Summary of Contents for Fortinet FortiWiFi 50G 5G
- Page 1 QuickStart Guide FortiWiFi 50G 5G FWF-50G-5G...
-
Page 2: Package Contents
FWF-50G-5G https://192.168.1.99 SSID: fortinet Username: admin Password: fortinet Password: leave blank FortiWiFi Fortinet Documents Library For a detailed administration guide, up-to-date hardware manuals and 1x FortiWiFi Device 1x QuickStart Guide reference materials, visit https://docs.fortinet.com/ Support Resources Register for FortiGuard updates, cloud management, firmware upgrades, technical support and warranty coverage at https://support.fortinet.com... - Page 3 Setup FortiExplorer Go Enable Bluetooth on your iOS device. Speed (default): 9600 Data bits: USB Console Cable Stop bits: (available for purchase) Parity: None Flow Control: None Console Port Management Computer Follow the on-screen instructions FortiGate Cloud Configure the management computer with dynamic IP https://192.168.1.99 Visit https://forticloud.com to add your device using the CloudKey Sticker.
-
Page 4: Antenna Installation
Attach the provided antennas to the SMA connections: 5G, GPS, and WiFi. SIM1 is primary, SIM2 is secondary; SIM type is 4FF - Nano SIM. Refer to the Admin guide for wireless configuration at https://docs.fortinet.com 2 SIM 1 2 SIM 1... - Page 5 Off: SVC not connected Flashing Off: Device is off Signed Firmware BIOS Security Level Controlled by Signed Firmware Switch, see Admin Guide at https://docs.fortinet.com Green: Security Level 2 (default) Green: HA enabled (normal) Green: 5G connected Amber: Security Level 1...
- Page 6 Rear FWF-50G-5G WIFI Signed Firmware Antenna Connector (8x SMA) Ports (5x RJ45) WAN, A – FortiLink, 3, 2, 1 Power Input 12V DC, 100-240V AC 50/60Hz adapter USB 3.0 Server Port CONSOLE (RJ45) CLI management Signed Firmware Switch...
-
Page 7: Cautions And Warnings
Cautions and Warnings Industry Canada Equipment Standard for Digital Equipment (ICES) – Canada This Class B digital apparatus complies with Canadian ICES-003. Environmental specifications Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Ambient operating temperature: 0°C to 40°C Innovation, Science and Economic Development (ISED) –... -
Page 8: European Conformity (Ce) - Eu
EU or countries that have implemented the EU Directives and/or spectrum regulation. Any Fortinet products not obtained directly from Fortinet or Fortinet’s authorized partners may not comply with EU Directives and Fortinet makes no assurances for such products. - Page 9 This product is in compliance with Statutory Instrument 1206 Radio Equipment Regulations 2017 The full Declaration of Conformity for this product is available in the link below: https://site.fortinet.com/ProductRegulatory/UK The device is restricted to indoor use only when operating in the 5150 to 5350 MHz frequency range in the following countries:...
- Page 11 Copyright © 2024 Fortinet, Inc. All rights reserved. Fortinet®, FortiGate®, FortiCare® and FortiGuard®, and certain other marks are registered trademarks of Fortinet, Inc., and other Fortinet names herein may also be registered and/or common law trademarks of Fortinet. All other product or company names may be trademarks of their respective owners.
