24
1
13
3
16
15
4
Lamp socket assembly
Reference
number
1
2
3
4
5
6
7
8
9-11
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
4
17
23
14 5
18
27
28
Part
Description
number
7060A3055
Housing, socket, casting, painted
7060A3057
Socket, light baffle casting, painted
7060A4007
Knob, X-Y, lamp set
7060A4008-02
Knob, Z, lamp set w/female insert
7060A4011
Bushing, cup
7060A3011
Hub, index, casting
7060A3012
Spring, lamp retainer
HW748
Spring, compression
M718
Complete TP22 450 degree-C CLCM assembly
W330-03
TP22 CLCM assembly, mica
W330-04
TP22 CLCM 16-gauge, 1/4" semi-striped, Ni-gold contacts,
600V, 450˚C with 44" tails
W330-02
TP22 CLCM assembly, ceramic
HW534
Nut, hex, 1/4-20, black zinc
7060A3025
Screw, 1/4-20 knurled head
HW746
Retaining ring, flat, Southco
HW5123
Nut, hex, 9/16-18, black zinc
HW747
Washer, wave
7060A3056
Clamp, strain relief, painted
HW3103
Screw, 8-32 x 5/8 PhFHMS, black zinc
HW5122
Bolt, 1/4-20 x 1.75, full thread, black zinc
HW2125
Screw, self tap, 6-32 x 1/4, black zinc
7060B7014
Euro S4 ground wire
7060B7013
Euro S4 cable assembly
HW749
Spring, ground
HW349
Washer, ext. #8
7060A3085
Lamp retainer wire
HW8203
Lamp retainer Tinnerman clip
HW385
Screw, 8-32 x 3/8 PhPHMS
7060B7015
Safety wire assembly
I320
Kapton tape, 3/4"
10
29
7
8
6
22
20
2
21
11
9
12
Quantity
required
1
1
1
1
1
1
1
1
1
(1)
(2)
(1)
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
2
1
1
Electronic Theatre Controls, Inc.
19
26
25
