Electric oven
Dear Customer!
Congratulations on your purchase. See for yourself: our
products read reliability.
These ample instructions have been compiled in order to help
you learn how to handle the appliance. They will show you step
by step what your appliance is capable of, so please read them
carefully before you attempt to use your cooker for the first
time.
Contents
Safety precautions .......................................................... 3
Intended use
Push-pull Knobs
Control Lamps
Description of the appliance .......................................... 4
Prior first use .................................................................. 5
Oven................................................................................. 5
Operation
Safety precautions
• To avoid any possible hazard, the appliance may be
installed by qualified personnel only.
• Any repairs by unqualified persons may result in electric
shock or short circuit. In order to avoid possible injuries to
your body or to the appliance, do not attempt any repairs by
yourself. Such work should be carried out by qualified
service personnel.
• Warning! Never let small children in the vicinity of the
cooker; they are not yet aware of danger of burns. Older
children may use the appliance only under your surveillance.
• Danger of burns! Oven and cooking accessories may
become very hot during operation. To avoid burns use
kitchen clothes and gloves when handling hot parts or
utensils.
• Mains lead of adjacent appliances may be damaged by
hotplates or if stuck between the oven doors, and produce
short circuit, therefore keep them at safe distance from the
appliance.
• Never clean the oven with the high-pressure steam cleaning
device, as it may provoke short circuit.
• Oven door may become very hot during operation.
Therefore, some models are equipped with the third glass to
reduce the surface heat of the glass, as an extra protection
against burns.
Intended use
This appliance is intended for use in your household. Never
use the appliance for any other purpose!
These instructions describe in detail all the particulars and
possibilities of its use.
Safety warnings are listed on page 4.
The first thing to do is to check if your appliance has arrived
undamaged. In case you find any transport damages, please
report it immediately to your local dealer, or to the regional
warehouse which supplied the appliance. You will find their
phone numbers on the invoice or on the delivery note.
We hope your cooker will successfully serve its purpose for
many years.
Cleaning and maintenance ...........................................11
Troubleshooting guide ..................................................12
Replacement of parts ....................................................13
Instructions for installation and connection ...............13
Installation of electric oven ..........................................14
Electric connection ........................................................15
Technical information...................................................15
After sale service ...........................................................16
Rating plate
Push-pull Knobs
(certain models only)
In order to operate the knob, you first have to slightly press the
knob, until it jumps out and then select the settings for the
cooking zones, the temperature of the oven and the operating
mode.
When the cooking zone or the oven is on, the ring around the
corresponding knob is illuminated.
When finished cooking, turn the knob to starting position and
slightly push it back.
WARNING!
Push-pull knob can be pulled out and pushed back only when
in non-operating, i.e. starting position.
Control Lamps
Illuminated dials
(certain models only)
The dial above the active knob is illuminated when the oven is
switched on.
Red Light
The red light comes on when the oven heaters are operating
and goes off when the preset temperature is reached.
Cooling fan
(certain models only)
The appliance is equipped with a built-in cooling fan, cooling
the casing and the control panel of the appliance.
The cooling fan is put in operation by selecting any of the oven
operation modes.
Instructions for use, installation and connection
GB IE MT
3
Advertisement
Table of Contents
Related Manuals for Gorenje EVP444-442MEVP443-444M
Summary of Contents for Gorenje EVP444-442MEVP443-444M
-
Page 1: Table Of Contents
Electric oven GB IE MT Safety warnings are listed on page 4. Dear Customer! The first thing to do is to check if your appliance has arrived Congratulations on your purchase. See for yourself: our undamaged. In case you find any transport damages, please products read reliability. -
Page 2: Cooling Fan
The symbol on the product or on its packaging Extended performance of cooling fan indicates that this product may not be treated as (applies to some models only) household waste. Instead it shall be handed over Cooling fan works for some time after the oven is turned OFF and thus additionally cools the appliance. -
Page 3: Prior First Use
Prior first use since the operation of oven is possible only after such Oven adjustment had been made. Take all the accessories out of the oven and clean it with warm Tips for the use of oven water and your usual mild detergent. Never use aggressive cleaners as they might cause scratches! •... -
Page 4: Oven Guide Levels
Oven guide levels Lower heater and ventilator Baking pans and accessories (oven grid, grease receptacle, Both the lower heater and hot air ventilator are in operation. baking tray, etc.) may be inserted into the oven in 5 guiding This mode is most appropriate for baking pizza. It may also be levels. -
Page 5: Grease Filter
Pastry is too light below Grease filter Use dark baking pan next time, or place the pan one level (depending on the model). lower, or switch on the lower heater a while before the Inserted grease filter at the rear panel of the oven protects the completion. -
Page 6: Roasting
Pastry Baking Table Type of pastry Guide level (from Temp. Guide level (from Temp. Baking time down upwards) (°C) down upwards) (°C) (in min.) Sweet pastry Raisin cake 160-170 150-160 55-70 Ring cake 150-160 60-70 160-170 Tree cake (tart form) 160-170 150-160 45-60... -
Page 7: Grilling And Browning (Barbecue)
Roasting Table Type of meat Weight Guide level Temp. Roasting time Temp. Roasting (in grams) (from bottom up) (°C) (in min.) (°C) time (in min.) Beef Beef loin 1000 200 -220 180-190 100-120 Beef loin 1500 200-220 170-180 120-150 Roastbeef, rare 1000 180-200 30-40... -
Page 8: Preserving Of Fruit And Vegetables
Grill table Type of meat for grill Weight Guide level Temp. Temp. Grill time (in (in grams) (from bottom up) (°C) (°C) min.) Meat and sausages 2 beefsteaks, rare 14-16 2 beefsteaks, medium 16-20 2 beefsteaks, well done 20-23 2 pork scrag fillets 19-23 2 pork chops 20-23... -
Page 9: Cleaning And Maintenance
Cleaning and maintenance Never clean the appliance with pressurized hot steam cleaner! Some useful hints Before cleaning switch the cooker off and let it cool down • When roasting large pieces of fatty meat we recommend completely. that you wrap them in aluminium foil or put them in a suitable roasting bag to prevent the grease from splashing all over Front side of the casing the oven. -
Page 10: Troubleshooting Guide
Removing oven door with a single axe hinge (differ according to different models) Open the door completely and turn the removable locks backwards (see fig). Then close the door slowly and let the locks fit to the notches. At an angle of about 15° lift the door slightly up and pull the door from the hinge supports (fig. -
Page 11: Replacement Of Parts
Replacement of parts The oven light bulb casing is under tension. Danger of bulb. Screw the glass cover back in place. electric shock! In case of side light remove Before replacing the oven bulb switch off the cooker and cut it the glass cover by inserting from mains by removing the mains power fuse or disconnect the screw into the slot and... -
Page 12: Installation Of Electric Oven
Installation of electric oven • Panels and furniture lining of the kitchen cabinet receiving because you may damage the cabinet sides or the enamel of the appliance. the hob must be treated with temperature resistant adhesives (100°C), otherwise they might be discoloured or deformed because of inadequate temperature resistance. -
Page 13: Electric Connection
Electric connection Electric connection may be carried out by Connection qualified service personnel only! • Using the screwdriver open the connector cover at the rear Wrong connection may permanently of the appliance. Release two locks located at either side of damage parts of the appliance and render your warranty the connector bottom. -
Page 14: After Sale Service
After sale service Repairs If you find your cooker malfunctioning and requiring repair, contact our nearest service center and quote the code and the type or model of the appliance. Attached is the list of service centers with addresses and phone numbers.
