Service: Manually Initiated Electronic Diagnostics
1
On
LAST RECHARGE
WATER MANAGEMENT SYSTEM
Turbine
Switch Turbine
count
Valve Minutes of cycle
position remaining
Fill
TIME
WATER MANAGEMENT SYSTEM
Turbine
2
RECHARGE
WATER MANAGEMENT SYSTEM
3
x 10
DAY
18
To enter diagnostics, press and hold the DATA button until the display appears as shown.
NOTE: If the softener is in the middle of a regeneration, top part of the display shows the cycle
of regeneration and minutes of the cycle remaining. If two cycle names are flashing, the valve
is in transition between the cycles.
A The three digits under WATER MANAGEMENT SYSTEM indicate water meter operation as
follows:
000 (steady) = soft water not in use...no flow through the meter.
—OPEN A NEARBY SOFT WATER FAUCET—
000 to 140 (continual) = repeats display for each gallon of water passing through the
meter.
If you don't get a reading in the display, with faucet open, pull the sensor from the valve outlet
port. Pass a small magnet back and forth in front of the sensor. You should get a reading in the
display. If you get a reading, shut off water supply, unhook the in and out plumbing and check
the turbine for binding.
B This display segment (
Use the TOUCH or HOLD button to manually advance the valve into each cycle and check correct
switch operation.
CORRECT SWITCH
DISPLAYS
Press the DATA button again. This diagnostic display shows the total number of recharges (top)
since the timer was connected to electrical power.
The number of days since the timer was connected to electrical power is shown in the bottom
part of the display. If over 1999 days, a (x10) indicator shows, meaning you must multiply the
number shown by 10.
Press DATA once again to return the present time to the display.
Motor
Position
switch
Sensor
housing
Turbine
Turbine
Valve support
outlet & shaft
), in the following chart, indicates an open POSITION switch.
VALVE CYCLE STATUS
Valve in service, fill, brining, backwash
or fast rinse position.
Valve rotating from one position to another.
