Summary of Contents for Gorenje GT8EC
- Page 1 INSTALLATION AND OPERATION INSTRUCTION BUILT-IN GAS HOBS GT7EC GT8EC For TG...
- Page 2 Preface Please read this manual carefully before you install or use the product. Any failure, accidents and losses caused by ignoring the following items and CAUTION mentioned in this installation and Operation Instruction are not covered by our warranty and liability. Please keep all attached documents and purchasing invoice well for future reference.
-
Page 3: Table Of Contents
Contents For the user SAFETY PRECAUTIONS ..........DESCRIPTION OF THE HOB ..........INSTRUCTIONS FOR USE ............4 The hob control knobs ...............4 For correct use the hob ..............5 CLEANING AND MAINTENANCE ......... 6 General cleaninghob ................6 Service and parts .................. 7 For the installation TECHNICAL DATA..............8 technician... -
Page 4: Safety Precautions
sAFetY PReCAUtIons • To avoid any possible hazard, the appliance must be installed by qualified personnel only. • During the operation of gas burners the room may be filled with extra heat and humidity, so it is necessary to assure adequate ventilation. Occasional opening of the window or door should provide enough exchange of air. -
Page 5: Description Of The Hob
DesCRIPtIon oF tHe HoB GT8EC GT7EC 1. Hob 2. Triple ring burner 3. Rapid burner 4. Control burner knob InstRUCtIons FoR Use The hob control knobs The symbols on the control knobs mean the following: No gas flow A...burner cap B...ignition... -
Page 6: For Correct Use The Hob
... To light a burner, proceed as follows: • Choose the control knob, push the knob of the burner fully down and turn it anticlockwise to the “maximum flow” setting symbol. • After lighting the flame, keep the knob pressed for about 3-5 seconds: this time is necessary to heat up the “thermocouple”... -
Page 7: Cleaning And Maintenance
CLeAnInG AnD MAIntenAnCe ! ... Before each operation, disconnect the appliance from the Before each operation, disconnect the appliance from the electrical mains and allow it to cool down. electrical mains and allow it to cool down. General cleaninghob • Wash enameled parts with lukewarm water and detergent: do not use abrasive products which might damage them. -
Page 8: Service And Parts
Service and parts • Before leaving the factory, this appliance was tested and adjusted by skilled staff to give the best operating results. Any subsequent necessary repairs or adjustments must be carried out with the greatest care and attention. • For this reason, we strongly advise you always contact the Dealer who sold you the appliance or our nearest Service Center, specifying the nature of the problem, the model of the equipment (Mod.), in the cover of this... -
Page 9: Technical Data
/h Large 2.90 2.20 0.760 Rapid 0.60 Burner Trip Flame 1.05 0.191 Burner 5.00 0.80 1.90 0.869 Main Burners Dimension voItage totaI type ModeI H/W/D 65/750/450 10.0 GT7EC DC 1.5 GT8EC 55/870/510 DC 1.5 12.9 Gas intake connection G1/2”... -
Page 10: Instructions For Installation
InstRUCtIons FoR InstALLAtIon ! ... ATTENTION! Accord ng to the Hong Kong Gas Sa ety ATTENTION! Accord ng to the Hong Kong Gas Sa ety ReguIat ons, any gas nstaIIat on works, ncIud ng ReguIat ons, any gas nstaIIat on works, ncIud ng appI ance and flex bIe hose nstaIIat ons shaII be appI ance and flex bIe hose nstaIIat ons shaII be undertaken by reg stered gas contractor. -
Page 11: Discharge Of Flue Gases
Discharge of flue gases • Gas cooking appliance must discharge their flue gases through hoods connected directly to flues or the outdoors. • If it is not possible to install the hood (fig. B) an electric fan must be installed on the outside wall or the window of the room, provided its possible for the ventilation opening to be increased in proportion to the delivery rate of the fan (fig. -
Page 12: Connection
Connection • Make the connection to the gas system using a rigid metal pipe and regulation unions, or with a stainless steel hose complying with the local standard. If metal hoses are used, take care that they do not come into contact with mobile parts and are not crushed. -
Page 13: Electrical Connection
eLeCtRICAL Conne ! ... The appliance is fitted to operate with a power supply The appliance is fitted to operate with a power supply voItage n the rat ng IabeI. The connect on must be voItage n the rat ng IabeI. The connect on must be made in accordance with the regulations and laws in made in accordance with the regulations and laws in force. -
Page 14: Building Into Fitted Kitchen Units
BUILDInG Into FItteD KItCHen UnIts • These hobs are designed for installation in fitted kitchen units up to 600mm deep with suitable characteristics. • Any cabinet side panels taller than the height of the hob itself must be at least 150mm away from the opening into which the hob is inserted. -
Page 15: Insertion And Fixing
Insertion and Fixing Before inserting the hob in the installation opening, place the special gasket around the bottom edge of the hob It is important to fix this gasket evenly without gaps or overlapping to prevent liquid from seeping underneath the hob. - Page 16 en/(05-12)
