Penpower WorldocScan Pro User Manual

Cordless scanner

Advertisement

Quick Links

WorldocScan Pro Introduction
WorldocScan Pro Scanner is a cordless scanner, allowing you to
scan anywhere. No computer connection is needed to scan. Turn it
on and scan.
Front
8 
Paper feed slot
(feed on left and face up)
Back
8 
Paper output
Side
8
mini USB Port for data transfer and charging
(charged only by USB cable)
USB host
(MS/MS Pro/MMC/xD/SD)
(flash disk)
Status Light
Power button
Memory card slot

Advertisement

loading
Need help?

Need help?

Do you have a question about the WorldocScan Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Penpower WorldocScan Pro

  • Page 1 WorldocScan Pro Introduction WorldocScan Pro Scanner is a cordless scanner, allowing you to scan anywhere. No computer connection is needed to scan. Turn it on and scan. Front 8  Status Light Paper feed slot Power button (feed on left and face up) Back 8 ...
  • Page 2 Tech Specs ● Optical Resolution: 300 x 300 dpi (default); 600 x 600 dpi ● Scan Modes: Color, 24 bits (R/G/B) ● Scanner size (D x W x H): 58 x 269.3 x 47.2 mm ● Scanner weight: 425.5g ● Page Size: up to Legal size (8.5”...
  • Page 3 Calibrate the scanner Scanner occasionally needs calibration to perform at its best. If the scans are showing lines or black dots, please calibrate your scanner. Please turn on the scanner and insert the calibration sheet (provided by Penpower) to start automatic calibration.
  • Page 4 Scan with Scanner Use your scanner to directly scan and store documents. There is no need to connect the scanner to a computer in order to scan. 1. Insert the memory card or connect the USB flash drive if necessary. Note: In addition to its internal memory, Scanner has built-in ports for USB f ash drives and memory cards to expand additional storage.
  • Page 5 Load Images After scanning, you may load the images to your computer, iPad or other Tablets. Load images to your computer 1. Turn on your computer. 2. Eject the memory card or the USB flash drive from the scanner and insert it into your computer. Note: You can also attach the scanner to your computer with the included USB cord.
  • Page 6 Load images to iPad via SD card reader 1. Plug a SD card into your scanner and scan your documents. 2. Connect the SD Card Reader to the iPad Dock Connector. 3. Unplug the SD card from your scanner and plug into SD card reader.
  • Page 7: Status Lights

    Status Lights Scanner has two light indicators: power light and status light. The power light indicates the battery status. The status light indicates the status of the scanner. Status Light Power light blinking slowly blinking fast on and not blinking no lights Note: The color of the status light indicates the resolution mode: 300dpi is white and 600dpi is blue.
  • Page 8 WorldocScan X WorldocScan X is a document management software bundled with WorldocScan Pro to help you manage scanned images. Install WorldocScan X 1. Place the installation CD in the CD/DVD-ROM drive and system will automatically run [Setup.exe]. 2. Please click on [Install WorldocScan X].
  • Page 9 Launch WorldocScan X Click the [WorldocScan X] desktop icon to launch the WorldocScan X. WorldocScan X Overview Current Category Categories Pane Switch View Mode Menu Toolbar Status Bar Files Pane Turn on the scanner, connect it to your PC and then click the button to save images on scanner into PC.
  • Page 10 WorldCard WorldCard is a contact management software bundled with WorldocScan Pro to recognize the scanned business card images and help you manage contacts. Install WorldCard 1. Place the installation CD in the CD/DVD-ROM drive and system will automatically run [Setup.exe].
  • Page 11 Launch WorldCard Click the [WorldCard] desktop icon to launch the WorldCard. WorldCard Interface E F G H G: Delete Category A: Toolbar H: Disk space used B: Category tab I: Alphabet Index C: Search tab J: Status D: Card Window K: Connection status E: Recycle bin F: Add Category...
