- Page 1 OPERATION and MAINTENANCE INSTRUCTION MANUAL ADU-17A Express Air Portable Dental System...
-
Page 2: Table Of Contents
Setting Up the Unit ....3 P.O. Box 1548 • Woodinville, WA 98072 Figure 1 - ADU-17A System ..3 8333 216 Street S.E. -
Page 3: Package Contents
Your new Aseptico Express Air Portable Dental System is the finest portable electric dental sys- tem available. The ADU-17A features a handpiece control, 3-way air/water syringe, HVE and sali- va ejector vacuum systems, a self contained water system, oilless air compressor, and vacuum pump. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS: Aseptico accepts no liability for direct or consequential injury or damage resulting from improper use, arising in particular through the non-observance of the operating instructions, or improper preparation and maintenance. WARNING: Sterilize before first and all uses. Clean, disinfect, and sterilize new or repaired instru- ments before first use. - Page 5 SETTING UP THE UNIT: FIG. 1 - ADU-17A Express Air 3-WAY AIR/WATER SYRINGE HANDPIECE CLIP-ON INSTRUMENT HOLDER LOW VOLUME VACUUM HIGH VOLUME (SALIVA EJECTOR) VACUUM (HVE) CASE HANDLE WASTE TANK TIE-DOWN RESERVOIR CONNECTOR WATER SUPPLY BOTTLE WASTE TANK COOLANT ON/OFF...
-
Page 6: Setting Up The Unit
SETTING UP THE UNIT Cont’d 1. Unpack the ADU-17A Case. 2. Verify that the Voltage Selector Insert is config- Fig. 2b Fig. 2a ured properly by checking the voltage indicator on the Voltage Selector Module (Figure 2a). The Voltage Module is located on the lower left of the Motor Cover. - Page 7 3. Mount the clip-on Holder to the extended handle of the front of the Waste Tank. Connect the Low the Case, as shown in Figure 3. Volume Vacuum (Saliva Ejector) hose to the black connector located on the front of the Tank. Fig.
-
Page 8: Operation Functions
OPERATION FUNCTIONS: 1. ON/OFF SWITCH: c.) Unscrew and remove Bottle from cap. Turns the ADU-17A system On or Off. d.) Fill Bottle with clean water. 2. AIR FOOT CONTROL: e.) Screw Bottle into the Water Reservoir The handpiece only operates when the foot Connector. -
Page 9: Operation
3. Depress the foot pedal to operate the CAUTION: handpiece. Adjust the air pressure and Some new ADU-17A compressor motors might water coolant flow to the desired settings require a 2-week “break-in” when first used. As a (See Fig. 6). (Turn the water coolant con-... -
Page 10: Sterilization & Maintenance
SYRINGE TIPS The ADU-17A unit features a three-way air/water syringe with quick-change autoclavable tips. To remove a tip, press on the locking collar surrounding the tip socket and pull the used tip straight out of the socket (see Fig. 7). To insert a new tip, press locking collar and push tip into socket as far as it will go. -
Page 11: Troubleshooting
TROUBLESHOOTING: Problem: Correction: Unit will not start Check system’s power connection. Turn On/Off switch ON for operation. Check that voltage selector module is set for source voltage. Check fuse. If blown, replace with 6A/125V medium time delay fuse for 120V operation, or a 3A/250V slo-blo fuse for 230V operation. -
Page 12: Repacking Instructions
REPACKING INSTRUCTIONS: 1. Remove all accessories from the unit. 2. Remove water bottle and place in travel pouch provided. 3. Position syringe in its holder on left side of case (Fig. 10). Lay tube behind syringe, FIG. 9 next to waste tank. 4. -
Page 13: Symbol Definitions
SYMBOL DEFINITIONS: Type B Equipment Protective earth (ground) Attention, consult IPX1 Protect Against Dripping Water accompanying documents Dangerous Voltage Serial Number Foot Switch Alternating current Handpiece - Air On/Off Switch Coolant Adjustment Switches Do Not Throw Into Trash Cavitron Connector Fuses... -
Page 14: Specifications
Continuous Classifications in accordance with UL-2601-1: IMPORTANT NOTE: - Class II When running the ADU-17A unit at 230VAC 50Hz, expect approximately 17% less vacuum - Type B Applied Parts and pressure volume due to the slower turning - Ordinary Protection of the compressor. -
Page 15: Warranty
In the event of alleged defect under warranty, the purchaser is to notify Aseptico's Customer Service Department promptly. Customer Service will provide instructions, usually directing that the product be returned for service. Shipment to Aseptico and the cost thereof is always the responsibility of the purchaser. - Page 16 P.O. Box 1548 • Woodinville, WA 98072 8333 216th Street SE • Woodinville, WA 98072 (425) 487-3157 • (800) 426-5913 www.aseptico.com • info@aseptico.com P/N: 420966 Rev. A ECO 12704 PRINTED IN 10/2011 THE U.S.A.
