H/W Monitor - Nexcom NEX 613 User Manual

Chapter 3: BIOS Setup

H/W Monitor

This section is used to monitor hardware status such as temperature, fan
speed and voltages.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Main Advanced H/W Monitor Boot
Hardware Health Event Monitoring
CPU Temperature : 54 °C
M/B Temperature : 29 °C
CPU_FAN1 Speed : N/A
CHA_FAN1 Speed : 2163 RPM
Vcore : +1.776 V
+ 3.30V : +3.376 V
+ 5.00V : +5.088 V
+ 12.00V : +11.985 V
[Full On]
CPU_FAN1 Setting
CHA_FAN1 Setting [Full On]
Over Temperature Protection [Disabled]
Case Open Feature [Disabled]
Version 2.15.1234. Copyright (C) 2012 American Megatrends, Inc.
CPU Temperature
Detects and displays the current CPU temperature.
M/B Temperature
Detects and displays the current motherboard temperature.
CPU_FAN1 Speed
Detects and displays CPU_FAN1 speed.
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
Security Exit
Quiet Fan Function Control
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Option
F1: General Help
F7: Previous Values
F9: Load UEFI Defaults
F10: Save and Exit
ESC: Exit
CHA_FAN1 Speed
Detects and displays CHA_FAN1 speed.
Vcore
Detects and displays the Vcore CPU voltage.
+ 3.30V
Detects and displays 3.3V voltage.
+ 5.00V
Detects and displays 5V voltage.
+ 12.00V
Detects and displays 12V voltage.
CPU_FAN1 Setting
Configures the speed of the CPU fan.
CHA_FAN1 Setting
Configures the speed of the chassis fan.
Over Temperature Protection
Enables or disables Over Temperature Protection.
Case Open Feature
Enables or disables the case open detection feature.
28
NEX 613 User Manual
