Acon ON-CALL PRO User Manual page 3

Feature
Measurement Range
Result Calibration
Sample
Minimum Sample Size
Test Time
On/Off Source
Battery Life
Glucose Units of Measure
Memory
Automatic Shutoff
Meter Size
Display Size
Weight
Operating Temperature
Operating Relative Humidity
Hematocrit Range
Data Port
Contact Technical Support at 1-800-838-9502
Specifications
24 hours a day, 7 days a week.
Specification
20 - 600mg/dL
Plasma-equivalent, calibrated
by using YSI (Model 2300 STAT
PLUS) Glucose Analyzer reference
instrument, which is traceable to
NIST reference standard.
Fresh capillary whole blood
0.4 μL
4 seconds
One (1) CR 2032 3.0 V coin
cell battery
1,000 tests for glucose testing
(not considering data transfer)
The meter is preset to mg/dL
when sold in the United States.
Up to 300 records with time
and date
2 minutes after last action
85.0 mm × 49.0 mm × 16.4 mm
35.0 mm × 32.0 mm
50.0 g (with battery installed)
41 - 113 ºF (5 - 45 ºC)
10 - 90% (non-condensing)
30 - 55%
9600 baud, 8 data bits, 1 stop bit,
no parity
iii
