Adjustable 5-Shelf Kit

Assembly Instructions
Warning
Maximum load capacity is 350 pounds equally
distributed per shelf

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WIL-1636-5B and is the answer not in the manual?

Questions and answers

Summary of Contents for designer's image WIL-1636-5B

  • Page 1 Adjustable 5-Shelf Kit Assembly Instructions Warning Maximum load capacity is 350 pounds equally distributed per shelf...
  • Page 2 Parts List Tapered Support Post with Plastic Sleeve Threaded End and 20 sets each Leveling Foot 2 sets spare 4 each (7/8" OD, 36.5"L) Support Post With Shelf Plastic Cap and 5 each Threaded End (16"D x 36"W) 4 each (7/8"...
  • Page 3 Assembly Instructions Step 1 Attach support posts with plastic cap and threaded end (C) to support posts with threaded end and leveling foot (B) Step 2: Choose desired bottom shelf height and snap tapered plastic sleeves (A), with the small tapered side facing up, to the groove at the selected height on all four supports.
  • Page 4 TIPPING RESTRAINT HARDWARE There is one set of tipping restraint hardware included in this shelf kit. When properly installed, this restraint can help limit the risk of unexpected tipping of the unit. It is strongly recommended that this hardware is installed properly to limit the possibility of tipping due to slight tremors or bumps. Full instructions for the installation of the tipping restraint hardware are printed on the back of the hardware bag.
