  • Page 1 USER MANUAL...

  • Page 2: Table Of Contents

    UMMARY PREFACE ................................. 5 PRECAUTIONS ..............................5 DESCRIPTION............................... 5 TECHNICAL SPECIFICATIONS ........................7 STRUCTURE ................................8 LCD DISPLAY ................................ 9 OPERATING INSTRUCTIONS ........................10 Charge ................................10 Battery installation ............................10 TFT display installation ........................... 10 Inserting and removing the memory card ....................11 FRONT SELECTORS AND SETTINGS MENU ...................
  • Page 3 Key tone (alarm buzzer) ..........................20 Status indicator ..............................20 Icon display (subtitles on) ..........................20 Display standby ..............................20 TV output ................................21 Language ................................21 Date/time setting ............................. 21 Format ................................21 Recover factory setting ..........................21 STARTING STEPS ............................... 22 USING THE VIDEO CAMERA ........................
  • Page 4 Precautions for the camera case........................34 Precautions for the 3M dual-side foam tape ..................... 34 INCLUDED IN THE PACK ..........................34 WARRANTY AND LEGAL NOTES ......................36...

  • Page 5: Preface

    PREFACE Thank you for purchasing an EVO 4K series high definition digital camera(HD), with the following features: • ultra small and compact overall dimensions • user-friendly interfaces • easy to use • hands-free shooting to easily shoot real scenes anywhere at any time •...
  • Page 6 • One-way USB 2.0 high speed data transmission from the cam to PC. • USB cable for battery charging. • All accessories are easy to use to facilitate shooting in any place and at any time. Supplemented by its accessories, this product is the result of multiple patented technologies and can be used for recording anything, anytime, anywhere.

  • Page 7: Technical Specifications

    TECHNICAL SPECIFICATIONS EVO 4K camera has the following specifications: • Supplied with a special purpose HD lens that supports 4K, 2.7K,1080P, 960P, and 720P HD video recording. • Takes 16M pictures in 4608×3456 resolution. • Wi-Fi function and other App functions. •...

  • Page 8: Structure

    STRUCTURE 1. Wi-Fi key 8. Power Switch 2. Wi-Fi status led 9. Battery lock release 3. Exposure meter key 10. Lens 4. Recording indicator 11. Cooling vent 5. Charge indicator 12. Recording indicators 6. G-Sensor 13. Threaded interface 7. Video recording key 14.

  • Page 9: Lcd Display

    LCD DISPLAY The symbol that appears on the LCD display is highly intuitive. Video recording mode Photo shooting mode 1080P-25 Video resolution Photo resolution 00:00:01 Recording timer 100-0088 Number of recorded files 2H30 Remaining recording time 1888 Remaining shots View angle Wi-Fi Battery level...

  • Page 10: Operating Instructions

    OPERATING INSTRUCTIONS HARGE Turn on the video camera and check battery status; if low, charge it. Either a computer USB port of power adapter (not included) can be used to charge it. When EVO 4K is charged in off status, the red status led will flash slowly. When finished charging, the red led will remain on.

  • Page 11: Inserting And Removing The Memory Card

    NSERTING AND REMOVING THE MEMORY CARD The EVO 4K video camera supports TF memory cards with capacity up to 64 GB. Any type of Micro SD card can be used but we recommend high speed cards to optimise performance. • Installation. 1.

  • Page 12: Front Selectors And Settings Menu

    FRONT SELECTORS AND SETTINGS MENU Some selectors are located on the front of the video camera. XPOSURE MODE SELECTOR According to need and lighting conditions, the video camera exposure meter can be set to SPOT mode. This mode is used to adjust the amount of light according to a well-defined central point.

  • Page 13: Operations Without Tft Screen

    OPERATIONS WITHOUT TFT SCREEN When the camera is on, hold down the "Video Recording" key for about 3 s to open the mode selection function; the full-screen function icons can be viewed as thumbnails, keys and icons at this time are described as follows: 1) Open menu items or confirm 2) Go back to previous option/Exit 3) Go to next option...

  • Page 14: Touch Tft Symbols

    Displayed in small letters at the bottom left, it 2H:17 Residual capacity indicates the memory available space for videos. Displayed in small letters at the bottom left, it 5307 Residual capacity indicates the memory available space for pictures A series of symbols are also displayed on the TFT screen at the same time; some similar to those already seen, others more specific.
  • Page 15 Once the required option is selected, two arrows appear on the right of the screen to let you explore all menu options. Once the various menus are opened, touch the symbol, the same one you touched to open the menu, at the top left to go back to the previous menu.

  • Page 16: Video Parameters Setting

    VIDEO PARAMETERS SETTING The EVO 4K must be in video mode to set video settings; an icon appears at the top left, if this is not the case, touch the video shutter key on the front. Symbol to select on the screen SING MODE SETTING Icon It allows to select the using mode of EVO 4K video camera.

  • Page 17: Video Resolution Setting

    IDEO RESOLUTION SETTING Icon It allows to select the desired resolution for the video recording. The choices for the video resolution are the following: Resolutions PAL system NTSC system 4K Cinema (17:9) 4096 x 2160 12 fps (17:9) 4096 x 2160 12 fps 4K (16:9) 3840 x 2160 12.5 fps 15 fps...

  • Page 18: 180° Rotation

    180° ROTATION Icon This function rotates the display and camera menu 180° The bit rate choices available are: • On, Off. This function is disabled in 4K, 2.7K, 1080P 48f/50f/60f and 720P 100f/120f modes. ISPLAY DATE TIME IN VIDEOS Icon This function records automatically the date and time during the video recording and displays them in a video in the bottom right corner of the screen.

  • Page 19: Camera Setting Parameters

    CAMERA SETTING PARAMETERS The EVO 4K must be in video mode to set video settings; an icon appears at the top left, if this is not the case, touch the shutter key on the top. Symbol to select on the screen CQUISITION MODE Icon Lets you set photo shooting mode.

  • Page 20: System Parameters Setting

    SYSTEM PARAMETERS SETTING The cam can be in either video or photo mode to set system settings. Symbol to select on the screen EY TONE ALARM BUZZER Icon Set this function to enable the tick tone. The choices available are: Off, 50%, 100%. TATUS INDICATOR Icon It allows you to turn off the frontal status led.

  • Page 21: Tv Output

    OUTPUT Icon It sets the output format for a TV connection. The purpose of this setting is to ensure that video recording frame speed complies with the TV reproduction format. The choices available are: • Ntsc, Pal. WARNING: format choice in many types of recordings also influences the number of frames per second used (see video resolution settings).

  • Page 22: Starting Steps

    STARTING STEPS Before using your EVO 4K: • Make sure that the battery is full. If the level is low, connect the video camera to a computer using the supplied USB cable to charge the battery. The mini red led slowly flashes when charging.

  • Page 23: Recording A Video In Time Lapse Mode

    restores to the preview state. In cyclic recording mode, the system automatically saves a file every 15 minutes. (The cyclic recording function and the pre-video function cannot be simultaneously enabled). ECORDING A VIDEO IN TIME LAPSE MODE In the preview state press the Record key, on the front of the camera, to start video recording without audio.

  • Page 24: Playing A Video Or Photo File

    To view a file, proceed as follows: 1. Key will appear 2. You can find three icons on the right side of the screen. 3. Press the key in sequence to enable view mode: Video only, photo only, video and photo. LAYING A VIDEO OR PHOTO FILE Display all thumbnails, touch the desired file to select and play it.

  • Page 25: Deleting, Protecting And Automatically Playing A File

    ELETING PROTECTING AND AUTOMATICALLY PLAYING A FILE In playback mode, you can delete, protect and automatically play a file. 1 Key will appear 2 Select a video or photo to be deleted 3 Select the icon at the top right and select the bin symbol 4.

  • Page 26: Output Interfaces

    OUTPUT INTERFACES EVO 4K photo camera has 1 audio video output interface: • Hdmi and one data files output: • Usb DMI VIDEO OUT You can connect the photo camera to a video input, through the Hdmi output, by using a specific cable (not supplied).

  • Page 27: Usb Output

    OUTPUT The USB connection allows to : • Give power supply to the EVO 4K video camera with a USB cable. • Connect the EVO 4K video camera to a computer in order to read the data in the memory and Micro SD card. The icon of USB connection is displayed on the LCD screen and the green indicator blinks slowly.

  • Page 28: Wi-Fi Connection

    WI-FI CONNECTION Thanks to the built-in Wi-Fi module, EVO 4K can be connected to Apple or Android Smartphones and Tablets and remotely controlled. Just download the free EVO 4K App to connect the device in Wi-Fi. ONNECTING THE PHONE AND VIDEO CAMERA •...

  • Page 29: Video Recording

    Video recording To start recording, press the central green key. Icon meanings are highly self- explanatory, starting from the top left in clockwise order: 1) Wi-Fi on 2) Battery level 3) Exit screen 4) Settings 5) Video mode on 6) Recording 7) Switch to view mode 8) Set video settings The mobile device must be used within max.
  • Page 30 Click on the gear at the bottom right to open the cam settings menu. Most parameters can be set and some operations run from this menu for correct cam operations. 4K function cannot be set via APP. This function can only be set using camera settings. Photo functions are only available when in photo mode just as video functions are only available in video mode.

  • Page 31: File Preview Mode (Playback)

    File preview mode (Playback) The image is immediately displayed when From the main menu, press to open the preview selected. file preview menu. Alternatively, the same menu can be opened from the home screen by selecting My Album. If the selector is positioned on cam (left) the user can either view a photo or video or download it to smartphone or tablet.

  • Page 32: Change Wi-Fi Connection Name And Password

    Move the selector to the right to smartphone opens the photo and video gallery device to open the downloaded photo and video gallery. Touching the icon depicting the photo album For best recorded photo and video viewing, we recommend using the player specific to the tablet or smartphone used.

  • Page 33: Technical Specifications

    TECHNICAL SPECIFICATIONS Wide angle 160° Shutter opening f/2.7 Digital zoom Pixel 16 million Video recording format Audio recording format Photo format JPG (JPEG) Wi-Fi coverage about 100 metres (Max.) Memory device Up to 64 GB on external Micro SD card Battery capacity 1500mAh With USB cable, about 3.5 hours, with charger, about 2.5...

  • Page 34: Precautions

    PRECAUTIONS RECAUTIONS FOR THE CAMERA CASE The waterproof case is a precision component. Please use the following precautions: • Do not randomly dismount and mount the O-ring of the case, keys and lens cover, otherwise the waterproof performance deteriorates. • Do not put the case in a place where it is exposed to corrosive acid or alkaline gases and keep it away from chemical or corrosive substances.
  • Page 35 The articles included in the pack are the following: 1 EVO 4K 1 TFT display 2 built-in batteries 1 waterproof case 1 interchangeable 1 USB cable backs 1 humidity proof 1 90 degree bracket lense 1 flat accessory 1 curve accessory 1 supporting bracket 2 lanyards...

  • Page 36: Warranty And Legal Notes

    WARRANTY AND LEGAL NOTES EVO 4K is equipped with a rechargeable lithium ion polymer battery. To reduce the risk of fire, please do not tamper with it and avoid falls, contact with water and fire To avoid personal injury, electric shock, fire or damage to various parts of the product, please follow the following instructions: Do not immerse the product in water without its waterproof case.
  • Page 37 • Two years, if fiscal documents indicate that it was sold to a private citizen. • This warranty applies in the event of a defect in conformity of product features. • Product support and warranty: visit www.nilox.com to learn more. Warranty restrictions: this warranty does not apply in the following cases: •...
  • Page 38 Brief Declaration of Conformity This device has been tested and found to comply with European Parliament and European Commission Directive 2011/65/EC and 1999/5/EC concerning radio equipment and peripheral devices for telecommunications and their mutual recognition. The declaration of conformity is available in our offices and on-line ftp:\\ftp.hellatron.it (username: declaration@hellatron pwd: hellatron).
