    Dear Customer TECHNICAL DATA Thank you for purchasing this Trend product, we hope you enjoy many years of creative and Voltage: UK & Eire 230V productive use. UK & Eire only 110V Europe 230V Please remember to return your guarantee card...

  • Page 3: Safety

    SAFETY n Use the attachment with the power n Connect dust extraction equipment. tools and accessories specified in If devices are provided for the this manual only. Do not force the connection of dust extraction and Observe the safety regulations in the tool or attachment to do a job for collection facilities, ensure these instruction manual of the Power Tool to...

  • Page 4: Safety

    All fastening screws and nuts packaging, in cutter instructions or the design requirements and should be tightened using the in the Trend Routing Catalogue. understands the levels of safety to appropiate spanner or key in be achieved. accordance with the manufacturers n Always use router cutters in a instructions.

  • Page 5: Electrical Safety

    Machines marked for 230 volt can also be operated from a 220 volt supply. The T9 is double insulated in accordance with EN 50144; therefore no Using an Extension Cable earth wire is required.

  • Page 6: Manufacturers Declaration

    NOISE/VIBRATION The noise level when working can exceed 85 dB(A). Wear ear protection! Weighted root mean square acceleration value according to EN 50144: < 2.5 (1.9) m/s (hand arm method) Managing Director Stephen Phillips Trend Machinery & Cutting Tools Ltd.

  • Page 7: Description Of Parts

    DESCRIPTION OF PARTS` Plunge locking lever Plunge depth adjustment knob Variable speed control dial Graduated ring Depth stop adjustment knob Thumb knob - depth stop Depth stop 3 way turret stop Collet nut Spindle lock Handle with on/off switch Dust extractor spout (internal dia.

  • Page 8: Assembly & Adjustment

    ASSEMBLY & ADJUSTMENT Fitting and Removing the Fitting Dust 35mm Dust Extractor Spout Extractor Spout n Insert the extractor spout in the routing base. The extractor spout is suitable for dust extractors with a hose diameter of 35mm. 26mm A separate adaptor is supplied for use with hose Ø...

  • Page 9: Depth Of Cut

    Adjusting the Depth of Cut n Place the machine on the workpiece. n Pre-set the 3-way turret stop (1) as required. n Undo the thumb knob (2) for securing the depth stop (3). n Lift up the plunge locking lever (4) for fixing the depth.

  • Page 10: Fitting & Removing Cutters

    How to Fit and Remove a Router Cutter Fitting Cutters n Insert at least of the shank length of the cutter (1) into the collet. n Press the spindle lock (2) forward until the router spindle is locked (you may need to turn the spindle slightly to engage it).

  • Page 11: Speed Control

    Setting the Electronic Speed Control Dial The speed is infinitely variable from 8,000 to 22,000 rpm using the electronic speed control dial (1) for uniform cutting results in all types of wood, plastics and in aluminium. n Turn the electronic speed control dial to the required level.

  • Page 12: Fixing Points

    15mm Trend Routing Catalogue. Stationary use 75mm When the T9 is used in a stationary position with a no volt release switch (ref. NVRS/230V or NVRS/230V/EUR) fitted, a trigger lock (ref. T9/LOCK) is available which will lock the trigger in the ‘on’ position.

  • Page 13: Operation

    OPERATION Cutting Direction Sequence of plunging The direction of routing must always be opposite to the cutter’s direction of rotation. Otherwise there is a risk of Step One kick-back. Plunge down and lock the motor carriage, by depressing the plunge Feed direction locking lever.

  • Page 14: Side-Fence Routing

    Side-fence Routing The side-fence is used to guide the router when moulding, edge profiling or rebating the edge of the workpiece or when routing grooves and slots in the centre of the workpiece, parallel to the edge. The edge of the workpiece must be straight and true.

  • Page 15: Template Guide Bush Fitment

    Fitting the Template Guide Bush and Inner Plate The T9 has a unique built-in line up system for the template guide bush. This system ensures that the guide bush is exactly concentric to the router cutter to ensure accurate work.

  • Page 16: Template Guide Bush Routing

    Routing with a Template The guide bush is used in conjunction with a template when the routing operation is repetitive or the workpiece is complex in shape. The template is fixed to the upper surface of the workpiece. A cutter is chosen with a diameter which will pass through the centre of the bush leaving enough clearance.

  • Page 17: Beam Trammel Routing

    Beam Trammel Routing using Accessory Ref. BEAM/009 Cutting Arcs with the Router n Place the machine on the workpiece. n Set the cutting depth using the depth stop dial (2). n Fasten the fence rod (1) in the routing base (3) with the thumb knob (4).

  • Page 18: Bearing Guided Cutters

    Bearing Guided Cutters Bearing Guided Cutters Edge profiling and shaping cutters are available with a bearing fitted to the end. This enables shaped or straight workpieces to be routed without the need for a guiding device such as a side-fence or batten. The edge must be free from imperfections as these will be reflected in the finish of the mould.

  • Page 19: Freehand Routing

    Freehand Routing with the Router The T9 can also be used for signwriting or creative freehand work without any form of guide. With practice, numbers or name plate designs can be routed freehand. Draw the design or motif on the workpiece and then rout the design, taking shallow passes.

  • Page 20: Maintenance & Care

    (8) is correctly positioned. n Refit the plunge depth knob and rod assembly Changing Brushes (2) carefully. n Always use original T9 spare parts. Ensure machine is isolated Lubrication from power supply. n The bearings of the machine need no The carbon brushes will need replacing when lubrication, as they are sealed.

  • Page 21: Spare Parts List

    T9/EURO) WP-T9E/004 Speed Control Circuit Board 110V (T9EL) WP-T9EL/004 Cable Guard WP-T9/005 2 Core Cable With Plug 230V UK (T9) WP-T9/006 2 Core Cable With Plug 110V UK (T9L) WP-T9L/006 2 Core Cable With Plug 230V Euro (T9/EURO) WP-T9EURO/006 Carbon Brush 230V (1 pair)
  • Page 22 T9 - SPARE PARTS LIST v4.0 08/2003 Qty. Desc. Ref. Cable Conduit Lower WP-T9/033 Cable Conduit Upper WP-T9/034 Switch 230V (T9E & T9/EURO) WP-T9E/035 Switch 110V (T9EL) WP-T9EL/035 Handle Inner Right WP-T9/036 Handle Outer Right WP-T9/037 Handle Inner Left WP-T9/038...
  • Page 23 T9 - SPARE PARTS LIST v4.0 08/2003 Qty. Desc. Ref. Conduit Cap WP-T9/070 Cable Block WP-T9/071 Block Pad WP-T9/072 Foam Packing WP-T9/073 Handle Anti-slip WP-T9/074 Inner Plate WP-T9/075 Machine Screw Pan M5 x 12mm Slot WP-SCW/42 Machine Screw Csk M5 x 8mm Slot...

  • Page 24: Spare Parts Diagram

    T9 - SPARE PARTS DIAGRAM v4.0 08/2003 -23-...
  • Page 25 NOTES: -24-...
  • Page 26 Web: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ www.trendmachinery.co.uk RECYCLABLE © Copyright Trend 2003. No part of this publication may be reproduced, stored or transmitted in any form without prior permission. Our policy of continuous improvement means that specifications may change without notice. Trend Machinery and Cutting Tools...
