This manual must be given to the rider of
this wheelchair.
User:
Before using this wheelchair read this entire manual and save
for future reference.
Quickie
®
Pulse
6BC, 6SC, 6CC, 5BC, 5CC, 6MPC
Distribuidor: Este manual debe ser entregado al pasajero de esta silla de
ruedas.
Pasajero:
Antes de usar esta silla de ruedas, lea este manual en su
totalidad y guárdelo para futura referencia.
Cada una de las sillas se envía con un manual de instrucciones en inglés. El manual en español
o francés está disponible en formato PDF en nuestra página en Internet:
www.SunriseMedical.com. Ingrese a la página del producto específico para descargar el manu-
al, o comuníquese con el proveedor autorizado de Sunrise Medical.
Quickie
®
Pulse
6BC, 6SC, 6CC, 5BC, 5CC, 6MPC
Fournisseur: Ce manuel doit être remis à l'utilisateur / utilisatrice de ce
fauteuil roulant.
Utilisateur / Utilisatrice:
Chaque fauteuil est livré avec un manuel d'instructions en anglais. Les versions en espagnol et
en francais sont à ançais est à votre disposition en format PDF sur le site:
www.SunriseMedical.com. Veuillez vous rendre à la page de votre produit pour télécharger
le manuel dans la langue souhaitée, ou contactez un fournisseur agréé Sunrise Medical.
SECTION
Avant d'utiliser ce fauteuil roulant, lisez entière-
ment ce manuel et conservez le pour le consul-
ter ultérieurement.
O w n e r ' s M a n u a l
M a n u a l d e I n s t r u c c i o n e s
M o d e d ' e m p l o i
EN GLISH
PULSE
Advertisement
Table of Contents
Related Manuals for Sunrise Medical Quickie Pulse 6BC
Summary of Contents for Sunrise Medical Quickie Pulse 6BC
- Page 1 à ançais est à votre disposition en format PDF sur le site: www.SunriseMedical.com. Veuillez vous rendre à la page de votre produit pour télécharger le manuel dans la langue souhaitée, ou contactez un fournisseur agréé Sunrise Medical.
-
Page 2: I.introduction
Quickie wheelchair. Failure to do so may result in damage and/or injury. Sunrise Medical (US) LLC Customer Service Department 2842 Business Park Ave DEALER/TECHNICIAN WARNING... -
Page 3: Table Of Contents
Q UI C KIE PU LS E II. TABLE OF CONTENTS I.INTRODUCTION ..................2 J. Manual Recline Operation ............18 III. YOUR CHAIR AND ITS PARTS ..........4 K. Swing-in/Swing-out Footrests..........18 IV. NOTICE– READ BEFORE USE...........5 L. Elevating Legrest...............18 V. EMI (ELECTROMAGNETIC INTERFERENCE).......5 M.Angle Adjustable Centermount Footrest......18 A. -
Page 4: Your Chair And Its Parts
Q UI C KIE PU LS E III. YOUR CHAIR AND ITS PARTS III. YOUR CHAIR AND ITS PARTS 1. Flip-back, height adjustable armrest 2. VR2 controller joystick (RNET option) 3. Captain’s seat 4. Front Caster 7” 5. Rear stabilizing caster 6” 6. -
Page 5: Notice- Read Before Use
Q UI C KIE PU LS E IV. NOTICE– READ BEFORE USE A. CHOOSE THE RIGHT CHAIR & SAFETY D. WARNINGS OPTIONS The word “WARNING” refers to a hazard or unsafe practice that may cause severe injury or death to you or to other persons. The Sunrise provides a choice of many power wheelchair styles, sizes “Warnings”... -
Page 6: D.distance From The Source
Contact: is of special concern. (See Section C.1) A person using one of Sunrise Medical, Customer Service Department at (800) 333-4000. these devices can bring high levels of EM energy very close to your chair without you knowing it. -
Page 7: General Warnings
Q UI C KIE PU LS E VI. GENERAL WARNINGS B. WEIGHT LIMIT WARNING WARNING Heed all warnings in this section. If you fail to do so, a fall, tip-over 1. The user plus items carried should never exceed the total or loss of control may occur and cause severe injury to you or weight capacity identified on your chair. -
Page 8: G.when Seated In A Parked Wheelchair
Q UI C KIE PU LS E VI. GENERAL WARNINGS G. WHEN SEATED IN A PARKED J. STREET USE WHEELCHAIR WARNING 1. This product is not intended for street use. Avoid streets WARNING whenever possible. 1. Always turn off all power to your chair when you are 2. -
Page 9: Transfers
Q UI C KIE PU LS E VI. GENERAL WARNINGS M. TRANSFERS O. DRESSING OR CHANGING CLOTHES WARNING WARNING It is dangerous to transfer on your own. It requires good balance Be aware that your weight will shift if you dress or change clothes and agility. -
Page 10: Reduce The Risk Of A Fall, Tip-Over Or Loss Of Control
Q UI C KIE PU LS E VI. GENERAL WARNINGS S. REDUCE THE RISK OF A FALL, TIP-OVER OR 4. Avoid moving forward if a wheel is “hung up” on the lip of the ramp. Backup, reposition the caster for a more direct LOSS OF CONTROL approach. -
Page 11: Warnings: Components And Options
Q UI C KIE PU LS E VII. WARNINGS: COMPONENTS AND OPTIONS F. MOTOR LOCKS WARNING WARNING Note: If you use parts or make changes not authorized by Sunrise 1. Do not engage or disengage motor locks unless power to the it may create a safety hazard and will void the Warranty. -
Page 12: Push Handles
Q UI C KIE PU LS E VII. WARNINGS: COMPONENTS AND OPTIONS 5. NEVER use positioning belts P. POWER SEATING (SC,MPC) a. As a patient restraint. A restraint requires a doctor’s WARNING order. b. On a rider who is comatose or agitated. 1. -
Page 13: Power Recline
WARNING tie-down systems for transportation of a user while in a wheel- chair, in a moving vehicle of any type. It is Sunrise Medical’s posi- Contact Sunrise Medical customer service (800-333-4000) with tion that users of wheelchairs should be transferred into the vehi-... - Page 14 Q UI C KIE PU LS E VII. WARNINGS: COMPONENTS AND OPTIONS SECURING THE WHEELCHAIR TO THE VEHICLE WARNING This wheelchair must be in a forward facing position during travel in a motor vehicle. The recommended clear zones for wheelchair seated occupants restrained by both pelvic and upper-torso belt(s) and only by a pelvic belt are shown in the diagrams and described below.
- Page 15 Q UI C KIE PU LS E VII. WARNINGS: COMPONENTS AND OPTIONS VEHICLE-ANCHORED BELTS This wheelchair has an overall rating of “A” with regard to accommodating the use and fit of vehicle-anchored belts. This rating is scored as follows: A = Excellent, B = Good, C = Fair, D= poor. The test for Lateral Stability Displacement for Point (P) is shown in the figure at right.
- Page 16 Q UI C KIE PU LS E VII. WARNINGS: COMPONENTS AND OPTIONS POSITIONING BELTS WARNING The angle of the pelvic belt should be within the preferred zone of 45 to 75 degrees to the horizontal or within the optional zone of 30 to 45 degrees to the horizontal. Steeper side-view pelvic belt angles are especially important if the pelvic belt is intended to be used for postural support in addition to occupant restraint in a frontal crash.
-
Page 17: Use And Maintenance
Q UI C KIE PU LS E VIII. USE AND MAINTENANCE 1. Airing up your tire: WARNING a. CAUTION– To prevent tire damage: • Use a hand pump (or a low volume air pump) The owner and/or Caregiver for the use of this product, is responsible for to inflate tires. -
Page 18: Folding Backrest
Q UI C KIE PU LS E VIII. USE AND MAINTENANCE I. FOLDING BACKREST Pulse wheelchairs are shipped with backrest in folded position. (optional) 1. Upright Positioning a. Lift backrest to upright position so that latch handles (A) lock into place. b. -
Page 19: N.dual-Post Fixed Height Standard, And Dual-Post Height
Q UI C KIE PU LS E VIII. USE AND MAINTENANCE N. DUAL-POST FIXED HEIGHT STANDARD AND DUAL-POST HEIGHT ADJUSTABLE ARMRESTS (Optional) The dual-post flip-back armrest can be either a flip-back or removable armrest. 1. Installing Armrest a. Insert front and rear posts into armrest receivers. b. -
Page 20: Q Motor Lock
Q UI C KIE PU LS E VIII. USE AND MAINTENANCE Q. MOTOR LOCK Disengage the Motor Lock when you need to manually push the chair. (For example, in an emergency, or if batteries fail). WARNING 1. Do not disengage Motor Lock unless chair power is off. 2. -
Page 21: Check Out
If your problem persists, contact your authorized supplier. If you still have a problem after contacting your authorized supplier, contact Sunrise Medical Customer service. See the introduction page for details of how to contact the people who can help you. -
Page 22: Controller, Joysticks & Operating Guide
Q UI C KIE PU LS E IX. CONTROLLER, JOYSTICKS & OPERATING GUIDE Profiles and modes explained Omni Display The operation of the R-net system is based around the concept of Profiles and Modes. screen A Profile is a collection of programmable parameters that affect the operation and performance of the wheelchair. -
Page 23: D.joystick Buttons And Controls
Q UI C KIE PU LS E IX. CONTROLLER, JOYSTICKS, & OPERATING GUIDE D. JOYSTICK BUTTONS AND CONTROLS Color Battery Indicator This displays the charge available in the battery and alerts the user when the charge level is low. • Steady: This indicates that all is well •... -
Page 24: Lcd Screen (Color And Advanced)
Q UI C KIE PU LS E IX. CONTROLLER, JOYSTICKS, & OPERATING GUIDE E. LCD SCREEN (color and advanced) This section covers those joystick modules that are fitted with a color LCD screen. The color LCD screen is split into three areas of information. The Top Bar, the Text Bar and the Main Screen Area. - Page 25 Q UI C KIE PU LS E IX. CONTROLLER, JOYSTICKS, & OPERATING GUIDE IMPORTANT ICONS AND MESSAGES (color and advanced) Latched When the control system is operating in a Latched condition this symbol will be displayed. Inhibit If the speed of the wheelchair is being limited; for example, by a tilted seat, then this orange symbol will be displayed.
-
Page 26: Performance Control Settings
Drives R-net system and allows for the set up of up to ten differ- ent functions into the ten discrete buttons, (each toggle switch is two buttons). This device uses the Sunrise Medical patented Assignable Buttons feature. The Ctrl+5 switches are pre-pro- grammed from the factory to default values for the actuators on the chairs. -
Page 27: Vr2 Joystick
Q UI C KIE PU LS E IX. CONTROLLER, JOYSTICKS, & OPERATING GUIDE L. VR2 JOYSTICK The standard VR2 joystick controls the chair’s performance. It consists of the following parts: 1. Speed Control or Drive Mode Selection Buttons (A, B and C) a. -
Page 28: Batteries
Q UI C KIE PU LS E X. BATTERIES A. INTRODUCTION Always remove and reattach the negative cable (black cable) NOTE– first. 1. Notes– Batteries should never be left for long periods in the dis- NOTE– • Batteries supply the power for your chair. They contain a charged state. -
Page 29: D.connecting Batteries
Q UI C KIE PU LS E X. BATTERIES D. CONNECTING BATTERIES WARNING 1. Batteries weigh up to 55 lbs. Take care to avoid injury when lifting. 2. Always wear rubber gloves and safety glasses when you handle batteries. 3 Before working with batteries, remove all metal effects, such as necklaces, rings, watches, pins and other metal jewelry that might contact battery terminal and cause a short. -
Page 30: Dealer Service And Adjustment
Professional. Service or adjustments should only be done with the advice of a Healthcare Professional. Always use parts and accessories that have been recommended and approved by Sunrise Medical when servicing this chair. A. DEALER SERVICE INTRODUCTION 1. -
Page 31: Shroud Removal
Q UI C KIE PU LS E XI. DEALER SERVICE & ADJUSTMENT E. SHROUD REMOVAL The plastic protective shroud can be removed for adjustment or servicing. 1. Remove the top shroud a. Remove the Seat (Section T previous page). b. Remove the six screws(A) that hold the shroud to the frame. c. -
Page 32: H.cantilever Armrests
Q UI C KIE PU LS E XI. DEALER SERVICE & ADJUSTMENT H. CANTILEVER ARMRESTS (Optional) 1. Adjusting Armrest Pad (forwards or backwards) a. Loosen the 2 bolts (A) on the armrest pad bracket. b. You can move the armrest and receiver forwards or backwards for a universal fit. c. -
Page 33: Joystick Controller Position
Q UI C KIE PU LS E XI. DEALER SERVICE & ADJUSTMENT K. JOYSTICK CONTROLLER POSITION The controller can be moved in or out in relation to the armrest. You can also move the controller to either side of your chair to accomodate left or right-hand use. WARNING Be careful of pinching your controller cords. -
Page 34: O.center Mount Hanger Adjustment
Q UI C KIE PU LS E XI. DEALER SERVICE & ADJUSTMENT O. CENTER MOUNT HANGER ADJUSTMENT (ASAP Seating only) 1. Removing the assembly a. Remove the four screws (A) and slide the footrest assembly out of the receiver. 2. Footplate Height Adjustment a. -
Page 35: Seat Depth Adjustment
Q UI C KIE PU LS E XI. DEALER SERVICE & ADJUSTMENT S. SEAT DEPTH ADJUSTMENT 10" - 18", 12" - 20" only The seat depth can be adjusted in one inch increments on standard rehab seating. 1. Seat Frame Depth Adjustment a. -
Page 36: Seat Height Adjustment
Q UI C KIE PU LS E XI. DEALER SERVICE & ADJUSTMENT 2. Back Support Frame Width Adjustment a. After measuring the width adjustment in the seating area, Remove the front securing hardware (A) from the adjustment tube (B) on the stabilizer bar. b. -
Page 37: X.captains Seat
Q UI C KIE PU LS E XI. DEALER SERVICE & ADJUSTMENT X. CAPTAINS SEAT 1. Seat depth adjustments with 1” increments a. Using a 5mm Hex Key, remove the M8 Flat head screws(A), (3 on each side) b. Using a 5mm Hex Key, remove the M8 Flat head screws (B), (1 on each side) c. -
Page 38: Controller Position
Q UI C KIE PU LS E XI. DEALER SERVICE & ADJUSTMENT 6. Armrest angle adjustment a. Lift the armrest straight up so that it is perpendicular to the floor. b. Loosen the jam nut (A) c. Turn the adjusting screw (B) to raise or lower the front of the armrest. d. -
Page 39: Sunrise Limited Warranty
H. ADDITIONAL WARRANTY INFORMATION D. LIMITATIONS For goods provided by Sunrise Medical Pty Ltd in Australia, our goods 1. We do not warrant: come with a guarantee by Sunrise that cannot be excluded under the Australian Consumer Law. -
Page 40: Appendix
Q UI C KIE PU LS E APPENDIX The product is intended for use in the electromagnetic environment specified below. The user of the product should assure that it is used in such an environment. TABLE 1 Emissions Test Compliance Electromagnetic environment guidance RF emissions The product uses RF energy only for its internal function. - Page 41 Q UI C KIE PU LS E APPENDIX The product is intended for use in the electromagnetic environment specified below. The user of the product should assure that it is used in such an environment. Electromagnetic Environment Guidance Immunity Test IEC 60601 Test Level Compliance Level TABLE 3...
- Page 42 Q UI C KIE PU LS E APPENDIX The product is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The user of the wheelchair can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the wheelchair as recommended below, according to the maximum output power of TABLE 4 the communications equipment...
- Page 43 Q UI C KIE PU LS E NOTES 119832 Rev. G...
- Page 44 Sunrise Medical • 2842 Business Park Ave. • Fresno, CA 93727 • USA In Canada (800) 263-3390 Customer Service: 800.333.4000 ©2016 Sunrise Medical (US) LLC www.SunriseMedical.com 7.16 119832 Rev.G...
