Parts catalog.

REF. #.
120
121
122
123
130
132
133
134
135
136
137
138
139
140
141
143
144
145
146
147
148
150
151
998
999
*NOTE: Codes in the State of Massachusetts require installation by a licensed
plumber and do not permit the use of the saddle valve. For installation, use
plumbing code 248-CMR of the Commonwealth of Massachusetts.
30
CAT. #. PART DESCRIPTION
WS03X10019 SEAL, O-RING 1/4" x 3/8"
WS15X10025 BODY VALVE
WS03X10020 SPRING
WS22X10029 PLUG, DRAIN SEAL
WS35X10020 SEAL KIT
WS22X10030 ADAPTOR, DRAIN HOSE
WS03X10025 SEAL, O-RING 15/16 x 1–3/16
WS03X10035 PLUG FLOW
WS03X10033 CLIP, DRAIN
WS26X10008 CAM AND GEAR
WS26X10009 BEARING
WS26X10007 PLATE MOTOR
WS02X10015 SCREW, #6–20 x 3/8"
WS26X10006 MOTOR ASM.
WS02X10016 SCREW, #6–20 x - 7/8"
WS60X10007 TUBE INSTALLATION
WS03X10037 O-RING 1–1/8 x 1–3/8
WS60X10008 CLIP
WS28X10009 HOUSING SENSOR
WS19X10008 TURBINE SUPPORT
WS19X10009 TURBINE
WS03X10024 SEAL, O-RING
WS15X10026 VALVE BY-PASS ASM.
WS35X10021 INSTALL KIT - GNSF39Z/GNSF48Z
49–50020 USE & CARE/INSTALL INSTR
GNSF39 GNSF48
2 2
1 1
1 1
1 1
1 1
1
1
1 1
1 1
1
1
1
1
1
1
1
1
3
3
1
1
2
2
2 2
4 4
2
2
1
1
1
1
1
1
1
1
1
1
1 1
1
1
