Product Description - HP ENVY Maintenance And Service Manual

1

Product description

Category
Product Name
Processors
Chipset
Graphics
Panel
Memory
Hard drive
Description
HP ENVY Notebook
4th generation Intel® Core™ i7 Processor (Haswell H, 2-chip BGA)
Intel Core i7-4722HQ 2.4-GHz (SC turbo up to 3.4-GHz) processor (1600-MHz FSB,
6.0-MB L3 cache, quad, 37 W)
6th generation Intel Core i7 Processor (SKL- H, 2-chip BGA)
Intel Core i7-6700HQ, 2.6–GHz (SC turbo up to 3.5-GHz) processor (1600-MHz
FSB, 6.0-MB L3 cache, quad, 45 W
Intel HM87 express chipset (4th generation Intel processor)
Intel® HM170 Express Chipset (C-2 step) (6th generation Intel processor)
Intel graphics: Intel HD Graphics 4600 (4th generation Intel processor)
Intel graphics: Intel HD Graphics 530 (6th generation Intel processor)
Discrete graphics: Nvidia N16P-GT (GeForce GTX 950M) with 4 GB of dedicated
video memory
Support for HD decode, DX12, and HDMI
Supports Optimus
Supports GPS (GPU performance scaling)
Support for low-voltage differential signalling LVDS, co-layout with eDP1.2
without PSR)
Touch solution with flush glass and multitouch enabled
15.6-in, full high-definition (FHD), white light-emitting diode (WLED), AntiGlare
(1920×1080), slim (3.2-mm), SVA, typical brightness 220 nits, 16:9 aspect ratio
15.6-in, high-definition (HD), white light-emitting diode (WLED), BrightView
(1366×768), flat (3.8-mm), SVA, typical brightness 220 nits, 16:9 aspect ratio
15.6-in, high-definition (HD), white light-emitting diode (WLED), AntiGlare
(1366×768), flat (3.8-mm), SVA, typical brightness 220 nits, 16:9 aspect ratio
Two customer-accessible/upgradable memory module slots
Support for DDR3L-1600-MHz dual channel
Support for 16834-MB of system RAM in the following configurations:
16834-MB (8192-MB×2)
●
12288-MB (8192-MB+4096-MB)
●
● 8192-MB (8192-MB×1, 4096-MB×2)
● 6144-MB (4096-MB+2048-MB)
Support for 6.35-cm (2.5-in) hard drives in 7.0-mm (.28-in) and 9.5-mm (.37-
in) thickness
Touch Non-touch
models models
× ×
× ×
× ×
× ×
× ×
× ×
× ×
×
×
× ×
× ×
