Lens Holder Assembly - ETC Source Four jr Assembly Manual

Lens holder assembly

Fixed field angle lens assembly
CE Source Four jr / jr Zoom Assembly Guide
Fixed Field Angle Lens
1. Snap on the bushings (14).
2. Position the lens by centering the paint dot between the three
2. Center one Tinnerman clip (15) on each tab, as shown in Figure
3. Firmly press each clip down and roll it away from the center of
4. Check lens and make sure the clips hold it securely.
5. Position safety screen as shown below, and secure with clips.
Figure 8
1, 2, 3
15
tabs, as shown below in figure 8.
9, and press clip until it is fully seated. If clips are in uneven
positions, lens will be tilted or loose.
the lens to ensure contact on lens surface.
16
6, 7, 8
14
17
18
19
Important:
Lens paint dot this side
9
