- Page 1 ® INSTALLATION AND USER GUIDE 3000LBY SINGLE LINE LOBBY PHONE TeleMatrix Copyright 2005 ©...
- Page 2 COMPLIANCE AND SAFETY As specified by FCC regulation, we are required to inform you of specific governmental and compliance regulatory requirements, safety notices, safety instructions and other informative information. TeleMa- trix, Inc. provides this information in a separate manual. We pack the separate Compliance and Safety Manual within each outer box or product box when shipped.
-
Page 3: Table Of Contents
CONTENTS Features ...........………..……………………………………........Controls ................……………………………………………….. Installation ..............……………………………………………..Operation ................……………………………………………..Care and Maintenance ..........……………………………………………..Service …………………………………………………..……………………………………….………… Warranty ...............…………………………………………….. -
Page 4: Features
FEATURES • One Line • Convenient Data Port • Handset Volume Control • HI/LOW Ringer Volume Control Switch • Desk or Wall Mountable • Fully Modular, Easy To Install... -
Page 5: Controls
CONTROLS Handset Hanger ………….…………………..… Temporarily holds the handset when the unit is wall mounted. Handset ..…………..…………..…... Hearing aid compatible, low profile styling. Ringer Controls ………………….……………. Adjusts the volume of the ringers to HI/LOW setting. Handset Jack ……………………………….… Modular receptacle where handset cord plugs into the base unit. Handset Volume Control ……………….…….. -
Page 6: Definition Of Controls
DEFINITION OF CONTROLS FRONT VIEW... -
Page 7: Installation
INSTALLATION Parts Check List The following parts are included in this package: 1. 15’ modular telephone line cord. 2. Modular coiled handset cord. 3. Base unit 4. Handset Caution • Never install telephone wiring during a lightning storm. • Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. •... - Page 8 INSTALLATION Figure 3 Connecting The Handset Cord A 10’ modular coil handset cord is provided. To install, simply plug one end of the handset cord into the modular jack on the handset. The remaining end of the handset cord plugs into the jack labeled “Handset”...
-
Page 9: Operation
OPERATION PLACING A CALL USING THE HANDSET HANDSET VOLUME CONTROL • Lift the handset. The handset volume control increases the volume of the handset. • Dial out by using the numeric dial pad or by pressing a speed dial location. When the handset is off hook, press the volume control key to increase the headset volume. -
Page 10: Care And Maintenance
CARE AND MAINTENANCE Keep the telephone dry. If it gets wet, wipe it dry immediately. Liquids might contain minerals that can corrode the electronic cir- cuits. Use and store the telephone only in normal temperature environ- ments. Temperature extremes can shorten the life of electronic devices, damage batteries, and distort or melt plastic parts. -
Page 11: Service
Fax: 719-638-8815 www.telematrixusa.com Many times a problem is either installation or user related. Please contact TeleMatrix PRIOR to sending a telephone to our service center for repair. In the unlikely event that a factory repair be necessary: 1. Include a brief description of the trouble that you are experiencing. -
Page 12: Warranty
STATEMENT OF LIMITED WARRANTY TeleMatrix, Inc. (TMX) warrants to its [original end customer] [purchaser] that Spectrum, Spectrum Plus and Marquis branded products manufactured by TMX are free from defects in materials and workmanship for five (5) years after the date of purchase, and Regency branded products manufactured by TMX are free from defects in materials and workmanship for three (3) years, other than the following products for which the warranty period shall be one (1) year: handset batteries, either NiCd or NiMH, used in TMX cordless products. - Page 14 252-0364 (3000LBY) Rev. May 2, 2005...
