- Page 1 OPERATION and MAINTENANCE INSTRUCTION MANUAL AEU-20 Endodontic System Endo P.O. Box 1548 • Woodinville, WA 9 • 8333 216th Street SE, Woodinville WA 98072 International (425) 487-3157 • Toll Free (800) 426-5913 • www.aseptico.com • info@aseptico.com...
-
Page 2: Table Of Contents
Note: The power supply cord is the mains appliance disconnect means. P.O. Box 1548 • Woodinville, WA 98072 8333 216th Street SE • Woodinville, WA 98072 (425) 487-3157 (800) 426-5913 www.aseptico.com • info@aseptico.com... -
Page 3: Introduction
Your new Aseptico AEU-20 Endodontic System is one of the finest units available to the medical profession. The system features a variable torque brushless motor with digital R.P.M. readout for precise speed control. These features combine to make the perfect surgical motor for endodontic and other medical surgeries. -
Page 4: Setting Up The Unit
SETTING UP THE UNIT: 1. Unpack the console and check that the unit is compatible with the voltage from the FOOT SWITCH power source. Use the 110V unit for 110- 120V 60Hz voltages, and the 220V unit for 220-250V 50Hz voltages. For alternative CONSOLE voltages (220V-250V), confirm that the type of plug cap is correct for the country... -
Page 5: Operation Functions
OPERATION FUNCTIONS: 1. Power Switch - Controls power on/off to TORQUE console. When turned on, console display LEVEL should light. DISPLAY INDICATOR INCREASE DECREASE 2. RPM - Controls speed of motor and hand- piece. Push the up arrow to increase speed and the down arrow to decrease speed. - Page 6 OPERATION FUNCTIONS - Cont’d 5. Torque Control - Allows user to adjust torque limit from maximum to minimum levels, thus reducing the risk of instrument breakage. Push the Torque up/down arrow to select the desired torque level. MAXIMUM TORQUE Continuous 360° Rotation Torque settings 1, 2, and 3 utilize an ‘Auto- HIGH TORQUE Reverse’...
-
Page 7: Operation
OPERATION: After the unit has been set up and you have made yourself familiar with the operation func- tions, you are ready for operation as follows: 1. Turn the power switch on the lower left front of the console to the ‘ON’ position. The front panel display will light. -
Page 8: Sterilization
O-rings. • Full Cycle Time: 20 minutes • Minimum Dry time: 30 minutes NOTE: Call Aseptico, Inc. at 1-425-426- B. Prevacuum Wrapped: 5913 for any questions or clarifications • Preconditioning Pulses: 3 on this sterilization procedure. -
Page 9: Maintenance & Cleaning
MAINTENANCE & CLEANING: SYMBOL DEFINITIONS: HANDPIECES - Thorough cleaning and Type B Equipment lubrication of handpieces after each use and before sterilization is very important to ensure proper operation and service life of Attention, consult the handpiece. Follow the instructions accompanying documents provided with the handpiece purchased for complete maintenance instructions. -
Page 10: Troubleshooting
TROUBLESHOOTING: Problem: Correction: Console does not light when turned on: Check console to power connection. Check that unit is compatible with voltage from power source. Check fuse. If blown, replace with 0.315A/250V slo-blo fuse for 110 volts, & 0.16A/250V slo-blo fuse for 220 volts. Console lights when turned on, but Check motor plug connection. - Page 11 NOTES:...
-
Page 12: Warranty
Aseptico's sole obligation under product warranty is (at its sole option and discretion) to repair or replace any defective component or product in part or whole. Aseptico shall be the sole arbiter of such action.
