Service Manual G-Shot P436 1. Function Test TOOL/EQUIPMENT SD card*2, TV, AC adapter, lens-wiping paper USB cable, flower, accessory, computer OPERATION DESCRIPTION ITEM OPERATON DESCRIPTION Part I Take out the camera, open the battery cover and insert SD card. Camera cannot be powered on if insert the battery reversely. Insert battery rightly and power on.
Page 4
Service Manual G-Shot P436 Shift to landscape mode and take a piece of photo towards beyond (more than 3m) in No flash mode. Then switch to night and red-eye mode , take a photo facing to the dark place under desk, and the camera must have flash and the pre-flash and main flash shall have clear differences before and after.
Service Manual G-Shot P436 2. Troubleshooting Item NG point NG Analyzing solution Charge Charging failure 1>. Check if connectors TP45-TP50 of J401 are Triggering cold solder, no solder, insufficient solder, System short-circuit, wrong solder, and etc. if there is any, remove the abnormity;...
Page 6
Service Manual G-Shot P436 Aperture shift NG 1>. Check if lens connecting board contact NG, cold solder or insufficient solder, remove the abnormity; 2>. If (1) is normal, check if R80, R81, R82, R83, R85, R86 are cold solder or insufficient solder, remove the abnormity;...
Page 7
Service Manual G-Shot P436 Power on without 1>. Check if two poles of buzzer are cold solder sound/ with or broken, remove the abnormity; abnormal sound 2>. Check if buzzer is ok, remove the abnormity; 3>. Check if R15, Q5, R8, R113 are cold solder, insufficient solder or NG, remove the abnormity.
Page 8
Service Manual G-Shot P436 Others USB connecting 1>. Check if USB connector is OK, remove the failure or can not abnormity; search the disk 2>. Check if USB_DTC related circuit is OK, remove the abnormity; 3>. Confirm if ASIC and related circuits are OK;...
Service Manual G-Shot P436 3. Disassemble Procedures Step Figure Description Remark Tools Examine if there's any Finished Product scratch on the surface. Do not scratch Remove the Rear the camera Cover at the camera surface while Screw driver housing. removing Rear Cover .
Page 10
Service Manual G-Shot P436 The soldering points Soldering are as image shown. iron Desolder the soldered Soldering joints by soldering iron iron as shown. The power wire and Soldering soldered joints as iron shown. Disassemble the Screw driver MCU PCB ASY.
Page 11
Service Manual G-Shot P436 Disconnect the connector form strobe Tweezer PCB ASY as shown. Remove the strobe PCB and flash tube Screw driver from Main Frame. Remove the lens unit Screw driver as shown. Version:K01A...
Service Manual G-Shot P436 4. Firmware Update Procedure To update this camera firmware, you will need to have 1. The new firmware file. 2. One SD card. 3. One card reader. Please follow the steps below to perform the update process: 1.
