- Page 1 English Quick Guide DP700 Series Programmable Linear DC Power Supply Mar. 2016 RIGOL TECHNOLOGIES, INC.
-
Page 2: Guaranty And Declaration
RIGOL products are covered by P.R.C. and foreign patents, issued and pending. RIGOL reserves the right to modify or change parts of or all the specifications and pricing policies at the company’s sole decision. Information in this publication replaces all previously released materials. -
Page 3: General Safety Summary
RIGOL General Safety Summary English Only the exclusive power cord Avoid circuit or wire exposure. designed for the instrument Do not operate the instrument and authorized for use within with suspected failures. the local country could be 10. Provide adequate ventilation. -
Page 4: Care And Cleaning
RIGOL Safety Symbols on the Product: English Hazardous Safety Protective Earth Chassis Ground Test Ground Voltage Warning Terminal Care and Cleaning Care Do not store or leave the instrument where it may be exposed to direct sunlight for long periods of time. -
Page 5: Document Overview
English This manual introduces some basic information that you should know when you use the DP700 series power supply for the first time. It contains the following contents: out-of-box inspection method, product overview, how to connect the instrument to the AC power, procedures for carrying out the power-on inspection and output inspection, as well as remote control overview. -
Page 6: General Inspection
The consigner or carrier shall be liable for the damage to the instrument resulting from shipment. RIGOL would not be responsible for free maintenance/rework or replacement of the instrument. 2． Inspect the instrument... -
Page 7: Product Overview
RIGOL Product Overview English DP700 series power supply is a type of affordable programmable linear DC power supply with high performance. With superb performance specifications, pure and reliable output, and clear user interface, the DP700 series supports timing output and trigger function, and provides a remote communication interface, enabling you to meet your diversified test requirements. - Page 8 2. AC Power Supply Connector 3. RS232 Interface 4. Air Outlet RIGOL TECHNOLOGIES,INC. MADE IN CHINA Figure 2 Rear Panel Note: Pin 7 and Pin 8 of the RS232 interface are not used in remote communication. They are used in the trigger function (optional).
-
Page 9: Power-On Inspection
English DP700 series power supply supports various specifications of AC input power. When the DP700 series is connected with different AC power supplies, the AC selector setting on the rear panel of the instrument is different, as shown in the table below. - Page 10 RIGOL 5． Power on the instrument English Press the Power key , and then the instrument is launched and begins to perform the self-inspection. If the instrument passes the self-inspection, the welcome interface is displayed; otherwise, self-inspection failure information about corresponding items (including the analog board, OVP, OCP, fan, and temperature) will be displayed.
- Page 11 RIGOL output voltage is approximately 30 V, the actual output current English approximately 0 A. (5) Press On/Off to turn off the channel output. Check the current output: verify the basic current functions with a short across the power supply’s output.
- Page 12 RIGOL Setting Methods for Output Voltage/Output Current: English Method 1: (1) Press the Up/Down arrow key to switch the parameter focus to "Voltage Voltage Setting Value" or "Current Setting Setting Value Value". Current (2) Enter a value by using the num key.
-
Page 13: Remote Control
Remote Control English DP700 series power supply can be connected to the PC via the RS232 interface to set up communication and realize remote control through the PC. The remote control can be realized by using SCPI (Standard Commands for Programmable Instruments) commands.
