Hayward SharkVAC Manual

Model: rc9740 rc9742

Hide thumbs Also See for SharkVAC:

Troubleshooting manual (72 pages)

User manual (177 pages)

General information manual (11 pages)

Table Of Contents

Quick Links

See also: Troubleshooting Manual , User Manual

Mail today to –

Fold, stamp and mail or fax to 561-688-0217 or register on the web at www.aquavacsystems.com

Serial #_______________________________________________________SharkVac

This registration card must be mailed within 10 days of purchase to secure limited warranty.

Name_____________________________________________________________________________________

Address___________________________________________________________________________________

City________________________________________________State___________Zip ____________________

Date Purchased____________________________________________________________________________

Is this replacing another pool vacuum?

Purchased from____________________________________________________________________________

City________________________________________________State___________Zip ____________________

The size of my pool surface is___________x__________ Surface is__________________________________

Have you seen us on the internet? Yes____

Aqua Vac Pool Cleaners

1711 Longwood Road

West Palm Beach, FL 33409

Attn: Warranty Records

(Located inside filter area)

Registration of Warranty

FOR USE IN THE U.S.A. ONLY.

Yes____ No____ If yes, what brand?______________________

No____

PLACE

STAMP

HERE

Table of Contents

Need help?

Do you have a question about the SharkVAC and is the answer not in the manual?

Questions and answers

Pam

May 13, 2025

Where can I order parts for Model #RC9742?

Summary of Contents for Hayward SharkVAC

Page 1 PLACE STAMP HERE Mail today to – Aqua Vac Pool Cleaners 1711 Longwood Road West Palm Beach, FL 33409 Attn: Warranty Records Fold, stamp and mail or fax to 561-688-0217 or register on the web at www.aquavacsystems.com Serial #_______________________________________________________SharkVac (Located inside filter area) Registration of Warranty This registration card must be mailed within 10 days of purchase to secure limited warranty.
Page 3 Cleaner has been manufactured, tested and inspected in accordance with carefully specified engineering requirements. It is warranted to be free from defects in material and workmanship. MODEL WARRANTY PERIOD COVERAGE SharkVac by Hayward 1 - Year Parts & labor on complete unit, power train, motor unit, and power supply, excluding filters.
Page 5: Table Of Contents
Owner’s Manual Contents Important Safety Precautions ..6-7 General Information ......8 General Operating Instructions ..9-10 Machine Assembly/Parts ..11-12 Maintenance ......13-15 Troubleshooting ......16-17 Specifications ........18 1711 Longwood Road, West Palm Beach, Florida 33409 USA Toll Free 1-800-327-0141 • (561) 688-0211 • Fax (561) 688-0217 E Mail: info@aquavacsystems.com www.aquavacsystems.com or www.haywardnet.com...
Page 6: Important Safety Precautions
Consumer Information and Safety Consumer Information and Safety The SharkVAC pool cleaner is designed and manufactured to provide safe and reliable service when The SharkVAC pool cleaner is designed and manufactured to provide safe and reliable The SharkVAC pool cleaner is designed and manufactured to provide safe and reliable service when installed, operated and maintained according to the information in this manual.
Page 7 Plug in only to GFCI (Ground Fault Circuit Interrupter) protected 120VAC volt AC outlet. Place the SharkVAC power supply so that it is at a minimum distance of 11.5 feet from the pool edge. The length of the standard SharkVAC cable is 50 feet.
Page 8: General Information
GENERAL INFORMATION. Congratulations on your purchase of a SharkVAC microprocessor controlled, fully automatic pool cleaner. The SharkVAC represents the highest standard in design, performance, and quality. This manual contains important information regarding the operation and maintenance of your SharkVAC. PLEASE READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY BEFORE PUTTING YOUR ShARkVAC INTO USE.
Page 9: General Operating Instructions
3. Connect the floating cable to the power supply. Use only the original SharkVAC Power Supply manufactured by Hayward Pool Products. 4. Place the SharkVAC in the pool. It will slowly sink to the bottom of the pool as the air inside is released.
Page 10 7. After the pool has been cleaned, switch OFF the power supply before removing the SharkVAC from the pool. 8. Remove the SharkVAC from the water at the shallow end of the pool by pulling the cable until the SharkVAC reaches the surface. Then lift it out of the water using the handle, NOT the cable.
Page 11: Machine Assembly/Parts
1. Power Supply 8. Wheel Brush 2. Floating Cable 9. Sealed Motor Unit 3. Handle 10. Side Panel 4. On/Off Switch 11. Dome Assy 5. Filter Cartridge 12. Filter Bucket 6. Drive T rack 13.Wheel 7. Wheel T ube 14. Filter Door...
Page 12 Caddy Cart Instructions – See Diagram 1. Caddy Cart will come partially assembled in the carton less the handle & tube. (1 & 3) 2. Insert the screw into the tube at the base of the caddy cart & secure with bolt (4) 3.
Page 13: Maintenance
& lifting up the dome cover. Remove the filter bucket assembly by lifting it up out of the SharkVAC with both hands from each side. Flip the bucket assembly over to remove the debris & then rinse with a garden hose to remove small particles.
Page 14 To Remove the filter cartridges: To Remove the filter cartridges: Unsnap and lift up both filter door latches. Pull out the filter cartridges. Using a garden hose with a spray nozzle, wash the filter elements to remove debris. Hold the filter elements as shown to allow the debris to fall out.
Page 15 Remove any debris that has accumulated between the tracks and wheels Remove any debris that has accumulated between the tracks and wheels When out of the water, store the SharkVAC in a dry, shady location at temperatures between 40F - 115F Storage...
Page 16: Troubleshooting
• Cleaning the filter cartridge after every use maximizes the unit’s performance. • Replace worn brushes. • To avoid clogging the SharkVAC’s filter elements, be sure all chemical powders are fully dissolved before operating the cleaner. • In a pool with usually high calcium content, more frequent cleaning of the filter is recommended.
Page 17 Troubleshooting (continued) • For the cleaners used in areas that have a lot of sand the cleaner may need to be rinsed with water at all flapper (filter bucket’s flapper is at intake port) areas and may need rinsing at the dome push button to allow free operation. •...
Page 18: Specifications
Bearing System Power Supply Input Primary Voltage 110-120 volt AC Output Secondary Voltage 24V DC Rated Output Current 4 amps Weight 8.3 lbs Shipping SharkVAC Length Width Height Carton Dimensions Shipping Weight with Caddy 49 lbs 43 lbs without Caddy...
Page 19 ITS SERVICE AGENT OR SIMILARLY qUALIFIED PERSONS IN ORDER TO AVOID A HAzARD. While the SharkVAC has been made to operate as safely as possible, we suggest you exercise reasonable care in the handling of the vacuum and inspect the electrical cord frequently for damage or wear, as with any other electrical appliance.
Page 20 PREVENTATIVE MAINTENANCE In order to maximize efficiency and receive long term service of your unit, we suggest the following: • Thoroughly rinse entire unit after use. • Clean ﬁlters thoroughly after each use—a clogged ﬁlter can decrease efficiency dra- matically. •...
Page 21 – NOTES –...
Page 22 – NOTES –...
Page 24 1711 Longwood Road, West Palm Beach, Florida 33409 USA Toll Free 1-800-327-0141 • (561) 688-0211 • Fax (561) 688-0217 E Mail: info@aquavacsystems.com www.aquavacsystems.com or www.haywardnet.com 11/08...
