NAVIGATOR
/POOLVAC V-FLEX SERIES
Suction Pool Cleaner
Owner's Manual
Hayward Pool Products (Australia) Pty Ltd
PO Box 4384, Dandenong South, VIC, 3164
Ph: 1300 POOLS1
W: www.hayward-pool.com.au
ISM0925AU rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Navigator V-Flex and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hayward Navigator V-Flex

  • Page 1 ® NAVIGATOR /POOLVAC V-FLEX SERIES Suction Pool Cleaner Owner’s Manual Hayward Pool Products (Australia) Pty Ltd PO Box 4384, Dandenong South, VIC, 3164 Ph: 1300 POOLS1 W: www.hayward-pool.com.au ISM0925AU rev. A...
  • Page 2: Safety Warnings

    Store the cleaner in a shaded safe area. Hayward Turbine Cleaners are powered by your pool’s filter system and are Hoses must be stored straight. DO NOT coil the hose. designed to work well with most systems. The performance of the Cleaner in your pool will be relative to its power source.
  • Page 3: Carton Contents

    Leader Chlorine: 1.0-3.0 P.P.M Total Alkalinity: 80 - 120 P.P.M Connector/Leader Hoses Accessory Kit Navigator V-Flex/ PoolVac V-Flex: x11 Connectors x1 Leader Correct shoe selection for operation FILTER - Your cleaner comes fitted with shoes to suit a concrete pool.
  • Page 4: Installation

    INSTALLATION Sizing Suction Hose Step 2 Pull hose to farthest point of the pool and then add 2 extra hose sections. Step 1 Connect hose sections. Note: Make sure all connections are tight to prevent air leaks. TIP: Wetting the hose ends will make it easier to connect the hose sections.
  • Page 5 Vac Lock without using the adapter to tapered male end of cone. • Hayward Regulator Valve the vacuum hose. To install the Regulator Valve: Remove the hose from the Skimmer Elbow Close the Regulator Valve by rotating the blue collar clockwise until tight.
  • Page 6 Cleaner is indicative of a system problem, and not a problem with the Cleaner. The Regulator Valve cannot be used to INCREASE the initial vacuum reading. View our YouTube video or contact your authorised Hayward Dealer for assistance. Step 6 Step 8...
  • Page 7: Fine Adjustments

    FINE ADJUSTMENTS • Sticking on Steps/Liner/Obstacles Be aware that your Cleaner will climb the vertical walls in concrete and fiberglass pools if there is at least a seven inch 180mm radius where the walls and floor meet. Your Cleaner should move about the pool without spending an Due to the programmed steering, the Cleaner will not climb a wall excessive amount of time against...
  • Page 8: Important Tips

    Coiled hoses are not covered under the Hayward Warranty. Do not swim while cleaner is in the pool. Do not add chemicals to the pool while cleaner is in the pool. Use only original Hayward spare parts and hoses to insure proper operation.
  • Page 9: Maintenance Tips

    Check the condition of the “shoes, wings, and flaps” periodically. Step 1 WEAR MARK GOOD SHOE WORN SHOE Step 2 WEAR LINE Hayward is not responsible for damage caused by worn or broken parts. Or damage caused by misuse of the cleaner.
  • Page 10 MAINTENANCE TIPS Wing Replacement: Step 3 Step 1 Step 2 Step 4...
  • Page 11: Troubleshooting

    TROUBLESHOOTING MAINTENANCE TIPS FOR TECHNICAL ASSISTANCE, CALL: 1300 POOLS 1 “Easy Opening Bottom”: For Turbine PROBLEM CAUSES SOLUTION Access and Inspection Lack of/improper water Check water flow with Flow Step 1 flow through cleaner Gauge and adjust as per Step 5 Blockage of the Cleaner Clear blockage throat...
  • Page 12 To the extent permitted by law, except as set out in this Warranty, Hayward Pool Products (Australia) limits its liability under any condition or warranty which cannot be legally excluded in relation to the supply of Goods and Services to: flow –either at the surface...
  • Page 13 To take a closer look at other product manuals or other Hayward products, go to ® www.hayward-pool.com.au or call 1300 POOLS1 PO Box 4384 I Dandenong South, VIC, 3164...
