Quick Guide
IC-602
1
B ef ore Getting Star ted
2
L et's Mak e P rin ts
3
In stalling S of tware
4
B asic Op eration s
5
Main tai nin g th e Fi nish ing Qu al i ty
6
Trou ble shoo tin g
7
A pp end ix

Advertisement

Table of Contents
loading

Related Manuals for Konica Minolta bizhub PRESS C1100

Summary of Contents for Konica Minolta bizhub PRESS C1100

  • Page 1 Quick Guide B ef ore Getting Star ted L et's Mak e P rin ts In stalling S of tware B asic Op eration s Main tai nin g th e Fi nish ing Qu al i ty Trou ble shoo tin g A pp end ix IC-602...

  • Page 2: Notations And Symbols Used In This Manual

    Welcome Thank you for purchasing this machine. This Quick Guide describes basic operations, maintenance, troubleshooting for this machine. This information will be useful to enable the full capabilities of this machine and to utilize such functionality efficiently. Please keep this manual in a safe place where you can access it easily.

  • Page 3: Intended Use

    The user's guides are intended for the following users of the system: Operator: Person who has been trained by Konica Minolta or authorized partner to operate the system for its intended use as well as manage consumables, and perform the maintenance and troubleshooting described in user's guides.

  • Page 4: Configuration And Usage Of This Guide

    Configuration and Usage of this Guide Configuration and Usage of this Guide There are two types of User's Guides for this machine: booklet manuals and User's Guide CD. When you want to learn about detailed functions or operation procedures, refer to the HTML User's Guide included in the User's Guide CD.

  • Page 5: Html User's Guide Operating Environment

    PRESS C1100/C1085 HTML User's Guide operating environment )Supported Operating Systems/Browsers This guide describes the operation verification in the operating systems and browsers shown below. Operating system Web browser Windows Vista (Service Pack 2) Internet Explorer 9.x Windows 7 (Service Pack 1)/Windows 8 Internet Explorer 10.x...

  • Page 6: Conventions Used In This Guide

    This guide describes product names and system configurations as follows. Product name Conventions used in this guide bizhub PRESS C1100/C1085 This machine: Indicates the entire system including options and functions. The main body: Indicates a main unit that covers printing functions.

  • Page 7: Table Of Contents

    PRESS C1100/C1085 Make a Note about This Machine Information Checking the mounted optional devices Get to know the optional devices mounted on this machine. You can check a part of the mounted optional devices on the [MACHINE] screen of the touch panel.

  • Page 8: Checking Network Information

    Make a Note about This Machine Information Checking network information Make a note about network information required to use functions of this machine such as printer functions and various applications. To check network information, print out the Configuration Page Print. )Printing out the Configuration Page Print From the [MACHINE] screen on the touch panel, select [Controller] - [Report Type] - [Network Setting], then press [Execute].
  • Page 9 PRESS C1100/C1085 Contents Intended use of this machine ........... . x-i Intended use .

  • Page 10: Contents

    Contents Installing Software Installing the Printer Driver............3-1 Operating environment .
  • Page 11 PRESS C1100/C1085 Image Quality Adjustment ........... . . 5-17 Image Quality adjustment .
  • Page 12 Contents Major Specifications ............7-12 Machine .

  • Page 13: Before Getting Started

    PRESS C1100/C1085 Before Getting Started Turning the Power ON/OFF )Power supply This machine has two power switches: main power switch and sub power switch. NOTICE The main power switch is normally kept turned on. The main power switch must be turned on or off only when you start this machine for the first time or when you restart this machine.

  • Page 14: Turning The Power Off

    Turning the Power ON/OFF Tips If [Machine is warming up] is displayed on the [MACHINE] screen, it indicates that this machine is in the warm-up state. Warm-up processing takes approximately eight minutes. )Turning the power off Turn off the sub power switch. The touch panel display is cleared, and the Power LED on the control panel is changed from green to red.

  • Page 15: Power-Saving Function

    PRESS C1100/C1085 )Power-saving function Using the following functions can reduce the power consumption of this machine and provide greater power-saving effects. Function Description Power Save func- Auto Low Power Turns off the touch panel display to reduce the power consumption tion of this machine.
  • Page 16 Turning the Power ON/OFF Tips Since Utility/Counter - [Administrator Setting] - [System Setting] - [Power Save Setting] - [Power Save Function Setting] is the same as Utility/Counter - [User Setting] - [System Setting] - [Power Save Setting] - [Power Save Function Setting], use either of the methods to configure a setting.

  • Page 17: Available Operations In This Machine

    PRESS C1100/C1085 Available Operations in this Machine Major functions of this machine )Print functions This machine can be used as a printing system by installing an optional Image Controller. You can print data on this machine via the printer driver using the application software installed on your computer.

  • Page 18: Scan Functions

    Available Operations in this Machine )Scan functions You can send the scan data as an E-mail attachment, send it to the shared computer (SMB server), FTP server, or WebDAV server, or save it on the USB flash drive installed on this machine by mounting optional Paper Feeder Unit PF-708 and Image Controller.

  • Page 19: Application Functions

    PRESS C1100/C1085 Application functions )Color management function (Color Centro) Color Centro is an application that enables efficient color management of the image controller through a computer. To successfully print in color, you can calibrate the image controller, and edit and manage profiles and replacement tables to adjust colors.

  • Page 20: Let's Make Prints

    Printing Flow Let's Make Prints This chapter describes a basic print workflow using this machine. First confirm the basic flow to print data, then add detailed settings and adjustment to meet your requirements. Reference For information about application settings of this machine and adjustment procedures, refer to the HTML User's Guide.

  • Page 21: Step 3: Configure Information Of The Paper Loaded Into A Tray In This Machine

    PRESS C1100/C1085 Step 3: Configure information of the paper loaded into a tray in this machine Specify the type, size, weight, and other values of paper. For details, refer to page 4-3. Step 4: Use the printer driver to print data Print original data through your computer.

  • Page 22: Step 5: Check The Finishing

    Printing Flow Click the [General] tab on the setting screen of the printer driver, then select the paper size of the original data in [Original Size]. Check the setting, then click [OK]. In [Paper Tray], you can select a tray to load paper to be printed into. For information about other functions of the printer driver, refer to the HTML User's Guide.

  • Page 23: Installing Software

    PRESS C1100/C1085 Installing Software Installing the Printer Driver Operating environment )In a Windows environment Item Specifications Operating System Windows Vista, Windows 7, Windows 8, Windows 8.1, Windows Server 2003, Windows Server 2003 R2, Windows Server 2008, Windows Server 2008 R2,...

  • Page 24: In A Windows Environment

    Installing the Printer Driver Reference The PPD driver is only supported in Windows. However, the PPD driver is not supported by Windows Server 2003 R2. In a Mac OS X environment, use the PS Plug-in driver. For details about the PPD driver, refer to the HTML User's Guide. In a Windows environment )Installation Start the installer from the Driver CD supplied with this machine, then install the printer driver on your computer.
  • Page 25 PRESS C1100/C1085 Select the name of the printer to be installed, then click [Next]. If the required printer name cannot be found, click [Have Disk], then directly specify the [Setup.inf] file. Click [Finish]. If the [Windows Security] window is displayed, click [Install].

  • Page 26: Default Setting

    Installing the Printer Driver )Default setting Check that optional information of this machine is configured correctly on the printer driver. If optional information of this machine is not configured correctly on the printer driver, you cannot use optional functions. If any optional function is mounted, be sure to configure a setting. Display the printer window.

  • Page 27: In A Macintosh Environment

    PRESS C1100/C1085 In a Macintosh environment )Installation Install the printer driver on your computer from the Driver CD supplied with this machine, then add the desired printer to the computer. This guide describes how to install the PS Plug-in driver in a Mac OS X 10.8 environment and add a Bonjour-connected printer.
  • Page 28 Installing the Printer Driver When the installation has been completed, click [Close]. Then, add a Bonjour-connected printer to your computer. In the Apple Menu, select [System Preferences], then click the [Print & Scan] ([Print & Fax] in OS X 10.5/10.6, [Printer & Scanner] in OS X 10.9) icon. Click [+].
  • Page 29 PRESS C1100/C1085 Specify the Bonjour-connected printer to be added in the [Name] list. Specifying a printer displays the appropriate printer driver in the [Use] field. If the printer driver is not displayed correctly, select [Select Printer Software], then directly specify the desired printer driver.

  • Page 30: Default Setting

    If any optional function is mounted, be sure to configure a setting. Select a print command of the application, then select the required printer name from [Print]. Select [bizhub PRESS C1100/C1085PS] from the pull-down list in the window, then click [Settings].

  • Page 31: Installing Applications

    PRESS C1100/C1085 Installing Applications Operating environment )Color Centro Item Specifications Operating System Windows Vista, Windows 7, Windows 8, Windows 8.1, Windows Server 2003, Windows Server 2003 R2, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2...

  • Page 32: Color Centro Setup

    Installing Applications Color Centro setup )Function overview / Color management Color Centro is an application that enables efficient color management of the image controller through a computer. Color Centro supports the following seven types of functions. Function Description [Calibration] Enhances accuracy and stability of color printing. You can cre- ate data to adjust a color shade by measuring the color printing condition of this machine.

  • Page 33: Installation

    PRESS C1100/C1085 )Installation Start the installer from the Color Centro CD-ROM supplied with this machine, and then install Color Centro on your computer. Before installing Color Centro, install Microsoft .NET Framework 3.5 Service Pack 1 or later on your computer.

  • Page 34: Start

    [Administrator Setting] - [Network Setting] - [NIC Setting] The JSP setting is a setting that relates to a connection with a Java application server. Open the Start menu, and then click [All Programs] - [KONICA MINOLTA] - [Color Centro] - [KONICA MINOLTA Color Centro].

  • Page 35: Job Centro Setup

    PRESS C1100/C1085 Job Centro setup )Function overview / Job management Using Job Centro, you can remotely operate jobs saved on this machine. You can also edit jobs and pages with Job Centro. You can change the paper setting or finish setting for jobs saved on this machine, move or delete pages while viewing page thumbnails, or insert a chapter separator.

  • Page 36: Installation

    Installing Applications )Installation Start the installer from the Job Centro CD-ROM supplied with this machine, and then install Job Centro on your computer. To install, the computer's administrator privilege is required. Insert the Job Centro CD-ROM into the CD-ROM drive of the computer. If the installer does not start, double-click [AutoRun.exe] on the CD-ROM, and then proceed to Step 3.

  • Page 37: Start

    [Administrator Setting] - [Network Setting] - [NIC Setting] The JSP setting is a setting that relates to a connection with a Java application server. Open the Start menu, and then click [All Programs] - [KONICA MINOLTA] - [Job Centro 2.0] - [KONICA MINOLTA Job Centro 2.0].

  • Page 38: Basic Operations

    Loading Paper Basic Operations Loading Paper Loading paper into the Paper Feeder Unit PF-708 The following describes how to load paper into an optional Paper Feeder Unit PF-708. The same paper loading procedure is used for Paper Feeder Unit PF-707 and Paper Feeder Unit PF-708. The same paper loading procedure is used for each tray.

  • Page 39: Loading Paper In Post Inserter Of Folding Unit Fd-503

    PRESS C1100/C1085 Press the side guide plates against the paper, then turn the side guide lock knobs (2 pieces) clockwise to fix them. Load the remaining paper into the tray, then press the rear guide plate against the paper.

  • Page 40: Paper Setting

    Paper Setting Paper Setting Specifying paper information for a tray Specify the required information (size, type, weight, and other values) for the paper loaded into a paper tray. If standard-size paper is loaded, its size is recognized automatically. To load custom-size paper, specify the required size.
  • Page 41 PRESS C1100/C1085 Press [Paper Size]. Select one of the options under [Size Setting] to fit the paper loaded into the tray.
  • Page 42 Paper Setting Specify the size. [Standard]: Recognized automatically. In [Detect Size Setting], you can select the size to be detected. There is, however, a group of sizes having subtle distinctions, so that the machine cannot distinguish in the operation of size detection. To identify these sizes as one size so that they can be judged by the machine, you can select the size to be detected in [Detect Size Setting].
  • Page 43 PRESS C1100/C1085 [Tab Paper]: Specify the paper size and the number of tabs. If you select [Detect Size Setting] in [Standard], press [OK]. This returns to the [Size Setting] screen. This step is not required if you select [Custom] or [Tab Paper].
  • Page 44 Paper Setting Specify other items, if necessary. Press [OK]. This returns to the [Paper Setting] screen. Press [Close]. This returns to the [MACHINE] screen. If you press [Paper Setting] on the [COPY] screen to specify the paper size, the screen returns to the [COPY] screen.

  • Page 45: Printer Driver Setting

    PRESS C1100/C1085 Printer Driver Setting Printer driver functions This section describes how to specify the color mode using the printer driver. )[Color Mode]: Select an output color Open [Color Mode] in the Printing Preferences window of the printer driver. For [Output Color], select [Auto Color], [Full Color], or [Gray Scale].

  • Page 46: [Color Mode]: 2-Color Printing

    Printer Driver Setting )[Color Mode]: 2-Color Printing To print process colors (CMYK) using Spot Colors (Special colors), open [Color Mode] in the print setting screen, then specify the colors to be used in [2-Color Printing]. In 2-Color Printing, process colors (CMYK) can be replaced with Spot Colors (Special colors) for printing. To specify each color, enter the spot color name into the text box on the right-hand side of the selected color.

  • Page 47: [Management]: Color Configuration

    PRESS C1100/C1085 )[Management]: Color Configuration The Color Configuration refers to a collection of a profile set available for all paper types and other color setting information. You can only specify one Color Configuration at the time of printing to easily apply the color setting available for all paper types.

  • Page 48: [Management]: Manual Setting Of A Color Conversion

    Printer Driver Setting )[Management]: Manual setting of a color conversion In Manual Settings, manually configure a color conversion setting for printing, for example, specifying an RGB or CMYK color conversion profile, specifying a printer profile appropriate to the required paper type, or selecting a Tone Curve.

  • Page 49: Maintaining The Finishing Quality

    PRESS C1100/C1085 Maintaining the Finishing Quality Both Sides Adjustment Both Sides Adjustment When performing the duplex printing, you can adjust a misalignment between the front and back sides to align the printing positions on the front and back sides. This task is referred to as Both Sides Adjustment.

  • Page 50: Making The Both Sides Adjustment For Each Tray

    Both Sides Adjustment NOTICE A high technical skill is required to adjust the reference position on the print side. Before carrying out this adjustment, contact your service representative. Making the Both Sides Adjustment for each tray Adjust a misalignment between the front and back sides, which is caused during the duplex printing, for each tray. The following methods are available to carry out the Both Sides Adjustment.
  • Page 51 PRESS C1100/C1085 Select the tray with the target paper loaded, then press [Change Set]. Press [Both Sides Adj]. Press [Print Mode]. When the [PRINT MODE] screen is displayed, press Start on the control panel. A test chart is printed out.
  • Page 52 Both Sides Adjustment Press [Exit Print Mode]. Measure the gap between the front and back sides at each point of [a] to [d] on the [back] side of the printed out chart. This figure shows an example to measure [a]. The scale resolution is 0.5 mm.
  • Page 53 PRESS C1100/C1085 Press [a] to [d] of each point, and enter the adjustment value using the keypad, [,], or [+] on the screen. If the printing position is misaligned to the minus (–) side, enter a positive value (+). If the printing position is misaligned to the plus (+) side, enter a negative value (–).
  • Page 54 Both Sides Adjustment Check a gap of the printing position refering the printed out chart. Repeat steps 7 to 10 until all gaps between the front and back sides are cleared. Press [Exit Print Mode]. After the adjustment is completed, press [OK].

  • Page 55: Chart Adjustment

    PRESS C1100/C1085 )Chart Adjustment You can print out a Both Sides Adjustment chart, measure measurement points using a scale, and enter measurement values in order to carry out the adjustment. Using this function, you can only enter measurement values to carry out the both-side adjustment. This is convenient when an unclear misalignment is detected between the front and back sides to perform the duplex printing with a new type of paper or to change paper in a tray.
  • Page 56 Both Sides Adjustment Select [Front], then press [Chart Adjustment]. Press [Print Mode]. When the [PRINT MODE] screen is displayed, press Start on the control panel. A test chart is printed out. Press [Exit Print Mode].
  • Page 57 PRESS C1100/C1085 Measure the line length at each of points [1] to [8] on the printed-out chart using a scale. The figure on the right illustrates an example to measure points [1] and [5]. As illustrated in this example, measure the line length at each printed point.
  • Page 58 Both Sides Adjustment When entry processing is completed, press [Adjustment Start]. In the next step, adjust the back side. Select [Back], then press [Chart Adjustment]. Press [Print Mode]. When the [PRINT MODE] screen is displayed, press Start on the control panel.
  • Page 59 PRESS C1100/C1085 Press [Exit Print Mode]. Measure a misalignment between the marks of [1] to [4] printed on the [back] side of the output chart and the marks on the [front] side. The figure shows an example to measure [1].
  • Page 60 Both Sides Adjustment Press [X] or [Y] at each point, then enter the measured value using the keypad, [,], or [+] on the screen. If the printing position is misaligned to the minus (–) side, enter a positive value (+). If the printing position is misaligned to the plus (+) side, enter a negative value (–).

  • Page 61: Zoom And Image Shift Adjustment

    PRESS C1100/C1085 Press [Close] to exit the adjustment. Chart Adjustment is then completed. To register adjustment values in a paper profile, press [Register]. For details about how to register a paper profile, refer to the HTML User's Guide. )Zoom and Image Shift Adjustment You can finely adjust the zoom ratio of the print side and the top, bottom, left, and right positions on the front and back sides.
  • Page 62 Both Sides Adjustment Press [Both Sides Adj.]. Press [Front] or [Back] to select the print side to be adjusted. Enter the zoom ratio or the image shift value using the keypad, [,], or [+] on the screen or the Keypad on the control panel. To specify the zoom ratio, press [Vertical] or [Horizontal], then enter a value.
  • Page 63 PRESS C1100/C1085 Zoom ratio adjustment example: The image on the front side is 10 mm in a lengthwise direction while the image on the back side has been lengthened to 10.1 mm. Press [Vertical] of [Back], then press [1][0][0].
  • Page 64 Both Sides Adjustment After the adjustment is completed, press [OK]. Press [Close] to exit the adjustment. Zoom and Image Shift Adjustment is then completed. To register adjustment values in a paper profile, press [Register]. For details about how to register a paper profile, refer to the HTML User's Guide.

  • Page 65: Image Quality Adjustment

    PRESS C1100/C1085 Image Quality Adjustment Image Quality adjustment Adjust the color image quality at periodic intervals to maintain consistent printing results against a change in ambient temperature or humidity, a change of this machine conditions, or a change of the color tone due to the paper type or print mode.

  • Page 66: Daily Image Quality Management (Calibration)

    Image Quality Adjustment Daily image quality management (Calibration) You can maintain the color image quality by executing calibration at the appropriate timing. The reference value (target) of the entire printing system is registered in advance. Compare this reference value with the current measurement value to adjust the difference, and correct the printing density.

  • Page 67: Calibration Timing

    PRESS C1100/C1085 )Calibration timing Adjust the daily color image quality at the times and in the order shown below. Two methods are available: To use Relay Unit RU-511 and to use the colorimeter and Color Centro that is supplied with the image controller.
  • Page 68 Image Quality Adjustment Daily adjustment flow (High) In addition to "Daily Adjustment Flow (Standard)", carry out adjustments in the following cases, in particular: Immediately before an image, in which the hue is important, is output When the color stability is insufficient (when enhancing the reproducibility) When the paper type is different Order Menu item...

  • Page 69: Maximum Density Auto Adjustment (Ru)

    PRESS C1100/C1085 Maximum Density Auto Adjustment (RU) Automatically adjust the maximum density of each of yellow, magenta, cyan, and black, using the output paper density sensor that is installed on the Relay Unit RU-511. Carry out this function before carrying out the [Color Density Control] function.
  • Page 70 Image Quality Adjustment Load the paper that has been used to register the target density into the tray. The paper profile of the tray is automatically switched to the paper profile that has been used to register the target density. Select the tray containing paper, then press [OK].

  • Page 71: Color Density Control

    PRESS C1100/C1085 Color Density Control If a Relay Unit RU-511 is mounted on this machine, you can configure a setting so that this machine automatically executes calibration at periodic intervals. Calibration is executed every arbitrarily specified number of sheets, and you can keep printing using the appropriate density.
  • Page 72 Image Quality Adjustment Specify each item as follows: [Use Color Density Control] ... [ON] [Periodical Adj. Execution] ... [ON] [Adjustment Execution Timing] ... [Before Job Start] [Chart Tray Setting] ... [OFF] Press [Next]. Specify each item as follows: [Switch Color (1st or 2nd)] ... [Precise] NOTICE Select [Precise] or [Normal] depending on the situation.
  • Page 73 PRESS C1100/C1085 Press [Close]. Press [Exit [ADJUSTMENT]]. Automatic Adjustment is set. A chart is printed out periodically, and calibration is carried out automatically. Tips Selecting [Color Density Manual Control] can carry out the manual adjustment. 5-25...

  • Page 74: Manual Setting Of Color Density Manual Control

    Image Quality Adjustment )Manual setting of Color Density Manual Control Press [Adjustment] on the [MACHINE] screen. Press [Color Density Control]. Press [Color Density Manual Control]. This function is only available when [Use Color Density Control] is set to [ON] in [Color Density Control] - [Basic Setting].
  • Page 75 PRESS C1100/C1085 Press [Quality Adj.]. Press [)] of [Screen Pattern] to select a screen. Press [Close]. Press Start. A chart is printed out, and calibration is carried out. 5-27...

  • Page 76: Executing Calibration Using The Image Controller

    Image Quality Adjustment Executing calibration using the image controller This guide describes how to carry out calibration for daily maintenance using Color Centro and a colorimeter (FD- 5BT). In addition, "Exact Color" or "G7 Calibration", which enables higher accuracy adjustment are available. For details, refer to the HTML User's Guide.
  • Page 77 PRESS C1100/C1085 Select [Instrument] on the [Settings] menu, then select [FD-5BT(M0)]. Click [Settings] in [1. Paper Type/Screen Settings]. Select [Paper Type] and [Screen Settings] required for calibration, then click [OK]. Click [Start Calibration]. 5-29...
  • Page 78 Image Quality Adjustment Click [Print]. Select the paper tray required to print out a chart, then click [Print]. A chart is printed out a short while after this machine started running. Click [Start]. 5-30...

  • Page 79: Working Table

    PRESS C1100/C1085 When a message appears, place the FD-5BT on the white calibration plate, then click [OK] while holding it down. NOTICE When the FD-5BT is placed on the plate, it does not come into contact with the white calibration plate.
  • Page 80 Image Quality Adjustment Likewise, measure rows B to E. The measured parts are color-displayed on the screen in the same way as for the chart. When the measurement is completed, click [Register]. Unregistered calibration data is erased when Color Centro is closed. When the message is displayed, click [OK].
  • Page 81 PRESS C1100/C1085 Check the calibration data measurement result using the graph displayed in the [Density Output] area. To change and check the contents of the graph displayed in the [Density Output] area, adjust the check boxes on the right-hand side.

  • Page 82: Specifying The Reference Image Quality

    Image Quality Adjustment Specifying the reference image quality To stabilize the image quality of this machine, specify the reference values (targets) of the entire printing system in advance. If you change the setting value in [Custom Screen], hue variations may be drastically changed. If you change the screen, specify the standard image quality following the procedure to avoid hue variations.

  • Page 83: Adjusting The Finisher And Saddle Stitcher

    PRESS C1100/C1085 Adjusting the Finisher and Saddle Stitcher Opening the screen to be adjusted When the finisher or saddle stitcher is mounted on this machine, you can finely adjust various functions such as fold positions or staple positions. Reference For details about how to adjust the finisher, refer to the HTML User's Guide.

  • Page 84: Adjustable Settings

    Adjusting the Finisher and Saddle Stitcher Press the items to be adjusted. The items displayed on this screen vary depending on the model of the mounted finisher. )Adjustable settings The following shows item examples that are displayed on the screen. The items displayed on this screen vary depending on the model of the mounted optional device.

  • Page 85: Troubleshooting

    PRESS C1100/C1085 Troubleshooting Replenish and Replace Consumables )Replacing a toner bottle WARNING WARNING WARNING Do not throw the toner bottle or toner into an open flame. The hot toner may scatter and cause burns or other damage. CAUTION CAUTION Do not leave toner-related parts (toner bottles or PC drum units) within easy reach of children.
  • Page 86 Replenish and Replace Consumables NOTICE To replace a toner bottle, check the toner type number indicated on the toner bottle cover. Use of incorrect toner bottles may cause the machine trouble. Press on the upper-right corner of the touch panel or Help on the control panel to display the help message.

  • Page 87: Replacing A Staple Cartridge

    PRESS C1100/C1085 Attach the cap of a new toner bottle to the used toner bottle, then place it into the package. For the subsequent treatment, contact your service representative. )Replacing a staple cartridge If staples run out, the message [Please add staples to the saddle stitcher left side stapler] is displayed on the [MACHINE] screen, and the [Staple Cartridge] indicator changes to red in the [Consumable and Scrap Indicators] display.
  • Page 88 Replenish and Replace Consumables Press [Consumable/Scrap]. Press the [Add Stapler] tab of the required saddle stitcher, then follow the on-screen instructions to replace a staple cartridge. The number on the right-hand side of the help message indicates a replacement procedure. To display the next step, press [,].

  • Page 89: Replacing A Waste Toner Box

    PRESS C1100/C1085 )Replacing a waste toner box WARNING WARNING WARNING NEVER throw the waste toner box into a fire. Otherwise, the toner may ignite and cause a dangerous situation. If the waste toner box fills up with waste toner, the message [Waste toner box is full Please replace the box] is displayed on the [MACHINE] screen, and the [Waste Toner Box] indicator changes to red in the [Consumable and Scrap Indicators] display.
  • Page 90 Replenish and Replace Consumables Press [Consumable/Scrap]. Press the [Waste Toner] tab, then follow the on-screen instructions to replace the waste toner box. The number on the right-hand side of the help message indicates a replacement procedure. To display the next step, press [,].

  • Page 91: Clearing Paper Jams

    PRESS C1100/C1085 Clearing Paper Jams How to view the animation guide If a paper jam occurs on this machine, the message [Mishandled paper / Please remove paper following the guide] is displayed, and the position of the paper jam is displayed on the screen.

  • Page 92: Illustration Screen For Jam Handling

    Clearing Paper Jams )Illustration screen for Jam handling The overview of the method required to clear the jam is displayed on the [JAM Position] screen. Changing to the Illustration screen displays the procedure guidance, so you can clear a paper jam while checking each step. Press [Illustration] on the [JAM Position] screen.
  • Page 93 PRESS C1100/C1085 Remove all jammed paper, then press [Close]. This returns to the [MACHINE] screen. Tips If the paper jam message has not been yet cleared even after all the jammed paper has been removed, the paper jam may have occurred in a place other than the one displayed. Check other places not displayed on the touch panel again.

  • Page 94: If The Specified Paper Is Not Found

    If the Specified Paper is not Found If the Specified Paper is not Found If the specified paper is not loaded into a tray at the time of printing, the message [Please load designated xxx paper / To check details, touch [Confirm Details]] is displayed on the screen. To address this problem, load the specified paper into a tray, or you can forcibly print on the currently loaded paper of a different size.
  • Page 95 PRESS C1100/C1085 Replace paper into the tray, then press [OK]. Press Start on the control panel. Printing starts using the selected tray. 6-11...

  • Page 96: Forcibly Printing Using The Loaded Paper

    If the Specified Paper is not Found )Forcibly printing using the loaded paper Press [Confirm Details] on the [MACHINE] screen. Select a tray with print paper loaded, then press [Forced Output]. Press Start on the control panel. Printing starts using the selected tray. 6-12...

  • Page 97: If An Error Has Been Displayed During Scanning

    PRESS C1100/C1085 If an Error has been Displayed during Scanning If a problem such as an HDD space insufficiency has occurred, an error message is displayed. Check the message content, then take the appropriate action. This section describes how to handle an HDD space insufficiency.

  • Page 98: Hue Adjustment

    Hue Adjustment Hue Adjustment Various problems, for example, the current hue is different from the previous one or the expected chromogenic effect has not been obtained, are caused due to a change in ambient temperature or humidity, a change of the machine conditions, or a change of the color tone by the paper type or print mode.

  • Page 99: Image Position Adjustment

    PRESS C1100/C1085 Image Position Adjustment The previously adjusted image position may be misaligned by a slight enlargement or reduction of paper that is caused due to a change in ambient temperature or humidity, a change of the machine conditions, usage of a different type of paper, or heat impact of the Fusing Unit.

  • Page 100: Appendix

    Good Use of the HTML User's Guide Appendix Good Use of the HTML User's Guide The HTML User's Guide is included in the User's Guide CD supplied with this machine. Select the desired item on the top page (Home), then check the detailed contents. To view the details about how to use the HTML User's Guide, select [User's Guides] on the top page (Home).

  • Page 101: Name Of Each Component

    PRESS C1100/C1085 Name of each Component External components Name Description Toner access door When adding toner, press the left-hand lever to open this door. Touch panel Displays a screen such as the [MACHINE] screen to enable you to carry out machine operations and settings. Also, operation or troubleshooting procedures can be provided.
  • Page 102 Name of each Component Name Description Dust proof filter A dust proof filter is installed in the built-in cooling fan to keep out dust. Power cord Supplies this machine with electricity. Image Controller IC-602 Required to use this machine as a printer or scanner. Port (type B) (USB 2.0/1.1 compati- Connected to use this machine as a USB-connected printer.

  • Page 103: Internal Components

    PRESS C1100/C1085 Internal components Name Description Main power switch Turns the main power of the machine on or off. The main power is basically turned on or off by your service rep- resentative. Be sure not to turn the main power switch off in usu- al operation.
  • Page 104 Name of each Component Name Description Conveyance fixing unit Pulled out to remove jammed paper. For information about how to handle levers and knobs of the conveyance fixing unit, refer to the screen displayed when a paper jam has occurred. Lever [M1] Locks the conveyance fixing unit.

  • Page 105: Control Panel Layout

    PRESS C1100/C1085 Control Panel Layout Name Description Keypad Enter the values such as the number of copies or the zoom ratio. Reset * Returns the contents you entered or changed on the control panel to the default settings. Power LED Lights up in red when the main power switch is turned on, then lights up in green when the sub power switch is turned on.
  • Page 106 Name of each Component Name Description Start LED Indicates the status of this machine with LED colors. • Light up in blue: This machine is ready to start operations. • Light up in orange: This machine is not ready to start opera- tions.

  • Page 107: Convenient Use Of Scan Function (Scan To Smb)

    PRESS C1100/C1085 Convenient Use of Scan Function (Scan to SMB) You can send the scan data as an E-mail attachment, send it to the shared computer (SMB server), FTP server, or WebDAV server, or save it on the USB flash drive installed on this machine.
  • Page 108 Convenient Use of Scan Function (Scan to SMB) Enable file sharing. In Windows 7/8/8.1, select [Control Panel] - [Network and Internet] - [Network and Sharing Center] - [Change advanced sharing settings], then click [Turn on file and printer sharing] in the [Advanced sharing settings] window.

  • Page 109: In A Macintosh Environment

    PRESS C1100/C1085 )In a Macintosh environment Tips To carry out this task, the computer's administrator privilege is required. Select [About This Mac] - [More Info] to check [IP Addresses] and [User name]. Enable file sharing. In the Apple menu, click [System Preferences] - [Sharing] to open the [Sharing] window, then select the [File Sharing] check box.

  • Page 110: Step 5: Send Scan Data To A Public Folder

    Convenient Use of Scan Function (Scan to SMB) Step 5: Send scan data to a public folder Send scan data to a public folder of the registered SMB server. In the [SCAN] screen of this machine, select an SMB destination, configure the scan conditions, then press Start. Reference You can specify conditions such as the image quality and scanning size.

  • Page 111: Major Specifications

    PRESS C1100/C1085 Major Specifications NOTICE The specifications of the machine and optional device are subject to a change without notice. Even if the specified paper size and weight are compatible with an optional device, if they are not supported by the entire system including the machine, the paper may not be able to be used.

  • Page 112: Paper Feeder Unit Pf-708

    Major Specifications Specifications Paper weight 55 g/m to 350 g/m / 13 lb Bond to 93 lb Bond • Coated paper: 81 g/m to 350 g/m / 22 lb Bond to 93 lb Bond Paper size When installed as the first paper feeder unit: •...

  • Page 113: Post Inserter (Folding Unit Fd-503)

    PRESS C1100/C1085 Specifications Paper size • SRA3 w, A3 w, B4 w, SRA4 w/v, A4 w/v, B5 w/v, A5 w/v, B6 w, A6 w, 13 e 19 w, 12 e 18 w, 11 e 17 w, 9 e 11 v, 8.5 e 14 w, 8.5 e 11 w/v, 5.5 e 8.5 w/v, 8K w, 16K w/v, Foolscap* •...

  • Page 114: Post Inserter Pi-502

    Major Specifications )Post Inserter PI-502 To use Post Inserter PI-502, mount it in Finisher FS-532. You can load paper into the upper and lower trays of Post Inserter PI-502 and feed paper to an output-related optional device. On the control panel of Post Inserter PI-502, you can configure the punch, staple, or fold function for paper to be fed from the lower tray.

  • Page 115: Output-Related Optional Devices

    PRESS C1100/C1085 Output-related optional devices Reference The paper size and weight vary depending on conditions such as setting or finishing. For details about the detailed conditions or specifications, refer to the HTML User's Guide. )Relay Unit RU-511 Conveyance Unit...

  • Page 116: Relay Unit Ru-510

    Major Specifications )Relay Unit RU-510 Conveyance Unit Specifications Function • Multi reversed paper conveyance • Reversed paper conveyance • Straight delivery Paper weight 40 g/m to 350 g/m / 11 lb Bond to 93 lb Bond SRA3 w, A3 w, B4 w, SRA4 w/v, A4 w/v, B5 w/v, A5 w/v, A6 w, Paper size •...
  • Page 117 PRESS C1100/C1085 Specifications: Straight delivery Sheet volume Primary (main) tray • 2500 sheets (80 g/m / 21 lb Bond): A4 w/v, B5 w/v, 9 e 11 v, 8.5 e 11 w/v, 7.25 e 10.5 w/v, 16K w/v • 1500 sheets (80 g/m / 21 lb Bond): SRA3 w, A3 w, B4 w, SRA4 w/v, 13 e 19 w, 12 e 18 w, 11 e 17 w, 8.5 e 14 w, 8K w, Foolscap*...

  • Page 118: Large Capacity Stacker Ls-506

    Major Specifications )Large Capacity Stacker LS-506 Output tray 1: Stacker tray 2: Secondary (sub) tray Specifications Function • Stacker tray with carriage • Sort output / group output (Offset output enabled) Paper weight Stacker tray: 50 g/m to 350 g/m / 13 lb Bond to 93 lb Bond Secondary (sub) tray: 40 g/m to 350 g/m...
  • Page 119 PRESS C1100/C1085 Specifications: Fold & Staple Paper size • SRA3 w, A3 w, B4 w, SRA4 w, A4 w, B5 w, 12 e 18 w, 11 e 17 w, 8.5 e 14 w, 8.5 e 11 w, 7.25 e 10.5 w, 8K w, 16K w, Foolscap* •...

  • Page 120: Perfect Binder Pb-503

    Major Specifications )Perfect Binder PB-503 Output tray Function Perfect binding Specifications Paper weight Perfect binder tray • Body set: 62 g/m to 105 g/m / 16 lb Bond to 28 lb Bond • Cover: 81 g/m to 216 g/m / 22 lb Bond to 57 lb Bond Secondary (sub) tray •...

  • Page 121: Finisher Fs-532

    PRESS C1100/C1085 )Finisher FS-532 To use the punch function, the Punch Kit PK-522 is required. Saddle Stitcher SD-510 is required to use the Multi Half-Fold, Multi Tri-Fold, and Fold & Staple functions. Output tray Function Staple Punch Multi Half-Fold Multi Tri-Fold Fold &...
  • Page 122 Major Specifications Specifications: Staple Paper weight 50 g/m to 300 g/m / 13 lb Bond to 81 lb Bond SRA3 w, A3 w, B4 w, SRA4 w/v, A4 w/v, B5 v, A5 v, Paper size • 13 e 19 w, 12 e 18 w, 11 e 17 w, 9 e 11 v, 8.5 e 14 w, 8.5 e 11 w/v, 7.25 e 10.5 v, 5.5 e 8.5 v, 8K w, 16K v, Foolscap* •...
  • Page 123 PRESS C1100/C1085 Specifications: Staple 257 g/m to 300 / 69 lb Bond to 80 lb Bond 301 g/m – – – – – – to 350 / 81 lb Bond to 93 lb Bond Number of stored copies •...

  • Page 124: Multi Puncher Gp-501

    Major Specifications Specifications: Multi Half-Fold / Multi Tri-Fold (with Saddle Stitcher SD-510 mounted) Paper weight Multi Half-Fold: 50 g/m to 216 g/m / 13 lb Bond to 57 lb Bond (Cover: 50 g/m to 300 g/m / 13 lb Bond to 81 lb Bond) Multi Tri-Fold: 50 g/m to 105 g/m / 13 lb Bond to 28 lb Bond...

  • Page 125: Electronic Optional Devices

    PRESS C1100/C1085 )Auto Ring Binder GP-502 Binder Unit Function Bind Specifications Paper weight Body: 75 g/m to 120 g/m / 20 lb Bond to 32 lb Bond Cover: 163 g/m to 216 g/m / 44 lb Bond to 57 lb Bond Tabbed paper: 163 g/m max.

  • Page 126: Original-Related Optional Devices

    Major Specifications )Image Controller IC-310 Specifications Function External print server Capacity • HDD capacity: 500 GB • Memory capacity: 8 GB Built-in fonts European 138 fonts Page description language Adobe PostScript3 (3019) )Authentication Unit AU-201 Specifications Function User Authentication Unit for Non-Contact IC Card Reading Applied cards FeliCa, TypeA, SSFC, FCF, FCF (campus) Original-related optional devices...

  • Page 127: Weight For Each Size

    PRESS C1100/C1085 Weight for each size NOTICE The product specifications are subject to a change without notice. )Weight for each size The paper weight (g/m / lb Bond) or ream weight (kg) unit is used to indicate the paper thickness, which varies depending on the manufacturer.

  • Page 128: Maximum Paper Size And Printing Area

    Maximum paper size and printing area Maximum paper size and printing area The maximum paper size and printing area that are available are as follows. Refer them when you output data or perform an imposition printing. 487.7 mm / 19.20" Maximum printing area Crosswise direction: 321 mm / 12.64"...
  • Page 129 PRESS C1100/C1085 MEMO 7-30...
  • Page 130 MEMO 7-31...
  • Page 131 http://www.konicaminolta.com Printed in China A5AW956111 © 2014 2014. 9...
