Built-In Hob
HII 63500 T

Advertisement

Table of Contents
loading

Related Manuals for Beko HII 63500 T

Summary of Contents for Beko HII 63500 T

  • Page 1 Built-In Hob HII 63500 T...
  • Page 2 Please read this manual first. Dear Customer, We would like you to obtain best performance with your product that has been manufactured in modern facilities and passed through strict quality control procedures. Therefore, we advise you to read through this User Manual carefully before using your product and keep it for future reference.

  • Page 3: Table Of Contents

    Table of Contents General information Preparation Overview ..........4 Tips for saving energy ......13 Technical specifications ....... 4 Initial use ..........13 First cleaning of the appliance ..13 Important safety instructions 6 How to use the hob General safety ........6 Intended use ........

  • Page 4: General Information Overview

    General information Overview Induction cooking plate Vitroceramic surface Assembly clamp Base cover Technical specifications Voltage / frequency 220-240 V~ 50 Hz Total power consumption max. 7200 W Fuse min. 16 A x 3 / 32 A Cable type / section H05RR-F 5 x 1,5 mm Cable length...
  • Page 5 IMPORTANT IMPORTANT Technical specifications may be Values stated on the product labels changed without prior notice to or in the documentation improve the quality of the product. accompanying it are obtained in laboratory conditions in IMPORTANT accordance with relevant Figures in this manual are standards.

  • Page 6: Important Safety Instructions

    Important safety instructions This section contains safety • Do not operate the product if it is instructions that will help you avoid defective or has any visible risk of injury and damage. All damage. warranties will become void if you do •...

  • Page 7: Intended Use

    • Vapour pressure that build up due Safety for children to the moisture on the hob surface • Electrical and/or gas products are or at the bottom of the pot can dangerous to children. Keep cause the pot to move. Therefore, children away from the product make sure that the oven surface when it is operating and do not...

  • Page 8: Installation

    Installation Product must be installed by a Before installation qualified person in accordance with the regulations in force. The The hob is designed for installation in a manufacturer shall not be held commercial worktop. A safety distance responsible for damages arising from must be left between the appliance procedures carried out by and the kitchen walls and furniture.

  • Page 9: Installation And Connection

    min. installation in accordance with the local regulations. Installation and connection DANGER • The product must be installed in The product must be connected to the mains supply only by an accordance with all local gas and authorised and qualified person. electrical regulations.
  • Page 10 • Connection must comply with national regulations. • The mains supply data must correspond to the data specified on the type label of the product. Type label is at the rear housing of the product. • Power cable of your product must comply with the values in "Technical specifications"...
  • Page 11 If the board is below: min. 55 mm min. IMPORTANT min. 55 mm When installing the hob onto a cabinet, a shelf must be installed in During installation of your induction order to separate the cabinet from hob, place the product parallel to the the hob as illustrated in the above installation surface.

  • Page 12: Disposal

    materials. Dispose of them properly and sort in accordance with recycled waste instructions. Do not dispose of them with normal domestic waste. Future Transportation • Keep the product's original carton Installation clamp and transport the product in it. Counter Follow the instructions on the »...

  • Page 13: Preparation

    Preparation Bottom of the vessels or pots must Tips for saving energy not be smaller than the hotplate. • Keep the cooking zones and The following information will help you bottom of the pots clean. Dirt will to use your appliance in an ecological decrease the heat conduction way, and to save energy: between the cooking zone and...

  • Page 14: How To Use The Hob

    How to use the hob Clean any melted such materials General information about on the surface immediately. cooking Such vessels should not be used to keep foods either. DANGER • Use flat bottomed saucepans or vessels only. Never fill the pan with oil more than one third of it.
  • Page 15 Spills may damage magnetic aluminium bottom should not the glass ceramic be used. surface and cause Saucepan recognition-focusing fire. system Do not use vessels In induction cooking, only the area with concave or covered by the vessel on the relevant convex bottoms.

  • Page 16: Using The Hobs

    Selecting cooking zone suitable to the vessel Large cooking zone Normal cooking zone Small cooking zone Large cooking zone Normal cooking zone Small cooking zone • Automatically fits to the • Automatically fits • Used for slow saucepan. to the saucepan. cookings (sauces, creams) •...
  • Page 17 Specifications Adjustment area (for temperature level and time setting) Light indicating that the relevant key is functioning On / Off key Keylock key Temperature Indicator (temperature setting 0 ... 19) Timer Activation / Deactivation Cooking zone light Cooking Zone Selection key Ouick Heating key / Booster Keep Warm Function symbol (*) Timer symbol...
  • Page 18 "0" appears on the cooking zone display and the light of the relevant IMPORTANT cooking zone illuminates. When any key (" " key) is NOTICE pressed for a long time, the If no operation is performed product automatically turns off within 20 seconds, the hob will for safety reasons.
  • Page 19 High Power (Booster) Function Turning off Booster function prematurely: For rapid heating, you can use booster function. However, this function is not Touch " " to turn off booster any recommended for cooking a long time. time you want. Booster function may not be available Quick heating in all cooking zones.
  • Page 20 the set temperature level and only Activating the cleaning lock the selected temperature value is displayed. Table: Quick Heating Operation Times Temperature level Operation time limit - second 1. When the hob is in On mode, press and hold " " key until a single signal sound is heard.
  • Page 21 IMPORTANT IMPORTANT If any key is pressed when the You can activate the keylock in Child Lock is active, the light of operation mode only. When keylock is activated, only the " " the " " key flashes. key will be functional. When you touch any other key, the light of the Deactivating the Child Lock "...
  • Page 22 "00" appears on the timer display and You can turn the timer off in two different ways: " " symbol starts flashing on the cooking zone display. 1-Turning off the timer by dropping 5. Adjust the desired time period by its value down to "00": touching the adjustment area or by 1.
  • Page 23 2. Touch " " key to activate the 2. If the timer is deactivated, select keep warm function for the relevant the cooking zone for which the cooking zone. keep warm function is activated. Set the desired temperature by IMPORTANT touching the adjustment area or by The cooking zone will go on sliding your finger across it in order...
  • Page 24 2. When the temperature value is "0", IMPORTANT touch " " key until you hear a Economy mode can only be single warning sound. activated for active cooking zones. The selected cooking zone will be set to the temperature and time in the 1.
  • Page 25 Operation time limit depends on the • Selected level may drop. However, selected temperature level. Maximum this condition cannot be seen on operation time is applied at this the indicator. temperature level. Overflow safety system The cooking zone may be restarted by Your hob is equipped with overflow the user after it is turned off safety system.
  • Page 26 Error codes / warning messages Cause of error Indicator Display and error sources Induction Cooking "Ex**" hardware error. zone symbol Table-2: display flashes Cause of error Indicator Display x**: “1,2,..,9” Two or more "E" symbol Cooking IMPORTANT keys are zone flashes For further information about error pressed or...

  • Page 27: Maintenance And Care General Information

    Maintenance and care wipe those parts clean, paying General information attention to sweep in one direction. Service life of the product will extend NOTICE and the possibility of problems will The surface might get damaged by decrease if the product is cleaned at some detergents or cleaning materials.
  • Page 28 Slight color fading may occur on IMPORTANT coatings or other surfaces in time. This Sugar-based foods such as thick will not affect operation of the product. cream and syrup must be cleaned Color fading and stains on the glass promptly without waiting the ceramic surface is a normal condition, surface to cool down.

  • Page 29: Troubleshooting

    Troubleshooting Product does not operate. The mains fuse is defective or has tripped. Check fuses in the fuse box. If necessary, replace or reset them. If the display does not light up when you Disconnect the appliance at the circuit switch the hob on again.
  • Page 30 Envelope IV IMPORTANT Consult the Authorised Service Agent or the dealer where you have purchased the product if you can not remedy the trouble although you have implemented the instructions in this section. Never attempt to repair a defective product yourself.
