Removal steps of the camera and microphone modules
When installing: Ensure that the connector is attached firmly.

2060 LCD cables

For access, remove these FRUs in order:
• "1010 Lenovo-OneLink-connector cover" on page 72
• "1020 Battery pack" on page 72
• "1030 Large bottom cover" on page 73
• "1040 Small bottom cover" on page 74
• "1050 Optical drive or optical-drive bay bezel" on page 75
• "1070 Hard disk drive assembly or solid-state drive assembly" on page 77
• "1080 Wireless LAN card" on page 79
• "1090 Coin-cell battery" on page 81
• "1110 Keyboard" on page 81
• "1120 Keyboard bezel assembly" on page 83
• "1130 System board and thermal fan" on page 86
• "1140 dc-in/USB-connector board with cable" on page 91
• "1150 Audio connector card with cable" on page 92
• "1170 LCD unit" on page 94
• "2010 LCD bezel" on page 100
• "2020 LCD panel" on page 100
1
2
4
3
Chapter 9
5
4
.
Removing or replacing a FRU
105
