  • Page 2: Important Safety Instructions

    Warning – Risk of Electrical Shock construction debris from new or renovated pools. The Hayward Viio Turbo Automatic Pool Cleaner is designed to • The Viio cleaner should not be used to remove excessive connect to a threaded 1-1/2 inch female pipe fitting on a sand (dense debris) following wind or sandstorm.

  • Page 3: Table Of Contents

    Limited Warranty ..........19 Use Only Genuine Hayward Replacement Parts.

  • Page 4: Introduction

    Congratulations on your purchase of the Hayward Viio Turbo Important Automatic Pool Cleaner. The Hayward Viio is designed to clean This manual is for Viio owners who want to install their your pool faster than other automatic pool cleaners so you and Automatic Pool Cleaner.

  • Page 5: Principle Parts

    Principle Parts Front view Product C C a a u u t t i i o o n n - - R R i i s s k k o o f f E E q q u u i i p p m m e e n n t t D D a a m m a a g g e e Hose may be stored folded pipe-to-pipe.

  • Page 6: Preparing The Pool

    Pools with excessive amounts of sand should be manually vacuumed before installing the Viio. The Viper is designed to operate with 1 cup of sand and the remainder of its bag filled with leaves, acorns, grasses. etc. Use Only Genuine Hayward Replacement Parts.

  • Page 7: Connecting Viio Turbo Cleaner To Pool

    U U n n i i v v e e r r s s a a l l W W a a l l l l F F i i t t t t i i n n g g Dedicated Return Line Universal Wall Fitting (O) Teflon ® is a registered trademark of E.I. du Pont de Nemours and Company. Use Only Genuine Hayward Replacement Parts.

  • Page 8: Assembling & Sizing The Rigid Pressure Hose

    At the farthest point from the Universal Wall Fitting hold Assemblies, you need to purchase the additional Pipe the Measuring Tape at the pool edge/coping and read the sections (P/N AX6000HE) from your Authorized Hayward number of Pipe Assemblies specified on the tape. Dealer.
  • Page 9 P P h h a a n n t t o o m m T T u u r r b b o o . . Use Only Genuine Hayward Replacement Parts.

  • Page 10: Operating The Viio Cleaner

    If more pressure is still required have an Authorized Hayward Pool Dealer or Service person check the Booster Pump, Filtration System and Plumbing to C C a a u u t t i i o o n n - - R R i i s s k k o o f f E E q q u u i i p p m m e e n n t t D D a a m m a a g g e e determine if they are functioning correctly.

  • Page 11: Large Capacity Debris Bag

    Note: Pools with excessive amounts of sand should be manually vacuumed before installing the Viper. Slide Float Closure off of Bag Figure 3A Hold Edges Apart Figure 3B Empty Sand Line Empty Sand Line (blue line) (blue line) Use Only Genuine Hayward Replacement Parts.

  • Page 12: Correctly Operating Cleaner

    (Wear Line) replace the Wear Rollers (P/N AX5006A) a bag of extra Wear Rollers is included. If a hole forms in the Sweep Hose, it must be replaced with a genuine Hayward Sweep Hose. (See Item 23 on page 18.)

  • Page 13: Cleaner Adjustments

    5. Screw the Thumbscrew into the stem. Different Cams Sun Logo 6. Close the Cam Cap. *This can also assist the cleaner make steep climbs from the deep end to the shallow end. 75-Second 50-Second 30-Second Use Only Genuine Hayward Replacement Parts.

  • Page 14: Adjusting Sweep Hose Power

    Sweep Hose power. • Sweep Hose Frequently Sprays Out Of The Pool: turn the Sweep Hose adjustment knob clockwise to reduce Sweep Hose power. Adjusting Sweep Hose Power Sweep Hose Adjustment Knob Use Only Genuine Hayward Replacement Parts.

  • Page 15: Maintenance

    M M a a n n i i f f o o l l d d F F i i l l t t e e r r 3. Hold open edges apart and shake debris from bag. 4. Slide Float Closure onto bag. Use Only Genuine Hayward Replacement Parts.

  • Page 16: Sweep Hose

    7AM). Running the Viio cleaner at this time will insure against damaging the Cleaner and may prevent freezing of pool water. Some parts will wear with normal use. To insure the high quality performance, insist on Genuine Hayward replacement parts (using non-Hayward replacement parts will Void the Viio Cleaner’s Warranty).

  • Page 17: Troubleshooting

    Troubleshooting For Technical Assistance Call: 1-908-355-7995 Use Only Genuine Hayward Replacement Parts.

  • Page 18: Booster Pump

    Seal Plate Assembly (incl. Drain Plug w.O-Ring) SPX4000FG Drain Plug w/O-Ring AX6060G Motor Support SPX3200Z5 Motor Belt SPX2707Z1B Motor, ⁄ HP, Square Flange 6060HKIT Hose Kit (incl. Hose, 2 Hose Fittings, and 4 Hose Clamps) Use Only Genuine Hayward Replacement Parts.

  • Page 19: Viio Parts Diagram And Replacement Parts List

    Wall Quick Connect O-Ring AX5010G18 Cleaner Connector O-Ring AX6000PTA Pressure Tester Assembly AX5010G20 Pipe Connector O-Ring (3-pack) AX5500BFLA4 Large Capacity Debris Bag with Float AX6000FC Float Closure AX6004R1 Inlet Filter Screen AX6004CA Hard Pipe Coupling Assembly (4-pack) Use Only Genuine Hayward Replacement Parts.

  • Page 20: Limited Warranty

    1. This Limited Warranty shall not apply to damage caused To the Original Retail Consumer / Purchaser (the “PURCHASER”) by failure to perform normal maintenance on the of the Hayward Viio Automatic Pool Cleaner (the CLEANER”). CLEANER (e.g. monitoring pressure/flow and replacing a worn bag and sweep hose).
  • Page 21 CLEANER. of the nearest Factory Service Center (outside the continental U.S. call (909) 594-1600. HAYWARD will at its option, repair or 8. This Limited Warranty is valid and enforceable only on replace all defective CLEANER parts covered by this Limited...
  • Page 22 620 Division Street Elizabeth, NJ 07207 Phone: (908) 351-5400 P/N IS55OOTC Rev. B...
