Summary of Contents for Xomax XM-CDB617
-
Page 2: Table Of Contents
CONTENTS Precautions........................1 How to Handle Discs....................1 Precautions & Warnings....................1 Lithium Battery Cell Warnings..................1 Drivers and Connections.....................1 Other Warnings......................1 Installation........................2 Installation Procedures....................2 Important........................2 To Install the Car Radio....................2-3 Wiring Connections....................3 Removal of the Main Unit ....................3 Control Panel Button Locations..................4 General Operation......................5 Turn Unit On/Off......................5 Adjust Volume (VOL)....................5 Adjust Menu Options (SEL)..................5-6... -
Page 3: Precautions
PRECAUTIONS How to Handle Discs • Handle a disc by its edges. Do not touch the playing side • Before inserting a disc, wipe the disc outward from the disc center with a clean, soft, dry and lint-free cloth. Do not use solvents or thinners such a petrol/benzene or cleaners. -
Page 4: Installation
INSTALLATION Installation Procedures First complete the electrical connections and then check for correctness. Installation Opening 53 mm This unit can be installed in any dashboard Having an opening as shown the right figure. 182 mm Important: Remove the transport CD deck screws before use. To Install the Car Radio Be sure you test all connections first, and then follow these steps to install this unit. -
Page 5: Wiring Connections
INSTALLATION(CONT.) INSTALLATION DIAGRAM - Only use speakers with 4 ohms impedance. - Do not attach the control panel to the chassis before wiring is complete. - The maximum current of the auto antenna is 200mA. Wiring Connections WIRING DIAGRAM CAUTION +12V DC NEGATIVE GROUND... -
Page 6: Control Panel Button Locations
CONTROL PANEL BUTTON LOCATIONS Bluetooth (power)/SRC (source) button 2. SEL (select/menu) button and VOL (volume) knob 3. BND(band) button, AMS (automatic music search) button, button (pause/play), Preset station1 button 5. INT (intro) , Preset station 2 button 6. RPT (repeat) , Preset station 3 button 7. -
Page 7: General Operation
GENERAL OPERATION Turn Unit On/Off • Press the power ( ) /SRC button on the front panel to turn on the unit, and long press it again to turn off the unit. • Press the power ( ) button on the remote control to turn the unit on or off. Adjust Volume (VOL) Rotate the knob on the front panel or press the... -
Page 8: Set The Clock (Clk)
GENERAL OPERATION (CONT.) This function is used for maintaining a program being listened to during a trip if its frequency changes. - TA ON/OFF: Enables or disables the TA function (traffic information). When this function is enabled, the tuner will periodically scan received frequencies and play any traffic information message that may be broadcast. -
Page 9: Radio Operation
RADIO OPERATION Change Bands (BAND) Press the BAND button to switch between the FM1, FM2 and FM3 band. Each band stores up to six preset stations. Manual Tuning ( Press and hold the button on the front panel or on the remote control to enter manual tuning mode. -
Page 10: Disc/Usb/Micro Sd Card Operation
USB port or a Micro SD card into the Micro SD card slot. Playback will begin automatically. Label surface up Bluetooth XM-CDB617 Eject Disc/USB/SD • To eject a disc, press the button to stop playback. Press the... -
Page 11: Select The Track Or File For Playback In Mp3 Format
DISC / USB / CARD OPERATION (CONT.) Select the track or le for playback in MP3 format Press the button repeatedly to select one of the following 3 search modes: NUM SCH (Searching by track or file serial number) DIR SCH (Searching by folder serial number) FILE SCH (Searching by track or file name) Searching by track or le serial number: a) In playback of files with MP3 format, press the... -
Page 12: Bluetooth Operation
2. When the phone the car audio system,the XOMAX XM-CDB617 name will be displayed. 3. Choose the XOMAX XM-CDB617 from the device list to pair and connect with the car audio system. Upon confirming, the BT logo will stop flashing. -
Page 13: Remote Control
REMOTE CONTROL Remove Insulating Sheet The remote control comes with an insulating sheet attached to the underside of the remote control, as illustrated on the right. The remote control will not work until the insulating sheet is removed. Replace Lithium Battery Cell 1. -
Page 14: Specifications
SPECIFICATIONS General Chassis Dimensions...............178(W) x 160(D) x 50(H) mm Power Supply Requirement ..................DC 12V Current Consumption ....................10A MAXMaximum Power Output ................W x 4CH Radio Frequency Range...............87.5 - 108.0 MHz (50KHz/Step) Usable Sensitivity ....................30 dBu I.F. Frequency ....................10.7 MHz CD/USB/Card Usable Audio Formats ................CD/MP3/WMA Pre-amp Output ..................Front and Rear Frequency Response .................20 Hz - 20 KHz... -
Page 15: Tr O U B L E S H O O T I N
TROUBLESHOOTING...
