THIS CRIB CONFORMS TO APPLICABLE
REGULATIONS PROMULGATED BY THE
CONSUMER PRODUCT SAFETY COMMISION
NOTE: THE STYLE OF YOUR CRIB OR OF YOUR
MATTRESS SUPPORT MAY VARY FROM WHAT IS
PICTURED IN THE INSTRUCTION SHEET
ASSEMBLY INSTRUCTIONS
FOR
3
02 CRESCENDO CRIB
WARNING:
THE PROPER USE OF THIS CRIB IS
IMPORTANT FOR YOUR BABY'S SAFETY. TO KEEP
Y O U R
B A B Y
S E C U R E
AND TO AVOID POTENTIAL INJURY OR DEATH,
CAREFULLY READ AND FAMILIARIZE YOURSELF
W I T H A L L W A R N I N G S , C A U T I O N S A N D
INSTRUCTIONS IN THE INSTRUCTION BOOKLET.
KEEP THIS INSTRUCTION BOOKLET FOR FUTURE
.
USE
DO NOT THROW THIS INSTRUCTION BOOKLET
IMPORTANT:
PLEASE, READ ALL INSTRUCTIONS
BEFORE ASSEMBLING!
PLEASE, SAVE INSTRUCTIONS FOR
FUTURE USE
6323 53rd Drive, Maspeth NY 11378
Phone 718 478 5100, Fax 718 478 5117
www.rominakidsfurniture.com
YOUR
A N D
S A F E ,

Advertisement

loading
Need help?

Need help?

Do you have a question about the 302 and is the answer not in the manual?

Questions and answers

Summary of Contents for Romina 302

  • Page 1 ASSEMBLY INSTRUCTIONS THIS CRIB CONFORMS TO APPLICABLE REGULATIONS PROMULGATED BY THE CONSUMER PRODUCT SAFETY COMMISION YOUR 02 CRESCENDO CRIB WARNING: THE PROPER USE OF THIS CRIB IS IMPORTANT FOR YOUR BABY'S SAFETY. TO KEEP Y O U R B A B Y S E C U R E A N D S A F E ,...
  • Page 3 / bolt on the upper diagram which is drawn in actual size. Be sure to ROMINA FURNITURE or your local use the proper size and shape specified in the instructions.
  • Page 4 STEP 1 Attach one of the stabilizing bars (S) to left opposite view smaller side (L) of the crib using 1 Allen bolt (3) and 1 barrel nut (4). Align the tenonattached at the end of the stabilizing bar with the upper hole existing on the inner face of the left side of the crib.
  • Page 5 STEP 2 Repeat STEP 1 for the second stabilizing bar. this shows how your crib should look after completing STEP 2 FIGURE 2...
  • Page 6 STEP 3 Assemble the result of steps 1&2 with the right side panel (R) using the same tehnique described above. Do not tighten the bolts completely at this step, you will be asked to do so later. this shows how your crib should look after completing STEP 3 FIGURE 3...
  • Page 7 STEP 4 Assemble the mattress support using the 4 bigger round head bolts (5), the 4 "butterfly" type nuts (7) supplied and a Phillips screwdriver (not supplied). There are three positions for the mattress support (from the highest one for a newborn to the lowest one for a child that is 35"...
  • Page 8 WARNING: STEP 5 TO KEEP YOUR BABY Mount the mattress support on the SECURE AND SAFE, AND TO AVOID stabilizing bars as these resulted after STEP POTENTIAL INJURY OR DEATH, IT'S 3, using the 4 smaller round head bolts (6) VERY IMPORTANT TO TIGHTEN supplied and a Phillips screwdriver (not...
  • Page 9 STEP 6 Attach the part of your crib resulted after STEP 5 to the back panel (B), using 2 bigger Allen bolts (1), 4 smaller Allen bolts ( ) the Allen wrench supplied (8). Do not tighten the bolts completely at this step, you will be asked to do so later.
  • Page 10 STEP 7 Attach the part of your crib resulted after STEP 6 to the front panel (F), using 2 bigger Allen bolts (1), 4 smaller Allen bolts ( ) the Allen wrench supplied (8). Do not tighten the bolts completely at this step, you will be asked to do so later.
  • Page 11 STEP 8 WARNING! sing the Allen wrench (8) supplied, you must tighten TIGHTEN COMPLETELY! completely all the bolts (1, 3) remained untighten from all previous steps (see FIGURE 8). REMINDER You have a total of 16 Allen bolts, distributed as following: - 2 bolts (1) in the bottom part of front panel (F);...
  • Page 12 Once completed STEP 8, attach the storage pouch supplied to the mattress support spring using two plastic ties (also supplied). Store this instruction booklet in the storage pouch for future use. this shows how your crib should look like after completing assembly...
  • Page 13 ASSEMBLY INSTRUCTIONS DAY BED OPTION OF YOUR 02 CRESCENDO CRIB WARNING (FOR DAY BED OPTION ONLY): § ANY MATTRESS USED IN THIS CRIB MUST BE AT LEAST 27 1/4 INCHES BY 51 5/8 INCHES WITH A THICKNESS NOT EXCEEDING 6 INCHES. §...
  • Page 14 STARTING FROM CRIB STEP A Remove both back panel (B) and front panel (F) by unscrewing completely all the bolts (1) & (3) using the Allen wrench supplied (8) (see FIGURE A). Keep these bolts at your hand for the following steps. opposite view FIGURE A...
  • Page 15 STEP B Remove all the 4 bigger round head bolts (5) located on your mattress support, adjust this to it's lowest position then tighten WARNING! completely bolts (5) and "butterfly" type TIGHTEN COMPLETELY! nuts (7) in their new position using a Phillips screwdriver (not supplied).
  • Page 16 STEP C Take the front panel (F). Using the supplied Allen wrench (8), unscrew completely the 4 Allen bolts (x) (previously mounted in factory) located 2 by 2 on the lateral sides of the legs. Then, remove the middle panel resulted(see FIGURE C).
  • Page 17: Very Important

    STEP D Assemble the middle part of your crib WARNING! resulted after completing STEP B with the TIGHTEN COMPLETELY! back panel (B) and the front legs resulted after completing STEP C using 4 bigger Allen bolts (1), 8 smaller Allen bolts ( ) and the Allen wrench supplied (8).
  • Page 18 STARTING FROM SCRATCH § FOLLOW STEPS 1 TO 5 FROM THE CRIB ASSEMBLY INSTRUCTIONS. WHEN YOU REACH STEP 4, PLEASE ADJUST YOUR MATTRESS SUPPORT TO ITS LOWEST POSITION (YOU MUST ALSO SEE STEP B FOR MORE DETAILS). § FOLLOW STEPS C & D FROM THE DAY BED OPTION ASSEMBLY INSTRUCTIONS.
  • Page 19 FULL SIZE BED OPTION OF YOUR 02 CRESCENDO CRIB NOTE: YOUR 302 CRESCENDO CRIB CAN CONVERT INTO A FULL SIZE BED WITH THE PURCHASE OF ROMINA FURNITURE ITEM CODE CKC 302 ( ONVERSION IT FOR RIBS, code 302 . ASSEMBLY INSTRUCTIONS FOR FULL SIZE BED OPTION CAN BE FOUND INSIDE OF CKC PACKAGE.
  • Page 20 Regular cleaning with mild soap on a soft cloth, followed by a clean damp cloth, then a dry cloth, will preserve the original luster and beauty of this fine finish of your Romina Furniture product. Thank you for beeing one of our distinguished clients.
