ETC Source Four jr Assembly Manual page 8

Lens holder assembly
Reference
number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
8
Part Description
number required
7062A3005 Lens holder, 26°
7062A3017 Lens holder, 36°
7062A3018 Lens holder, 50°
7062A3019 Lens holder, Zoom, forward
7062A3020 Lens holder, Zoom, rear
7062A4001 Lens, 26°, "black dot"
7062A4002 Lens, 36°, "white dot"
7062A4003 Lens, 50°, "yellow dot"
7062A4008 Lens, Zoom, forward
7062A4009 Lens, Zoom, rear, black
7062A3027 Lens cover, Zoom, front, 25°– 50°
7062A3026 Lens cover, Zoom, rear, 25 °– 50°
(mounted on rear side of lens holder)
HW751 Rivet, lens assembly
7060A4010 Bushing, gate
rear lens
front lens
HW8209 Tinnerman clip
7062A1013 CE safety screen, Fixed field angle lens
HW4117 Nylon washer, flat, #10
HW779 Spring compression
HW8201 Lens knob, 10-32 x .50 LG male stud, black
Zoom
Fixed field angle
7062A3029 Plate, secondary aperature
HW196 Nut 4-40 Keps
7062A2001 Lens holder assembly, 26° (black)
7062A2003 Lens holder assembly, 36° (white)
7062A2004 Lens holder assembly, 50° (yellow)
7062A2005 Lens holder assembly, Zoom, forward
7062A2006 Lens holder assembly, Zoom, rear
Quantity
1
1
1
1
1
1
1
1
1
1
1
4
2
4
3
1
2
2
2
1
1
4
1
1
1
1
1
Electronic Theatre Controls, Inc.
