FrameSaver
9623 Router
Installation Instructions
Document Number 9623-A2-GN11-00
March 2003
Contents
Product Documentation Online ..................................................................... 2
Upgrading a Unit to the Advanced SLM Feature Set .................................... 2
Package Checklist ......................................................................................... 2
Preparation ................................................................................................... 3
Cables You May Need to Order .................................................................... 3
Safety Instructions ........................................................................................ 4
Installing the Power Supply and Cord ........................................................... 4
Connecting to an Asynchronous Terminal or PC .......................................... 5
Verifying that Self-Test Passed ..................................................................... 5
Menu Hierarchy ............................................................................................. 6
A Quick Guide to Configuration .................................................................... 9
About the Installation Procedures ................................................................. 10
Full Installation and Setup ............................................................................ 10
Minimal Installation for Service Providers ..................................................... 12
Setting Up Local Management at the Central Site ........................................ 13
Automatic Configuration ................................................................................ 13
Connecting to the Network ........................................................................... 14
Configuring SNMP Trap Managers and Traps .............................................. 15
Connecting to the Ethernet ........................................................................... 16
Verifying That Data is Being Received .......................................................... 17
Checking PVC Connections .......................................................................... 17
Provisioning the Router Interface .................................................................. 17
Important Safety Instructions ....................................................................... 18
Warranty, Sales, Service, and Training Information ...................................... 22
Document Feedback ..................................................................................... 22
Trademarks ................................................................................................... 22
Patent Notification ......................................................................................... 22
1
Advertisement
Table of Contents
Related Manuals for Paradyne framesaver 9623
Summary of Contents for Paradyne framesaver 9623
-
Page 1: Table Of Contents
® FrameSaver 9623 Router Installation Instructions Document Number 9623-A2-GN11-00 March 2003 Contents Product Documentation Online ..............2 Upgrading a Unit to the Advanced SLM Feature Set ........2 Package Checklist ..................2 Preparation ....................3 Cables You May Need to Order ..............3 Safety Instructions .................. -
Page 2: Product Documentation Online
FrameSaver SLV Operations Guide (9000-A2-GB33) FrameSaver SLV Router Command Line Interface (9000-A2-GB34) To order a paper copy of a Paradyne document, or to speak with a sales representative, please call 1-727-530-2000. Upgrading a Unit to the Advanced SLM Feature Set Full Service Level Management (SLM) capability can be activated in units that have the basic diagnostic feature set at any time. -
Page 3: Preparation
Preparation Make sure you have: ❑ A dedicated, grounded power outlet that is protected by a circuit breaker within 6 feet of the FrameSaver unit ❑ A clean, well-lit, and ventilated site that is free from environmental extremes ❑ One-to-two feet of clearance for cable connections ❑... -
Page 4: Safety Instructions
Safety Instructions Important Safety Instructions Please refer to the on page 18. Installing the Power Supply and Cord Procedure 1. Insert the power cord’s plug into the POWER jack. Grounded Power Outlet ETHERNET POWER 9623 FrameSaver FrameSaver FLEX ® System System Network Port... -
Page 5: Connecting To An Asynchronous Terminal Or Pc
Connecting to an Asynchronous Terminal or PC A VT100-compatible asynchronous terminal or a PC providing VT100 terminal emulation must be used to set up access to and management of the unit. Procedure 1. Configure the terminal or PC so it is compatible with the FrameSaver unit: —... -
Page 6: Menu Hierarchy
Menu Hierarchy The Menu Hierarchy shows the organization of the FrameSaver unit’s screens. Support for all features may not be available in the firmware release you are running. Status System and Test Self-Test Results Status Last Reset Health and Status Test Status LMI Reported DLCI... -
Page 7: Configuration System
Test Network PVC PVC Loopback Tests Send Pattern Monitor Pattern Network Physical Local CSU Loopback Tests Local DSU LoopbackSend Pattern Monitor Pattern IP Ping Lamp Test Abort All Tests Configuration System Frame Relay and LMI Class of Service Definitions Service Level Verification General Network Physical... - Page 8 Control System Device Name Information System Name, Location, Contact Date Time Administer Logins Login ID Password Access Level Change Operating Back-to-Back Mode Mode Standard Mode Select Software Current Release Release Alternate Release Switch & Reset LMI Packet Capture Interface Capture Utility Packet Capture Start/Stop Status Packets in Buffer...
-
Page 9: A Quick Guide To Configuration
A Quick Guide to Configuration The FrameSaver unit should operate using the default (factory-set) configuration options, with exception to the changes specified in these installation instructions. Refer to the following table for help in navigating through the menus. Press the . . . To . -
Page 10: About The Installation Procedures
About the Installation Procedures There are two methods for installing and setting up the FrameSaver unit. One person can install and set up the unit. If this is the case, see Full Installation and Setup . An installer can physically install and set up access to the unit, and the network Minimal operation center (NOC) can complete the setup. - Page 11 2. Verify that the Service Type is Frame Relay. 3. Enter the Node IP Address and Subnet Mask. 4. Set TS Access to DLCI, then select a DLCI on the network interface that will be used for the troubleshooting access link. 5.
-
Page 12: Minimal Installation For Service Providers
Minimal Installation for Service Providers Verify with your service provider that frame relay service is turned on at the site. Follow Step 1 through Step 10 Full Installation and Setup on page 10. Physical installation of the unit is complete; the NOC can now remotely access the unit for additional configuration. -
Page 13: Setting Up Local Management At The Central Site
Setting Up Local Management at the Central Site Procedure 1. Create a DLCI for the data port. Configuration Data Ports DLCI Records 2. Save the configuration. 3. Create a Management PVC using the data port DLCI just created. Configuration Management and Communication Management PVC Minimally, enter the following options: —... -
Page 14: Connecting To The Network
Connecting to the Network Now that the FrameSaver unit is set up, the unit can be connected to the network. Procedure 1. Insert the 8-pin connector of the RJ48S network cable into the network interface. 2. Insert the other end of the cable into the RJ48S modular jack. RJ48S Jack ETHERNET... -
Page 15: Configuring Snmp Trap Managers And Traps
Configuring SNMP Trap Managers and Traps Once the FrameSaver unit is connected to the network, SNMP trap managers and SNMP traps can be configured. Procedure To enter SNMP managers and configure traps: 1. Select SNMP Traps. Main Menu Configuration Management and Communication SNMP Traps 2. -
Page 16: Connecting To The Ethernet
Connecting to the Ethernet Procedure 1. Insert one 8-pin connector of the Ethernet cable into the Ethernet port. 2. Insert the other end of the cable into the Ethernet interface of the LAN where the NMS resides. ETHERNET POWER 00-16687 3. -
Page 17: Verifying That Data Is Being Received
Verifying That Data is Being Received Procedure 1. Return to the Main Menu. 2. Select Performance Statistics, and select an interface’s frame relay statistics. Main Menu Status Performance Statistics Frame Relay Net1-FR1 3. Verify that the Frames Received and Characters Received counts under the Frame Relay Link statistics are incrementing, and there are no errors under the Frame Relay LMI statistics. -
Page 18: Important Safety Instructions
Important Safety Instructions 1. Read and follow all warning notices and instructions marked on the product or included in the manual. 2. Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these slots and openings must not be blocked or covered. -
Page 19: Emi Notices
The authority to operate this equipment is conditioned by the requirements that no modifications will be made to the equipment unless the changes or modifications are expressly approved by Paradyne. CANADA – EMI NOTICE: This Class A digital apparatus meets all requirements of the Canadian interference-causing equipment regulations. -
Page 20: Government Requirements
Government Requirements Certain governments require that instructions pertaining to connection to the telephone network be included in the user documentation. Specific instructions are listed in the following sections. United States Notice to Users of the Telephone Network This equipment complies with Part 68 of the FCC rules. On the bottom of the housing is a label that contains, among other information, the FCC registration number for this equipment. - Page 21 Canada Notice to Users of the Canadian Telephone Network The Industry Canada label identifies certified equipment. This certification means that the equipment meets telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The Department does not guarantee the equipment will operate to the user’s satisfaction.
-
Page 22: Warranty, Sales, Service, And Training Information
Document Feedback We welcome your comments and suggestions about this document. Please mail them to Technical Publications, Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773, or send e-mail to userdoc@paradyne.com. Include the number and title of this document in your correspondence. Please include your name and phone number if you are willing to provide additional clarification. - Page 24 *9623-A2-GN10-20* *9623-A2-GN11-00*...
