Windows/OS X with USB

B
USB MGMT
1. Download FortiExplorer from http://forti.net/fexp.
Microsoft Windows Install
2. Connect the USB cable and launch
FortiExplorer if it does not appear
automatically.
FortiExplorer Setup Wizard
1. Follow prompts or click "Register" to register your device with FortiCare.
2. Click "Setup Wizard".
3. Login using username "admin" and
4. Follow Setup Wizard steps.
5. Click "Configure" to complete the setup of your device.
6 6
Mac OS X Install
2. Double-Click the .dmg file and drag the
FortiExplorer icon to the Applications
folder.
3. Connect the USB cable.
4. Click the FortiExplorer icon to launch the
application.
no password.
Terminal Emulation with Console
C
Cable
To Connect to the CLI (Console Models Only)
1. Connect the FortiGate unit console port
standard console cable (not provided).
2. Start a terminal emulation program on the management computer. Select the
port and use the following settings:
Baud Rate: 9600
8
Data bits:
Parity: None
Stop bits: 1
Flow Control: None
3. Press Enter on your keyboard to connect to the
4. Login using username "admin" and no
configuring your FortiGate unit.
Get started by typing "?" for a list of available commands.
Begin typing a command and type "?"
For example "config ?" will show the lowest level of configuration options.
For a detailed guide visit http://forti.net/cli.
to the management computer using a
COM
CLI.
password. You can now proceed with
for a list of available ways to complete.
7 7
