THIS CRIB CONFORMS TO APPLICABLE
REGULATIONS PROMULGATED BY THE
CONSUMER PRODUCT SAFETY COMMISSION
NOTE: THE STYLE OF
Y O U R
C R I B ,
MATTRESS SUPPORT
OR TODDLER RAIL
M AY VA R Y F R O M
WHAT IS PICTURED IN
THE INSTRUCTION
S
H
E
E
T
ASSEMBLY INSTRUCTIONS
FOR YOUR
2501 CONVERTIBLE CRIB
* READ ALL INSTRUCTIONS BEFORE ASSEMBLING
CRIB. KEEP INSTRUCTIONS FOR FUTURE USE.
* NEVER USE PLASTIC SHIPPING BAGS OR OTHER
PLASTIC FILM AS MATTRESS COVERS BECAUSE
T H E Y
C A N
C A U S E
* INFANTS CAN SUFFOCATE IN GAPS BETWEEN CRIB
SIDES AND A MATTRESS THAT IS TOO SMALL.
WARNING:
THE PROPER USE OF THIS CRIB IS IMPORTANT FOR
YOUR BABY'S SAFETY. TO KEEP YOUR BABY SECURE AND SAFE,
AND TO AVOID POTENTIAL INJURY OR DEATH, CAREFULLY READ
AND FAMILIARIZE YOURSELF WITH ALL WARNINGS, CAUTIONS AND
INSTRUCTIONS IN THE INSTRUCTION BOOKLET. KEEP THIS
INSTRUCTION BOOKLET FOR FUTURE USE.
IMPORTANT:
INSTRUCTIONS BEFORE
ASSEMBLING! PLEASE, SAVE
INSTRUCTIONS FOR FUTURE USE
Furniture
20 Corporation Row, Edison, NJ 08817
Phone (718) 478 5100, Fax (718) 478 5117
www.rominafurniture.com
S U F F O C A T I O N .
PLEASE, READ ALL
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Romina 2501
Summary of Contents for Romina 2501
- Page 1 THIS CRIB CONFORMS TO APPLICABLE REGULATIONS PROMULGATED BY THE CONSUMER PRODUCT SAFETY COMMISSION FOR YOUR 2501 CONVERTIBLE CRIB * READ ALL INSTRUCTIONS BEFORE ASSEMBLING CRIB. KEEP INSTRUCTIONS FOR FUTURE USE. * NEVER USE PLASTIC SHIPPING BAGS OR OTHER PLASTIC FILM AS MATTRESS COVERS BECAUSE...
- Page 4 Please, refer to this number in the event diagram which is drawn in actual size. Be sure to use the proper that you need to call ROMINA size and shape specified in the instructions. Be sure to FURNITURE or your local distributor.
- Page 5 STEP 1 (Two adults are required to complete this step) Attach the left and right panels (LP) & (RP) to the headboard (HB), using 4 Allen bolts (12), 4 bigger washers (7) and the Allen wrench supplied (1). 12+7 Do not completely tighten the bolts at this step, you will be asked to do this later.
- Page 6 STEP 2 (Two adults are required to complete this step) WARNING! COMPLETELY TIGHTEN! Attach the footboard (FB) to the left and right panels (LP) & (RP) as they resulted after completing STEP 1 using 4 Allen bolts (3), 4 bigger washers (7) and the Allen wrench supplied (1).
- Page 7 STEP 3 Assemble the mattress support using 4 bigger round head bolts (4), 4 "butterfly" type nuts (6), 4 smaller lock washers (8) and a Phillips screwdriver (not supplied). The lock washer must be attached 4+8+6 to the bolt after the bolt passed through the frame and the metallic bracket of the mattress support and before attaching the nut.
- Page 8 STEP 4 (Two adults are required to complete WARNING! this step) COMPLETELY TIGHTEN! Turn your crib with the headboard on the floor, taking care not to scratch its finish. Attach the mattress support (MS) to the inner wooden blocks using 4 smaller rounded head bolts (5), 4 smaller washers (8) and a Phillips screwdriver (not supplied).
- Page 9 ASSEMBLY INSTRUCTIONS FOR DAYBED OPTION OF YOUR 2501 CONVERTIBLE CRIB WARNING (FOR DAY BED OPTION ONLY): ANY MATTRESS USED IN THIS CRIB MUST BE AT LEAST 27 1/4 INCHES BY 51 5/8 INCHES WITH A THICKNESS NOT EXCEEDING 6 INCHES.
- Page 10 STEP A (Two adults are required to complete this step) Remove the mattress support of your crib (see STEP 4 for details). Remove the footboard of your crib (see STEP 2 for details). Take the footboard of your crib and carefully hold it in vertical position, with its feet on the floor.
- Page 11 STEP B (Two adults are required to complete this step) Using a Phillips screwdriver (not supplied) or just the hand, insert two screw-in dowels (9) into the metallic inserts holes found into each leg’s top (please see the assembly tip for dowel correct positioning). Insert two cam fittings (10) into the bigger holes found into the wooden blocks (WB), taking care that the little arrow of the cam is pointing downwards, to the drilled face of the wooden block.
- Page 12 STEP C (Two adults are required to complete this step) Take the footboard of your crib (FB) as resulted after completing STEP B and attach it to the rest of the crib (see STEP 2 for details). Do not completely tighten the bolts at this step, you will be asked to do this later. STEP D Take the mattress support (MS) and adjust it to its lowest position (see STEP 3 for details) then attach it to your crib (see STEP 4 for details).
- Page 13 NOTE: YOU CAN ATTACH A TODDLER RAIL TO YOUR CRIB WITH THE PURCHASE OF ROMINA FURNITURE ITEM TR 2501 (TODDLER RAIL 2501). ASSEMBLY INSTRUCTIONS FOR TODDLER RAIL CAN BE FOUND INSIDE OF TR 2501 PACKAGE. PLEASE, CONTACT ROMINA FURNITURE OR YOUR LOCAL DISTRIBUTOR FOR MORE INFORMATION.
- Page 14 FULL SIZE BED OPTION OF YOUR 2501 CONVERTIBLE CRIB (THE CONVERSION KIT IS SOLD SEPARATELY) NOTE: YOUR 2501 CONVERTIBLE CRIB CAN CONVERT INTO A FULL SIZE BED WITH THE PURCHASE OF ROMINA FURNITURE ITEM CODE CKC 2501 (CONVERSION KIT FOR CRIBS, code 2501).
- Page 16 Regular cleaning with mild soap on a soft cloth, followed by a clean damp cloth, then a dry cloth, will preserve the original luster and beauty of the fine finish of your Romina Furniture product. Thank you for being one of our distinguished clients.
