Summary of Contents for HygroMatik C01 KIT

  • Page 1 Manual CompactLine KIT Electrode Steam Humidifier...
  • Page 2 Because of this you should monitor your new unit during initial operation. Make sure that it has been properly installed and is operating to your satisfaction. Consult your HygroMatik specialists. We will test the quality of your water and advise you on installation and initial operation. Your HygroMatik steam humidifier will be carefully adapted to your particular application.
  • Page 3: Table Of Contents

    1. Introduction ........................5 1.1 Directions for Use ......................5 1.2 Typographic Distinctions ....................6 1.3 Documentation ........................7 2. Safety Notes ........................8 2.1 Overview ........................... 8 2.2 Guidelines for Safe Operation ................... 8 2.3 Disposal after Dismantling ....................9 3.
  • Page 4 7.1 Electrical Installation ......................37 7.2 Safety Interlock ........................40 7.3 Wiring Diagram ........................40 7.4 Electrical Installation Checklist ..................40 8. Maintenance ........................41 8.1 Maintenance Work ......................42 8.1.1 Cleaning the Steam Cylinder ..................43 8.1.2 Electrode Wear ....................... 45 8.2 Replacing Electrodes ......................
  • Page 5: Introduction

    They will impress you with their safety, ease of use and econom- ical operation. In order to operate your HygroMatik steam humidifier safely, properly and efficiently, please read these operating instructions. Employ your steam humidifier only in sound condition and as directed.
  • Page 6: Typographic Distinctions

    C2: Range of high conductivity (adjustments recommended) D2: Upper threshold Warning: HygroMatik steam humidifiers emit steam with a tem- perature of 100° C. The steam may not be inhaled directly. The HygroMatik Steam Humidifier is not designed for outdoor fit- ting 1.2 Typographic Distinctions •...
  • Page 7: Documentation

    If the product is resold, turn the documenta- tion over to the new operator. If the documentation is lost, please contact HygroMatik. Versions in Other Languages These operating instructions are available in several languages. If interested, please contact HygroMatik or your HygroMatik dealer. Page 7...
  • Page 8: Safety Notes

    2. Safety Notes 2.1 Overview These safety notes are required by law. They promote work- place safety and accident prevention. Warnings and Safety Symbols The safety symbols below identify sections containing warnings about hazards or potential dangers. Please familiarize yourself with these symbols.
  • Page 9: Disposal After Dismantling

    HygroMatik steam humidifiers are IP20-protected. Make sure that the unit is protected from drips in its installed location. Installing a humidifier in a room without water discharge requires safety devices to protect against water leakages. Accident Prevention Regulations Comply with the Accident Prevention Regulation Electrical Sys- tems and Equipment to prevent injury to yourself and others.
  • Page 10: Transport

    3. Transport 3.1 Overview Note: Proceed carefully when transporting the steam humidifier in order to prevent damage due to stress or careless loading and unloading. 3.2 Carton outer Size and Weight Type* Height Width Depth Weight [cm] [cm] [cm] [kg] C01KIT C02KIT - C10KIT...
  • Page 11: Operation And Installation

    4. Operation and Installation 4.1 Mode of Operation The HygroMatik steam humidifier utilizes the conductivity nor- mally present in tap water for steam production. Electrodes inside an enclosed steam cylinder are immersed directly into the tap water. They are connected to the alternating current.
  • Page 12 Please also see Section „Exploded View“. Location Designation adapter vent pipe max. water level sensor electrode water drain, discharge top part of steam cylinder o-ring cylinder flange cylinder flange and o-ring lower part of cylinder solenoid valve water inlet blow-down pump o-ring cylinder base electrodes...
  • Page 13 The concentration of dissolved salts increases over time, which can lead to a rise in the conductivity of the water. If this contin- ues, conductivity may increase until a short circuit occurs. This could damage the unit, but in any case would significantly reduce the life span of the electrodes.
  • Page 14: Installation

    The minimum clearances indicated in the diagram below must be observed; these are necessary to ensure adequate ventilation for the housing. • HygroMatik humidifiers are not suitable for direct out- door installation. • The steam humidifier should be installed as close as possible to the steam manifold.
  • Page 15: Fitting

    5.1.1 Fitting Wall Mounting Note: To function properly the steam humidifier must be installed verti- cally. » Position the steam humidifier in the planned location, adjust with spirit level and mark position of hanging bolts. » Hang the unit onto bolts screwed into the marked posi- tion and tighten.
  • Page 16: Equipment Dimensions Compactline Kit

    5.1.2 Equipment Dimensions CompactLine KIT Dimension [mm] Dimensions DBE 17-45 Page 16...
  • Page 17: Fan Unit (Optional)

    5.2 Fan Unit (optional) Note: The fan unit should be positioned to avoid drafts. In gen- eral, a minimum height of 2 m is sufficient. Install the fan unit directly on a wall. Fan Unit Type for wall installation VG 08, 17, 30 Warning: •...
  • Page 18: Absorption Distance Bn

    5.3 Absorption Distance B The "absorption distance" (B ) is defined as the distance from the steam feed to where the steam is completely absorbed in the treated air. Inside the absorption distance, steam is visible as mist in the air stream. Condensation may collect on anything installed inside the absorption distance.
  • Page 19 Length I of the usable steam manifold depends on the dimen- sions of the air duct. The length of the absorption distance can be reduced by using multiple steam manifolds (also see section on the steam manifold). Method: Graphically determine absorption distance B using the absorp- tion distance nomogram (also see Section „Absorption Distance Nomogramm“).
  • Page 20: Absorption Distance Nomogram

    5.3.2 Absorption Distance Nomogram Source: Henne, Erich: Luftbefeuchtung (Air Humidification), 3 Edition 1984 (Page 101), Olden- bourg Industrieverlag, Munich Page 20...
  • Page 21: Steam Manifold

    5.4 Steam Manifold 5.4.1 Notes on Installation These notes are based on a homogeneous Horizontal installation of Standard steam manifold installation: steam manifold Duct Steam Manifold Air flow L1=L2=L3 An even distribution of steam manifolds ensures a uniform steam distribution. Please use the total hight of the duct! Steam Manifold Air flow...
  • Page 22 Air duct Positioning of steam manifolds Sample flat Staggered vertically and laterally Air flow very flat By tilting the steam manifold 30 - 45° very flat duct towards the air flow direction, the mini- mum upper clearance can be reduced to 70mm.
  • Page 23 With high-pressure air-conditioning systems, the unit's drain hose system must be modified depending on the over pressure. When this is the case please consult HygroMatik. • Install the steam manifold as close as possible to the steam humidifier in order to minimize steam loss through condensation.
  • Page 24 2x(2xDN40) 2x(1xDN40) 2x(1xDN12) * For units HL 6 - 12 and HC3-12 HygroMatik delivers one adapter DN40 / 25 (but not for SPA applications).. ** For units HL 36 - 45 HygroMatik delivers one t-connector for separating the steam on two steam manifolds.
  • Page 25: Steam Line

    Note: When installing the steam hose, please pay attention to the following: • The steam hose diameter may not be smaller than the steam outlet of the HygroMatik steam humidifier (do not restrict the cross-section, otherwise back pressure will increase). •...
  • Page 26: Cover Plate

    5.6 Cover Plate HygroMatik flange plates may be used to neatly complete instal- lation of the steam humidifier in the air duct. Two-piece flange plates are available for the DN25 and DN40 steam manifolds. flange plate DN25 E-2604260 flange plate DN40 E-2604410...
  • Page 27: Drill Pattern

    5.7 Drill Pattern 5.7.1 Drill Pattern DN25 (not to scale) Note: Due to variable print media the dimensions are not to scale. Page 27...
  • Page 28: Drill Pattern Dn40 (Not To Scale)

    5.7.2 Drill Pattern DN40 (not to scale) Note: Due to variable print media the dimensions are not to scale. Page 28...
  • Page 29: Condensate Hose

    5.8 Condensate Hose Note: When installing the condensate hose, please pay atten- tion to the following: Warning: To keep condensate from accumulating in the duct, make sure condensate can drain freely. If the steam manifold is positioned higher than 500 mm above the steam humidifier: »...
  • Page 30 Steam hose with falling slope Steam hose with rising slope Steam manifold is positioned below the steam humidifier. » Lay steam hose at a height of at least 400 mm and then connect to the steam manifold with a constant fall. »...
  • Page 31 Detail X: wrong! Page 31...
  • Page 32: Steam Solenoid Valves

    5.10 Steam Solenoid Valves When humidifying a number of loads, which are to be controlled separately, using a single steam humidifier, steam solenoid valves can be included in the steam hoses. Valve control has to provided by the customer. • Install the vertical risers with flow from bottom to top.
  • Page 33: Water Installation

    For water installation please use the water connecting hose that is delivered with the unit. 6.1 Operation with Softened Water Warning: Unless special measures are taken, feeding softened water into the HygroMatik steam humidifier is dangerous. It can cause • unacceptably high conductivity •...
  • Page 34: Water Supply

    Note: Please contact HygroMatik if you wish to operate the unit with softened water. If using a water softening system, we recommend diluting the softened water with normal tap water to produce an overall hard- ness between 4-8°dH. This value can be set lower if the water does not foam.
  • Page 35: Water Discharge

    » Use a cap nut (internal thread ¾“) with inner seal for a customer-provided water installation. 6.3 Water discharge min.: 250mm max.: 1000mm Warning: During blow down hot water with a temperature of about 95°C is being drained. If touched this can cause burns to the skin.
  • Page 36: Water Installation Check

    There is a 3mm-wide crack between the pump drain hose jacket and the inner surface of the housing drain connection. If water collects in the base plate, it will flow through this crack into the drainage system. 6.4 Water Installation Check Go down the following water installation checklist: ...
  • Page 37: Electrical Connection

    7. Electrical Connection Danger, Hazardous Voltage: All work related to electrical instal- lation to be performed by authorized personnel only (electricians or professionals with equivalent training). The customer is responsible for checking qualifications. Danger, Hazardous Voltage: Do not plug the steam humidifier into the power grid until after all installation work has been com- pleted.
  • Page 38 HyLine: Type Main Power Supply HY05 - HY45 1 x 400V/3Phase/N HY60 - HY116 2 x 400V/3Phase/N CompactLine: Type Main Power Supply CompactLine 1 x 400V/3Phase/N MiniSteam: Type Main Power Supply 1 x 400V/3Phase/N MS10 1 x 230/1Phase/N CompactLine KIT: Type Main Power Supply C01KIT, C02KIT...
  • Page 39 CompactLine: Type Power Usage Circuit Protection 6,5 A 3 x 10 A 10,8 A 3 x 16 A 18,4 A 3 x 20 A 23,8 A 3 x 35 A 32,5 A 3 x 35 A 48,8 A 3 x 63 A 62,8 A 3 x 63 A MiniSteam:...
  • Page 40: Safety Interlock

    7.2 Safety Interlock Note: Install contact interlocks, i.e. max. hygrostat, vane relay, pressure controller, air interlock, in series between terminals 1 and 2. Warning: A max-hygrostat should be installed in the safety inter- lock. The max-hygrostat acts as a safety device in case the humidity sensor malfunctions.
  • Page 41: Maintenance

    8. Maintenance The HygroMatik steam humidifier is easy to maintain. However, inadequate or improper maintenance can lead to operational malfunctions. Perform regular maintenance to give your unit a long life span. Warning: When performing maintenance work, please note: • During operation and also for a while after switching off the unit the steam cylinder is hot.
  • Page 42: Maintenance Work

    In extreme cases, water pretreatment may be necessary (soft- ening by dilution to approx. 4 - 8 °dH; decarbonization/partial desalination to achieve target reductions in carbonate hard- ness). HygroMatik would be pleased to refer you to companies specializing in water treatment systems. Page 42...
  • Page 43: Cleaning The Steam Cylinder

    Warning: Both the clamps that fix the steam cylinder halves and the electrodes have sharp edges and angles that possibly could lead to cut injuries. 8.1.1 Cleaning the Steam Cylinder Disassembly » Drain residual water in the cylinder. » Press the on/off control switch in position "II". »...
  • Page 44 » Remove o-ring (35) from the lower part of the cylinder. » Insert a new solvent-free, moistened HygroMatik o-ring (35) into the cylinder base. Note: The types C02KIT and C06KIT are supplied with a steam hose adapter (1). Exchange o-ring if maintenance steam cylin- der.
  • Page 45: Electrode Wear

    "Cylinder full" condition. As a guide they must still be a third to one half their original length. The original length of HygroMatik stainless steel large-area elec- trodes is as follows: Type...
  • Page 46: Replacing Electrodes

    In this case please contact HygroMatik for advice. remove handnut remove electrode detailed view...
  • Page 47 • black slime collects inside the cylinder, or • there is "lightning" in the cylinder, the conductivity of the water is too high or it isn't decanted often enough. In this case please contact HygroMatik. Page 47...
  • Page 48: Cleaning The Blow- Down Pump

    8.3 Cleaning the Blow- Down Pump » Remove cylinder » Detach e-cable from the pump. » Detach adapter (30) from the pump. » Loosen screws (44) and remove the pump from the base. » Open the pump (bayonet lock). » Remove residues from the drain hoses and pump (if neccessary replace o-ring (33) or housing (34) if these components are no longer in excellent condition).
  • Page 49: Cleaning The Water Inlet Solenoid Valve

    8.4 Cleaning the Water Inlet Solenoid Valve Removal » Shut off water supply and loosen water installation hose connection. » Remove cylinder; please also see chapter „Removing and Cleaning Steam Cylinder“ » Loosen connecting hose (21) from the base. » Detach e-cable from the solenoid valve.
  • Page 50: Chekking Cable Connections And Electrode Cables

    8.5 Chekking Cable Connections and Electrode Cables » Make sure that no cable and plug connections are loose. Warning: Plugs must be pressed down onto electrodes as far as they will go. Loose cable connections cause excessive contact resistance and overheating of contact surfaces. »...
  • Page 51: Checking Operation

    8.6 Checking Operation Start up the unit and operate for a few minutes at maximum out- put if possible. » Check safety devices. » Check hose connections for possible leaks. 8.7 Dismantling After you stop using the steam humidifier, dismantle (demolish or scrap) it by following the installation procedures in reverse order.
  • Page 52: Spare Parts

    9. Spare Parts Description CompactLine KIT 01 02 06 10 17 30 45 Article No. Bracket Steam section retaining bracket E-210101 4 E-210701 2 Steam section retaining bracket E-210701 6 Steam section retaining bracket Steam Generation Steam cylinder CY1 compl. with electrodes an d B-321613 1 Hand nuts Steam cylinder CY2 compl.
  • Page 53: Water Drain

    Description CompactLine KIT 10 17 30 45 Article No. B-320404 7 Sen sor electrode compl. without hand nut Sen sor electrode compl. without hand nut B-320403 7 B-320402 7 Sen sor electrode compl. without hand nut Sen sor electrode compl. without hand nut B-220407 5 Plu g-in contact wi th insulating hose fo r sensorelectrode...
  • Page 54 Description CompactLine KIT 10 17 30 45 Article No. E-322000 5 O-rin g for adapter pump - drai n hose O-rin g cylinder base - pump E-322000 5 B-240402 7 Drain pump without mounting set Drain pump housing E-240400 8 O-rin g seal for d rain pump E-240400 6 B-242401 4...
  • Page 55: Fax Form - Order For Spare Parts

    10. Fax Form - Order for spare parts Fax Form Please copy, fill in and fax to HygroMatik GmbH Lise-Meitner-Str. 3 . +49(0)4193/895-31 Fax.No 24558 Henstedt-Ulzburg Tel. +4904193/895-0 Order of spare parts unit type *______________ serial no.* ___________________ commission: ______________ order no.: __________________...
  • Page 56: Exploded View

    11. Exploded View Page 56...
  • Page 57: Technical Specification

    12. Technical Specification Technical data C01KIT - C45KIT Type Steam output [kg/h] Power supply * 230V/1/N 400V/3/N 50-60Hz Power Usage [kW] 0,75 12,8 22,5 33,8 Input [A] 10,8 18,4 32,5 48,8 Circuit Protection [A]*** 1x10 3x10 3x16 3x25 3x35 3x63 Control Control voltage 230 V...
