Summary of Contents for Aseptico DTC 2 AEU-26

  • Page 1 OPERATION MAINTENANCE INSTRUCTION MANUAL 2 Electronic Endodontic System ® Model AEU-26...
  • Page 2: Table Of Contents

    Warranty ......25 INFORMATION CONCERNING THE ACCURACY AND PRECISION OF THIS PRODUCT MAY BE OBTAINED CLASSIFICATIONS: UPON REQUEST BY CONTACTING ASEPTICO AT THE ADDRESS SHOWN ON THIS PAGE. • Class I Equipment • Type B Equipment •...
  • Page 3: Introduction

    ® Your new Aseptico DTC 2 Endodontic System is one of the finest units available to the dental profession. The system features a high torque brushless motor, intuitive user interface, and an easy to read digital display. These features combine to make the ®...
  • Page 4: Safety Precautions

    Important additional information and hints. SAFETY PRECAUTIONS: Aseptico accepts no liability for direct or consequential injury or damage resulting from improper use, arising in particular through the non-observance of the operating instructions, or improper preparation and maintenance of this product.
  • Page 5 WARNING: Do not disassemble or alter the AEU-26 motor, console, or foot switch. CAUTION: Use only appliance cord Type C13,10A per IEC / EN 60320-1. Note: North America, Denmark, Australia, and New Zealand may require hospital grade plugs. Consult local codes. WARNING: Never use damaged or worn files as they may separate in the root canal.
  • Page 6: Setting Up The Unit

    SETTING UP THE UNIT: 1. Unpack the Console and accessories (see Fig. 2 - Motor Cradle Figure 1). 2. Install the Motor Cradle: The autoclavable CHASSIS Motor Cradle can be attached to either side of the Console or placed flat on any adjacent CRADLE tabletop surface or tray.
  • Page 7 5. Connect the Motor/Cord Assembly to the Motor Receptacle on the lower right front of the console. The motor cord connector and console receptacle are keyed to engage one another. IMPORTANT: Align the red dot on the motor cord connector with the arrow located on the top of the receptacle.
  • Page 8: Quick Start Operation

    An introduction will scroll across the screen then briefly display the software Note: Pressing, holding, then version installed and date: releasing the CAL/SETUP ASEPTICO key will enable the system’s advanced setup options AEU-26 menu. Refer to the Advanced Operation Ver.
  • Page 9: Presets - Chart Of Default Settings

    Chart 1 - AEU-26 Default Presets Preset Button 1 Default File Series: DENTSPLY Tulsa Dental Specialties VORTEX ® 04 Taper Files File #1: VORTEX 04, .35 through .50 taper ® File #2: VORTEX 04, .25 and .30 taper ® File #3: VORTEX ®...
  • Page 10: Control Panel Functions

    CONTROL PANEL FUNCTIONS The intuitive user interface makes it easy to begin using your new AEU-26. Advanced features for editing and programming the system are discussed following the control panel descriptions. Fig. 8 - Console Display & Controls OPERATION MODE DISPLAY HANDPIECE RATIO INDICATOR AUTO-STOP...
  • Page 11 1. Main Power Switch: Press and release CAL key to activate the Located on back of console (see Figure 3). calibration program. The following prompt Controls main power On/Off to the console. will display: 2 Standby Key Attach Handpiece To Turns control panel on and off.
  • Page 12 CONTROL PANEL FUNCTIONS - cont’d Note: Speed ranges are accurate when once the load is removed. When the 1:5 handpieces are used with the supplied 30K handpiece is selected, the Torque Limit motor. Mode is automatically enabled. 8 PRESETS: Fig. 9 - AEU-26 SPEED RANGES Allows user 1,500 - 150,000 to quickly...
  • Page 14: Advanced Operation & Functions

    ADVANCED OPERATION: After the unit has been set up and the user NOTE: These latter changes will has become familiar with the system’s con- overwrite any previous changes that were made in Step A. trol panel functions, there are two different Either change the Name using the same modes that can be used to begin operation: editing procedure shown in Step 4) - b),...
  • Page 15 a) SELECT Handpiece: NOTE: The new file will be inserted into • Use the UP or Down Keys to locate the the list in front of (above) the cursor location. To insert a file at the end of the ratio that matches the handpiece being list, position the cursor on the last line item used.
  • Page 16: Recall Factory Setup

    ADVANCED OPERATION - Cont’d: 3. Recall Factory Setup: SETUP Recalling the Factory Setup allows you to Press and hold the CAL/SETUP reset your Endo System to factory specifi- Key to enter Setup Options cations. When this feature is selected, the Mode.
  • Page 17: Reverse Beeper

    When the Auto Stop Mode feature is when the torque level reaches selected, the following message will approximately 75% of the selected torque display: limit. When this feature is selected, the following message will display: Auto Stop Mode: Cancel Torque Warning: Auto Stop Reverse Cancel Auto Stop Manual...
  • Page 18: Sleep Mode

    ADVANCED OPERATION - Cont’d: 8. Sleep Mode: 9. System Volume: The Endo System can be programmed to Controls the volume of all system sounds, enter Sleep Mode after 15 or 30 minutes including reverse beeper, torque warning, of inactivity, to conserve power. In Sleep and keypress beep.
  • Page 19: Optional Foot Control Operation

    MULTI-FUNCTION FOOT CONTROL OPERATION The optional AE-70V2E Multi-Function Fig. 10 - Foot Control Connection Foot Control may be used on the AEU-26 System to control motor on/off, direction, AEU-26 CONNECTOR torque mode, and to select presets. Installation: 1. Attach the Foot Control cable to the connector on the back of the AEU-26 Console (see Figure 10).
  • Page 20 FOOT CONTROL OPERATION - Cont’d 3. The ‘T’ pad (Upper right - Handle Installation/Removal: Lavender) cycles through the three 7. The Foot Control Handle may be installed for Torque Modes: Auto-Stop Reverse easy repositioning of the AE-70V2E. (ASR), Maximum (MAX), or Torque Grasp vertical guide rods and push handle Limit.
  • Page 21: Reprogramming The Unit

    Programming Successful. common consumer devices. These cards, Eject Card. available from Aseptico, enable a user to update software or replace existing • Press the card inward slightly, then software that might have been accidentally release it to eject it.
  • Page 22: Sterilization

    & cord assembly is of debris. steam autoclaved. Sterilize 3) Select one of the three following NOTE: Call Aseptico Inc. at 1-800-426-5913 sterilization methods (A. B. or C.): for any questions or clarifications on this sterilization procedure. Wrapped Sterilization – Place in an appropriately sized sterilization pouch and seal it.
  • Page 23: Maintenance & Cleaning

    MAINTENANCE & CLEANING: HANDPIECES - Thorough cleaning and lubrication of handpieces after each use and before sterilization is very important to ensure proper operation and service life of the handpiece. Follow the instructions provided with the handpiece for complete maintenance instructions.
  • Page 24: Troubleshooting

    TROUBLESHOOTING: Problem: Correction: Console does not light when on: • If Preset LEDs are blinking, press Standby key on Control Panel or press foot pedal to exit Sleep Mode. • Check console to power connection. • Check fuse. If blown, replace with 1.6A, 250V slo-blow fuse.
  • Page 25: Specifications

    SPECIFICATIONS: Environmental Conditions: Console Dimensions: 6.8”W x 7.2”L x 4.5”H - Operating Temperature 10 to 28°C (50 to 82.4°F) (17.3 cm x 18.5 cm x 11.3 cm) - Transportation & Storage Temperature -20 to 60°C Console Weight: 2.0 lbs (0.91kg) (-4 to 140°F) Power: 100-240V...
  • Page 26: Symbol Definitions

    SYMBOL DEFINITIONS: Authorized European Representative Type B Equipment Standby Switch Dangerous Voltage Footswitch Alternating current Manufacturer Protection Against Dripping Water Fuse Rating Protective Earth (Ground) 250V Motor Direction Preset Step Through Torque Mode Step Through File Series Step Through Temperature Limitation Serial Number Attention, consult Humidity Limitation...
  • Page 27: Warranty

    Aseptico's sole obligation under product warranty is (at its sole option and discretion) to repair or replace any defective component or product in part or whole. Aseptico shall be the sole arbiter of such action.
  • Page 28: P.o. Box 1548 • Woodinville, Wa

    P.O. Box 1548 • Woodinville, WA 98072 8333 216 Street S.E. • Woodinville, WA 98072 (425) 487-3157 • (800) 426-5913 www.aseptico.com • info@aseptico.com P/N: 420728 Rev. I ECO 13508 PRINTED IN THE USA 12 /2014...
