5.10.1 Selecting, changing and saving parameters

ENTER (Enter the menu)
•
Switch off machine at the main switch.
•
Press and hold the "left parameter selection" button and switch the machine on again at the
same time.
NAVIGATION (Navigate the menu)
•
Select parameters by turning the "welding parameter setting" rotary dial.
•
Set or change the parameters by turning the "arc length correction/select welding program"
rotary dial.
EXIT (Exit the menu)
•
Press the "right parameter selection" button (switch machine off and on again).
ENTER
0
A
Display
099-005403-EW501
18.08.2016
+
l
B
A
B
Setting/selection
Ramp time for wire inching
0 = -------- normal inching (10s ramp time)
1 = -------- fast inching (3s ramp time) (Ex works)
Block program "0"
0 = -------- P0 enabled (Ex works)
1 = -------- P0 blocked
Display mode for Up/Down welding torch with one-digit 7-segment display (two
keys)
0 = -------- normal display (ex works) program number/welding power (0–9)
1 = -------- display toggles between program number/welding type
Program limitation
Programs 1 to max. 15
Ex works: 15
Special cycle in the special latched and non-latched operating modes
0 = -------- normal (previous) non-latched/latched (Ex works)
1 = -------- WF3 cycle for non-latched/latched
Design and function
Special parameters (advanced settings)
0
l
A
Figure 5-73
EXIT
NAVIGATION
A
B
