4 75.5 in. (1920 mm) Wheelbase 145.6 in. (3700 mm) Front tread 67.9 in. (1725 mm) Rear tread 67.9 in.
Page 585 6-1. Specifications 4WD models Cab type Regular Cab Double Cab Bed type Standard Long Standard Long Overall 209.8 in. 247.6 in. 228.7 in. (5810 mm) length (5330 mm) (6290 mm) Overall width 79.9 in. (2030 mm) 76.3 in. 76.1 in. 76.3 in.
Page 586 6-1. Specifications Cab type CrewMax Bed type Short Overall length 228.7 in. (5810 mm) Overall width 79.9 in. (2030 mm) 76.1 in. (1935 mm) Overall height *3,*4 75.9 in. (1930 mm) Wheelbase 145.6 in. (3700 mm) Front tread 67.9 in. (1725 mm) Rear tread 67.9 in.
Page 587: Vehicle Capacity Weight
6-1. Specifications Vehicle capacity weight Regular Cab models Driving Vehicle capacity weight Model code Engine Bed type system (Occupants+luggage) 4.0 L V6 GSK50L-TRADKA Standard 1495 lb. (675 kg) (1GR-FE) GSK51L-THADKA Long 1575 lb. (710 kg) engine 1730 lb. (780 kg) UCK50L-TRADKA Standard 1655 lb.
Page 588 6-1. Specifications Double Cab models Driving Vehicle capacity weight Model code Engine Bed type system (Occupants+luggage) 4.0 L V6 GSK51L-CRASKA (1GR-FE) 1300 lb. (585 kg) Standard engine 1415 lb. (640 kg) UCK51L-CRASKA 1340 lb. (605 kg) Standard 1450 lb. (655 kg) UCK51L-CRALKA 1375 lb.
Page 589 6-1. Specifications Driving Vehicle capacity weight Model code Engine Bed type system (Occupants+luggage) 1470 lb. (665 kg) USK56L-CRTSGA 1395 lb. (630 kg) 5.7 L V8 Standard (3UR-FBE) 1505 lb. (680 kg) USK56L-CRTLGA engine 1430 lb. (645 kg) USK57L-CHTSGA Long 1365 lb. (615 kg) →...
Page 590 6-1. Specifications Driving Vehicle capacity weight Model code Engine Bed type system (Occupants+luggage) 1470 lb. (665 kg) USK51L-PSTSKA 1395 lb. (630 kg) 1360 lb. (615 kg) 1530 lb. (690 kg) USK51L-PSTLKA 1455 lb. (655 kg) 5.7 L V8 1420 lb. (640 kg) (3UR-FE) 1400 lb.
Page 591: Towing Capacity
6-1. Specifications Towing capacity Regular Cab models Driving Towing capacity Model code Engine Bed type system (Trailer weight + cargo) 4.0 L V6 GSK50L-TRADKA Standard 5100 lb. (2310 kg) (1GR-FE) GSK51L-THADKA Long 5000 lb. (2265 kg) engine 7000 lb. (3175 kg) UCK50L-TRADKA Standard 8500 lb.
Page 592 6-1. Specifications Driving Towing capacity Model code Engine Bed type system (Trailer weight + cargo) 8700 lb. (3945 kg) USK55L-TRTDGA Standard 10100 lb. (4580 kg) 5.7 L V8 *3,4 (3UR-FBE) 9600 lb. (4350 kg) engine 8600 lb. (3900 kg) USK56L-THTDGA Long 10500 lb.
Page 593 6-1. Specifications Double Cab models Driving Towing capacity Model code Engine Bed type system (Trailer weight + cargo) 4.0 L V6 GSK51L-CRASKA (1GR-FE) Standard 4800 lb. (2175 kg) engine 6700 lb. (3035 kg) UCK51L-CRASKA 8100 lb. (3670 kg) Standard 6600 lb. (2990 kg) UCK51L-CRALKA 8100 lb.
Page 594 6-1. Specifications Driving Towing capacity Model code Engine Bed type system (Trailer weight + cargo) 8300 lb. (3760 kg) USK56L-CRTSGA 10300 lb. (4670 kg) 5.7 L V8 Standard (3UR-FBE) 8300 lb. (3760 kg) USK56L-CRTLGA engine 10300 lb. (4670 kg) USK57L-CHTSGA Long 10200 lb.
Page 595 6-1. Specifications CrewMax models Driving Towing capacity Model code Engine Bed type system (Trailer weight + cargo) 6500 lb. (2945 kg) UCK51L-PSASKA 8000 lb. (3625 kg) 6500 lb. (2945 kg) UCK51L-PSALKA 4.7 L V8 8000 lb. (3625 kg) (2UZ-FE) 6200 lb. (2810 kg) engine UCK56L-PSASKA 7700 lb.
Page 596 Vehicle identification number The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 597 6-1. Specifications Engine number The engine number is stamped on the engine block as shown. 4.0 L V6 (1GR-FE) engine 4.7 L V8 (2UZ-FE) engine 5.7 L V8 (3UR-FE, 3UR-FBE) engine...
Page 598 6-1. Specifications Engine 4.0 L V6 (1GR-FE) engine Model 1GR-FE Type 6-cylinder V-type, 4-cycle, gasoline 3.70 × 3.74 in. (94.0 × 95.0 mm) Bore and stroke Displacement 241.4 cu.in. (3956 cm Drive belt tension Automatic adjustment Valve clearance (engine cold) 0.006 ⎯...
Page 599 6-1. Specifications 5.7 L V8 (3UR-FE, 3UR-FBE) engine Model 3UR-FE, 3UR-FBE Type 8-cylinder V-type, 4-cycle, gasoline 3.70 × 4.02 in. (94.0 × 102.0 mm) Bore and stroke Displacement 345.6 cu.in. (5663 cm Drive belt tension Automatic adjustment Valve clearance (engine cold) Intake Automatic adjustment Exhaust...
Page 600: Lubrication System
6.6 qt. (6.2 L, 5.5 Imp.qt.) Without filter 6.0 qt. (5.7 L, 5.0 Imp. qt.) Oil grade ILSAC multigrade engine oil Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the grade and viscosity shown below. Recommended oil viscosity Outside temperature *: 5W-30 is an oil that provides optimal levels of fuel efficiency.
Page 601 7.4 qt. (7.0 L, 6.2 Imp.qt.) Without filter 6.9 qt. (6.6 L, 5.8 Imp.qt.) Oil grade ILSAC multigrade engine oil Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the grade and viscosity shown below. Recommended oil viscosity...
Page 602: Cooling System
3UR-FBE) Vehicles with towing package engine 13.7 qt. (13.0 L, 11.4 Imp. qt.) Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 603: Ignition System
6-1. Specifications Ignition system Spark plug 4.0 L V6 (1GR-FE) engine Make DENSO K20HR-U11 LFR6C11 0.043 in. (1.1 mm) 4.7 L V8 (2UZ-FE) engine Make DENSO SK20R11 IFR6A11 0.043 in. (1.1 mm) 5.7 L V8 (3UR-FE, 3UR-FBE) engine Make DENSO SK20HR11 0.043 in.
Page 604: Electrical System
6-1. Specifications Electrical system Battery 12.6 ⎯ 12.8 V Fully charged Open voltage at 12.2 ⎯ 12.4 V Half charged 68°F (20°C): 11.8 ⎯ 12.0 V Discharged (Voltage checked 20 minutes after the key is removed with all the lights turned off) Charging rates 5 A max.
Page 605 3.8 qt. (3.60 L, 3.2 Imp.qt.) Toyota Genuine Differential Gear Oil LT 75W-85 GL-5 or equivalent “Toyota Genuine Differential Gear Oil” is filled in your Toyota vehicle at factory fill. Use Toyota Oil type and viscosity approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification.
Page 606 : The fluid capacity is the quantity of reference. If replacement is necessary, contact your Toyota dealer. NOTICE Automatic transmission fluid type Using automatic transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied vibration,...
Page 607 6-1. Specifications Brakes Pedal clearance 4.1 in. (104 mm) Min. 0.04 ⎯ 0.20 in. (1 ⎯ 5 mm) Pedal free play Brake pad wear limit 0.04 in. (1.0 mm) Parking brake lining wear limit 0.04 in. (1.0 mm) Parking brake pedal travel 6 —...
Page 608 6-1. Specifications Tires and wheels Type A Tire size P255/70R18 112T Front tires: 30 psi (210 kPa, 2.1 kgf/cm or bar) Tire inflation pressure Rear tires: (Recommended cold tire 33 psi (230 kPa, 2.3 kgf/cm or bar) inflation pressure) Spare tire: 33 psi (230 kPa, 2.3 kgf/cm or bar) 18 ×...
Page 609 6-1. Specifications Type C P275/55R20 111H, Tire size P255/70R18 112T (spare tire) Front tires: 30 psi (210 kPa, 2.1 kgf/cm or bar) Tire inflation pressure Rear tires: (Recommended cold tire 33 psi (230 kPa, 2.3 kgf/cm or bar) inflation pressure) Spare tire: 33 psi (230 kPa, 2.3 kgf/cm or bar)
Page 610 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights 9005 (high beam) Headlights (low beam) Front fog lights 9145 Front side marker lights Front turn signal/parking 4157NAK 28/8 lights Exterior Rear turn signal lights 3157A 27/8 Stop/tail and rear side 3157 27/8 marker lights...
Page 611: Fuel Information
At minimum, the E85 you use should meet the specifications of ASTM D5798 in the U.S.A. Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps.
Page 612 In very few cases, driveability problems may be caused by the brand of fuel you are using. If driveability problems persist, try changing the brand of fuel. If this does not correct the problem, consult your Toyota dealer. Gasoline quality standards...
Page 613 Toyota allows the use of oxygenate blended gasoline where the oxygenate content is up to 10% ethanol or 15% MTBE. If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 87. Toyota does not recommend the use of gasoline containing methanol.
Page 614 6-1. Specifications NOTICE Notice on fuel quality Do not use improper fuels. If improper fuels are used the engine will be damaged. Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters causing the emission control system to malfunction. Gasoline engine: Do not use gasohol other than that stated here.
Page 615: Tire Information
6-1. Specifications Tire information Typical tire symbols Tire size (→P. 624) DOT and Tire Identification Number (TIN) (→P. 623) Location of treadwear indicators (→P. 626) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire.
Page 616 6-1. Specifications Radial tires or bias-ply tires A radial tire has RADIAL on the sidewall. A tire not marked RADIAL is a bias-ply tire. Summer tire or all season tire (→P. 497) An all season tire has M+S on the sidewall. A tire not marked M+S is a summer tire.
Page 617 6-1. Specifications Tire size Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol...
Page 618 U.S.A. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades.
Page 619 6-1. Specifications Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on the government course as a tire graded 100.
Page 620 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either separately or in combination, can cause heat buildup and possible tire failure. Glossary of tire terminology Tire related term Meaning...
Page 621 6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as Occupant distribution specified in the third column of Table 1 below The combined weight of installed regular production options weighing over 5 lb.
Page 622 6-1. Specifications Tire related term Meaning The surface area of the rim not covered by the Weather side inflated tire The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components Bead separation...
Page 623 6-1. Specifications Tire related term Meaning The parting of the innerliner from cord material Innerliner separation in the carcass (a)The sidewall that contains a whitewall, bears white lettering, or bears manufacturer, brand, and/or model name molding that is higher or deeper than the same molding on Intended outboard the other sidewall of the tire, or sidewall...
Page 624 6-1. Specifications Tire related term Meaning A layer of rubber-coated parallel cords A parting of rubber compound between Ply separation adjacent plies A mechanical device made of rubber, chemicals, fabric and steel or other materials, Pneumatic tire that, when mounted on an automotive wheel, provides the traction and contains the gas or fluid that sustains the load A pneumatic tire in which the ply cords that...
Page 625 6-1. Specifications Tire related term Meaning That portion of a tire that comes into contact Tread with the road A tread section running circumferentially Tread rib around a tire Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear designed to give a visual indication of the...
Page 626: Customization
Programming these preferences requires specialized equipment and may be performed by an autho- rized Toyota dealership. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Customized Item Function...
Page 627 6-2. Customization Customized Item Function Default setting setting Speed-detecting auto- matic door lock function Opening driver’s door unlocks all doors. Shifting gears to “P” unlocks all doors. Shifting gears to posi- Door lock tion other than “P” locks (→P. 47) all doors.
Page 628 6-2. Customization Customized Item Function Default setting setting 7.5 seconds Time elapsed before 15 seconds lights turn off 30 seconds Illumination Operation after the → P. 393) engine is off Operation when the doors are unlocked Seat Belt Vehicle speed linked Reminder seat belt reminder Buzzer...
Page 629: Items To Initialize
6-2. Customization Items to initialize The following items must be initialized for normal system operation in cases such as after the battery is reconnected, or maintenance is performed on the vehicle. Item When to initialize Reference • After reconnecting or changing Moon roof the battery P.
Page 630: Reporting Safety Defects For U.s. Owners
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 631: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English.
Page 633: Camper Information
National Highway Traffic Safety Administration of the U.S. Department of Transportation. It provides the purchas- ers and/or prospective purchasers of Toyota vehicles with infor- mation on truck-camper loading. Your Toyota dealer will help answer any questions you may have as you read this informa- tion.
Page 634 Double Cab models with standard bed Recommended location cargo center of gravity for cargo weight rating Rear end of truck bed Double Cab models with long bed Recommended location cargo center of gravity for cargo weight rating Rear end of truck bed CrewMax models Recommended location...
Page 635 CAUTION Loading precaution If a load is too far back, it can cause dangerous handling. If it is too far forward, the front axle may be overloaded. Cargo weight rating and proper matching When the truck is used to carry a slide-in camper, the total cargo load of the truck consists of the manufacturer’s camper weight figure, the weight of installed additional camper equipment not included in the manufacturer’s camper weight figure, the weight of camper cargo,...
Page 636 Cargo weight rating CWR: Cargo Weight Rating C.W.R Passenger Engine Drive Grade number (lb.) (kg) Standard 1045 Long 1125 Standard 1205 Long 1305 Standard 1145 Regular – Long 1240 Standard 1135 Long 1450 Standard 1080 Long 1385...
Page 637 CWR: Cargo Weight Rating C.W.R Passenger Engine Drive Grade number (lb.) (kg) Standard Standard Limited Long Standard Limited Double Long Standard Limited Long Standard Limited Long...
Page 638 CWR: Cargo Weight Rating C.W.R Passenger Engine Drive Grade number (lb.) (kg) Limited Limited Crew Short Limited Limited CAUTION Overloading Be careful — overloading can cause dangerous braking and handling problems, and can damage your vehicle and its tires.
Page 639 Gross axle and vehicle weight ratings Secure loose items to prevent weight shifts that could affect the bal- ance of your vehicle. When the truck camper is loaded, drive to a scale and weigh on the front and on the rear wheels separately to determine axle loads.
Page 640 GAWR and GVWR Regular Cab models GAWR Driving Model code ∗ Engine GVWR system type Front Rear GSK50L- 3700 lb. 6200 lb. Standard 4.0 L V6 TRADKA (1675 kg) (2810 kg) 3900 lb. (1GR-FE) (1765 kg) GSK51L- 3800 lb. 6400 lb. engine Long THADKA...
Page 641 Double Cab models GAWR Driving Model code ∗ Engine GVWR system type Front Rear 4.0 L V6 GSK51L- 3900 lb. 3800 lb. 6400 lb. (1GR-FE) Standard CRASKA (1765 kg) (1720 kg) (2900 kg) engine UCK51L- CRASKA 4000 lb. 6700 lb. Standard (1810 kg) (3035 kg)
Page 642 GAWR Driving Model code ∗ Engine GVWR system type Front Rear USK56L- CRTSGA 7100 lb. Standard 5.7 L V8 (3220 kg) USK56L- 4000 lb. 4150 lb. (3UR-FBE) CRTLGA (1810 kg) (1880 kg) engine USK57L- 7200 lb. Long CHTSGA (3265 kg) ∗...
Page 643 GAWR Driving Model code ∗ Engine GVWR system type Front Rear USK56L- 5.7 L V8 PSTSGA 4000 lb. 4150 lb. 7200 lb. (3UR-FBE) Short (1810 kg) (1880 kg) (3265 kg) USK56L- engine PSTLGA ∗ : The model code is indicated on the Certification Label. (→P. 603)
Page 645: Abbreviation List
Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Two Wheel Drive Four Wheel Drive Anti-Lock Brake System Accessory AI-SHIFT Artificial Intelligence shifting Automatic Locking Retractor A-TRAC Active Traction Control AUTO LSD Automatic Limited Slip Differential Calibration Child Restraint System Electronic Control Unit Event Data Recorder Emergency Locking Retractor Flexible Fuel Vehicle...
Page 646 ABBREVIATIONS MEANING Resume RSCA Roll Sensing of Curtain shield Airbags Supplemental Restraint System Tire Identification Number TPMS Tire Pressure Warning System TRAC Traction Control Treadwear indicators US/M U.S. Customary System and metric Vehicle Identification Number Vehicle Stability Control...
Page 647: Alphabetical Index
Alphabetical index Alphabetical index A/C........276, 285 Anti-lock brake system..230 ABS ...........230 Armrest ........444 Accessory meter ......204 Ashtray ........429 Active traction control Audio input....... 325 system ........230 Audio remote controls .... 327 Air conditioning filter....507 Audio system Air conditioning system A/V input adapter ....
Page 648 Alphabetical index Battery Front passenger occupant Charging system warning classification system ...131 light ........545 Infant seats, definition ...138 Checking ......489 Infant seats, installation..153 If the vehicle has Installing CRS with lower discharged battery ..... 581 anchorages ..147, 150, 151 Preparing and checking Installing CRS with seat before winter ......
Page 649 Alphabetical index Cruise control......214 If the shift lever cannot be Cup holders ......414 shifted ......... 577 Curtain shield airbags .....115 If the vehicle has Customizable features..200, 633 discharged battery ....581 If the warning buzzer sounds ........ 545 Daytime running light If the warning light turns system ........208 on........
Page 650 Alphabetical index Preparing and checking Fuel pump shut off system ..542 before winter ...... 246 Gas station information ..672 Warning light ......546 Information ......618 Engine oil maintenance Refueling .......103 data ........483 Type ........606 Engine switch ......177 Warning light ......548 Event data recorder ....
Page 651 Alphabetical index I/M test........470 License plate lights Identification Replacing light bulbs..... 530 Engine ........604 Switch ........207 Tire ........623 Wattage......... 617 Vehicle ........603 Light bulbs Ignition switch......177 Replacing ......522 Illuminated entry system..393 Wattage......... 617 Immobilizer system....108 Lights Indicator lights ......194 Automatic light off system ..208 Initialization Cargo lamp switch ....
Page 652 Alphabetical index Meter Passenger risk group ....128 Accessory meter....204 Pen holder ........409 Instrument panel light Personal lights control ........ 193 Switch........395 Meters ........188 Wattage.........617 Mirrors Power back window....97 Inside rear view mirror.... 85 Power outlet .....432, 437 Side mirror heaters..293, 295 Power steering Side mirrors ......
Page 653 Alphabetical index Reporting safety defects Front seat adjustment for U.S.A. owners....638 precautions ......62 Roll sensing of curtain Driver’s seat position shield airbags off switch..129 memory.........68 Head restraint ......71 Properly sitting in the seat..113 Seatback table......445 Raising the bottom Seat belts cushion .........64 Adjusting the seat belt.....75 Seat heaters......442...
Page 654 Alphabetical index Steering Tachometer.......188 Column lock release....83 Tailgate Steering wheel Removing the tailgate .....53 Adjustment ......83 Tailgate ........52 Audio switches ..... 327 Tail lights Steering wheel memory..68 Replacing light bulbs .....528 Telephone switches....365 Switch........207 Stop lights Wattage.........617 Replacing light bulbs ....
Page 655 Alphabetical index Towing Four-wheel drive system Bumper towing ......261 warning buzzer ....549 Dinghy towing......272 Driver’s seat belt ....547 Emergency towing....535 Front passenger occupant Fifth wheel trailer....260 classification system... 546 Trailer towing......250 Front passenger’s Traction control......230 seat belt ......547 TRAC .........230 Low brake fluid......
Page 656 Alphabetical index Washer ......... 211 Windshield wiper de-icer ......293, 295 Windshield wipers....211 Wireless remote control Replacing the battery ... 510 Wireless remote control..44 Winter driving tips....246 WMA disc ......... 314...
Page 657 What to do if... What to do if... A tire punctures If you have a flat tire P. 558 P. 575 If the engine will not start The engine does not start P. 108 Engine immobilizer system If the vehicle battery is discharged P.
Page 658 What to do if... The warning light or indicator If a warning light turns on P. 545 light comes on Instrument cluster Vehicles with multi-information display Vehicles without multi-information display (type A)
Page 659 What to do if... Vehicles without multi-information display (type B) Center panel...
Page 660 What to do if... nWarning lights Master warning light Brake system warning light P. 548 Slip indicator* P. 545 P. 547 Charging system warning Tire pressure warning light light P. 545 P. 548 Malfunction indicator Open door warning light lamp P.
Page 661 Memo...
Page 662 Memo...
Page 663: Gas Station Information
GAS STATION INFORMATION Auxiliary catch lever Fuel filler door P. 475 P. 103 Hood lock release lever Tire inflation pressure P. 475 P. 615 Fuel tank capacity 26.4 gal. (100.0 L, 22.0 lmp.gal.) P. 606 Fuel type Cold tire inflation P.

Toyota TUNDRA 2009 Manual

Quick Links

Related Manuals for Toyota TUNDRA 2009

Summary of Contents for Toyota TUNDRA 2009
