Summary of Contents for Aseptico AEU-7000-70V
- Page 1 OPERATION MAINTENANCE INSTRUCTION MANUAL AEU-7000-70V & AEU-7000 Implant / Surgery Systems AEU-7000-70V System...
-
Page 2: Table Of Contents
Ver. 1.X Software. INDICATIONS FOR USE: RX: FEDERAL LAW RESTRICTS THIS DEVICE TO The AEU-7000-70V & AEU-7000 are drive systems for SALE BY OR ON THE ORDER OF A DENTIST instruments and tools used in dentistry for surgical and prosthetic implant procedures. The systems include an... -
Page 3: Introduction
Your new Aseptico AEU-7000-70V & AEU-7000 Implant / Surgery Systems are two of the finest units available to the dental profession. The systems feature a high torque brushless motor with a digital display and self-contained irrigation pump. These fea- tures combine to make the perfect surgical motor and irrigation System for implant and other oral surgery applications. -
Page 4: Safety Precautions
Important additional information and hints. SAFETY PRECAUTIONS: Aseptico accepts no liability for direct or consequential injury or damage resulting from improper use, arising in particular through the non-observance of the operating instructions, or improper preparation and maintenance of this product. - Page 5 WARNING: Always comply with the surgical handpiece and file manufacturers’ instructions regarding maximum speeds, torques, forward and reverse directions, and use of all instrumentation, drills, burs, etc., used in implantology and other oral surgery appli- cations. CAUTION: The irrigation supply System is designed for use with a saline solution or sterile water.
-
Page 6: Setting Up The Unit
CORD IN PORT Fig.3 - Setup ELECTRONIC CONTROL IRRIGATION BAG CONSOLE HANGER ROD MULTI-FUNCTION HANDPIECE FOOT CONTROL & MOTOR CALIBRATION ADAPTER STORAGE MOTOR CRADLE & BRACKET DOOR RELEASE BUTTON DYNAMOMETER PORT MOTOR IRRIGATION RECEPTACLE PUMP DOOR MOTOR CORD (AEU-7000-70V System shown) - Page 7 b. Install Pump Tubing Assembly into pump 5. Attach the appropriate "E-Type" handpiece to the motor as shown in Figure 4. door as shown in Figure 5. Install tubing connector into the slot located on the Fig. 4 - Handpiece/Motor Connection back end of pump door.
-
Page 8: Control Panel Functions
CONTROL PANEL FUNCTIONS: will return the System to the last state 1. Main Power Switch: used. Located on back of console (see Figure 2). Controls main power On / Off to the console. 3 Calibration (CAL): Activates the dynamometer and 2 Control Panel ‘Standby’... -
Page 9: Speed Ranges
Note: Multiple handpieces with different 4 Handpiece Ratio Selector: ratios are often required to obtain the vari- Allows user to select ratio of hand- ous high torque and low speed ranges piece. Ensures accurate display of used in dental surgery procedures. speed and torque levels. - Page 10 CONTROL PANEL FUNCTIONS - Cont’d: 8 Torque Modes (A-S / MAX): 9 Irrigation Pump Controls (FLOW): Allows the user to select from Allows user to turn pump On/Off one of three torque control and select Flow rate. modes: Auto-Stop, Maximum, or a.
- Page 11 Preset 6 13 PRESETS 1 - 6: - Install Implant /Abutment: • 20:1 Handpiece Allows the user to store and quickly access • 15 RPM, FWD up to 6 different implant configurations. • 32 N•cm Torque, Auto-Stop Each preset can be reprogrammed by the •...
-
Page 12: Operation
OPERATION: System to the last state used. NOTE: The GETTING STARTED: After the unit has been unit is in Sleep Mode when the Preset set up and the user has become familiar with LEDs blink consecutively. the System’s control panel functions, there are two different modes that can be used to Manual Mode: begin operation:... - Page 13 user when the handpiece torque level Handpiece calibration consists of either a reaches 75% and 100% of the “MAX” limit. one-part or two-part procedure, depending CAUTION: Because of the unrestrained on which type handpiece is used: torque characteristics inherent in MAX Part-1 “Free Run”...
- Page 14 OPERATION - Cont’d: Free Run In Progress Fig.8 - Ratio & Torque Tests Please Wait ... DYNAMOMETER The System will automatically perform the PORT “Free Run” Calibration test on either increaser or reduction type handpieces. NOTE: Pressing Preset Button #3 at any time during the calibration process will exit the procedure, however, no calibration set- tings will be saved into the System.
- Page 15 Step 3: located above the preset button will illumi- nate, indicating which preset is activated. A display prompt then asks the user: Preset - (X) Note: If a preset is activated and its set- Save Settings? YES/NO tings are changed in any way, the preset’s LED will turn off, signifying that the unit has Press the ‘Yes’...
- Page 16 OPERATION - Cont’d: Position the cursor under the specific System Setup: character that needs to be changed. 14.To enter the System Setup menu, press “NAME X” and hold the “SETUP” button for 1 second. Step 6: 15.The following prompt will be displayed: Use the Up or Down (“Yes”...
- Page 17 NOTE: The Reverse Warning Tone emits a NOTE: The System will automatically Exit beeping signal with a 1/2-second cadence the “SETUP” menu at the completion of that is easily distinquishable from the two this Step. Torque Warning Tones in Step #16 above. IMPORTANT: If both Torque and Reverse Warning Tone options are enabled and acti- vated at the same time (e.g., user reaches...
-
Page 18: Foot Switch Description & Operation
VARIABLE-SPEED FOOT CONTROL OPERATION The AE-70V Variable-Speed Foot Control Fig.10 - Foot Control Connection comes as standard equipment on the AEU-7000-70V System, and as an option AEU-7000-70V on the AEU-7000 System. The AE-70V can control motor speed, direction, torque, select presets, and turn the pump On/Off. - Page 19 3. The ‘T’ pad (Upper right - Fig.12 - Handle Installation/Removal Lavender) increases the torque setting by 2 N•cm each time the pad is pressed, up to a maximum increase of 10 N•cm’s. Once the total increase in torque reaches this 10 N•cm threshold, the unit will cycle the next torque setting back down to its initial (lowest) set- ting.
-
Page 20: Reprogramming The Unit
Programming successful. mon consumer devices. These cards, Eject card. available from Aseptico, enable a user to update software or replace existing soft- • Press the card inward slightly, then ware that might have been accidentally release it to eject it. -
Page 21: Sterilization And Maintenance
STERILIZATION & MAINTENANCE: HANDPIECES - Thorough cleaning and Fig. 16 MOTOR & CORD STERILIZATION lubrication of handpieces after each use and before sterilization is very important to ensure proper operation and service life of the handpiece. Follow the instructions provided with the handpiece for complete maintenance instructions. -
Page 22: Troubleshooting
• Replace worn tube section located under the pump door with a new section from extra tube set provided with this system. CHANGING THE FUSE: NOTE: The AEU-7000 & AEU-7000-70V WARNING feature auto-sensing, global voltage compatibility. The fuse indicated is correct for Turn the power off and unplug the unit 100V-240V 50/60 Hz line voltage. -
Page 23: Specifications
SPECIFICATIONS: Console Dimensions: 9.98”W x 9.42”L x 5.10”H Environmental Conditions: (25.3 cm x 23.9 cm x 12.9 cm) Operating Temperature 10 to 28°C (50 to 82.4°F) Transportation & Storage Temperature -20 to 60°C (-4 to 140°F) Console Weight: 7.3 lbs (3.3kg) Relative Humidity 10 to 90% non-condensing Power: 100-240V... -
Page 24: Warranty
Aseptico's sole obligation under product warranty is (at its sole option and discretion) to repair or replace any defective component or product in part or whole. Aseptico shall be the sole arbiter of such action.
