MF253
Let's go
Getting started with your device.
ZTE CORPORATION
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057
Confidential and Proprietary Information of ZTE CORPORATION 1

Advertisement

Table of Contents
loading

Related Manuals for Zte MF253

Summary of Contents for Zte MF253

  • Page 1 MF253 Let’s go Getting started with your device. ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057 Confidential and Proprietary Information of ZTE CORPORATION 1...
  • Page 2 ZTE Corporation. The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice. Version No. : R1.0...

  • Page 3: Connecting Your Device

    Connecting Your Device Follow the number to connect your device. If you select a different operation mode, the connection of the LAN port is different. Please refer to the chapter “Accessing the Internet”. If you want to use the mobile network to connect to the Internet or use your home phone, you need insert your (U)SIM card first.

  • Page 4: Configuring Your Pc

    Indicator State Description Blue Blinking The phone is ringing. Blue ON The phone is in calling. Blue ON Signal strength is very good or good. Blue Blinking Signal strength is weak. There is no signal. The device is turned on but not registered to the mobile network.
  • Page 5 Right-click the icon for Connection, and then select Properties. Select Internet Protocol (TCP/IP), and then click Properties. 4. Select the two items indicated in the following figures, and then click OK to finish the configuration.

  • Page 7: Accessing The Internet

    Accessing the Internet Before accessing the Internet, please make sure that the following operations are finished.  Your device is connected via a network cable or Wi-Fi.  Your PC is configured. To access the Internet: Log in the 4G CPE Page. Launch the Internet browser and enter http://192.168.0.1 in the address bar.
  • Page 8  For Bridge You need to connect the WAN to the LAN port via Ethernet cable and set the clients to obtain the IP address automatically. Your clients can obtain the IP address from the WAN DHCP host and connect to the Internet directly. NOTE: If you want to change the operation mode, you need to set the client a fixed IP address between 192.168.0.100 and 192.168.0.200, and then log in the 4G CPE page to change it.
  • Page 9 NOTE：Your service provider gives you the static address information.  DHCP mode Please select DHCP and then click Apply. NOTE：Your service provider does not give you any parameters.  For Wireless Broadband If you want to use your PC to connect to the Internet, please connect your PC to the LAN port via Ethernet cable.

  • Page 10: Voice Function

    Begin to enjoy your Internet service. Voice Function Making a Call You can make a call through (U)SIM card. To make a call: 1. Pick up the handset. 2. Key in the telephone number. 3. You can either press # key on the telephone to send the call, or wait 4～8 seconds for the call to be connected automatically.

  • Page 11: Wps Function

    WPS Function Your device supports WPS function. You can use this function to connect the client to your device. Power on your device, and enable the Wi-Fi function on your device. Enable the WPS function. Please check the WPS Setting on the 4G CPE page. Press the WPS button on your device to start Wi-Fi Protected Setup authentication process.
  • Page 12 NOTE: Please set the client to obtain an IP address automatically, and the client will get an IP address like “192.168.0.101”. Select the SSID of your device, and then click Connect. NOTE: Please check the label on your device to get the default SSID. Input the password and then click Connect.

  • Page 13: Troubleshooting

    Troubleshooting Voice Related Problems Symptoms Possible Problems/ Solutions  No Dial Tone Please wait for 1~2 minutes after the router is turned  If SIG LED light is blinking, you have no good RF reception. Change the location of the router. There is a prompt/ phone alert/ announcement as soon as I Make sure your (U)SIM card is inserted correctly and lift the phone off the hook.
  • Page 14 Others Symptoms Possible Problems/ Solutions  The 3G/4G signal indicator is always blinking or does not This indicates poor reception. Try moving the router light. to another location near the window.  For the Wi-Fi connection password, please check the label on the device.

  • Page 15: Warning And Notice

    Do not use your router in dangerous environments such as oil terminals or chemical factories where there are explosive gases or explosive products being processed.  Please use original accessories or accessories that are authorized by ZTE. Unauthorized accessories may affect the router performance, damage the router or cause danger to you. ...

  • Page 16: Limitation Of Liability

    ZTE had been advised, knew or should have known of the possibility of such damages, including, but not limited to lost profits, interruption of business, cost of capital, cost of substitute facilities or product, or any downtime cost.
